OPERATOR'S MANUAL


Fig. 1
Fig. 4 Fig. 5
Fig. 3
oil cap/ dipstick
recoil
starter grip
air Filter
cHoke leVer
FUel cap circUit
Breaker
FUel tank
FUel cap
oil cap/
dipstick
oil Fill Hole
carBUretor
drain screw
oil cap/
dipstick
Fig. 2
FUel tank

Fig. 6
ON
OFF
ON
OFF
Fig. 8Fig. 7
air Filter
recoil
starter grip
FUel ValVe
Fig. 9
cHoke leVer to start
(cHoke closed)
to rUn
(cHoke open)
latcHes
cHoke leVer to start
(cHoke closed)
latcHes

21
2))
Fig. 10
ON
OFF
Fig. 11 Fig. 12
Fig. 13
ON
OFF
ON
OFF
spark plUg
cap
spark plUg
FUel
line FUel
ValVe
BarB
FUel
ValVe
o-ring
Filter
sediment
cUp
oil cap/ dipstick

1


This product has many features for making its use
more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design
of this product, making it easy to maintain and operate.

 (See Figure 1)
To avoid the risk of shock or electrocution, the
generator must be properly grounded. The nut and
ground terminal on the frame must always be used
to connect the generator to a suitable ground source.
The ground path should be made with 0.75m2
size wire. Connect the terminal of the ground wire
between the lock washer and the nut, and tighten the
nut fully. Connect the other end of the wire securely
to a suitable ground source.


  Failure
to follow all instructions listed below may result
in electrocution, fire, and/or carbon monoxide
poisoning, which will cause death or serious
injury.

 
National Electric Code requires the generator
to be grounded to an approved earth ground.
Before using the ground terminal, consult
a qualified electrician, electrical inspector, or
local agency having jurisdiction for local codes
or ordinances that apply to the intended use of
the generator.

This manual contains important instructions that should
be followed during installation and maintenance of the
generator and batteries.
nDo not allow children or untrained individuals to use
this unit.
nNever start or run the engine inside a closed or partially
enclosed area. Breathing exhaust fumes will kill you.
nWear eye protection as well as hearing protection when
operating this equipment.
nKeep all bystanders, children, and pets at least 3m
away.
nWear sturdy and dry shoes or boots. Do not operate
while barefoot.
nDo not operate the generator when you are tired or
under the inuence of drugs, alcohol, or medication.
nKeep all parts of your body away from any moving parts
and all hot surfaces of the unit.
nProduct users in some states, must comply with re
prevention regulations. This product is not equipped
with a spark arrestor. Check with the federal, areas,
or local authorities in your area before use.
nDo not touch bare wire or receptacles.
nDo not use the generator with electrical cords which
are worn, frayed, bare, or otherwise damaged.
nBefore storing, allow the engine to cool.
nDo not operate the generator in rain, snow, or wet
weather.
nEmpty fuel tank, close fuel valve, and restrain the unit
from moving before transporting in a vehicle.
nAllow engine to cool for ve minutes before refueling.
nTo reduce the risk of re and burn injury, handle fuel
with care. It is highly ammable.
nDo not smoke while handling fuel.
nStore fuel in a container approved for unleaded fuel.
nPosition the unit on level ground, stop engine, and allow
to cool before refueling.
nLoosen fuel cap slowly to release pressure and to keep
fuel from escaping around the cap.
nTighten the fuel cap securely after refueling.
nWipe spilled fuel from the unit.
nNever attempt to burn off spilled fuel under any
circumstances.
nUse only authorised replacement parts and accessories
and follow instructions in the Maintenance section of
this manual. Use of unauthorised parts or failure to
follow Maintenance instructions may create a risk of
shock or injury.
nMaintain the unit per maintenance instructions in this
Operator’s Manual.
nInspect the unit before each use for loose fasteners,
fuel leaks, etc. Replace damaged parts.
nThe generators vibrate in normal use. During and after
the use of the generator, inspect the generator as well
as extension cords and power supply cords connected
to it for damage resulting from vibration. Have damaged
items repaired or replaced as necessary. Do not use
plugs or cords that show signs of damage such as
broken or cracked insulation or damaged blades.

