Honeywell Home TH6220WF2006 User manual

Package Includes:
• T6 Pro Smart Thermostat
• UWP™ Mounting System
• Decorative Cover Plate
• Screws and anchors
• Thermostat literature
T6 Pro Smart
Programmable Thermostat
TH6220WF2006
TH6320WF2003
Professional Install
Guide
PM
Menu FanMode
Fan
Auto
Mode
Heat
Wake Away HomeSleep
Following Schedule
Search for local rebates: HoneywellHome.com/Rebates
33-00392-09
Read before installing
Compatibility
• Compatible with most heating, cooling, and heat pump systems
• Required: 24 VAC power (“C” wire)
• Input: 24 V ~ @ 60 Hz, 1 A
• Does not work with electric baseboard heat (120V-240V)
• Does not work with millivolt systems
• Android or iOS smartphone or tablet
Customer assistance
WEB customer.resideo.com
PHONE [phone]

2
UWP Mounting System installation
1. Open package to find the UWP.
See Figure 1.
2. Position the UWP on the wall. Level and
mark hole positions. See Figure 2.
Drill holes at marked positions, and then
lightly tap supplied wall anchors into wall
using a hammer.
‒If your box contains red anchors, drill
7/32” (5.6 mm) holes for drywall.
If your box contains yellow anchors, drill
3/16” (4.8 mm) holes for drywall.
3. Pull the door open and insert wires
through wiring hole of the UWP. See
Figure 3.
4. Place the UWP over the wall anchors.
Insert and tighten mounting screws supplied with
the UWP. Do not overtighten. Tighten until the UWP
no longer moves. Close the door. See Figure 4.
1
2
3
4
Optional Decorative Cover Plate installation
Use the Optional Cover Plate when you need to
cover paint gap from the old thermostat.
There are different cover plates depending on
when the thermostat was manufactured.
One plate is square, the other is rectangular.
1. Separate the cover plate from the mounting
plate. See Figure 1.
2. Mount the mounting plate to the wall using
any of the screw holes. Insert and tighten
mounting screws supplied with the cover
plate. Do not overtighten. Make sure the
mounting plate is level. See Figure 2a
(square) or 2b (rectangle).
3. Attach the UWP by hanging it on the top
hook of the mounting plate and then
snapping the bottom of the UWP in place.
See Figure 3.
4. Snap the Cover Plate onto the mounting
plate. See Figure 4.
If there are no existing wall anchors, you can fol-
low the same instructions for the UWP Mounting
System installation to install the cover plate.
Just use 2 screws rather than 3.
Use 3x supplied screws
(#8 1-1/2" [38 mm] for
red anchors and #6 1-1/2
[38 mm] for yellow anchors)
1
2
3 4
1 2
3
4
1
4
3
2a 2b

3
Terminal designations
Conventional Systems Heat pump systems
Terminal Description Terminal Description
S/S Input for a wired indoor,
outdoor sensor S/S Input for a wired indoor, outdoor sensor
Y Compressor Stage 1 Y Compressor Stage 1
Y2 Compressor Stage 2 Y2 Compressor Stage 2
G Fan Relay G Fan Relay
C
24VAC Common wire from
secondary side of cooling
transformer (if 2 transformers)
C
24VAC Common wire from
secondary side of cooling
transformer
K* Connect to K on C-wire
adaptor K* Connect to K on C-wire adaptor
U/U** Relay for ventilation U/U** Relay for ventilation
A L/A Connect to compressor
monitor
W Heat Stage 1 O/B Changeover valve for heat
pumps
W2 Heat Stage 2 Aux Backup Heat
E Emergency Heat
R 24 VAC Heating transformer R 24 VAC Heating transformer
Rc 24 VAC Cooling transformer Rc 24 VAC Cooling transformer
* The THP9045A1098 C-wire adaptor is used on heat/cool systems when you only have four wires at
the thermostat and you need a fifth wire for a common wire. Use the K terminal in place of the Y and
G terminals on conventional or heat pump systems to provide control of the fan and the compressor
through a single wire—the unused wire then becomes your common wire. See THP9045 instructions
for more information.
** Ventilation is not available on all models. When the U slider is in the down position (2 wires), the U
contacts are a dry set of contacts. If your ventilation system requires 24 volts, move the U slider to the
up position (1 wire). Lower U terminal is internally jumped to the Rc terminal. In this application, you
would hook up one wire from your damper to the upper U terminal and the other to the common side of
the transformer.
Wiring UWP
Push down on the tabs to put the wires into the inner holes of their corresponding terminals
on the UWP (one wire per terminal) until they are firmly in place. Gently tug on the wires to
verify they are secure. If you need to release the wires again, push down the terminal tabs
on the sides of the UWP.
This wiring is just an example,
yours may vary.

