Honeywell Acuix IP Series User manual

Document 800-02460 – Rev A – 08/08
Installation Guide
ACUIX™IP Series
Rugged Housing and Dome

2
Revisions
Issue Date Revisions
A 08/08 New document

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 3
08/08
Explanation of Symbols
FCC Compliance Statement
Information to the User: This equipment has been tested and found to comply with the limits for a Class B digital
device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference. For example, try orienting or
relocating the receiving antenna, increasing the separation between the equipment and receiver, or connecting the
equipment to an outlet on a different circuit.
WARNING! The exclamation point in a red octagon is a WARNING. Failure to take or
avoid a specific action could result in physical harm to a person or
irreparable damage to equipment.
Caution The lightning flash with arrowhead symbol within an equilateral triangle alerts
the user to the presence of uninsulated dangerous voltage within the
enclosure of the product that may be of sufficient magnitude to constitute a
risk of electric shock to the person.
Caution The exclamation point in a yellow equilateral triangle is a Caution. Failure to
take or avoid a specified action could result in loss of data or damage to
equipment and may contain important operating and maintenance servicing
information.

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 4
08/08
Canadian Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Manufacturer’s Declaration of Conformance
North America
The equipment supplied with this guide conforms to UL60065, CAN/CSA C22.2 No. 60065:03.
Europe
The manufacturer declares that the equipment supplied with this guide is compliant with the essential protection
requirements of the EMC directive 2004/108/EC and the Low Voltage Directive LVD 2006/95/EC, conforming to the
requirements of standards EN 55022 for emissions, EN 50130-4 for immunity, and EN 60065 for Electrical Equipment
safety.
Australia
This Class B digital apparatus complies with Australian Communications Authority (ACA) C-Tick standards, supplier
number N219.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Users of the product are responsible for checking and complying with all federal, state and
local laws and statutes concerning the monitoring and recording of video and audio signals.
Honeywell Video Systems shall not be held responsible for the use of this product in violation
of current laws and statutes.

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 5
08/08
Warnings and Cautions
Read the following cautions and warnings prior to installation and use of this product.
Important Safety Instructions
BEFORE OPERATING OR INSTALLING THE UNIT, READ AND FOLLOW ALL INSTRUCTIONS.
AFTER INSTALLATION, retain the safety and operating instructions for future reference
1. HEED WARNINGS - Adhere to all warnings on the unit and in the operating instructions.
All installations and servicing must be performed by qualified technical personnel and
must be in accordance with all national and local mechanical and electric codes.
To prevent injury, this apparatus must be securely attached to the wall/ceiling in
accordance with the installation instructions.
To prevent damage to the interface board, follow standard industry precautions for
electrostatic discharge sensitive devices.
Consider using a UPS source to ensure satisfactory performance.
Using replacement parts or accessories other than the original manufacturers may invalidate the
warranty.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 6
08/08
2. INSTALLATION
• Install in accordance with the manufacturer’s instructions.
• Installation and servicing should be performed only by qualified and experienced technicians to conform to
all local codes and to maintain your warranty.
• Do not install the unit in an extremely hot or humid location, or in a place subject to dust or mechanical
vibration. The unit is not designed to be waterproof. Exposure to rain or water may damage the unit.
• Any wall or ceiling mounting of the product should follow the manufacturer’s instructions and use a
mounting kit approved or recommended by the manufacturer.
3. POWER SOURCES - This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supplied to your facility, consult your product dealer or
local power company.
4. HEAT - Situate away from items that produce heat or are heat sources such as radiators, heat registers, stoves,
or other products (including amplifiers).
5. MOUNTING SYSTEM - Use only with a mounting system recommended by the manufacturer, or sold with the
product.
6. ATTACHMENTS - Do not use attachments not recommended by the product manufacturer as they may result in
the risk of fire, electric shock, or injury to persons.
7. ACCESSORIES - Only use accessories specified by the manufacturer.
8. CLEANING - Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
9. SERVICING - Do not attempt to service this unit yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
10. REPLACEMENT PARTS - When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
Warranty and Service
Subject to the terms and conditions listed on the Product Warranty Card, during the warranty period Honeywell will
repair or replace, at its sole option, free of charge, any defective products returned prepaid. In the U.S.A. and Canada,
call 1.800.796.2288.
In the event you have a problem with any Honeywell Video product, please call Customer Service for assistance or to
request a Return Merchandise Authorization (RMA) number. Be sure to have the model and serial number, and the
nature of the problem available for the technical service representative. Prior authorization must be obtained for all
returns, exchanges, or credits. Items shipped to Honeywell without a clearly identified Return Merchandise
Authorization (RMA) number may be refused.
WEEE (Waste Electrical and Electronic Equipment). Correct disposal of this product
(applicable in the European Union and other European countries with separate collection
systems). This product should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 7
08/08
Contents
About Using This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Related Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring and Power Cautions and Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring and Power Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Recommended Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Step 1: Connect the Field and Terminal Block Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
About the Terminal Blocks (J1, J4 and J6) and Switch (SW1). . . . . . . . . . . . . . . . . . 13
Connecting the Wiring to the Housing Interface Board . . . . . . . . . . . . . . . . . . . . . 14
Step 2: Set Switches on the Scan Assembly Circuit Board . . . . . . . . . . . . . . . . . . . . . . . . 17
About the SW5 and SW6 DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting DIP Switches SW5 and SW6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 3: Mount the Rugged Housing Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Step 4: Mount the Housing to the Ceiling or Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Step 5: Install the Scan Assembly into the Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Step 6: Install the Lower Dome onto the Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Step 7: Install the ACUIX IP Software and Configure the Dome . . . . . . . . . . . . . . . . . . . . . . 22

