Gas Cultivator
Model No. UT60526
REPAIR SHEET
(All Versions)

2
HOMELITE GAS CULTIVATOR – MODEL NO. UT60526
FIGURE A
26
21
20
8
24
22
22
10
13
44
19
6
3
18
5
4
1
19
17
18
10
48
47
11
9
43
15
23
46
45
49
40
7
14
16
41
25
2
28 32
33
39
42
31
37
38
36
35
27
12
29
30
34

3
HOMELITE GAS CULTIVATOR – MODEL NO. UT60526
30 660934002 Screw (M5 x 60 mm T.F.) ....................................... 1
31 638566001 Clutch Drum .......................................................... 1
32 678187002 Clip ........................................................................ 1
33 519811001 Plate Adapter ........................................................ 1
34 660466003 Screw (M5 x 40 mm T.F.) ....................................... 3
35 308236002 Wheel Assembly (6 in. Dia.)................................... 2
36 638635001 Cotter Pin .............................................................. 2
37 638017002 Washer .................................................................. 2
38 310260001 Frame Assembly ................................................... 1
39 661606001 Screw (M5 x 19 mm Pan Hd.) ............................... 3
40 760679001 Switch ................................................................... 1
41 660973014 Bolt (M8 x 25 mm Hex Hd).................................... 1
42 678355002 Hex Nut (M8) ......................................................... 2
43 950119010 Foot Warning Label............................................... 1
44 941484003 Starting Label........................................................ 1
45 940654088 Combustion Warning Label................................... 1
46 941484004 Model Label .......................................................... 1
47 940654082 Warning Label ....................................................... 1
48 941484001 Icon Warning ......................................................... 1
49 941485007 Hang Tag ............................................................... 1
NOT SHOWN:
50 310266001 Airbox Cover ........................................................ 1
51 901688001 Filter ...................................................................... 1
52 570367001 Airbox Seal............................................................ 1
53 310816001 Fuel Cap................................................................ 1
54 870174001 * Spark Plug (Champion RCJ-6Y)............................ 1
987000551 Operator’s Manual................................................. 1
987000571 Replacement Parts List......................................... 1
5-25-10
(REV:04)
1 220029010 Gear Box Assembly .............................................. 1
2 620888001 Drive Shaft............................................................. 1
3 308693001 Tine A, Outer Right................................................ 1
4 308693002 Tine B, Inner Right................................................. 1
5 308693003 Tine C, Inner Left................................................... 1
6 308693004 Tine D, Outer Left.................................................. 1
7 638717001 Lower Handle ........................................................ 1
8 308629002 Upper Handle Assembly ....................................... 1
9 310263001 Front Handle.......................................................... 1
10 661527001 Carriage Bolt (M8 x 60 mm) .................................. 2
11 660669001 Screw (8-16 x 1/2 in.) ............................................ 1
12 638660001 Ball Bearing (6003zz)............................................. 1
13 660643001 Bolt (1/4-20 x 1.5 in.)............................................. 4
14 690696001 Washer (Curved).................................................... 4
15 678013001 Washer .................................................................. 4
16 310261001 Tine Shield Assembly............................................ 1
17 308213005 Wheel/Drag Stake Assembly
(Incl. Key No. 35-38).............................................. 1
18 900755001 Felt Washer ........................................................... 2
19 638001004 Clevis Pin .............................................................. 2
20 678135001 E-Clip .................................................................... 1
21 518256002 Trigger ................................................................... 1
22 519790003 Knob (M8).............................................................. 3
23 308330004 Throttle Cable Assembly (Incl. Key No. 40)........... 1
24 519807001 Cable Clip.............................................................. 1
25 678132001 Lock Nut (1/4-20) .................................................. 8
26 638132001 Pin ......................................................................... 1
27 660643002 Bolt (1/4-20 x 1 in.)................................................ 4
28 519794001 Engine Adapter...................................................... 1
29 660970010 Screw (M4 x 95 mm) ............................................. 1
PARTS LIST (FIGURE A)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY

4
HOMELITE GAS CULTIVATOR – MODEL NO. UT60526
FIGURE B
12
3
45
6
7
8
9
10 11
12 13 14
15
16
17
18
19
20
21
22
31
32
33
34
35
36
37
38
39
43
42
41
23
24
27
45
44
28
29 30
25
26
40

5
HOMELITE GAS CULTIVATOR – MODEL NO. UT60526
1 300960002 Clutch Assembly ................................................... 1
2 638090001 Washer .................................................................. 1
3 638284002 Spacer Tube .......................................................... 1
4 660970003 Screw (M4 x 20 mm) ............................................. 1
5 690969001 Washer .................................................................. 1
6 660970001 Screw (M4 x 16 mm) ............................................. 2
7 308889006 Lower Housing w/Starter Assembly
(Inc. Key Nos. 8-14)............................................... 1
8 308981009 Lower Housing Assembly ..................................... 1
9 900849010 Starter Rope.......................................................... 1
10 638033001 Spring & Container Assembly ............................... 1
11 511731001 Grip ....................................................................... 1
12 518501001 Starter Pulley......................................................... 1
13 638389001 Pulley Retainer ...................................................... 3
14 660967001 Screw (M4 x 14 mm) ............................................. 3
15 650017001 Washer .................................................................. 1
16 308811001 Flywheel Assembly................................................ 1
17 309960013 Short Block Assembly........................................... 1
18 901550001 Crankcase Cover Gasket ...................................... 1
19 638337003 Crankcase Cover................................................... 1
20 660925003 Screw (M4 x 12 mm) ............................................. 6
21 518726004 Top Housing .......................................................... 1
22 660466001 Screw (M4 x 18 mm) ............................................. 4
23 901551001 Intake Gasket ........................................................ 1
24 518497001 Heat Dam .............................................................. 1
25 901552001 Carburetor Gasket................................................. 1
26 518690001 Baffle Plate ............................................................ 1
27 308054032 Carburetor ............................................................. 1
28 519792001 Air Box Base ......................................................... 1
29 570367001 Air Box Seal........................................................... 1
30 660454007 Muffler Bolt............................................................ 2
31 901452004 Muffler Gasket....................................................... 1
32 308990018 Muffler Assembly................................................... 1
33 638442002 Heat Shield............................................................ 1
34 660638003 Screw (10-24 x 2-1/8 in.)....................................... 2
35 309264003 Ignition Module ..................................................... 1
36 660968001 Screw (M4 x 19 mm) ............................................. 2
37 308863028 Lead Wire Assembly ............................................. 1
38 310264002 Fuel Tank with Cap Assembly ............................... 1
39 638576004 Flat Washer ........................................................... 1
40 660493001 Screw (M5 x 17 mm) ............................................. 1
41 660970008 Screw (M4 x 19 mm, Shoulder) UT60526 Only).... 2
660970002 Screw (M4 x 16 mm, Shoulder)............................. 2
42 638588001 Bracket (UT60526 Only) ........................................ 2
43 570256001 Bumper (UT60526 Only)........................................ 2
44 561635001 Primer Bulb ........................................................... 1
45 518824001 Choke Lever .......................................................... 1
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