4
Setting Slider Tabs
Set R Slider Tab, see Figure 9.
• Use built-in jumper (R Slider Tab)
to differentiate between one or two
transformer systems.
• If there is only one R wire, and it is
connected to the R, Rc, or RH terminal
on the old thermostat, set the slider to
the up position (1 wire).
• If there is one wire connected to the R
terminal and one wire connected to the
Rc terminal, set the slider to the down
position (2 wires).
Set U Slider Tab, see Figure 10.
• Use built-in jumper (U Slider Tab) of
relay to wire ventilation. Please note
that ventilation is not supported on all
models.
• When the U Slider Tab is in the down
position (2 wires) the U contacts are a
dry set of contacts.
• If the ventilator is powered by the
cooling transformer, move the jumper
switch to the up position (1 wire). With
this switch set to 1 wire, the lower U
terminal is internally jumped to the Rc
terminal. In this application, hook up
one wire from the vent damper to the U
terminal and the other to the common
side of the cooling system transformer.
10
9

5
Wiring
1H/1C System (1 transformer)
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor
C24VAC common
WHeat relay
GFan relay
NOTES:
1 Available wiring configurations differ by product models/product numbers.
2 Use 18-to 22-gauge thermostat wire. Shielded cable is not required.
3 Set the R Slider Tab on the UWP to the up position (1 wire) for 1 transformer
systems or the down position (2 wires) for 2 transformer systems. See "Setting
Slider Tabs" on page 4.
4 Set the U Slider Tab to the up position (1 wire) for non-powered ventilation or the
down position (2 wires) for powered ventilation. See "Setting Slider Tabs" on page
4.
Conventional systems
1H/1C System (2 transformers)
RPower (heating transformer)
Rc Power (cooling transformer)
YCompressor contactor
C24 VAC common from cooling transformer
WHeat relay
GFan relay
2H/2C System (1 transformer)
RPower
Rc [R+Rc joined by Slider Tab]
Y Compressor contactor (stage 1)
C24VAC common
WHeat relay (stage 1)
GFan relay
W2 Heat relay (stage 2)
Y2 Compressor contactor (stage 2)
Hot Water Relay Panel
RPower
Rc [R+Rc joined by Slider Tab]
WHeat Relay
C24VAC common
Heat-only System with Fan
RPower
Rc [R+Rc joined by Slider Tab]
C24VAC common
WHeat relay
GFan relay
Cool-only System with Fan
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor
C24VAC common
GFan relay
NOTE: If the panel does not provide 24 volts AC
at R and C, set the slider to down position and
wire a separate transformer to Rc and C.

6
Heat pumps systems
1H/1C Heat Pump System
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor
C24VAC common
O/B Changeover valve
GFan relay
2H/1C Heat Pump System
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor
C24VAC common
O/B Changeover valve
GFan relay
Aux Auxiliary heat*
EEmergency heat relay*
LHeat pump fault input
NOTE: If dual fuel, TH6320WF2003
model needed.
2H/2C Heat Pump System
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor (stage 1)
C24VAC common
O/B Changeover valve
GFan relay
Y2 Compressor contactor (stage 2)
LHeat pump fault input
3H/2C Heat Pump System
RPower
Rc [R+Rc joined by Slider Tab]
YCompressor contactor (stage 1)
C24VAC common
O/B Changeover valve
GFan relay
Aux Auxiliary heat*
EEmergency heat relay*
Y2 Compressor contactor (stage 2)
LHeat pump fault input
NOTE: TH6320WF2003 only.
* If you do not have separate wires for the Aux and E terminals, connect the wire to the Aux terminal.
NOTE: Do NOT use Wfor heat pump applications. Auxiliary heat must wire to AUX or E.

7
Ventilation systems
NOTE: Ventilation is not available on all models.
Mounting thermostat
1 Push excess wire back into the wall
opening.
2 Close the UWP door. It should remain
closed without bulging.
3 Align the UWP with the thermostat, and
push gently until the thermostat snaps in
place.
4 If needed, gently pull to remove the
thermostat from the UWP.
5 Search for local rebates:
Your thermostat may now be eligible for
local rebates. Search for offers in your area
at HoneywellHome.com/Rebates
Using U Slider Tab
Wired to ERV/HRV whole
house ventilator with internal
power supply.
Wired to fresh air damper
powered by furnace
transformer.
11 12

8
Installer setup – using the thermostat
Setup using the thermostat
• After the thermostat has powered up,
touch START SETUP on the thermostat.
You’ll be asked if you want to perform
setup via app. Touch No.
• Touch or to toggle between
Installer Set Up (ISU) options.
• Touch Edit or touch text area, and
then touch or to edit default
setup option.
• Touch Done or touch text area to
confirm the setting or press Cancel.
• Touch or to continue to setup
another ISU option.
NOTES:
• To see a list of all setup parameters,
go to "Installer setup options (ISU) –
advanced menu" on page 11. The
thermostat displays the ISU name
and the ISU number.
• To finish setup and save your settings,
scroll to the Finish screen at the end of
the ISU list.
• Touch Select or touch text area to
save changes and exit, or touch to
return to initial setup screen.
Cancel
Done
Edit ISU
ISU #
ISU option blinking
Cancels ISU option
selection, go back
to view ISU
Arrow buttons used
to scroll through ISU
options
Saves selected ISU
option moves on to
the next ISU screen
Edit
View ISU
ISU #ISU name and
option (scrolling)
Arrow buttons used
to scroll through
ISUs
Select
No Yes
Back