2



        
 the generator must
be installed by a qualified electrician and
connected to a transfer switch as a separately
derived system in accordance with NFPA 70,
National Electrical Code. The generator shall
be connected through a transfer switch that
switches all conductors other than the equipment
grounding conductor. Failure to isolate the
generator from power utility can result in death or
injury to electric utility workers.
nExhaust contains poisonous carbon monoxide,
a colorless, odorless gas. Breathing exhaust can
cause loss of consciousness and can lead to death.
If running in a confined or partially-enclosed area,
the air may contain a dangerous amount of carbon
monoxide. To keep exhaust fumes from building up,
always provide adequate ventilation.
nAlways use a battery-powered carbon monoxide
detector when running the generator. If you begin to
feel sick, dizzy, or weak while using the generator,
shut it off and get to fresh air immediately. See a
doctor. You may have carbon monoxide poisoning.
nPlace the generator on a flat, stable surface with a
slope of no more than 4°.
nOperate in a well-ventilated, well-lit area isolated
from working areas to avoid noise interference.
nOperating the generator in wet conditions could
result in electrocution. Keep the unit dry.
nKeep the generator a minimum of 1m away from all
types of combustible material.
nDo not operate the generator near hazardous
material.
nDo not operate the generator at a gas or natural gas
filling station.
nDo not touch the muffler or cylinder during or
immediately after use; they are HOT and will cause
burn injury.
nDo not connect to a building’s electrical system
unless a transfer switch has been properly installed
by a qualified electrician.
nDo not allow the generator’s gas tank to overflow
when filling. Fill to 25mm below the top neck of the
unleaded fuel tank to allow for fuel expansion. Check
the ventilation hole inside the fuel tank cap for debris.
Do not block the vent.
nDo not smoke when filling the generator with
unleaded fuel.
nAllow the engine to remain in a shut-down condition
for at least five minutes before adding unleaded fuel
or oil.
nDo not remove the oil dipstick or the fuel tank cap
when the engine is running.
nPay close attention to all safety labels located on the
generator.
nKeep children a minimum of 10 feet away from the
generator at all times.
nThe unit operates best in temperatures between 5°C
and 40°C with a relative humidity of 30~95%.
nDo not operate the generator at altitudes above
1000m.
n When using extension lines or mobile distribution
networks the total length of lines for a cross section
of 1.5mm2 should not exceed 60m; for a cross
section of 2.5mm2 this should not exceed 100m.
n The generating set must not be connected to other
power sources
nSave these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions
also.

3


Some of the following symbols may be used on this tool. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the tool better and safer.
  
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
hrs Hours Time
gal Gallon Volume
qt Quart Volume
Wet Conditions Alert Do not expose to rain or use in damp locations.
Read The Operator’s Manual To reduce the risk of injury, the user must read and understand
the operator’s manual before using this product.
Eye Protection Always wear safety goggles or safety glasses with side shields
and, as necessary, a full face shield when operating this product.
Safety Alert Precautions that involve your safety.
Electric Shock Failure to use in dry conditions and to observe safe practices
can result in electric shock.
Toxic Fumes Running the generator gives off carbon monoxide, an odorless, colorless, poison gas. Breathing carbon monoxide can cause
nausea, fainting, or death.
Fire/Explosion Fuel and its vapors are extremely ammable and explosive. Fire
or explosion can cause severe burns or death.
Hot Surface To reduce the risk of injury or damage, avoid contact with any
hot surface.
Lifting Hazard To reduce the risk of serious injury, avoid attempting to lift the
generator alone.
Ground Consult with local electrician to determine grounding
requirements before operation.
Electrocution Failure to properly ground generator can result in electrocution,
especially if the generator is equipped with a wheel kit.

4


The following signal words and meanings are intended to explain the levels of risk associated with this product.
  
 Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
 Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
 Indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury.
 (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.

Servicing requires extreme care and knowledge and should
be performed only by a qualied service technician. For
service, contact your nearest AUTHORISED SERVICE
CENTRE for repair. When servicing, use only identical
replacement parts.

