HOMELITE
26cc BLOWER
MODEL NO. UT09521
ALL VERSIONS
REPAIR SHEET

HOMELITE 26cc BLOWER – MODEL NUMBER UT09521
2
Figure A
1
2
7
9
10
6
4
5
See Figure B
11
12
8
3

HOMELITE 26cc BLOWER – MODEL NUMBER UT09521
3
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 570543002 Upper Blower Tube ................................................................................................................1
2 580537002 Sweeper Nozzle.....................................................................................................................1
3 941080001 Throttle Label.........................................................................................................................1
4 310816001 Fuel Cap Assembly................................................................................................................1
5 521852001 Air Box Cover.........................................................................................................................1
6 570107003 Air Box Gasket.......................................................................................................................1
7 870174001 * Spark Plug (RCJ6Y) ...............................................................................................................1
8 940867001 Model Label ...........................................................................................................................1
9 940657043 Warning Label........................................................................................................................1
10 940654088 Combustion Warning Label ...................................................................................................1
11 940868002 Choke Label...........................................................................................................................1
12 940734078 Starting Instructions Label.....................................................................................................1
Not Shown:
988000332 Operator’s Manual .................................................................................................................1
11-19-10
(REV:01)

HOMELITE 26cc BLOWER – MODEL NUMBER UT09521
4
Figure B
1
256
7
8
13
14
15
16
17
18
19
20
42
41
22
24
1
25
23
48
21
10
9
12
11
1
26
29
39
40
30
31 32
33
44
34
35
43
47
36
46
37
38
27
28
45
4
34

HOMELITE 26cc BLOWER – MODEL NUMBER UT09521
5
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660466001 Screw (M4 x 18 mm)........................................17
2 521802002 Outer Volute ......................................................1
3 660730001 Lock Nut (3/8 in.) ...............................................1
4 650016001 Washer ..............................................................2
5 521308001 Fan ....................................................................1
6 638091008 Spacer ..............................................................1
7 660970001 Screw (M4 x 17 mm, T.F.) ..................................4
8 308981017 Inner Volute .......................................................1
9 521803001 Handle Cover ....................................................1
10 660968001 Screw (M4 x 19 mm, T.F.) ..................................2
11 850108009 Ignition Module..................................................1
12 308563006 Lower Housing w/Starter Assembly..................1
13 900849012 Starter Rope (42 in.)...........................................1
14 511731001 Starter Grip ........................................................1
15 638088004 Eyelet.................................................................1
16 522600001 Shield.................................................................1
17 638033001 Spring & Container ............................................1
18 521316001 Starter Pulley .....................................................1
19 638389001 Pulley Retainer...................................................3
20 660967001 Screw (M4 x 14 mm, T.F.) ..................................3
21 650017001 Washer...............................................................1
22 308811004 Rotor and Pawl Assembly .................................1
23 309963001 Short Block Assembly .......................................1
24 521804001 Engine Cover .....................................................1
25 901362002 Muffler Gasket ...................................................1
26 309327001 Muffler Assembly...............................................1
27 638442009 Muffler Heat Shield............................................1
28 660638003 Screw (10-24 x 2-1/8 in.) ...................................2
29 660927007 Screw (10-24 x 2.5 in.).......................................2
30 518920001 Heat Dam...........................................................1
31 638659002 Washer...............................................................2
32 660927003 Screw (M5 x 25 mm)..........................................2
33 521505001 Baffle..................................................................1
34 901552002 Heat Dam Gasket ..............................................1
35 308054041 Carburetor .........................................................1
36 521851001 Air Box Base......................................................1
37 678868001 Hex Nut (M5)......................................................2
38 901550001 Crankcase Cover Gasket...................................1
39 638337001 Crankcase Cover...............................................1
40 660925003 Screw (M4 x 12 mm)..........................................6
41 660970002 Screw (M4 x 14 mm)..........................................3
42 310753001 Fuel Tank Assembly w/Cap ...............................1
43 521850001 Choke Lever ......................................................1
44 561635001 Primer Bulb........................................................1
45 901551001 Heat Dam Gasket ..............................................1
46 521608001 Choke Cover......................................................1
47 660345001 Screw (M4 x 12 mm, T.F.) .................................1
48 300759005 Fuel Filter ...........................................................1