8
Figures and Tables
Figures
Figure 1-1 ACUIX IP Housing Interface Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 1-2 J6 Terminal Block Alarm Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 1-3 Ferrite Bead Installation Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 1-4 Rugged Housing Cable Access Hole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 1-5 (A) PCB Location (B) DIP Switch Location (C) DIP Switch Example . . . . . . . . . . . . . 18
Figure 1-6 Rugged Housing Bracket Hole Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 1-7 Insert the Scan Assembly into the Housing. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 1-8 Rugged Housing - Lower Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tables
Table 1-1 Related Documents and External Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Table 1-2 ACUIX IP Recommended Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 1-3 Wire Gauge Required for Maximum Distance to Dome . . . . . . . . . . . . . . . . . . . . 12
Table 1-4 Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 1-5 ACUIX IP Terminal Strip Pins and Functions (J1 and J6) . . . . . . . . . . . . . . . . . . . 15
Table 1-6 ACUIX IP DIP Switch Settings (SW5 and SW6) . . . . . . . . . . . . . . . . . . . . . . . . 17

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 9
08/08
ACUIX IP Rugged Housing and Dome
About Using This Guide
This guide has instructions to install the rugged dome with the ACUIX IP dome.
ACUIX Terminology
Dome: the complete installed product
including the housing, mounting
bracket, lower dome, and the scan
assembly.
Scan Assembly: the combination of
firmware, electrical and mechanical
components including the camera. The
scan assembly is installed into the
housing and enclosed by a lower dome.
The scan assembly is a component of a
dome.
•Camera: the particular model
camera purchased. The camera is
a component of the scan
assembly.
Housing: the in-ceiling, indoor or
outdoor pendant and surface mount
upper enclosure. Housing is a hardware
component of the dome.
•Mount: the hardware used to mount the housing to the applicable surface (for
example, a ceiling or wall). The mount is a hardware component used with a
specific type of housing.
Lower Dome: the clear or colored enclosure that covers the scan assembly and attaches
to the housing. With the rugged dome, it also includes the trim ring. The lower dome is a
hardware component of the dome.
Housing
Mounting bracket
Lower dome
Trim ring
Scan assembly
The ACUIX Dome is comprised of:

10
ACUIX IP Rugged Housing and Dome
Rugged Housing and Dome Model Numbers
For other model numbers and information on the Honeywell Video web site, see Related
Documents on page 11.
Housing
• HDH00RD00: Rugged, white, digital
Lower Dome
• HDB00R0CW: Rugged, clear lower dome, white trim ring
• HDB00R0SW: Rugged, smoked lower dome, white trim ring
Installation Overview
A complete ACUIX IP system installation is a multi-step process and depends on
individual hardware configurations. Some of the information to complete the installation
may be in the manual associated with the hardware being installed. For related
documentation and the link to the Honeywell Video web site, see Related Documents on
page 11.
A typical installation has the following steps. The order may be slightly different for each
type of installation.
1. Connect the field and terminal block wiring on the housing interface board, page 13.
Also refer to the ACUIX IP High Speed Dome User Guide for more information.
2. Set the DIP switches on the scan assembly circuit board, page 17. Also refer to the
ACUIX IP High Speed Dome User Guide for more information.
3. Mount the bracket to the ceiling, wall or other surface, page 19.
4. Mount the housing, page 20.
5. Install the scan assembly into the premounted housing, page 21.
6. Install the lower dome to cover the scan assembly and enclose the housing,
page 22.
7. Refer to the ACUIX IP High Speed Dome User Guide to complete these steps:
• Install the Honeywell IP Utility and ACUIX Web-Client software, configure the
network and discover devices.
• If applicable, continue setting up and configuring other custom settings
including privacy zones and preset tours.
• If required or applicable, proceed to user configurations based on other
hardware, for example, a DVR.
For all outdoor installations, joints, bolts, and screws in the mount must be properly
sealed to prevent moisture from entering the housing.

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 11
08/08
Related Documents
Table 1-1 Related Documents and External Links
Wiring and Power Cautions and Requirements
Wiring and Power Cautions
Document title or link Part number
ACUIX IP High Speed Digital Dome User Guide 800-00336
ACUIX IP Quick Installation Guide 800-00020
Honeywell Video online literature
http://www.honeywellvideo.com/support/literature/index.html
Access PDF versions of data sheets, quick references, installation and user guides,
specifications, product notices and other useful material
• To make good wire contact and ensure the wire does not short to adjacent
wires, fully insert the wire in the hole on the terminal strip.
• A good earth ground must be connected at J1, pin 2. Surge suppression is not
provided if the unit is not connected to a good earth ground.
• Ensure there are no bare wires touching or faulty operation may occur.
• Ensure the cabling does not interfere with the rotation of the pan and tilt
assembly.
• To maintain 24 VAC ± 10% at each dome, the proper wire size for the distance
and the number of domes must be determined.
• For CE compliance, the power supply must be connected to a CE approved
240V UPS (uninterruptible power supply). See Table 1-4 for a list of the power
supplies which must be used to meet FCC and UL requirements.

12
ACUIX IP Rugged Housing and Dome
Recommended Wiring
Power Requirements
The outdoor ACUIX requires a 24 VAC power supply @ 2.6 A, measured at the dome.
Refer to Table 1-3 and Table 1-4 to determine the wire sizes and maximum distances for
one power source for one ACUIX and the required power supplies for CE compliance.
Table 1-2 ACUIX IP Recommended Wiring
Type Recommended Cable Maximum Distance
Ethernet CAT5 or above 328 feet (100 meters)
Power 18 AWG 2-Conductor, Vinyl
Jacket
See gauge chart for each
unit
Alarm 20 gauge unshielded twisted
pair
10,000 feet (348 meters)
Table 1-3 Wire Gauge Required for Maximum Distance to Dome
AWG 24 VAC Camera plus Heater & Blower (2.6 A)
22 29 feet (8.8 meters)
20 45 feet (13.7 meters)
18 72 feet (21.9 meters)
16 115 feet (35.1 meters)
14 183 feet (55.8 meters)
12 291 feet (88.7 meters)
Table 1-4 Power Supplies
Model Number Description
HPTV2404 4 Output, 24 VAC, 4A
HPTV2404CB 4 Output, 24 VAC, 4A, PTC
HPTV2404WP 4 Output, 24 VAC, 4A. NEMA4X Weatherproof enclosure
HPTV2404WP-2 4 Output, 24 VAC, 8A, NEMA4X Weatherproof enclosure
HPTV2401S Single Output, 24 VAC, 8A, Indoor (includes power and video
surge suppression)
HPTV2401Z Single Output, 24 VAC, 8A, Indoor (includes power, video, and
data surge suppression)
HPTV2401WPS Single Output, 24 VAC, 8A, Weatherproof (includes power and
video surge suppression)
HPTV2401WPZ Single Output, 24 VAC, 8A, Weatherproof (includes power, video,
and data surge suppression)