Observe all normal safety precautions related to
avoid electrical shock.

To avoid death or serious personal injury, do not
attempt to operate this product until you read
thoroughly and understand completely the operator’s
manual. If you do not understand the warnings and
instructions in the operator’s manual, do not use this
product. Call your nearest authorised service centre
for assistance.
 
The operation of any products can result in
foreign objects being thrown into your eyes,
which can result in severe eye damage. Before
beginning power tool operation, always wear
safety goggles or safety glasses with side
shields and, when needed, a full face shield. We
recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with
side shields. Always wear eye protection.


5


The information below can be found on the generator.
For your safety, please study and understand all of the
labels before starting the generator.
If any of the labels come off the unit or become hard
to read, contact the authorised service centre for
replacement.

No smoking when filling with unleaded fuel. Do not
overfill. Full level is 25mm below the top of the fuel neck.
Stop the engine for five minutes before refueling to avoid
the heat from the muffler igniting fuel vapors.

You must add oil before first operating the generator.
Always check the oil level before each operation. The oil
level should always register within the hatched area on
the dipstick. The unit is equipped with an oil sensor which
will automatically shut off the engine if oil level falls below
a safe limit.

Do not touch the muffler or aluminum cylinder of the
engine. They are very HOT and will cause severe burns.
Don’t put any flammable or combustible materials in the
direct path of the exhaust.

READ THE OWNERS MANUAL AND ALL LABELS BEFORE OPERATING.
ONLY OPERATE IN WELL-VENTILATED AREA.
EXHAUST GAS CONTAINS POISONOUS CARBON MONOXIDE.
CHECK FOR SPILT FUEL LINE OR FUEL LEAKS.
STOP ENGINE BEFORE REFUELING.
DO NOT OPERATE NEAR FLAMMABLE MATERIALS.
ELECTROCUTION CAN OCCUR IF GENERATOR IS USED IN RAIN.
SNOW, OR NEAR WATER, KEEP THIS UNIT DRY AT ALL TIMES.
1.
2.
3.
4.
5.
6.
WARNING
HOT MUFFLER
LOW OIL WARNING !
IN THE CASE OF AUTO-STOP OR LIGHTING OF
OIL PRESSURE ALERT LAMP. DO NOT RUN
ENGINE WITHOUT CHECKING OIL LEVEL.
CHECK ENGINE OIL
EACH TIME FILLED
SAE10W30 (CCCLASS)


6



Make sure the generator can supply enough continuous
(running) and surge (starting) watts for the items you will
power at the same time. Follow these simple steps.
1. Select the items you will power at the same time.
2. Total the continuous (running) watts of these items.
This is the amount of power the generator must
produce to keep the items running. See the wattage
reference chart at right.
3. Estimate how many surge (starting) watts you will
need. Surge wattage is the short burst of power
needed to start electric motor-driven tools or
appliances such as a circular saw or refrigerator.
Because not all motors start at the same time, total
surge watts can be estimated by adding only the
item(s) with the highest additional surge watts to the
total rated watts from step 2.

Tool or
Appliance
Continuous
(Running)
Watts
Surge
(Starting) Watts
CD Player 100 0
Space Heater 1800 0
Drill 500 0
Light (75 Watts) 75 75
2475 Total
Running Watts
75 Highest Surge
Watts
Total Continuous (Running) Watts 2475
Plus Highest Additional Surge Watts + 75
Equals Total Generator Output Required 2550

To prolong the life of the generator and attached devices,
it is important to take care when adding electrical loads to
the generator. There should be nothing connected to the
generator outlets before starting its engine. The correct and
safe way to manage generator power is to sequentially add
loads as follows:
1. With nothing connected to the generator, start the
engine as described later in this manual.
2. Plug in and turn on the first load, preferably the largest
load you have.
3. Permit the generator output to stabilise (engine runs
smoothly and attached device operates properly).
4. Plug in and turn on the next load.
5. Again, permit the generator to stabilise.
6. Repeat steps 4 and 5 for each additional load.
Never add more loads than the generator capacity. Take
special care to consider surge loads in generator capacity
as previously described.