9
Advanced menu options
Device Setup
This is used to access the device ISU setting.
Screen Lock
The thermostat touch screen can be set to lock
fully or partially.
Rater View
A read only place to view all the ventilation
settings.
System Test
Test the heating and cooling system.
Range Stop (Temperature)
Set the minimum, maximum, cool and heat
temperature set points.
Installer setup – using the Honeywell Home app
Setup using the app
Download the Honeywell Home app from App Store or
Google Play to use a hidden PRO installation feature
that will allow you to configure the thermostat and
personally invite your customer to connect to the
installed thermostat at the same time.
Enter Contractor Mode
To enter Contractor Mode, press and hold the Honeywell Home logo for 5 seconds.
Then tap Confirm to begin using Contractor Mode. Follow steps to personally invite
your customer to connect their Honeywell Home App.
Installer setup – advanced menu
To access the advanced menu, press and hold the Menu button for 5 seconds.
Touch or to go through the options in the advanced menu.
AM
Menu FanMode
Fan
Auto
Mode
Heat
Wake Away Home Sleep
Following Schedule
Reset
Access all reset options on the
thermostat. This is the only place
to access factory reset.

10
Auto Chg. On
AM
Heat On
Menu FanMode
Fan
Auto
Mode
Heat
Wake Away Home Sleep
Following Schedule Recovery
Key features
The screen will wake up by pressing the center area of the displayed temperature.
The screen will stay lit for 45 seconds. Brightness can be adjusted in the Menu.
System status
information
Cool On, Heat On
Emergency Heat On,
Recovery, or Auto
Changeover On.
Schedule information
Following time-based
or location-based
temperature control.
Desired Temperature
Displays the current
desired temperature
setting.
Indoor Temperature
Displays the current
indoor temperature.
Mode
Select system mode:
Auto/Heat/Cool/Off/EM
Heat (Emergency Heat).
Connection status
information
Status of Wi-Fi
Connection: Connected,
Disconnected, or Wi-Fi
is Off.
Messaging
Shows device setup
options, menu options,
reminders, schedule
overrides.
Schedule period
Shows schedule period:
Wake/Away/Home/
Sleep.
Fan
Select Fan mode Auto/
On/Circulate.
Time, ISU #, or
Alert #
Menu
Touch to display
options. Start here
to set a program
schedule.
Note: Long press of
Menu button for 5
seconds to access
Advanced Menu
options.

11
Installer setup options (ISU) – advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 120 Schedule Type No Schedule
MO-SU = Every day the same MO-FR, SA, SU = 5-1-1 schedule MO-FR, SA-SU = 5-2 schedule Each Day = Every day individual
You can change default MO-FR, SA-SU schedule here. To edit periods during days, temperature setpoints, or to turn Schedule On/Off, from the home screen, go to MENU/SCHEDULE.
125 Temp Scale Fahrenheit, Celsius
130 Outdoor Temp No, Wired, Internet Select outdoor temperature data source. This ISU automatically defaults to Internet when registered to
Honeywell Home app and no wired outdoor sensor is selected. We recommend using a wired outdoor sensor connected to the “S” terminals on the UWP. (See "Wiring" on page 5.) An outdoor temperature is required to set the following ISUs: ISU 355 Compressor Lockout, ISU 356 Aux Heat Lockout, ISU 1013 Low Outdoor Temperature Ventilation Lockout, ISU 1014 High Outdoor Temperature Ventilation Lockout, and ISU 1015 High Outdoor Dew Point Ventilation Lockout.
200 System Type Conventional Forced Air
Heat Pump Boiler Cool Only
Basic selection of system your thermostat will control.
205 Equipment Type Conventional Forced Air Heat:
Standard Gas (STD GAS), High Efficiency Gas (EFF GAS), Oil, Electric, Fan Coil* Heat Pump: Air To Air, Geothermal Boiler: Hot Water, Steam
This option selects the equipment type your thermostat will control. Note: This option is NOT displayed if ISU 200 is set to Cool Only. *Fan coil setting is for a residential application with a hot water coil in an air-handler.
218 Reversing Valve 0/B on Cool, 0/B on Heat This ISU is only displayed if ISU 200 is set to Heat Pump. Select whether reversing valve O/B should energize
on cool or on heat
220 Cool Stages
(#200=Conv./ 200=HP)
0, 1, 2 Only 1 compressor stage available on TH6220WF model if configured for heat pump.
221 Heat Stages/Aux/E
Stages (#200=Conv./ 200=HP)
Heat Stages: 0, 1, 2
AUX/E Stages: 0, 1
Maximum of 2 Heat Stages for conventional systems. Maximum of 1 Aux/E stages for heat pump systems.
230 Fan Control Equipment, Thermostat This ISU is only displayed if ISU 205 is set to Electric Forced Air or Fan Coil. 253 Aux/E Control Both Aux/E, Either Aux/E Set “EITHER AUX/E” if you want to setup and control Auxiliary and Emergency heating separately . This ISU is
only displayed if ISU 200 is set to Heat Pump AND if ISU 221 Aux/E stages = 1. Note: This ISU available on TH6320 model only.
Note: ISU options available may vary upon the thermostat model and equipment setup.
Table 1.

