Home Protector GT-RD-2R User manual

Wireless digital door chime
User’s Guide
After Sales Support
Now you have purchased a Home Protector®product
you can rest assured in the knowledge that as well as your
3 year parts and labour warranty you have the added
peace of mind of dedicated helplines and web support.
AFTER SALES SUPPORT
UK / N.IRELAND HELPLINE NO 0800 328 6020
REP. IRELAND HELPLINE NO 00800 4467 5888
E-MAIL SUPPORT [e-mail]
MODEL NUMBER: GT-RD-2R/GT-RD-1T

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 02
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 03
04-05 Introduction
05 Packaging
05 Disposal of the device
06 Proper use
06-09 Safety instructions
08 General instructions
08-09 Instructions for use
10-11 Description of parts
12 Scope of delivery
12-21 Startup and installation
12 Insert batteries in the receiver
13 Insert battery in the transmitter
13-14 Programme radio channel
15 Select signal
15 Selection of bell tone
15-16 Set volume of the acoustic signal
16 Installation of receiver and transmitter
16-18 Permanent installation
18-19 Installing the receiver
19-21 Installing the transmitter
21-22 Problem solving
22 Cleaning
23 Storage
23 Technical data
24 Conformity declaration
25-27 Warranty
28 Warranty card
Index Index

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 04
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 05
Congratulations on choosing to buy
a Home Protector®product.
By doing so you now have the assurance and
peace of mind that comes with purchasing a
product made by one of Europe’s leading
manufacturers.
All products brought to you by Home Protector®
are manufactured to the highest standards of
performance and safety, and, as part of our
philosophy for customer service and satisfaction,
are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for
many years to come.
Packaging
Keep the packaging, if possible. If you do not wish
to keep the packaging, please dispose of it in an
environmentally friendly manner.
Disposal of the device
If the device should no longer be able to be used,
please contact the responsible waste disposal asso-
ciation. You will receive information here regarding
proper disposal.
Batteries are not permitted to be disposed of
with household waste. Every consumer is legally
obliged to dispose of batteries properly in the
designated collection centres.
Introduction Introduction

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 06
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 07
With the Wireless digital door chime, wireless
transmission of a signal can take place from the
transmitter to the receiver. After receiving the
signal, the receiver will emit a visual and/or acou-
stic signal. The transmission of the signal takes
place in the form of radio waves. “Visual contact”
between the transmitter and the receiver is there-
fore not necessary.
Safety instructions
Before you start ...
• Neverrechargebatteries!Explosionhazard!
• Keepbatteriesawayfromchildren,donotthrow
into fire, short circuit or dismantle.
• Immediatelycontactadoctor,ifabatteryis
swallowed.
• Payattentiontothecorrectpolaritywheninser-
ting batteries.
• Cleanbatteryanddevicecontactspriortoinsertion,
if required.
• Immediatelyremovedepletedbatteriesfromthe
device!Increasedriskofleakage!
• Neverexposebatteriestoexcessiveheat,suchas
from sunshine, radiators or similar. Increased risk of
leakage!
• Ifthisisnotobservedbatteriescanbedischarged
beyondtheirmaximumvoltageandleak!Immedi-
ately remove batteries, in order to avoid damage.
• Avoidcontactwithskin,eyesandmucous
membranes.
In case of contact with battery acid, immediately
rinse the affected area with plenty of clean water
and contact a doctor immediately.
• Alwaysreplaceallbatteriesatthesametime.
• Onlyusebatteriesofthesametype,donotuse
different types or used and new batteries together.
• Incaseoflongerdisuse,removethebatteriesfrom
the device.
Safety instructionsProper use

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 08
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 09
Safety instructions Safety instructions
General instructions
1. Read through these instructions carefully before
using the device.
2. Keep this instructions manual.
3. The device is exclusively designed for private use.
4. Keep packaging material (e.g. film bag) out of
reach of children.
Instructions for use
1. Onlythefunctionsdescribedintheseoperating
instructions may be carried out with the doorbell.
2. Prior to initial use, please read through these
operating instructions carefully and pay particular
attention to the safety instructions.
3. Do not allow children to handle the device
unsupervised.
TheWirelessdigitaldoorchimeisnotatoy!
Improper use (e.g. short-circuiting the battery) can
resultinfirehazardorbatteryexplosionhazard!
4. The receiver (5) must not come into contact with
dripping or spray water/other liquids.
5. Although the transmitter (1) is weatherproof,
ensure that it is not situated in a location, where it
could be exposed to rain and direct sunlight.
6. Heat and cold impair the service life of the
batteries.
7. Do not carry out any changes to the device.
Repairs should exclusively take place by qualified,
specialist personnel. If necessary, contact our
service centre, see warranty (Page 25-27).
8. Do not operate the device, if aerosol (spray)
products are used.