Do not overload the generator’s capacity. Exceeding the
generator’s wattage/amperage capacity can damage the
generator and/or electrical devices connected to it.










Light Bulb − 75 Watt 75 75
Refrigerator/Freezer 700 2200
Sump Pump − 1/2 HP 1050 2200
Water Well Pump − 1/3 HP 1000 1500
Electric Water Heater 4000   0

Furnace Fan − 1/2 HP 800 2350
Window AC − 10,000 BTU 1200 1800
Space Heater 1800   0

Microwave Oven − 1000 Watt 1000   0
Coffee Maker 1000   0
Electric Stove − Single Element 2100   0
Toaster Oven 1200   0

VCR 100   0
CD/DVD Player 100   0
Stereo Receiver 450   0
Colour Television − 27 in. 500   0

Security System 500   0
Curling Iron 1500   0
Garage Door Opener − 1/2 HP 875 2350
Hair Dryer − 1/2 HP 1250   0

Quartz Halogen Work Light 1000   0
Airless Sprayer − 1/3 HP 600 1200
Reciprocating Saw 960   0
Electric Drill − 1/2 HP 600 900
Circular Saw − 7-1/4 in. 1400 2300
Miter Saw − 10 in. 1800 1800
Planer/Jointer − 6 in. 1800 1800
Table Saw/Radial Arm Saw − 10 in. 2000 2000
Air Compressor − 1 HP 1600 4500
*Wattages listed are approximate. Check tool or appliance for actual wattage.

7


 

AC Frequency (Hz) 50
AC Output voltage (V) 230
Rated AC Output (W) 900
Rated Current (A) 3.9
Circuit Breaker (A) 4
Power Factor 1.0

Volts 12
Amps 5.8

Engine Number UP154
Engine Type 4-Stroke; air-cooled OHV; Gasoline
Bore x Stroke 54x38
Displacement (cc) 87
Starting System recoil
Fuel Type Unleaded fuel
Lubrication oil SAE 10W-30
Engine Oil Volume(L) 0.6L
Fuel Tank Capacity (l) 6
Max. Output (hp) 2.4
Max Output (rpm) 3,600
Full Load (h) 6
Half Load (h) 11.0

CE Yes
Euro Emission Yes
4m Noise Level LpA dB (A) 73
4m Noise Level LwA dB (A) 93
Uncertainty dB (A) 2
7m Noise Level LpA dB (A) 68
7m Noise Level LwA dB (A) 88

8



See Figure 3.
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarise yourself with all
operating features and safety rules.

The circuit breaker is provided to protect the generator
against electrical overload and can be used to turn the
generator’s electrical power on or off.

The air lter helps to limit the amount of dirt and dust drawn
into the unit during operation.

The choke lever is used when starting the engine.

The engine switch is used in combination with the recoil
starter grip to start the generator. It is also used to turn
the generator off.

Consult the fuel level gauge to determine the amount of
fuel remaining in the generator.

6 litres

The ow of fuel through the generator is controlled by the
position of the fuel valve.

The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock.
Consult with a local electrician for grounding requirements
in your area.

When changing the engine oil, the oil drainage bolt is
loosened to allow old engine oil to be drained.

Remove the oil ll cap to check and add oil to the generator
when necessary.

Your generator has the following single phase, 50 Hz outlets:
one 230 Volt AC, 16 Amp receptacle. These can be used
for operating appropriate appliances, electrical lighting,
tools, and motor loads.

The recoil starter grip is used (along with the engine switch)
to start the generator’s engine.

The DC terminals may ONLY be used for charging 12 volt
automotive type batteries.
The terminals are colored red to identify the positive (+)
terminal and black to identify the negative (-) terminal. The
battery must be connected to the generator DC terminals
with the proper polarity ( battery positive to generator
red terminal and battery negative to the generator black
terminal).

The DC circuit protector automatically shuts off the DC
battery charging circuit when the DC charging circuit is
overloaded, when there is a problem with the battery,
or when the connections between the battery and the
generator are improper.


This product has been shipped completely assembled.
n Remove one end of the box and carefully slide out the
generator and any accessories.
 The generator is heavy. If you must lift the unit
out of the box, get another person to help you and lift
with your legs, not your back.
n Inspect the unit carefully to make sure no damage
occurred during shipping.
n Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
n If any parts are damaged or missing, please contact
your nearest authorised service centre for assistance.

Generator Spark Plug Wrench
Oil Bottle / Oil Funnel Operator’s Manual

9


If any parts are damaged or missing do not
operate this product until the parts are replaced.
Failure to heed this warning could result in
serious personal injury.

Do not attempt to modify this tool or create
accessories not recommended for use with
this tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.

 
  Using a generator indoors
WILL KILL YOU IN MINUTES.
Generator exhaust contains high levels of carbon monoxide
(CO), a poisonous gas you cannot see or smell. If you
can smell the generator exhaust, you are breathing CO.
But even if you cannot smell the exhaust, you could be
breathing CO.
nNever use a generator inside homes, garages,
crawlspaces, or other partly enclosed areas. Deadly
levels of carbon monoxide can build up in these
areas. Using a fan or opening windows and doors
does NOT supply enough fresh air.
nONLY use a generator outdoors and far away from
open windows, doors, and vents. These openings
can pull in generator exhaust.
Even when you use a generator correctly, CO may leak
into the home. ALWAYS use a battery-powered or battery-
backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator
has been running, move to fresh air RIGHT AWAY. See
a doctor. You could have carbon monoxide poisoning.
 
Failure to properly ground generator can result
in electrocution, especially if the generator is
equipped with a wheel kit. Generators have
to be properly grounded to an approved earth
ground. Call an electrician for local grounding
requirements.
 
Do not allow familiarity with tools to make you
careless. Remember that a careless fraction of a
second is sufficient to inflict serious injury.
 
Do not use any attachments or accessories not
recommended by the manufacturer of this
product. The use of attachments or accessories
not recommended can result in serious personal
injury.

This generator is designed to supply electrical power for
operating compatible electrical lighting, appliances, tools,
and motor loads.

Position the generator on a at surface before checking
uid levels or adding uid.
 
Attempting to start the engine before it has been
properly filled with oil will result in equipment
failure.

See Figure 4.
Engine oil has a major influence on engine performance
and service life. For general, all-temperature use, SAE
10W-30 is recommended. Always use a 4-stroke motor
oil that meets or exceeds the requirements for API
service classification SJ.
 Non-detergent or 2-stroke engine oils will
damage the engine and should not be used.
n Unscrew the oil cap/dipstick and remove.
n Wipe dipstick clean and re-seat in hole; do not
re-thread.
n Remove dipstick again and check oil level. Oil level
should fall within the level indicator area on the
dipstick.
n If level is low, add engine oil until the fluid level rises
to the upper portion of the level indicator area on the
dipstick.
n Replace and secure the oil cap/dipstick.

See Figure 5.
n Check the fuel level gauge. If fuel is needed, continue
with the next step.
n Remove the fuel cap.
n Fill the fuel tank to 25mm below the top of the fuel
neck.
n Replace and secure the fuel cap.
 Always use unleaded gasoline with a pump octane
rating of 86 or higher. Never use old, stale, or contaminated
unleaded fuel, and do not use an oil/gas mixture. Do not
allow dirt or water into the fuel tank.

10


Fuel gets old, oxidizes, and breaks down over time. Adding
a fuel stabiliser extends the usable life of fuel and helps
prevent deposits from forming that can clog the fuel system.
Follow fuel stabiliser manufacturer’s directions for correct
ratio of stabiliser to fuel.
nAdd stabiliser to fuel tank, then fill with unleaded fuel
following previous instructions.
 Fuel stabiliser and unleaded fuel can be
mixed prior to filling the tank by using a gas can or
other approved fuel container and shaking gently to
combine.
nReplace and secure the fuel tank cap.
nStart and run the engine for at least 5 minutes to
allow stabiliser to treat the entire fuel system.



Some conventional petrol are blended with alcohol
or an ether compound. This type of petrol is collectively
referred to as oxygenated fuel; in Australia known as Ethanol.
The use of ethanol fuel, or fuels containing ethanol is not
recommended for this product.
 