12
Installer setup options (ISU)– advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 255 Aux Heat Type Electric, Gas/Oil (or Fossil Forced Air) This ISU is displayed only if ISU 200 is set to heat pump AND if ISU 221 Aux/E heat stages = 1.
Note: Options of this ISU may vary depending on the model of the thermostat.
256 EM Heat Type Electric, Gas/Oil (or Fossil Forced Air) This ISU is displayed only if ISU 200 is set to Heat Pump AND if ISU 221 Aux/E heat stages = 1 AND if ISU 253
is set to run AUX/E heat separately. Note: This ISU may not be available at all on some models.
260 Fossil Kit Control Thermostat, External (Fossil Fuel Kit Controls Backup
Heat)
This ISU is displayed only if ISU 200 is set to Heat Pump AND if ISU 221 Aux/E heat stages = 1, AND if ISU 256 is set to Gas/Oil. Note: This ISU available on TH6320 model only.
300 Auto Changeover On, Off OFF: The user must select heating or cooling as needed to maintain the desired
indoor temperature. ON (Automatic): On (enabled) Allows user to select Auto Changeover as one of the system modes from the home screen. In auto mode, the thermostat can control either heating or cooling to maintain the desired indoor temperature.
303 Auto Differential 0 °F to 5 °F or 0.0 °C to 2.5 °C Differential is the minimum number of degrees rise or fall required during off cycle to switch from the last
active mode (heat or cool) to the opposite mode when the thermostat is in auto-changeover. Differential is NOT deadband. The deadband temperature between when heating (or cooling) cycles on and cycles off to maintain setpoint is not adjustable. The thermostat uses an algorithm that fixes deadband at 0 °F (0 ° C).
305 High Cool Stage
Finish
Yes, No This ISU is only displayed when the thermostat is set to 2 cool stages. When set to YES, this feature keeps the
higher stage of the cooling equipment running until the desired setpoint is reached.
306 High Heat Stage
Finish
Yes, No This ISU is only displayed when the thermostat is set to 2 or more heat stages. When set to YES, this feature
keeps the higher stage of the heating equipment running until the desired setpoint is reached.
340 Aux Heat Droop 0 = Comfort; 2 °F to 15 °F from setpoint (in 1 °F incre-
ments) or 1.0 °C to 7.5 °C from setpoint (in 0.5 °C increments)
Aux heat droop can be set on heat pump systems with an auxiliary heat stage. The Comfort setting is NOT available for Dual Fuel systems. Default setting is 0 °F (0 ° C) (Comfort) for Electric while 2 °F (1.0 °C) for Gas/ Oil. The indoor temperature must drop to the selected droop setting before the thermostat will turn Aux Heat on. For example, if Aux Heat is set to 2 °F (1.0 °C), the indoor temperature must be 2 ° F (1.0 ° C) away from the setpoint before Aux Heat turns on. When set to Comfort, the thermostat will use Aux Heat as needed to keep the indoor temperature within 1 °F (0.5 ° C) degree of the setpoint.
350 Up Stage Timer Aux
Heat
Off, 30, 45, 60, 75, 90 minutes 2, 3, 4, 5, 6, 8, 10, 12, 14, 16 hours
The Auxiliary Heat Upstage Timer starts when the highest stage of the previous heating equipment type turns on. Auxiliary heat will be used (if needed) when the timer expires. This ISU is only displayed when ISU 340 (AUX Heat Droop) is set to 2 °F (1.0 °C) or higher.
Table 2.

13
Installer setup options (ISU)– advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 355 Balance Point
(Compressor Lockout)
Off, 5 °F to 60 °F (in 5 °F increments) or -15.0 °C to 15.5 °C (in 2.5 °C or 3.0 °C increments)
Compressor Lockout requires an outdoor temperature. Set Compressor Lockout to the temperature below which it is inefficient to run the heat pump. When outside temperature is below this setting, thermostat will lockout heat pump and run Aux Heat only. This ISU is only displayed if ISU 130 = Wired or Internet, ISU 200 is set to Heat Pump, ISU 221 Aux/E stages = 1, AND ISU 260 is set to Thermostat. We recommend using a wired remote sensor as an outdoor temperature source. Default is 40 °F (4.4 °C) if ISU 205 Heating Equipment is Air to Air Heat Pump and ISU 255 Aux Heat Type is Gas/Oil. Default is Off if ISU 205 Heating Equipment is Air to Air Heat Pump and ISU 255 Aux Heat Type is Electric. Default is Off if ISU 205 Heating Equipment is Geothermal. Compressor Lockout is optional for any type of heat pump (Air to Air Heat Pump, Geothermal Heat Pump).
356 Aux Heat Lock Out
(Aux Heat Outdoor Lockout)
Off, 5 °F to 65 °F (in 5 °F increments) or -15.0 °C to 18.5 °C (in 2.5 °C or 3.0 °C increments)
Aux Heat Lockout requires an outdoor temperature. Set Aux Heat Lockout to optimize energy bills and to not allow it to run the more expensive Aux Heat source above certain outdoor temperature limit. This ISU is only displayed if ISU 200 is set to Heat Pump, AND ISU 260 is set to Thermostat control AND if ISU 221 Aux/E stages = 1.
365 Cool 1 CPH (Cooling
cycle rate stage 1)
1 - 6 CPH (3 CPH) This ISU is only displayed when Cool /Compressor Stages is set to 1 or more stages. Cycle rate limits the maxi-
mum number of times the system can cycle in a 1 hour period measured at a 50% load. For example, when set to 3 CPH, at a 50% load, the most the system will cycle is 3 times per hour (10 minutes on, 10 minutes off). The system cycles less often when load conditions are less than or greater than a 50% load.
366 Cool 2 CPH (Cooling
cycle rate stage 2)
1 - 6 CPH (3 CPH) This ISU is only displayed when Cool /Compressor Stages is set to 2.
370 Heat 1 CPH (Heating
cycle rate stage 1)
1 - 12 CPH This ISU is only displayed when Heat Stages is set to 1 stage or more stages. Cycle rate limits the maximum
number of times the system can cycle in a 1 hour period measured at a 50% load. For example, when set to 3 CPH, at a 50% load, the most the system will cycle is 3 times per hour (10 minutes on, 10 minutes off). The system cycles less often when load conditions are less than or greater than a 50% load. The recommended (default) cycle rate settings are below for each heating equipment type: Standard Efficiency Gas Forced Air = 5 CPH; High Efficiency Gas Forced Air = 3 CPH; Oil Forced Air = 5 CPH; Electric Forced Air = 9 CPH; Fan Coil = 3 CPH; Hot Water Radiant Heat = 3 CPH; Steam = 1 CPH.
371 Heat 2 CPH (Heating
cycle rate stage 2)
1 - 12 CPH This ISU is only displayed when Heat Stages is set to 2 stages. The recommended (default) cycle rate settings
are below for each heating equipment type: Standard Efficiency Gas Forced Air = 5 CPH; High Efficiency Gas Forced Air = 3 CPH; Oil Forced Air = 5 CPH; Electric Forced Air = 9 CPH; Fan Coil = 3 CPH; Hot Water Radiant Heat = 3 CPH; Steam = 1 CPH.
375 Aux Heat CPH
(Heating cycle rate Auxiliary Heat)
1 - 12 CPH This ISU is only displayed when ISU 200 = Heat Pump and ISU 221=1. It is only displayed when Auxiliary Heat
is configured. The recommended cycle rate settings are below for each heating equipment type: Standard Efficiency Gas Forced Air = 5 CPH; High Efficiency Gas Forced Air = 3 CPH; Oil Forced Air = 5 CPH; Electric Forced Air = 9 CPH.
Table 3.

14
Installer setup options (ISU)– advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 378 EM Heat CPH
(Heating cycle rate Emergency Heat)
1 - 12 CPH This ISU is only displayed when Emergency Heat is configured and ISU 253: Aux/E Terminal Control is set to
control Aux and E heat Independently. The recommended cycle rate settings are below for each heating equip- ment type: Standard Efficiency Gas Forced Air = 5 CPH; High Efficiency Gas Forced Air = 3 CPH; Oil Forced Air = 5 CPH; Electric Forced Air = 9 CPH.
387 Compressor
Protection
Off, 1 - 5 minutes The thermostat has a built in compressor protection (minimum off timer) that prevents the compressor from
restarting too early after a shutdown. The minimum-off timer is activated after the compressor turns off. If there is a call during the minimum-off timer, the thermostat shows “Wait” in the display. This ISU is displayed if ISU 220 is set to at least 1 stage.
390 Ext Fan Run Time
in Cool
Off, 30, 60, 90 seconds 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 minutes
After the call for cooling ends, the thermostat keeps the fan on for the selected amount of time for increased efficiency. This may reintroduce humidity into the living space. This ISU is displayed if ISU 220 is set to at least 1 stage.
391 Ext Fan Run Time
in Heat
Off, 30, 60, 90 seconds 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 minutes
After the call for heating ends, the thermostat keeps the fan on for the selected amount of time for increased efficiency. This ISU is displayed if ISU 230 is set to Thermostat Controls Fan.
425 Adaptive Recovery On, Off Adaptive Intelligent Recovery (AIR) is a comfort setting. Heating or cooling equipment will turn on earlier,
ensuring the indoor temperature will match the setpoint at the scheduled time.
429 Max Cool Temperature from Min. Cool Temp. to 99 °F or to 37.0 °C (90 °F or 32 °C) The user cannot set the cooling temperature above this level. 430 Min Cool Temperature from 50 °F or 10.0 °C to Max. Cool Temp. (50 °F or 10 °C) The user cannot set the cooling temperature below this level. 431 Max Heat Temperature from Min. Heat Temp. to 90 °F or to 32.0 °C (90 °F or 32 °C) The user cannot set the heating temperature above this level. 432 Min Heat Temperature from 40 °F or 4.4 °C to Max. Heat Temp. (50 °F or 10 °C) The user cannot set the heating temperature below this level. 500 Indoor Sensor Yes, No Set this ISU when you want to wire a remote indoor sensor to the “S” terminals on the UWP - see "Wiring" on
page 5. This ISU is only displayed only if ISU 130 is set to NO wired outdoor sensor configured
515 Sensor type 10k, 20k Choose resistance type of wired indoor sensor. This ISU is only displayed when indoor sensor is configured -
ISU 500.
520 Temperature Control Thermostat, Wired, Average This ISU is only displayed when indoor sensor is configured - ISU 500. You can choose what temperature
source to be used or you can ask thermostat to use both thermostat and remote sensors for higher accuracy of measurement.
702 Air Filters 0- 2 This ISU refers to the number of air filters in the system. 711 Air Filter 1 Reminder Off
10, 20, 30, 45, 60, 90, 120, 150 Run Time Days 30, 45, 60, 75 Days 3, 4, 5, 6, 9, 12, 15 Months
Choose either calendar or equipment run time-based reminder.
712 Air Filter 2 Reminder Off
10, 20, 30, 45, 60, 90, 120, 150 Run Time Days 30, 45, 60, 75 Days 3, 4, 5, 6, 9, 12, 15 Months
Choose either calendar or equipment run time-based reminder.
Table 4.