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 13
08/08
Step 1: Connect the Field and Terminal Block Wiring
Note Each housing has a MAC address label attached to it that can be used to
differentiate ACUIX IP domes that are connected on the same network. For
more details, refer to the ACUIX IP High Speed Dome User Guide.
About the Terminal Blocks (J1, J4 and J6) and Switch (SW1)
The field wiring is connected to the interface board (see Figure 1-1) located at the top of
the ACUIX rugged housing. There are three terminal blocks (J1, J4 and J6) and one
switch (SW4) that require setting or wiring connections.
Terminal Blocks J1, J4 and J6
• J1: With power supply pins. See Table 1-5.
• J4: The RJ-45 Ethernet network connector is used to connect the ACUIX IP dome to
your network with a network (10Base-T, 100Base-TX) cable. See Table 1-5.
• J6: With alarm activation pins (see Figure 1-2).
Restore to Factory Defaults Switch SW1
You can restore the configurations, compression settings and password factory defaults
using switch (SW1) on the housing interface board. When this switch is held down for
three seconds and LED2 starts to blink (see Figure 1-1), the dome reboots and all the
defaults are restored.
The wiring installation must be performed by qualified technical personnel and
must be in accordance with all national and local mechanical and electrical
codes.
To prevent damage to the interface board, follow standard industry precautions
for electrostatic discharge sensitive devices.

14
ACUIX IP Rugged Housing and Dome
Figure 1-1 ACUIX IP Housing Interface Board Layout
Connecting the Wiring to the Housing Interface Board
Note The terminal strips accept 16–30 AWG wire. If larger or smaller field-run wire
is required, a 16–30 AWG wire must be spliced onto the field wire for insertion
into the terminal strip.
1. Route the field wiring (power, alarm and CAT5 network cable):
a. Through the field wiring access hole in the housing, and
Wiring access hole
SW1
LED2
J4
J1
J6
Restore to factory
defaults
Terminal block with
alarm activation pins
Ethernet network
connector
Terminal block with
power supply pins
Blinks to indicate
the dome is
rebooting

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 15
08/08
b. Through the access hole in the interface board installed in the housing.
2. Remove the plug-in terminal blocks on terminal strips J1 and J6. See Figure 1-1.
3. To set up the alarm input terminal block:
a. On terminal strip J6, connect a twisted-pair cable from each peripheral alarm
contact to each input at the alarm number terminal and the alarm common
terminal.
b. Refer to the ACUIX IP High Speed Dome User Manual to configure the alarms.
Note that the common terminals are doubled up, as shown in Figure 1-2.
Note The alarm input is a dry contact between the alarm input and common and
that they can be configured as normally open (NO) of normally closed (NC).
4. Loosen the screws on the terminal strip.
5. Install the 24 VAC power wires and alarm wires on the correct positions on terminal
strips J1 and J6. See Table 1-5.
6. Tighten the screw on the terminal strip to secure the wire.
7. Plug the terminal strips into the respective connectors on the interface board.
8. Secure the wires from the terminal strip together with a cable tie.
9. Feed extra wire and cable up through the hole in the housing and route it so that it
doesn't interfere with the pan and tilt unit when it is inserted.
10. Connect an RJ45 network cable to the J4 terminal block Ethernet connection.
11. After connecting the power cabling, install the ferrite bead clamp (shipped with the
housing) on the cable as close to the dome as possible, preferably within 24 inches
(609 mm). See Figure 1-3. Note that the image displayed is for pendant housing.
For rugged housing the wiring access hole extends from the side of the housing as
in Figure 1-4.
Note A ferrite bead is a passive electric component used to suppress high frequency
noise in electronic circuits.
Table 1-5 ACUIX IP Terminal Strip Pins and Functions (J1 and J6)
Terminal Strip J1 Function
Pin 1 24 VAC (AC)
Pin 2 Earth Ground
Pin 3 24 VAC (AC)
Terminal Strip J6 Function
Pin 1 Alarm 1 (A1)
Pin 2 Alarm Common (CM)
Pin 3 Alarm 2 (A2)
Pin 4 Alarm 3 (A3)
Pin 5 Alarm Common (CM)
Pin 6 Alarm 4 (A4)

