Holland greenhouse PRO S010402 User manual

1
S010402
www.hollandgreenhouse.ca
Warning: For your personal safety,
READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Instruction Manual For
12L Battery Sprayer
S010402

2
S010402
www.hollandgreenhouse.ca
No. Name No. Name
1Cap 20 Shock pad
2 Cap O-ring 21 Hose
3Valve 22 Lance
4 Filter 23 Gasket
5 Connector 24 Back cap
6 O-ring for Connector 25 Screw
7 Pipe tube 26 Screw
8 Inlet water filter 27 Clip for circuit board
9Screw 28 Circuit board compartment
10 Tank 29 Battery compartment
11 Cover 30 Nut
12 O-ring in cover 31 Switch cover
13 Plastic Nut 32 Li-lon battery
14 Clamp 33 Battery compartment cover
15 Water inlet hose 34 Back squab
16 Water pump clip 35 Screw
17 Shock pad 36 Screw
18 Water pump 37 Strap
19 Nut
Assembly:

3
S010402
www.hollandgreenhouse.ca
• Lithium battery needs to be charged indoors not outdoors to avoid accidents.
• When the lithium battery needs charging, remove it from the sprayer and plug in the charger.
If the light is red the battery is charging; when the light is green the battery is fully charged.
• The charger can only be used with this battery and it is prohibited for other use to avoid
overcharging or shortening the battery’s life. The battery and charger must be removed from
the electrical outlet when charging is complete.
• Please only use the charger provided; if any other charger is used the battery may not work
properly or may cause a fire or explosion.
• If you think the charger or lithium battery has been damaged or does not work properly,
please contact the manufacturer or distributor at once, DO NOT use the damaged unit.
• For uncharged lithium battery, the capacity of the battery determines the charging time. If
the charging indicator lights don’t respond unplug the power adapter.
• When charging the lithium battery, it is best no to overcharge to avoid shortening the life of
the battery.
• If the lithium battery has not been used or stored correctly it may not hold a charge. For best
results charge once every six months to prevent the battery from being completely drained or
damage to the internal structure.
• Store in a cool dry environment with room temperature between 15 to 35 degrees Celsius
and no more than a relative humidity of 65%.
• It is prohibited to place the battery into seawater or water – store in a cool, dry environment
when not in use.
• It is prohibited to put the battery near a heat source, such as fire, heater, etc.
• It is prohibited to reverse charge the battery.
• It is prohibited to throw the battery in a fire or to heat in a container.
• It is prohibited to use metal on the battery cathode which could cause a direct short circuit.
• It is prohibited to transport or store the battery with metal.
• It is prohibited to break open the battery.
• It is prohibited to use around electrostatic or magnetic fields.
Safety instructions and cautions for lithium battery:
Warning:

4
S010402
www.hollandgreenhouse.ca
Back squab
Battery compartment
cover
Open the cap
Put pesticide and water inside
O/on
Power Indicator
O/on
Steel telescopic lance
Trigger
Operating instructions:
Hose

5
S010402
www.hollandgreenhouse.ca
1. Please open the battery cap as pic 1 in above.
2. Put battery(NO.32 in page 2) inside the machine. Please refer to pic 2 in above.
3. Close the battery cap as pic 3 in above.
4. Take out lance and trigger as pic 4 in above.
5. Screw the nuts in lance to the trigger as pic 5 in above.
Direct
Spray
Assembling instruction:
Steel telescopic lance

6
S010402
www.hollandgreenhouse.ca
1. Remove the battery from sprayer.
2. Put the battery into charger.
3. Plug the charger into power outlet.
4. It is charging when the red light (E) comes on, after approximately (2.5 hours )
5. Remove the battery when charging is complete, disconnect power.
Item No. S010402
Total capacity 12.0L
Voltage 12V
Current flow 1.3A
Battery capacity 2.5 Ah-2.6Ah
Work time 120min
Charging time 150min
Flow 0.95L/min
How to use charger:
Product information/technical data:
Under charging
(red light)
Charging finish
(green light)

7
S010402
www.hollandgreenhouse.ca
1. Remove the battery after use and recharge it if fully discharged.
2. Clean the machine by water.
3. Put the machine in a cool and dry place.
• Always wear protective clothing, gloves, eyewear and mask when spraying.
• Suitable measures must be taken to keep the unit out of the reach of children.
• If spraying in light wind conditions, always spray downwind of yourself and others.
• Do not spray contents of sprayer at people or animals.
• Ensure all parts are intact and the temperature of the liquid is under 40 degrees Celsius
before each use.
• Chemical sprays are dangerous if swallowed or comes in contact with the skin, always
refer to the chemical supplier safety instructions or contact the poison information
centre or a doctor immediately.
• Always release pressure before refilling, servicing or storing.
• Do not leave the sprayer (filled, empty or pressurized) unattended in direct sunlight.
• Not to be used to spray solvents or flammable liquids
CAUTION: CONTENTS UNDER PRESSURE READ THIS BEFORE OPERATING.
Problems Causes S010402
Themotorfailstostart
afterbeing poweredon
1. The power cables come o
2. The battery is out of power
3. The power switch has been damaged
1. Dismantle the base to connect
the cables only
2. Charging
3. Replace the switch
Water cannot go out Filter maybe clogged Open the bottle and take out the
filter to clean it
WEAR PROTECTIVE
CLOTHING
WEAR EYE
PROTECTION
WEAR
GLOVES
WEAR
A.S APPROVED
FILTER MASK
Maintenance of equipment:
Troubles shooting:
Safety instructions:
