HOMCOM B61-009V80CG User manual

1
IN230800079V01_US_CA MODEL/MODÈLE:
B61-009V80CG
CLOTHES DRYER
SÈCHE-LINGE
INSTRUCTION MANUAL
MANUEL D'UTILISATION

2
To prevent the risk of fire, electric
shock and injury to persons, follow
basic safety precautions, including
the following:
For your safety
Read all instructions carefully, even if you
are familiar with this appliance.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning the use of the
appliance by a person responsible for their
safety.
• Children must be supervised when near this
appliance.
• INDOOR USE ONLY. Do not use outdoors.
• Keep the appliance away from candles and
other naked flames. Keep the appliance and
its cord away from radiators, heaters, air
ducts, direct sunlight and other heat sources.
• Do not block any of the ventilation openings.
Ensure the vents are not covered by
newspapers, tablecloths, curtains or any
other materials.
• Do not run the cord under carpets, rugs or
other floor coverings. Keep the cord away
from congested areas, so it cannot become a
trip hazard.
• To disconnect the appliance, turn it off, switch
off the power outlet and remove the plug from
the wall socket.
• Never carry the appliance by its cord. When
unplugging the appliance, do not pull the cord
– instead, grasp the plug and pull.
• If the appliance, its cord or plug is damaged or
the appliance malfunctions in any way, do not
use it. Consult the manufacturer for repair or
replacement.
• Do not attempt to repair, disassemble or
modify the appliance – this will void your
warranty. This appliance must be serviced by
qualified personnel.
• Do not reach into the appliance if the drum is
moving.
• If items come into contact with flammable
liquids, do not place them in the dryer without
washing them thoroughly with a deterrent
beforehand.
• Do not bend, stretch or twist the power cord. Do
not place heavy objects on the power cord.
• This appliance can only be serviced by qualified
personnel. There are no user-serviceable parts
inside.
• Do not install this appliance into a tight-fit
cabinet.
• Do not overload the tumble dryer.
• If items have been cleaned, washed or soaked
in gasoline, dry-cleaning solvents or other
flammable and explosive substances, do not
place them in this dryer. They can give off
vapours, which could ignite or explode.
• If disposing of this appliance, be sure to remove
its door.
• Do not expose this appliance to any weather.
• Do not tamper with controls.
• Do not attempt to replace or repair any part of
this appliance, unless it is specifically
recommended in this instruction manual, you
understand the instructions and have the skills
to do so.
• Do not use fabric softeners or products to
remove static unless it is recommended by the
manufacturer of the fabric softener or product.
• Do not use heat to dry items containing foam,
rubber or rubber-like materials.
• For areas surrounding the exhaust opening and
adjacent surrounding areas, keep them free
from lint, dust and dirt.
• Only qualified personnel can clean the interior
of the appliance and exhaust duct.
• If items have been exposed to cooking oil, do
not place them in the dryer. The oil may
contribute to a chemical reaction, which is a fire
risk.
• Keep foreign objects out of this dryer.
• Before and after each load, clean the lint
screen.
Important Safeguards EN

3
Oil-affected items can ignite spontaneously, especially when exposed to
heat sources such as a tumble dryer. The items become warm, causing
an oxidant ion reaction in the oil. Oxidation creates heat. If the heat
cannot escape, the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat from escaping,
creating a fire risk.
To ensure safety while using the tumble dryer, follow these guidelines:
• If fabrics contain vegetable or cooking oil or have been contaminated by hair products, you
must wash them in hot water with extra detergent before placing them in the dryer. This
reduces the risk of hazards associated with such oils and fabrics.
• Never place unwashed items directly into the tumble dryer. Always ensure items are clean
and free from substances, which may pose a risk during drying.
• If items have been soiled with substances like cooking oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax removers, wash them in hot water
with extra detergent before placing them in the dryer.
• The final part of the tumble dryer cycle occurs without heat (cool down cycle), ensuring that
items are left at a temperature that avoids damage.
• WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items
are quickly removed and spread out so that the heat is dissipated. Never stop a tumble
dryer before the end of its drying cycle, unless all items are quickly removed and spread
out, so the heat can disperse.
Never place this appliance upside down
WARNING
-Risk of Fire
To reduce the risk of fire, the installation must be carried out by a qualified installer. When
installing this clothes dryer, follow both the manufacturer’s instructions and local codes.
Avoid using flexible plastic venting materials for the clothes dryer. Instead, use a specific
type of venting material, which is approved by the manufacturer for use with clothes dryers.
Flexible materials can collapse, get easily crushed and trap lint, which obstructs the airflow
and increases the fire risk.
To reduce the risk of severe injury or death, follow all instructions in this manual.
To ensure your safety, properly ground this appliance. In case of any malfunction or
breakdown, grounding reduces the risk of electric shock – it provides a path of least
resistance for the electric current. This appliance comes with a cord that has an equipment-
grounding conductor, which has been grounded according to all local codes and ordinances.
Always prioritise proper grounding for electrical appliances.
WARNING
Improper connection of the equipment-grounding conductor can result in a serious risk of
electric shock. If in doubt, consult a qualified electrician or a representative from the
manufacturer. Do not attempt to modify the appliance plug. If the plug does not fit the outlet,
have a proper outlet installed by a qualified electrician.
Ensure the dryer is placed on firm and level ground. Avoid placing the dryer on carpet, as
this can block the intake and affect its performance. There should be at least 10cm of space
between the dryer and the surrounding walls, so air can circulate properly.