15
Installer setup options (ISU)– advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 810 Hum Pad Reminder Off
6, 12 Calendar Months
921 Dehum Filter
Reminder
Off 30, 60 Calendar Days 3 - 12 Calendar Months (in 1 month increments)
1000 Vent Type None, ERV/HRV, Passive, Fresh Air Damper None: The thermostat does not control ventilation.
ERV/HRV: The thermostat controls an Energy Recovery Ventilator or Heat Recovery Ventilator for ventila- tion. Passive (Fan Only): The thermostat turns on the fan for ventilation. When set to passive fan, the thermo-
stat does not control a damper or ventilator. The passive ventilation/passive fan setting only runs the indoor blower fan. This setting does not open a damper or run a ventilator. To use this setting for ventilation, the home would need to be set-up with a pipe from outdoors into the return duct that is either permanently open or has a damper that automatically opens whenever the blower fan is on. Note: Some models only offer the passive fan setting.
1005 Vent Method ASHRAE 2010, ASHRAE 2013, Percent On Time Note: Options of this ISU may vary depending on the model of the thermostat.
1006 Vent Fan Control Thermostat, Equipment Thermostat: The thermostat turns on the ventilation and the fan when ventilation is needed.
Equipment: Ventilation equipment controls the blower fan.
1007 Bedrooms 1 - 6 (2) This ISU is only displayed when ISU 1005 Ventilation Method is set to ASHRAE 2010 or 2013. 1008 Home Size 1000 Sq. Ft. - 5000 Sq. Ft. (1000 Sq. Ft.) This ISU is only displayed when ISU 1005 Ventilation Method is set to ASHRAE 2010 or 2013. 1009 Vent Rate 30CFM - 350CFM (in 5CFM increments) (150CFM) This ISU is only displayed when ISU 1005 Ventilation Method is set to ASHRAE 2010 or 2013. 1011 Vent Percent On Time 10% - 100% (30%) The thermostat operates ventilation equipment based on a percentage entered in the installer setup (ISU
1012). For example, if Percent on Time is set to 50%, the ventilation equipment will run at random times dur- ing a 1 hour period until it reaches a 50% run time (approximately 30 minutes). This ISU is only displayed if ISU 1005 is set to Percent On Time.
1012 Vent Priority Lockouts, ASHRAE Lockouts are Priority: The thermostat places a priority on lockouts versus the ASHRAE ventilation
standard. The thermostat will not run ventilation during the following lockout conditions (if configured), unless you manually call for ventilation: Lockout Ventilation during Outdoor Conditions (ISU 1013, 1014 and 1015). Lockout Ventilation during “Sleep” program periods. Note: This option is set by the user on the Ventilation screen in the Menu. ASHRAE is Priority: ASHRAE requires additional ventilation following a long off cycle. The thermostat meets the ASHRAE ventilation standard by running additional ventilation when outdoor conditions are favor- able. If ASHRAE cannot be met when outdoor conditions are favorable, the thermostat will override the outdoor lockouts and run ventilation. When using this option, it is recommended that you increase the rate (CFM) of the ventilation equipment to meet the ASHRAE ventilation standard in a shorter run time. The ability to lockout ventilation during the “Sleep” is not an option when you select ASHRAE is Priority.
Table 5.

