Holman SWC1000 User manual

User Guide
User Guide
150mm Ground
Light Twin Pack

2 of 20
PRODUCT CODE: SWC1000
iOS is a trademark of Apple Inc. Android is a trademark of Google LLC. The
Android robot is reproduced or modified from work created and shared by
Google and used according to terms described in the Creative Commons 3.0
Attribution License. The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Holman
Industries is under license. Other trademarks and trade names are those of their
respective owners. All other content is Copyright©HolmanIndustries2022.
Scan here for the latest manual
or visit
https://www.holmanindustries.com.au/product/
150mm-ground-light-twin-pack

3 of 20
Contents
Overview 4
Package Content 4
Setup 5
Preparation 5
Pairing 9
Key Functions 11
Dimmer 11
Pallete (Scene) 12
Music 13
More 13
Troubleshooting 16
Specifications 18
Warranty 19

4 of 20
Overview
Package Content
1. 2 × 2W RGBW Bluetooth®Mesh Ground [a] IP65
2. 2 × Ground Spikes [b]
3. 1 × Plug in Power Supply [c], for outdoor power point (GPO)
4. 1 × Inline DC Adaptor [d] IP67, 90cm from plug to inline
DC adaptor, 40cm from inline DC adaptor
to the first light connector
5. 1 × End Cap included
6. 2 × Zip Style Cable Ties (to secure cable to light spike neatly)
included
b
d
c
a
ÁNo modification or addition
to the light configuration is possible

5 of 20
Setup
Preparation
1. Ensure that the power point
is no more than 3.4m away,
there is no extension or
modification for the cable
(90cm from plug to
inline adaptor, 2.5m to
first light – 2.5m cable
between each light)
2. Put the click lock ground
spikes onto the lights. To do
this align the spike to the
base and then twisted to
lock [a]. No tools are needed
– please only use your hands
3. Place the ‘end’ cap onto
the ‘tail’ of the second
light [b]– this creates a
waterproof seal for the light
4. Plug the ground lights
into the inline adaptor and
their joining cable, before
connecting ensure the red
O-Ring is in place [c] (for
electrical protection) and that
the plug is correctly oriented
a
b
c

6 of 20
Setup (continued)
Preparation (continued)
5. Once the plugs are
connected screw down
the threaded cover onto
the plug connection
6. Plug in the power cord to
the power point (GPO) and
observe the lights, they should
be flashing white (pairing
mode). If the lights are not
flashing white, turn the power
point on/off/on/off/on to get
the lights into pairing mode

7 of 20
Setup (continued)
Installing Holman Home
1. Download Holman Home to
your mobile device via the
App Store or 
Google Play
2. Open Holman Home
on your mobile device
®You may be prompted to allow
notifications–the app can
still function if you choose to
opt out
3. Tap SIGN UP
4. Read our User Agreement
and Privacy Policy and tap
AGREE if you wish to proceed
5. Follow the prompts to register
a Holman Home account
with your email address
ÁEnsure your country
details are correct at this
stage
®You must allow the
‘Discovering Nearby
Device’ permission (or
Bluetooth®permission,
depending on your phone
operating system) – this
allows Bluetooth®mesh
products to be added into
Holman Home
®You may be prompted to
allow access to your location.
This allows the app to show
weather information-it will
still function if you choose to
opt out

8 of 20
Setup (continued)
Bluetooth®Connetion
LEnsure you and your
smartphone are close to your
light kit during the connection
process - you may need to
prompt pairing mode
LYour lighting kit will
perform preset schedules
from the app, even if
your smartphone is out of
Bluetooth®connection range
(schedules must be sent
within Bluetooth®range)

9 of 20
Setup (continued)
Pairing
1. Pairing of the ground
lights is via Bluetooth®
Mesh, please ensure
you have allowed the
Bluetooth®(iOS)or
Nearby Devices (Android)
permission
2. These lights will flash
white/fast to indicate
they are ready to pair
(default/pairing mode)
3. Tap ‘Add Device’ from
the Holman Home Home
screen, you will see the
ground lights appear under
‘Discovering devices’
4. Press ‘Add’ to
commence pairing
5. When you see the blue
circle [a] appear on the
‘Add Device’ screen please
tap this (or ‘Add All’ [b])
to commence pairing
6. After 30 seconds to 1
minute the light will be
successfully added
a
b

10 of 20
Pairing (continued)
Setup (continued)
7. Tap ‘Done’ [c] to
completepairing. You will now
see the lights on the home
page. If you are still within
Bluetooth®range you will
see a power on/off icon [c]
8. If you’re out of range, the
Bluetooth®[d] symbol
will appear greyed out
c
d

Key Functions
Dimmer
Functions
®Menu options at the bottom of the home screen
1. Dimmer - RGB/W mode, colour selection
2. Pallete - Scenes
3. Music
4. More – includes schedule
®Top left – light name (tap 3
dots to top right to change
this) [a]
®Switch [b] – toggle the light
on/off
®Colour or White selection [c] -
tap the word to move between
options
®Colour selection [d] – tap to
move the bulb icon between
colours (current colour is
displayed at the top right of
the screen as the light circle,
inside this is the colour name)
®Brightness - slide your finger
along the bar to reduce
brightness
a
d
c
b
e