On a level surface with the engine off, check the
oil level before each use of the generator.

nUnplug all loads from the generator.
nSwitch the AC circuit breakers to the OFF (O)
position.
nStart the engine (refer to "STARTING THE ENGINE"
section. (later on this page)
nSwitch the AC circuit breakers to the ON ( I ) position.
nPlug in the appliance.

The DC terminals may ONLY be used for charging 12 volt
automotive type batteries.
 
   



 




nBefore connecting the battery charging cables to
a battery that is installed in a vehicle, disconnect
the vehicle ground battery cable from the battery
negative (-) terminal.
nConnect the positive (+) battery cable to the battery
positive (+) terminal.
nConnect the other end of the positive (+) battery
cable to the generator positive (+) terminal.
nConnect the negative (-) battery cable to the battery
negative (-) terminal.
nConnect the other end of the negative (-) battery
cable to the generator negative (-) terminal.
nStart the engine. (refer to "STARTING THE ENGINE"
section)
     Do not start the vehicle while the battery
charging cable is connected and the generator
is running. The vehicle or the generator may be
damaged.
An overloaded DC circuit, excessive current draw by the
battery, or a wiring problem will trip the DC circuit protector
(PUSH button extends out). If this happens, wait a few
minutes before pushing in the circuit protector to resume
operation. If the DC circuit protector continues to go OFF,
discontinue charging and see your nearest authorised
service centre.

nDisconnect the negative (-) battery cable from the
generator negative (-) terminal.
nDisconnect the other end of the negative (-) battery
cable from the battery negative (-) terminal.
nDisconnect the positive (+) battery cable from the
generator positive (+) terminal.
nConnect the other end of the positive (+) battery
cable to the battery positive (+) terminal.
nReconnect the vehicle ground battery cable to the
battery negative (-) terminal. 

See Figures 6 - 8.
 If location of generator is not level, the unit may not
start or may shut down during operation.
nTurn the fuel valve to the ON position.
nMove the choke lever to the START position.
 If engine is warm or the temperature is above
10˚C, push the choke lever in to the RUN position.
nPut the engine switch in the ON ( I ) position.
nPull the recoil starting grip until the engine runs (a
maximum of 6 times).
 Do not allow the grip to snap back after
starting; return it gently to its original place.
nAllow the engine to run for 30 seconds, then move
the choke lever in to the RUN position.

11


See Figures 6- 7.

nRemove any load from the generator.
nSwitch the AC circuit breakers to the OFF position.
nDisconnect DC battery charging cables.
nTurn the fuel valve to the OFF position.
nPut the engine switch in the OFF ( O ) position.
nTurn the key to "OFF" position (Electric start only).

n Put the engine switch in the OFF ( O ) position.

 
When servicing, use only identical Ryobi
replacement parts. Use of any other parts may
create a hazard or cause product damage.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts should
be replaced at an authorised service centre.

Keep the generator in a clean and dry environment where
it is not exposed to dust, dirt, moisture, or corrosive vapors.
Do not allow the cooling air slots in the generator to become
clogged with foreign material such as leaves, snow, etc.
Do not use a garden hose to clean the generator. Water
entering the fuel system or other internal parts of the unit can
cause problems that will decrease the life of the generator.

nUse a soft bristle brush and/or vacuum cleaner to
loosen and remove dirt and debris.
nClean air vents with low pressure air that does not
exceed 25 psi.
nWipe the exterior surfaces of the generator with a
damp cloth.

See Figure 9.
For proper performance and long life, keep air lters clean.
n Lift the latches located at the top and bottom of the
air filter cover. Remove the cover and set aside.
n Remove the filter elements.
n If the filter elements are dirty, clean with warm, soapy
water. Rinse and let dry.
n Apply a light coat of engine oil to the elements, then
squeeze it out.
n Replace the elements in the air filter unit.
n Replace the air filter cover and close latches to
secure.
 Do not run the generator without the air filter.
Rapid engine wear will result.