16
Installer setup options (ISU)– advanced menu
# ISU ISU Name ISU Options (defaults in bold) Notes 1013 Low Outdoor Temp
Vent Lockout
Off, -20 °F to -40 °F (in 5 °F increments) or -28.0 °C to -4.0 °C (in 2.0 °C increments)
ISU 130 must be set to Wired or Internet. This ISU is only displayed when ISU 1000 Ventilation Type is set to ERV / HRV or Fresh Air Damper.
1014 High Outdoor Temp
Vent Lockout
Off, 80 °F to 110 °F (in 5 °F increments) or 26 °C to 44 °C (in 2 °C increments)
ISU 130 must be set to Wired or Internet. This ISU is only displayed when ISU 1000 Ventilation Type is set to ERV / HRV or Fresh Air Damper.
1015 High Outdoor
Dewpoint Vent Lockout
Off, 65 °F to 85 °F (in 5 °F increments) or 18 °C to 30 °C (in 2 °C increments)
ISU 130 must be set to Internet. This ISU is only displayed if ISU 1000 Ventilation Type is set to ERV/ HRV or Fresh Air Damper.
1017 Vent Core Reminder Off, 3, 6, 9, 12 months This ISU is displayed only if ISU 1000 is set to ERV/HRV. 1018 Vent Filter Reminder Off, 3, 6, 9, 12 months 1100 UV Devices 0- 2 Some systems may have two UV devices, one for the A-Coil and another for Air Treatment. A replacement
reminder can be setup for each one separately.
1105 UV Bulb 1 Reminder Off, 6, 12, 24 months 1106 UV Bulb 2 Reminder Off, 6, 12, 24 months 1401 Idle Brightness 0= Off, 0 - 5 Adjust brightness of an inactive backlight (idle screen) from default 0 (backlight off) to 5 (maximum
brightness).
1410 Clock Format 12 hour, 24 hour
1415 Daylight Saving On, Off Set to Off in areas that do not follow Daylight Saving Time. 1420 Temp Offset Off, -3 °F to 3 °F (in 1 °F increments) or
-1.5 °C to 1.5 °C (in 0.5 °C increments)
0 °F (0 °C) - No difference in displayed temperature and the actual room temperature. The thermostat can display up to 3 °F (1.5 C) lower or higher than the actual measured temperature.
Table 6.

17
Performing a system test
You can test the system setup in ADVANCED
MENU under SYSTEM TEST option.
1 Press and hold Menu on the thermostat for
5 seconds to access ADVANCED MENU
options.
2 Touch or to go to SYSTEM TEST.
3 Touch Select or touch text area.
4 Touch or to select system test type.
Touch Select or touch text area.
5 For the heat test and cool test, use or
to activate each stage of the equipment.
For the fan test, use or to turn the fan
on and off.
NOTE: The clock is used as a timer while the
stages are running. The Heat On and Cool On
indicators are displayed when the system test
is running.
Viewing equipment status
You can see the status of thermostat-
controlled equipment in the Menu under the
EQMT STATUS option.
1 Touch Menu on your thermostat.
2 Touch or to go to EQMT STATUS.
Touch Select or touch text area.
3 Touch or to view statuses of all the
equipment the thermostat is controlling.
Depending on what feature the thermostat
supports or how it was installed, the
Equipment Status screen reports data for
the following systems:
• Heating and cooling
• Fan
• Ventilation (available on certain
models only)
Heat On
Heat
Done
Done
Back Select
Back Select
Back Select

18
Screen is blank • Check circuit breaker and reset if necessary.
• Make sure power switch at heating and cooling system is on.
• Make sure furnace door is closed securely.
Screen is difficult
to read
• Change screen brightness in thermostat Menu. Increase brightness intensity for
inactive backlight of the thermostat screen (max. is level 5).
Heating or
cooling system
does not respond
• Touch Mode to set system to Heat. Make sure the temperature is set higher than
the Inside temperature.
• Touch Mode to set system to Cool. Make sure the temperature is set lower than
the Inside temperature.
• Check circuit breaker and reset if necessary.
• Make sure power switch at heating & cooling system is on.
• Make sure furnace door is closed securely.
Heat runs with
cooling
• Verify there is not a wire attached to W for heat pump systems. See wiring on
pages 5-6.
Troubleshooting
Number Alert/Reminder Definition
164 Heat Pump Needs
Service
Heat pump needs service. Contact dealer to diagnose
and service heat pump.
168 Wi-Fi Radio Error Wireless features are not available. Try removing the
thermostat from the wallplate or power cycle at breaker
for 1 minute. If the code is still shown, please contact
dealer to replace the thermostat.
170 Internal Memory Error The memory of the thermostat has encountered an
error. Please contact dealer for assistance.
171 Set the Date and Time Set the date and time on your thermostat. The date and
time are required for certain features to operate, like the
program schedule.
173 Thermostat
Temperature Sensor
Error
The sensor of the thermostat has encountered an error.
Please contact dealer to replace the Thermostat.
175 AC Power Resumed AC power resumed to thermostat after power loss.
177 Indoor Temperature
Sensor Error
Wired indoor temperature sensor is not connected
or there is a wiring short. Please contact dealer for
assistance.
178 Outdoor Temperature
Sensor Error
Wired outdoor temperature sensor is not connected
or there is a wiring short. Please contact dealer for
assistance.
Alerts and reminders are displayed via the alert symbol and alert number in the clock
area on the home screen. You can read more information about active alerts, snooze
or dismiss non-critical alerts in Menu/Alerts.
Alerts and reminders