12 of 20
Key Functions (continued)
Pallete (Scene)
Functions
®Brightness - slide your finger
along the bar [a] to reduce
brightness
ÁWhite mode screen –
brightness changes slide
up/down
®Tap the Scene to apply it to
the light
ÁBe mindful this is per light
– not for both
a

Music
More
Functions (continued)
®Requires audio recording
permission, as this uses the
device microphone to work
®The light will change colour
(dance) to the beat (must be
set per light)
®Schedule -tap to set a
regular timer for each light
®Timer - tap to set an ‘off’
time for light to turn off (i.e 2
hours from now)
®Default Light - tap to choose
the default light state when
the light comes on
®Switch Gradient – tap to
select dimming on start up/
turn off (in seconds)

14 of 20
More (continued)
Setting Schedule
®Schedules are set for on or
off – one of each is needed
for regular on/off timing
®Tap the blue circle [a] to
create a Schedule, select
‘Local Timer’ from the
menu
®24hr (military) time is used
for setting the schedule
®For day of the week
selection blue squares are
‘on’ (selected) [b], while
black squares are ‘off’ (not
selected) [c]
Functions (continued)
ac
c
b

15 of 20
More (continued)
Functions (continued)
®Tap ‘Action’ [c] to select
on/off as the action for the
schedule
Example – complete
schedule ON/OFF
weekend use:

16 of 20
®1 user at a time, if more than
1 person is trying to enter
the light they will not be be
able to get control until the
first person has exited
The primary user (current
user) will see a green [a] on/
off power icon when they
have control
Other users within the same
home will see a Bluetooth®
symbol [b] with a cross
through it.
To take control, attempt to
open the light in the app,
you may need to open/close
more than once to gain/
regain control
®To remove the device from
Holman Home, tap the ‘…’
the top right of the screen,
then ‘remove device’ [c] at
the bottom of the screen
Troubleshooting
a
b
c

17 of 20
®Because this device is
Bluetooth®there is no
‘cloud’ connection, the
device will only offer
‘Disconnect and wipe
data’
®Once the device is removed,
it will return to pairing mode.
This is confirmed by the
lights turning white and
flashing fast again
Troubleshooting
The Holman website has a host of additional information on features. Head to
support.holmanindustries.com.au for more tips, tricks and support content.
If you still need help, feel free to email our friendly Customer Service team at
[email protected] or call at 08 9416 9999.

18 of 20
Specications
Ground Light
Input 240V AC
Output 12V DC
Light Output 2W per light
Pack Output 4W total
Brightness 115lm
Lifespan 30000 hrs
Size ø150mm
Height 235mm
Colour RGBW Multi
Waterproof Rating IP65
Housing Plastic

19 of 20
Warranty
2 Year Replacement Guarantee
Holman Industries offers a 2 year
replacement guarantee with this product.
In Australia our goods come with
guarantees that cannot be excluded
under the Australian Consumer Law. You
are entitled to a replacement or refund
for a major failure and compensation for
any other reasonably foreseeable loss or
damage. You are also entitled to have the
goods repaired or replaced if the goods
fail to be of acceptable quality and the
failure does not amount to a major failure.
As well as your statutory rights referred
to above and any other rights and
remedies you have under any other laws
relating to your Holman product, we also
provide you with a Holman guarantee.
Holman Industries guarantees this
product against defects caused by faulty
workmanship and materials for 2 years
domestic use from the date of purchase.
During this guarantee period Holman
Industries will replace any defective
product. Packaging and instructions
may not be replaced unless faulty.
In the event of a product being replaced
during the guarantee period, the
guarantee on the replacement product
will expire 2 years from the purchase
date of the original product, not 2years
from the date of replacement.
To the extent permitted by law, this Holman
Replacement Guarantee excludes liability
for consequential loss or any other loss
or damage caused to property of persons
arising from any cause whatsoever. It
also excludes defects caused by the
product not being used in accordance with
instructions, accidental damage, misuse,
or being tampered with by unauthorised
persons, excludes normal wear and tear
and does not cover the cost of claiming
under the warranty or transporting the
goods to and from the place of purchase.
Should you suspect your product may
be defective and need some clarification
or advice please contact us directly:
1300 716 188
[e-mail]
11 Walters Drive,
OsbornePark 6017 WA
If you are certain your product is
defective and is covered by the terms
of this warranty, you will need to
present your defective product and
your purchase receipt as proof of
purchase to the place you purchased
it from, where the retailer will replace
the product for you on our behalf.

The Holman website has a host of additional information on features. Head to
support.holmanindustries.com.au
for more tips, tricks and support content.
If you still need help, feel free to email our friendly Customer Service team at
[e-mail]
or call at 08 9416 9999.
We really appreciate having you as a customer, and
would like to say thank you for choosing us.
We recommend registering your new product on our website. This will ensure we have
a copy of your purchase and activate an extended warranty. Keep up to date to with
relevant product information and special offers available through our newsletter.
www.holmanindustries.com.au/product-registration/
Copyright © 2023 Holman Industries
Thanks for being a
#SMARTGARDENER
