HOMELITE
BACKPACKER II BLOWERS
MODEL NOS.
UT08072, UT08572 AND UT08572A
REPAIR SHEET

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
2
SEE
FIGURE B
Figure A
1
3
2
4
56
7
8
9
10
11
12
16
17
18
19
20
21
22
28
25
26
27
27
15
23
24 24
15
14
11
11
11
10
10
1
6
13

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
BLOWER or when ordering repair parts.
1 650028001 VIBRATION ISOLATOR........................................3
2 900968001 FOAM PAD ..........................................................1
3 678108001 SQUARE NUT .....................................................2
4 518093001 PUSH CLIP..........................................................6
5 660678001 * SCREW (1/4-20 x 3/4 in.) ....................................2
6 678110001 FLAT WASHER ....................................................4
7 518092001 BLOWER FRAME ................................................1
8 638085001 FRAME BRACKET...............................................1
9 638155001 ISOLATOR BRACKET..........................................1
10 678109001 LOCK WASHER...................................................4
11 678111001 * HEX NUT .............................................................6
12 678112001 WING NUT...........................................................1
13 660629001 * SCREW (10-14 x 3/4 in. TORX TRUSS HD.) .......2
14 580577001 SWEEPER NOZZLE .............................................1
15 580569001 STRAIGHT TUBE.................................................2
16 760363002 SWITCH...............................................................1
17 580567001 HANDLE CONTROL - RT ....................................1
18 580568001 HANDLE CONTROL - LT.....................................1
19 660680001 BOLT ...................................................................1
20 518090001 TRIGGER LATCH.................................................1
21 518091001 TRIGGER.............................................................1
22 940615001 BACKPACKER LABEL.........................................1
23 580565001 ELBOW................................................................1
24 900971001 CARRYING STRAP..............................................2
25 348006003 CLAMP ................................................................1
26 580566001 BELLOWS ...........................................................1
27 348006002 TUBE CLAMP......................................................2
28 580570001 UPPER TUBE ......................................................1
29 650031001 CABLE BRACKET (NOT SHOWN) ......................1
30 270020001 HARNESS WIRES & THROTTLE
(NOT SHOWN) .....................................................1
31 638081001 TAB (MALE 250 x 032, NOT SHOWN) ................1
32 900969001 SAFETY STRAP (NOT SHOWN)..........................1
33 900972001 NYLON TIE STRAP (NOT SHOWN).....................1
983000595 OPERATOR’S MANUAL (960277008)
983000782 OPERATOR’S MANUAL (UT08572A)
8-07-08
(REV:05)
KEY PART
NO. NUMBER DESCRIPTION QTY

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
4
Figure B
SEE
FIGURE C
19
28
29
28
3
4
2
6
7
36
37
5
33
24
26
27
10
35
21 30
34
31 23
25
22
12
16
11 8
120
13
32
17
19
14 18 15 928
38
42
39
41
40
30