4
Name of Components

5
Operating your dryer
Electrical requirements
Plug this appliance into a reliably
grounded three-pin socket.
Plug the power cord into the socket.
Loading the dryer
Place items into the dyer one at a time.
This ensures they do not get tangled,
which results in uneven drying. When
closing the dryer door before starting the
unit, ensure items are not jammed in the
door.
Tips before drying
Before loading the dryer, ensure items do
not have the following symbols anywhere
on them. If they do, they cannot be
tumble dried.
• Before drying, ensure laundry does not
have lighters, hairpins, coins or other
combustible materials or foreign objects
on them.
• Turn items with zippers inside out and
fasten the buckles.
• The heat from the dryer may cause
stains to be permanent. Before drying,
ensure stains are removed.
• Separate dark and light-coloured
laundry, as you would do when
washing.
• For the best results, load the dryer with
similar fabrics. Place small and delicate
items in a mesh bag – do not overload
the dryer.
• When loading the dryer, do not exceed
5.5 lbs of dry textile material. The
tumble dryer is for drying textile
materials that have been washed in
water.

6
Control Panel Functions
Remaining time display (in minutes)
Light bar: Displays various colours, such as red, white,
blue and green, corresponding to different modes
Power button
When the cord is connected to the socket, the power button is slightly lit. When you touch the
power button, other buttons and descriptions on the control panel will appear - the dryer
enters standby.
Mode Button
This button is used to select different drying modes, as described below.
a) Strong drying: When selecting this mode, the light bar will turn red. The default
remaining time will display at '150' minutes. The heater will operate at full power. Once the
set time (150 minutes) elapses, the appliance will automatically shut down, completing the
drying process. This mode is ideal for large-sized clothing items.
b) Intelligent drying: When selecting this mode, the light bar will turn white. Instead of
displaying a specific remaining time, this display will show 'IHS', which stands for
intelligent. The heater operates at full power, providing efficient and optimal heating for
laundry. Once clothes are fully dried, the dryer will automatically shut down.
c) Additional low heat drying: When selecting this mode, the light bar will turn blue. The
remaining time will be displayed as 30 minutes. The heater does not heat, but the drying
process runs for the set time (30 minutes) before automatically shutting down. This
procedure is for removing unpleasant odours from clothing, such as when clothes have
been stored for long periods.
d) Normal drying: When selecting this mode, the light bar will turn green. The remaining
time will be displayed as ‘90’ minutes. The heater operates at half the power. Once the set
time (90 minutes) elapses, the appliance will automatically shut down, completing the
drying process. This mode has two functions: ironing, which doesn’t last for more than 90
minutes. Once the set time lapses, the laundry will still contain moisture for easy ironing.
The other function is drying – this is usually no less than 120 minutes. This is generally
used for small pieces of clothing or a small amount of laundry.
Note: When the dryer is in use, this button is inactive. To change the mode, touch the
‘Start/Pause’ button to pause the dryer, then press this button to change the mode.
Time Button
This button is used to set the drying time. With each touch, the time increases by 20 minutes,
up to a maximum of 200 minutes. If the remaining time is more than 180 minutes, touching
the button makes it jump to 20 minutes. Note: In the ‘Intelligent Drying’ mode, this button
becomes inactive. It is also inactive while the dryer is running. To change the time during
operation, press the ‘Start/Pause’ button to pause the dryer, then adjust the time using the
‘Time’ button.
Start/Pause Button
Press this button to start or pause the dryer.
When the mode and time are set, touch this button to start the dryer. To change the time or
mode while the dryer is running, first press this button to pause the machine, then select
your new mode or time.
Start/Pause Time Program Power