19
Alerts and reminders
Number Alert/Reminder Definition
181 Replace Air Filter (1) Replace air filter (1). Reset the timer by touching
the "dismiss" button on thermostat screen after it is
replaced.
182 Replace Air Filter (2) Replace air filter (2). Reset the timer by touching
the "dismiss" button on thermostat screen after it is
replaced.
183 Clean Humidifier Tank
and Replace Water
Filter
Clean humidifier tank and replace the water filter, or
contact dealer to do this for you. Reset the timer by
touching the “dismiss” button on the thermostat screen
after it is replaced.
184 Replace Humidifier
Pad
Replace humidifier pad. Reset the timer by touching
the “dismiss” button on the thermostat screen after it is
replaced.
185 Replace Dehumidifier
Filter
Replace the dehumidifier filter. Reset the timer by
touching "dismiss" button on thermostat screen after it
is replaced.
186 Clean Ventilator Core Clean ventilator core. Reset the timer by touching
the “dismiss” button on thermostat screen after it is
replaced.
187 Clean or Replace
Ventilator Filter
Clean or replace ventilator filter. Reset the timer by
touching the “dismiss” button on thermostat screen
after it is replaced.
188 Replace UV Bulb (1) Replace UV Bulb (1). Reset the timer by touching
the "dismiss" button on thermostat screen after it is
replaced.
189 Replace UV Bulb (2) Replace UV Bulb (2). Reset the timer by touching
the "dismiss" button on thermostat screen after it is
replaced.
210 Register Online For
Outdoor Temperature
Online registration is required to receive outdoor
temperature from the Internet. Outdoor temperature
is needed for your current system setup. Download the
Honeywell Home app to register your thermostat.
388 Register Online for
Remote Access and
Outdoor Temperature
Online registration is required for remote access and
outdoor temperature. Download the Honeywell Home
app to register your thermostat.
399 No Internet The connection to the Internet has been lost. Please
check your network settings.
400 No Wi-Fi Signal The Wi-Fi signal has been lost. Please wait for the
thermostat to reconnect or select a new Wi-Fi network.
Follow steps in the Honeywell Home app
508 Wi-Fi Not Configured Please download the Honeywell Home app and follow
the steps to connect thermostat to your Wi-Fi network.

Wi-Fi® is a registered trademark of
Wi-Fi Alliance®
www.resideo.com
© 2020 Resideo Technologies, Inc. All rights reserved.
The Honeywell Home trademark is used under license from Honeywell International, Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates.
Resideo Technologies, Inc.
1985 Douglas Drive North, Golden Valley, MN 55422
1-800-633-3991
33-00392—09 M.S. Rev. 04-20 | Printed in United States
CAUTION: MERCURY NOTICE
If this product is replacing a control that contains mercury in a sealed tube, do not place the old control in the trash.
Contact your local waste management authority for instructions regarding recycling and proper disposal.
CAUTION: EQUIPMENT DAMAGE HAZARD
Compressor protection is bypassed during testing. To prevent equipment damage, avoid cycling the compressor
quickly.
CAUTION: ELECTRICAL HAZARD
Can cause electrical shock or equipment damage. Disconnect power before beginning installation.
Temperature Ranges
Heat: 40 °F to 90 °F (4.5 °C to 32.0 °C)
Cool: 50 °F to 99 °F (10.0 °C to 37.0 °C)
Operating Ambient Temperature
37 °F to 102 °F (2.8 °C to 38.9 °C)
Shipping Temperature
-20 °F to 120 °F (-28.9 °C to 48.9 °C)
Operating Relative Humidity
5% to 90% (non-condensing)
Physical Dimensions in inches (mm) (H x W x D)
T6 Pro Smart Thermostat (TH6320WF2003):
4-5/64 x 4-5/64 x 1-1/16 (104 x 104 x 27)
T6 Pro Smart Thermostat (TH6220WF2006):
4-5/64 x 4-5/64 x 1-1/16 (104 x 104 x 27)
Specifications
Electrical Ratings
Terminal Voltage
(50Hz/60Hz)
Running
Current
WHeating 20 Vac-30 Vac 0.02 A-1.0 A
(Powerpile) 750 mV DC 100 mA DC
W2 (Aux) Heating 20 Vac-30 Vac 0.02 A-1.0 A
EEmergency Heat 20 Vac-30 Vac 0.02 A-0.5 A
YCompressor Stage 1 20 Vac-30 Vac 0.02 A-1.0 A
Y2 Compressor Stage 2 20 Vac-30 Vac 0.02 A-1.0 A
GFan 20 Vac-30 Vac 0.02 A-0.5 A
O/B Changeover 20 Vac-30 Vac 0.02 A-0.5 A
L/A Input 20 Vac-30 Vac 0.02 A-0.5 A
U20 Vac-30 Vac 0.02 A-0.5 A
Power Consumption
Backlight On: 1.48VA
Backlight Off: 0.88VA
Regulatory information
FCC REGULATIONS
47 CFR § 15.19 (a)(3)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
47 CFR § 15.21 (USA only)
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
47 CFR § 15.105 (b)
See https://customer.resideo.com/en-US/support/residential/codes-
and-standards/FCC15105/Pages/default.aspx for additional FCC
information for this product.
IC REGULATIONS
RSS-GEN
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may
cause undesired operation of the device.
The operation of this equipment is subject to the following two conditions:
(1) this equipment or device may not cause harmful interference, and (2) this
equipment or device must accept any interference, including interference that
may cause undesired operation.
5-year limited warranty
For Warranty information go to
http://customer.resideo.com