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 10
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 11
Description of parts
3
1
2
4
7
5
8
9
10
11
12
13
14
15
16
17
6
18
1. Transmitter
2. Battery compartment
on the back
 (for1batterysize
3LR50 (12 V),
included in scope
of delivery)
3. LED function control
4. Doorbell button
5. Receiver
6. Flash
7. Melody
8. Learn
9. Selection switch
Flash
Flash and ring
Ring
10. Selection switch for
signal volume
(1/quiet, 2/medium,
3/loud)
11. Battery compartment
on the back
 (for2batteriessize
AA, LR6 (1.5 V),
included in scope of
delivery)
12. Loudspeaker
13. Base
14. Lid and wall bracket
for the transmitter
15. Holes for fastening
the lid for the
transmitter
16. Rubber seal
17. Tabs for opening
the lid
18. New code
Description of parts

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 12
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 13
Insert the battery in the transmitter (1)
1. Remove the lid of the battery compartment (2), by
pulling of the tabs (17).
2. Insertthebatterysize3LR50intothebattery
compartment. Please pay attention to the polarity:
Press the minus pole of the battery against the
spring and then push the battery in.
Programme radio channel
1. Press the New Code button (18) into the
transmitter (in the battery compartment).
2. At the same time, push the learn button (8) and
the bell button (4).
Startup and installation
18
• Transmitter(GT-RD-1T)
• Receiver(GT-RD-2R)
• Base
• Batteries:2xAA/LR61.5Vand1x3LR5012V
• Fasteningmaterialforwallmounting
• Paperstripsforthenamelabel
• Operatinginstructions
Startup and installation
Insert batteries in the receiver (5)
1. Pull the lid of the battery compartment (11)
downward.
2. InserttwobatteriessizeAA,LR6inthebattery
compartment. Pay attention to the correct polarity:
Press the minus pole of the battery against the
spring and then push the battery in.
3. Close the battery compartment with the lid.
Scope of delivery

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 14
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 15
Startup and installation
− The receiver confirms reception by emitting a
signal. Depending on the position of the selection
switch (9), a light signal (6), a light signal (6) and
an acoustic signal (12), or only an acoustic signal
(12).
3. If you do not intend to permanently install the
transmitter, close the battery compartment with
the lid (14).
NOTE:
If you should determine that the Wireless digital
door chime is not functioning normally, e.g. if the
red light permanently illuminates, the bell tone
is continuously repeated or the device does not
respond when pushing the bell button, remove
the batteries from the device for a while and
then insert them again. It is recommended that
you programme a new code prior to starting up
again.
Select signal
1. Slide the selection switch (9) of the receivers to
position:
if you only intend to see a light signal;
if you intend to see a light signal and simulta-
neously intend to hear an acoustic signal;
if you only intend to hear an acoustic signal.
Selection of the bell tone
In order to select one of the 16 bell tones, push
the selection button (7) , until you have reach
the desired tone.
Setting the volume of the acoustic
signal
1. Slide the selection switch for the signal volume
(10) of the receivers to position 1 for quiet, to
position 2 for medium and to position 3 for loud.
Startup and installation

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 16
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 17
Please note:
• Ifthesignalofthereceiverbecomestooquiet/too
weak, replace the batteries in the receiver.
• IftheLEDfunctioncontrol(3)ofthetransmitter
does not illuminate at all, or only weakly, when
pushing the button, replace the batteries in the
transmitter.
Installation of receiver and transmitter
You can use transmitter (1) and receiver (5) in a
mobile form or permanently install each/both.
If you use the Wireless digital door chime in a
mobile form (e.g. as a call signal within a home),
you can push the base (13) onto the receiver, in
order to be able to stand it up better.
Permanent installation
CAUTION:
Ensure that with the permanent installation of the
receiver in the home, no electric cables, gas or
Startup and installation Startup and installation
water pipes are laid under the plaster at the
installation site. When drilling the holes, the risk
exists of an electric shock or damage to the pipes.
Before permanently installing the transmitter and
receiver, check whether the receiver can receive
the signal of the transmitter in its future position.
For this, the transmitter should also be situated in
its future position.
Please note:
• Thetransmissionrange(100munderoptimum
conditions);
• Thatthetransmissionrangecanbeinfluencedby
the existence of walls, electrical lines or similar.
• Donotinstallonmetalitems,e.g.metalcabinets,
metal doors. These can shield the signal.
• Strongradiowavescanalsodisruptthesignal
transmission.

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 18
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 19
NOTE:
For permanent installation of the device, skilled
handling of tools is necessary. If necessary, please
contact an electrical engineer, if you have no tools
orarenotexperiencedinhandlingtools!
Installation of the receiver
For installation on plaster or brickwork:
1. Drill 30 mm deep (ø 5 mm) with an impact drill;
2. Insert wall plugs (S5) in the drill hole;
3. Turn in a suitable screw (head diameter not larger
than 7 mm), such that the head protrudes approx.
5 mm.
4. Suspend receiver.
For installation on wood or similar:
1. Drill approx. 0.5 mm (ø 2 mm) deep using a drill.
2. Turn in a suitable screw (head diameter not larger
than 7 mm), such that the head protrudes approx.
5 mm.
Startup and installation
3. Suspend receiver.
Installation of the transmitter
NOTE:
The wall bracket for the transmitter (14) should
be attached to the wall without a gap, because
water could otherwise penetrate the housing and
damage the electronic parts.
Thetransmittershouldalwaysbeinstalledhorizon-
tally. You can label the transmitter with a name.
The name field (3) is covered with a film. The film
can be removed in the area of the LED function
control (4) (press in with fingernail).
For installation on plaster or brickwork:
1. Maketwohorizontalmarksatadistanceof65mm.
2. Drill 30 mm deep (ø 5 mm) with an impact drill;
3. Insert wall plugs (S5) in the drill hole;
Startup and installation