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
5
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
BLOWER or when ordering repair parts.
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
1 308088001 PRIMER BULB ................................................... 1
2 900954001 CRANKCASE GASKET ...................................... 1
3 660664001 * SCREW (10-24 x 9/16 in. PAN HD.)................... 4
4 638031001 CRANKCASE COVER ........................................ 1
5 570256001 RUBBER BUMPER ............................................ 2
6 570549001 BIG BUMPER..................................................... 1
7 308123004 FUEL TANK ASSEMBLY
(INC. KEY NOS. 36-38 AND 42)......................... 1
8 650013001 BUSHING-STARTER ROPE ............................... 1
9 638032001 BAFFLE PLATE .................................................. 1
10 660668001 * SCREW (1/4-20 X 3/4) ....................................... 1
11 660630002 * SCREW (10-24 x 3/4 in. TRUSS HD.) ................ 4
12 900849004 STARTER ROPE................................................. 1
13 650014001 BUSHING STARTER .......................................... 1
14 638033001 SPRING & CONTAINER ..................................... 1
15 900957001 BAFFLE GASKET ............................................... 1
16 518073001 STARTER GRIP .................................................. 1
17 518249001 INNER VOLUTE HOUSING................................ 1
18 308134001 PULLEY ASSEMBLY.......................................... 1
19 660629001 * SCREW (10-14 x 3/4 in. TORX TRUSS HD.)...... 6
20 660667001 * SCREW (10 x 1-5/8 in. HEX HD.)....................... 1
21 518250001 OUTER VOLUTE ................................................ 1
22 650016001 FLAT WASHER................................................... 1
23 640858001 FAN ADAPTOR .................................................. 1
24 650017001 FLAT WASHER................................................... 1
25 518077001 FAN .................................................................... 1
26 650018001 FAN SPACER ..................................................... 1
27 518078001 DOOR................................................................. 1
28 660669001 * SCREW (#8 x 1/2 in. PAN HD.) .......................... 6
29 518251001 BLOWER SHROUD............................................ 1
30 660618001 * SCREW (10-24 x 3/4 in. TORX TRUSS HD.)...... 3
31 660730001 * NUT (3/8-24) ...................................................... 1
32 940630007 SWITCH COVER LABEL .................................... 1
33 940647001 CHOKE LABEL................................................... 1
34 940299493 FAN INTAKE WARNING LABEL ......................... 1
35 940642005 WARNING/STARTING LABEL............................ 1
36 308283001 FUEL FILTER KIT (INC. KEY NOS. 39-41) ......... 1
37 300758006 FUEL CAP ASSEMBLY ...................................... 1
38 570259005 RUBBER TUBING (196.85 mm) ......................... 1
39 300759003 FUEL FILTER...................................................... 1
40 570258003 RUBBER TUBING (114.3 mm) ........................... 1
41 690765001 WIRE CLAMP..................................................... 1
42 580553002 FUEL TANK ........................................................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
6
Figure C
19 21
26
20
16
22
1
3
2
5
6
7
11
12
15
13
14
17
18 4
8
10
9
24
25
23

HOMELITE BACKPACKER II BLOWERS – MODEL NUMBERS UT08072, UT08572 AND UT08572A
7
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
BLOWER or when ordering repair parts.
PARTS LIST (FIGURE C)
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660660001 SCREW THD FORMING............................................................................................. 2
2 870174001 SPARK PLUG CHAMPION - RCJ-6Y......................................................................... 1
3 850080001 IGNITION MODULE.................................................................................................... 1
4 308028004 CARBURETOR ........................................................................................................... 1
5 900950001 HEAT DAM GASKET .................................................................................................. 1
6 660346002 CARBURETOR MOUNTING BOLT............................................................................. 2
7 660662001 * SCREW (10-24 x 1.11 PAN HD.). ............................................................................... 2
8 900951004 CARBURETOR GASKET............................................................................................ 1
9 518120001 SPACER ..................................................................................................................... 1
10 900711003 GASKET ..................................................................................................................... 1
11 518087001 HEAT DAM ................................................................................................................. 1
12 518248001 AIR FILTER BOX......................................................................................................... 1
13 900952001 AIR FILTER ................................................................................................................. 1
14 518072001 AIR FILTER COVER .................................................................................................... 1
15 678027001 * HEX NUT (10-24)........................................................................................................ 2
16 300748010 MUFFLER................................................................................................................... 1
17 638133002 THROTTLE CABLE CLIP............................................................................................ 1
18 660734001 SCREW-FILTER BOX ................................................................................................. 1
19 308281001 CARBURETOR KIT (INC. KEY NOS. 4, 8-10 AND 24) ............................................... 1
20 308119002 PISTON ASSEMBLY KIT ............................................................................................ 1
21 308099003 SHORT BLOCK ASSEMBLY (INC. KEY NOS. 20, 25)................................................ 1
23 300952002 ROTOR AND PAWL ASSEMBLY ................................................................................ 1
22 308284001 IGNITION KIT (INC. KEY NOS. 1-3) ........................................................................... 1
24 900994004 CARBURETOR GASKET............................................................................................ 1
25 900953001 CYLINDER GASKET................................................................................................... 1
26 900994001 MUFFLER GASKET.................................................................................................... 1