See Figure 10.
nRemove the oil cap/dipstick.
nPlace a container underneath the oil drainage bolt to
collect used oil as it drains.
nUnscrew the oil drainage bolt and remove.
nAllow oil to drain completely.
nReinstall the oil drainage bolt and tighten securely.
nRefill with oil following the instructions in the
 section.
nReinstall the oil cap/dipstick.
 Used oil should be disposed of at an approved
disposal site. See your local oil retailer for more
information.

See Figure 11.
The sediment cup prevents dirt and water that may have
gotten into the fuel tank from entering the carburetor. If the
engine has not been run for a long time, the sediment cup
should be cleaned before use.
nTurn the fuel valve to the OFF position.
nRemove the sediment cup using a 10 mm wrench
(not provided).
nRemove the O-ring and filter.
nClean each of the parts in carburetor cleaner or any
comparable cleaning product.
nReinstall the filter, O-ring, and sediment cup. Tighten
with wrench to secure.
nReturn the fuel valve to ON position and check for
leaks.

See Figure 12.
The spark plug must be properly gapped and free of deposits
in order to ensure proper engine operation. To check:
nRemove the spark plug cap.
nClean any dirt from around base of spark plug.
nRemove spark plug using wrench provided.
nInspect spark plug for damage, and clean with a wire
brush before reinstalling. If insulator is cracked or
chipped, spark plug should be replaced.
 If replacing, use the following recommended
spark plugs or equivalent: Champion RN11YC or
NGK BPR6ES.
nSeat spark plug in position; thread in by hand to
prevent cross-threading.
nTighten with wrench to compress washer. If spark
plug is new, use 1/2 turn to compress washer
appropriate amount. If reusing old spark plug, use 1/8

12

to 1/4 turn for proper washer compression.
  An improperly tightened spark plug will
become very hot and could damage the engine.

Depending on the type of fuel used, the type and amount of
oil used, and/or your operating conditions, the exhaust port
and mufer may become blocked with carbon deposits. If
you notice a power loss with your petrol-powered tool, you
may need to remove these deposits to restore performance.
We highly recommend that only qualied service technicians
perform this service.

Product users in some areas, must comply with re
prevention regulations. This product is equipped with a
spark arrestor.

When not using a fuel stabiliser, draining the fuel from the
tank and carburetor before storage may help prevent gum
deposits in the fuel system.

See Figure 13.
nTurn the engine switch OFF ( O ).
nClose fuel valve.
nRemove the fuel line from the barb by squeezing the
ends of the retaining clip and sliding the fuel line off.
nInstall one end of a drain line over the barb, and
place the other end in a fuel container large enough
to catch the fuel being drained from the tank.
nOpen fuel valve.
nWhen the fuel has drained from the tank, close the
fuel valve and reinstall fuel line on barb.

See Figure 2.
n Turn the engine switch off ( O ).
n Close the fuel valve.
n Position an approved fuel container under the
carburetor drain screw to catch fuel; loosen the
screw.
n Allow fuel to drain completely into container.
n Retighten drain screw.
 After draining the fuel tank and carburetor,
start the engine and allow it to run until the unit runs
out of fuel. Consult hazardous waste management
guidelines in your area for the proper way to dispose
of used fuel.

nTurn engine switch OFF ( O ).
nClose the fuel valve.
nMake sure engine and exhaust of unit is cool.
nKeep unit level to prevent fuel spillage.
nDo not drop or strike unit or place under heavy
objects.

13



When preparing the generator for storage, follow the guidelines below.
 
Less than 1 month nNo special preparation is required.
1 to 2 months nEmpty fuel from fuel tank.
2 months to 1 year nEmpty fuel from fuel tank.
nDrain fuel from carburetor.
nClean fuel sediment cup.
1 year or more nEmpty fuel from fuel tank.
nDrain fuel from the carburetor.
nClean fuel sediment cup.
nRemove spark plug.
nPut a tablespoon of engine oil into the spark plug cylinder. Turn the engine slowly with the pull
rope to distribute the oil.
nReinstall spark plug.
nChange engine oil.
*Use unleaded fuel stabilisers formulated to extend storage life. For recommendations, contact your nearest authorized
service center.















 n
 n n
 n
 n
 n

 n
 n
 n
 n

 n

 n
 n
* These items should only be carried out by an authorized service center.
 Maintenance should be performed more frequently when generator is used in dusty areas.
When generator has exceeded the maximum figures specified in the table, maintenance should still be cycled
according to the intervals of time or hours stated herein.