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 20
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 21
4. With suitable screws (countersunk screws, head
diameter max. 7 mm) fasten the wall bracket for
the transmitter (14).
NOTE:
Note the position of the rubber seal (16) when
attaching the transmitter. In order to achieve a bet-
ter seal on the battery compartment, the rubber
seal can be painted with some silicone lubricant.
5. Push the transmitter onto the wall bracket.
For installation on wood or similar:
1. Maketwohorizontalmarksatadistanceof65mm.
2. Drill approx. 5 mm deep (ø 2 mm) with an impact
drill;
3. With suitable screws (countersunk screws, head
diameter max. 7 mm) fasten the wall bracket for
the transmitter (14).
NOTE:
Note the position of the rubber seal (16) when
attaching the transmitter. In order to achieve a
Startup and installation Startup and installation
better seal on the battery compartment, the rub-
ber seal can be painted with some silicone lubri-
cant.
4. Push the transmitter onto the wall bracket.
Problem solving
Receiver does not respond to transmitter:
• Carryoutprogramming,seeunderProgramme
radio channel.
• Checkthebatteries.
• Transmitterandreceiveraretoofarapartfromone
another.
• Thesignaltransmissionisbeinghindered.Change
the position of the transmitter/receiver.
The right light is permanently illuminated:
• Checkwhetherthebellbuttonisstuck.
• Brieflyremovethebatteriesfromthedeviceand
carry out reprogramming.

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 22
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 23
The bell tone is continuously repeated:
• Checkwhetherthebellbuttonisstuck.
• Brieflyremovethebatteriesfromthedeviceand
carry out reprogramming.
Cleaning
• Cleanthetransmitterandreceiverwithaslightly
damp cloth and carefully dry off all damp residues.
• Donotuseanyabrasiveorcorrosivedetergentfor
cleaningthetransmitterorreceiver.Otherwisethe
surface could be damaged or the electronic
components could corrode.
Problem solving
• IfyoushouldnotuseyourWirelessdigitaldoor
chime for a long period of time, please remove the
batteries from the transmitter and from the recei-
ver, in order to prevent battery leakage.
• Keepthedeviceinitsboxorinaclean,dry
location, out of reach of children.
Technical data
Receiver batteries: 2 x AA, LR6 (1.5V)
Transmitter battery: 1 x 3LR50 (12V, 23A)
Transmitter range: up to 100m outdoors
Transmissionfrequency: 433.92MHz
Storage

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 24
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 25
Conformity declaration Warranty
Model: Wireless digital door chime
GT-RD-2R/ GT-RD-1T
The appliance has been manufactured with
the greatest care.
The warranty period is three years from the
date of purchase. Please retain the sales receipt
as proof of purchase as without it the warranty
claim cannot be processed.
During the warranty period, the sales receipt
and the completed warranty card with a descrip-
tion of the fault must be returned once you have
contacted the service centre by phone. A new
appliance will be returned.
This warranty is in addition to your statutory
rights. Your statutory rights are not affected.
We declare that this product conforms to the basic
requirements and other relevant regulations of the
Directive 1999/5/EC.
The complete conformity declaration can be
found on the Internet at
www.gt-support.de.

Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 26
Helpline No. UK/Northern Ireland 0800 328 6020
Rep. Ireland 00800 4467 5888
E-mail Support [email protected]
Model Number: GT-RD-2R/GT-RD-1T 27
Warranty
This warranty does not apply in cases of damage
caused by accident, improper use, abuse and
force majeure.
This warranty will be invalidated if the appliance
is tampered with in any way whatsoever.
For warranty claims, please first contact us
by telephoning the service centre free phone
number or email:
Dario London Service Centre
POBox70
Chislehurst
BR7 5YH
UK
UK: 0800 328 6020
Ireland: 00800 4467 5888
[email protected]
Warranty
If the appliance has to be returned to us, it must
be packed correctly as we cannot accept any
responsibility for damage caused in transit.

Wireless digital
door chime
3 YEAR WARRANTY CARD
Name _______________________________________________
Address _____________________________________________
______________________________________________________
______________________________________________________
Email______________________ Tel No_______________
Model No. GT-RD-2R/ GT-RD-1T
Purchase location___________________________________
Please send your completed Warranty Card to:
UK + Ireland
Dario London Service Centre
POBox70
Chislehurst
BR7 5YH
UK
E42303 01/10