7
Operation precautions
Before drying, place delicate items into a
nylon net bag. Underwire bras are not
recommended for this dryer.
Keep foreign objects out of this dryer.
Empty all pockets and fasten buttons,
buckles and zips. This also helps reduce
the impact noise when laundry hits the
turning drum.
Whilst the dryer is in use, do not add extra
items.
When drying blankets and other large
items, it is recommended to open the door
occasionally, shake the item and place it
back into the dryer to dry. This ensures
even drying.
To get the best out of the anti-wrinkle
function, do not overload the dryer and
remove dried items immediately, hanging
them on coat hangers. Iron items if
needed.
To minimise fire risk, follow these steps:
• If garments have been spotted or
soaked in vegetable or cooking oil, do
not place them in this tumble dryer – this
is a fire hazard.
Oil-affected items can ignite
spontaneously, especially when exposed
to heat sources such as in a tumble dryer.
The items become warm, causing an
oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape,
the items can become hot enough to
catch fire. Piling, stacking or storing oil-
affected items can prevent heat from
escaping, creating a fire hazard.

8
If you have fabrics containing vegetable or cooking oil or have been contaminated by hair
care products, and you cannot avoid putting them in a tumble dryer, make sure you wash
them with extra detergent. This will help reduce potential hazards, although it will not
completely eliminate them.
When using this tumble dryer, use the ‘cool down’ cycle to lower the temperature of items
inside. Do not remove the items from the dryer or pile them up while they are still hot.
If items have been exposed to petrol, gasoline, dry-cleaning solvents or other flammable or
explosive substances, do not put them in this tumble dryer.
Be aware that certain highly flammable substances are commonly used in domestic
environments. These include acetone, denatured alcohol, petrol/gasoline, kerosene, some
brands of spot removers, turpentine, waxes and wax removers.
• Items containing foam rubber (also known as latex foam) and other rubber-like materials
should not be dried in a tumble dryer in a heat setting.
When heated, foam rubber materials can spontaneously combust, which is a fire risk.
• Avoid using fabric softeners or similar products in a tumble dryer to eliminate static
electricity, unless the fabric softener manufacturer specifically recommends it for this
purpose.
• Do not put undergarments that have metal reinforcements in a tumble dryer.
Items with metal reinforcements can cause damage if the metal comes loose during the
drying process. If possible, use a drying rack for such items to avoid damage.
• Avoid putting shower caps, baby waterproof napkin covers or other plastic articles in this
tumble dryer.
• Do not place rubber-backed articles, clothes with foam rubber pads, pillows, goloshes or
rubber-coated tennis shoes in the tumble dryer.

9
Installation instructions
Never place this dryer upside down!
Keep this dryer in a well-ventilated area,
away from direct sunlight and other heat
sources.
If the dyer is not wall-mounted, it must be
placed on firm and horizontal ground.
Never place the dryer on carpet – this will
block the air intake. Ensure there is at
least 15cm of space between the dryer
and walls.
The dryer comes with fixed legs, which
need to be assembled for added stability.
If the dryer rack is mounted, a secure
bracket is required to ensure stability and
prevent vibration. Ensure there is at least
15cm of space between the dryer and
walls (the bracket is not included).
Wall mounting
instructions
1. Determine the dyer position on the wall,
then mark the required bracket position.
Do not place the dryer directly on top of a
washing machine.
* Ensure there is at least 50mm between
the top of the dryer and the ceiling.
* If mounting above a washing machine,
allow sufficient room to open the lid of the
washer.
2. Fix the wall hanging brackets
(two supplied) to the wall
securely (e.g., into the stud).
If the stud position is too wide,
fit a timber slat between the
studs to mount the brackets.

10
3. To install the hanging hook to timber, start at Fig. 2.
4. Align the hanging hooks and fasten the screws tightly.
5. Adjust the exhaust connector direction, then attach the exhaust connector to the connector (refer to
Fig. 3).
6. Turn the exhaust connecter clockwise, until it inserts into the connector’s groove.
7. Using 4 x 12mm screws (provided), fix the two spacers (refer to Fig. 4).
8. With the help of someone else, mount the dryer on the wall bracket (refer to Fig. 5).
This appliance should not be vented into a chimney, wall, ceiling, attic, crawl space or any
concealed space within the building.
Only rigid or flexible metal ducts are allowed for venting.
In Canada, that only those foil-type flexible ducts, if any, specifically identified for use with
the appliance by the manufacturer shall be used. In the United States, that only those foil-
type flexible ducts, if any, specifically identified for use with the appliance by the
manufacturer and that comply with the outline for Clothes Dryer Transition Duct, Subject
2158A, shall be used.
In Canada, that the exhaust duct shall be 102 mm in diameter. In the United States, the
required exhaust duct diameter.
That the total length of flexible metal duct shall not exceed 2.4 m. That the duct shall not
assembled with screws or other fastening means that extend into the duct and catch lint.