14


  
Engine will not start. Engine switch is OFF.
No fuel.
Oil level is low.
Fuel valve is OFF.
Spark plug faulty, fouled, or improperly
gapped.
Fuel is not reaching carburetor.
Choke is OPEN.
Engine stored without treating or draining
unleaded fuel, or refueled with bad
unleaded fuel.
Turn engine switch to ON.
Fill fuel tank.
Check engine oil level and fill, if
necessary.
Turn fuel valve ON.
Replace spark plug.
Clean fuel sediment cup.
Move choke lever out to START.
Drain fuel and carburetor. Refuel with
fresh unleaded fuel.
Engine lacks power. Fuel element clogged.
Engine stored without treating or draining
unleaded fuel, or refueled with bad
unleaded fuel.
Check air lter element. Clean or replace
as needed.
Drain fuel and carburetor. Refuel with
fresh unleaded fuel.
AC receptacle does not work. Circuit breaker is OFF.
Item plugged in is defective.
Turn ON the AC circuit breaker.
Try a different item.
Generator makes a “spark knock” or
“pinging” noise.
An occasional light “knocking” or
“pinging” under heavy load is not a cause
for concern. However, if the knocking
or pinging occurs under normal load
at a steady engine speed, the problem
may be with the brand of unleaded fuel
being used.
Switch to a different brand of unleaded
fuel, making sure that the octane rating
is 86 or higher. If problem continues,
contact your nearest authorized service
center.
If problem persists after trying the above solutions, contact your nearest authorized service center for assistance.
The following symptoms may indicate problems that will affect the emissions level of the unit:
nHard starting or stalling after starting
nRough idle
nMisfiring or backfiring under load
nAfterburning (backfiring)
nBlack exhaust smoke or high fuel consumption
If you encounter any of these symptoms, have the unit inspected and repaired by the nearest authorized service center.

15

WIRING DIAGRAM - HGN1200B


TTI warrants this outdoor product to be free of defects in material and workmanship for 24 months from the date of purchase
by the original purchaser, subject to the limitations below. Please keep your invoice as proof of date of purchase.
               This
warranty does not cover damage or liability caused by / due to misuse, abuse, accidental or intentional acts by user,
improper handling, unreasonable use, negligence, failure by end user to follow operating procedures outlined in the user’s
manual, attempted repair by non-qualied professional, unauthorized repair, modication, or use of accessories and/or
attachments not specically recommended by authorized party. Please see your local dealer for list of authorized service
centers in your area.
This warranty does not cover belts, brushes, bags, bulbs or any part which ordinary wear and tear results in required
replacement during warranty period. This warranty does not cover transportation cost or consumable items such as fuses
and batteries.
This limited warranty is void if the product’s original identication (trade mark, serial number, etc.) markings have been defaced,
altered or removed or if product is not purchased from an authorized reseller or if product is sold AS IS and / or WITH ALL
FAULTS.
Where permitted, the provisions of this limited warranty are in lieu of any other written warranty, whether express or implied,
written or oral, including any warranty of MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO
EVENT SHALL WE BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES. OUR
MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.


Technical documents are kept by Homelite Far East Co., Ltd. 24/F, 388 Castle Peak Road, Tsuen Wan, N.T., Hong Kong.
Declared in 09/2008 by Homelite Far East Co., Ltd.
The gures quoted are emission levels and are not necessarily safe working levels. Whilst there is a correlation between
the emission and exposure levels, this cannot be used reliably to determine whether or not further precautions are required.
Factors that inuence the actual level of exposure of work-force include the characteristics of the work room, the other
sources of noise, etc. i.e. the number of machines and other adjacent processes, and the length of time for which an
operator is exposed to the noise. Also the permissible exposure level can vary from country. This information, however, will
enable the user of the machine to make a better evaluation of the hazard and risk.