16
ACUIX IP Rugged Housing and Dome
Figure 1-2 J6 Terminal Block Alarm Connection
Figure 1-3 Ferrite Bead Installation Location
Figure 1-4 Rugged Housing Cable Access Hole
Alarm 1
Alarm 2 Alarm 3
Alarm 4
Ferrite bead clamp
installed on the cable
extending from the
housing
Mounting bracket
Pull wiring through
access hole and
attach the ferrite
bead clamp

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 17
08/08
Step 2: Set Switches on the Scan Assembly Circuit Board
About the SW5 and SW6 DIP Switch Settings
The scan assembly printed circuit board (PCB) has DIP switches SW5 and SW6 that
require setting as detailed in Table 1-6 so that the ACUIX IP dome works correctly. Switch
SW5 sets the protocol to IntelliBus and switch SW6 sets the baud rate to 38400 (positions
1 to 4) and No Parity (positions 5 and 6).
Setting DIP Switches SW5 and SW6
• Set the DIP switches on the scan assembly printed circuit board as required for your
system configuration. Use Figure 1-5 and Table 1-6 to help set it correctly.
.
Leave SW5-8 ON. Setting the DIP switch SW5-8 to OFF enables a user to change the
address, protocol, baud rate and parity from the OSD menu (which is not recommended
with most installations).
Table 1-6 ACUIX IP DIP Switch Settings (SW5 and SW6)
Switch Position
12345678
SW5 - Set for IntelliBus Protocol
OFF OFF OFF OFF OFF OFF OFF ON
SW6 - Set Baud Rate to 38400 and No Parity
OFF ON ON OFF OFF OFF OFF OFF

18
ACUIX IP Rugged Housing and Dome
Figure 1-5 (A) PCB Location (B) DIP Switch Location (C) DIP Switch Example
SW5 Baud rate
and parity
SW6 IntelliBus
protocol
Printed circuit board location
(PCB) on top of the scan assembly
Scan assembly
(including camera)
ON
OFF
Positions 1, 2, 4, 6, and 7 set to OFF
Positions 3, 5, and 8 set to ON
Example of a DIP Switch
Setting
DIP Switch Location on the
PCB
A
B
C

ACUIX IP Rugged Housing and Dome Installation Guide
Document 800-02460 Rev A 19
08/08
Step 3: Mount the Rugged Housing Bracket
Note The mounting bracket can be at any angle from 0° to 90° with respect to the
housing. The housing must be positioned horizontally and parallel to the
floor.
1. Select the location for the housing.
• Each ACUIX requires a 24 VAC ± 10% power source measured at the housing.
• Ensure a 24 VAC @ 2.6A power source is available.
• For maximum wiring distances to the dome, see Table 1-2 on page 12.
2. Prepare the mounting surface by pre-drilling four holes to attach the mounting
bracket to the ceiling or wall. See Figure 1-6 for hole dimensions.
3. Secure a safety cable to a
building support structure.
Attach the safety cable
(from the building support
structure) to the mounting
bracket by:
a. Routing the safety
around the mounting
bracket, then
b. Through a hole in the
side of the mounting
bracket and then
c. Through the other side
of the looping sleeve,
and
d. Crimp the looping sleeve to secure the safety cable.
Mounting bracket
One of two bolts that
attach bracket to housing

20
ACUIX IP Rugged Housing and Dome
Figure 1-6 Rugged Housing Bracket Hole Dimensions
Step 4: Mount the Housing to the Ceiling or Wall
Note With outdoor installations or a wet indoor area, the conduit and conduit fitting
must be water tight.
1. Install a 0.75"(19 mm) conduit fitting in the hole on the housing.
2. Place the supplied gasket between the hole in the housing and the conduit fitting to
prevent leakage. Tighten the conduit nut.
3. Secure the housing to the mounting bracket, previously installed to a ceiling
support structure or wall support structure using the appropriate hardware for the
mounting surface.
0.21 in (5.3 mm)
diameter
0.31 in (8 mm)
diameter
3.9 in (100 mm)
3.5 in (89 mm)
2.6 in (67 mm)
2.6 in (67 mm)
3.5 in (89 mm)
4.1 in (105 mm)
6.5 in (165 mm)
