Honeywell HCC-960 Series User manual

OPERATION MANUAL
WDR / DNR
High Resolution Color Camera
HCC-960/965 Series
READ AND KEEP THIS OPERATION MANUAL
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance(servicing) instructions in the literature
accompanying the appliance.

2
CAUTION : TO REDUCE THE RISK OF
ELECTRIC SHOCK.
DO NOT REMOVE COVER(OR BACK).
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PRERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Explanation of Graphical Symbols.
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance(Servicing) Instructions
in the literature accompanying the appliance.

3
Important Safety Instruction
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, hear registers, stoves, or other apparatus
(including amplifiers) that produce hear.
9. Do not defeat the safety purpose of the polarized or ground plug: A polarized plug has two blades
with one wider than the other. The wide blade is provided for your safety. When the provided plug
does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plug, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a can is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as p0ower supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture.
16. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, shall
not be placed on the apparatus.

4
CAUTION FOR SAFE OPERATION
1. Water and Moisture
To prevent fire or shock hazard, do not expose this
camera to rain or moisture.
2. Servicing
Do not attempt to disassemble or repair by yourself.
You may be exposed to dangerous voltage or other
hazards.
Note that all servicing is qualified service personnel.
Modifications not approved by manufacturer could
void the user's authority to operate the equipment.
3. Power Sources
To prevent electric shocks and risk of hazards,
do NOT use more than the specified power source.
4. Environment
Do not install too warm or too cold place.
Recommended operation temperature is between
-5℃ and 50℃
5. Sunlight
Do not point the camera at the sun.
CCD can be damaged.
6. Heavy Shock and Vibration
Do not drop the camera or subject it to heavy shock
of vibration.
7. Install on an Unstable Place
Do not place or install this camera on an unstable
place, stand, tripod, bracket or table.
That may cause serious injury to people or damage
to appliance.
8. When operation is incorrect or a malfunction is observed
While operating, if any abnormal condition
(strange sound, smell or smoke) or a malfunction
(no pictures, etc.) is observed, stop using the camera
immediately, turn the power off, then contact your supplier.
9. Cleaning
Turn the power off and wipe off the dirt with a dry soft cloth.
If it is extremely dirty, use furniture cleaner to wipe it off.
To clean the lens, use a blower or lens cleaning tissue.
(available from any camera dealer)
10. Do not shoot any source of bright light.
If the objects contain very bright areas, bright vertical or horizontal
lines may appear on the screen. This is called "smear",
a Phenomenon which often occurs with solid-state pickups,
and is not a malfunction.
11. Damage Requiring service
Unplug the camera from the power source and refer servicing to
qualified service personnel under the following condition:
a. If the power-supply cord or plug is damaged.
b. If the camera has been exposed to rain or water.
c. If liquid has been spilled, or objects have fallen into the camera.
d. If the camera does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualified technician to restore the camera to its normal operation.
e. If the camera has been dropped or the cabinet has been damaged.
f . If the camera exhibits a distinct change in performance.
g. Warranty is not covered in case of natural disaster or wrong
Installation.

5
Contents
1. Features ------------------------------------------------ 6
2. Names & Functions ---------------------------------------- 7
3. Installation ---------------------------------------------- 9
4. Remote Control Connection -------------------------------- 11
5. On Screen Display ---------------------------------------- 12
6. Specifications ------------------------------------------- 20
7. Dimensions --------------------------------------------- 22
Thank you for using this High Resolution Camera with WDR. To get the best
efficiency, read carefully all instructions in this manual before use, and keep this
manual for reference. If you have any problems with this camera, contact your
supplier to service.

1. Features
Honeywell’s HCC-960/965 Series is a high resolution color camera with high sensitivity CCD.
▣ 1/3” Super HAD CCD Ⅱ( NTSC: 520,000 / PAL: 610,000 )
▣ Outstanding BLC implementation with WDR (Wide Dynamic Range) function
▣ High Sensitivity with SENS-UP (max. 512FLD) in the dark
▣ Excellent DNR (Digital Noise Reduction) function (2D-NR, 3D-NR)
▣ PZM (Privacy Zone Masking) of selected views for privacy protection
▣ Digital Zoom function (max. x256)
▣ Adapted adjustable C/CS mount
▣ Excellent signal-to-noise ratio of more than 50dB.
▣ 2-WAY Auto Iris : Both Video iris or DC iris lens can be used.
▣ Auto White Balance : Auto white balance realizes true color reproduction within various
light sources.
▣ OSD Control
▣ Various Protocol for Remote Control (DEFAULT, PELCO, KD6, VCL)
6

2. Names & Functions
C/CS Mount Adaptor
•C-Mount lens : Turn Counterclockwise
•CS-Mount lens : Turn Clockwise
Set Screw
Loosen Locking Ring with a Phillips
screwdriver to adjust Mounting Ring
Lens Connector
Connect Auto Iris Lens plug
7

+-
CONT
DC 12V -+ GND
+-
CONT
DC 12V
AC 24V -+ GND
8
(-) BUTTON
(UP) BUTTON
MENU BUTTON
(DOWN) BUTTON
(+) BUTTON
CAMERA CONTROL
CONNECTOR
VIDEO OUTPUT
LENS TYPE SELECT SWITCH
POWER ON LAMP
DC Lens : with no iris amp.
VSD Lens : with iris amp.
POWER INPUT TERMINAL
HCC-960 Ser.
(DC12V MODEL) HCC-965 Ser. (AC24V/DC12V MODEL)
POWER INPUT
TERMINAL
DC12V AC24V or DC12V

3. Installation
9
3.1 Check all accessories in the enclosed package .
-. HCC-960/965 SET
-. 4-pin connection cable
-. OPERATION MANUAL
-. Auto Iris Lens Plug
3.2 Mounting a Lens
3.2.1 C/CS Mount Lens
①Remove the protective cap in front of the camera.
②Adjust the mount ring whether it is for C or CS.
③Loosen Set Screw with a Phillips screwdriver.
④Turn the mount ring counterclockwise in case of C-Mount Lens.
Turn the mount ring clockwise in case of CS-Mount Lens
3.2.2 Auto Iris Lens
①Remove the cover of the iris lens plug and connect with Lens cable.
VSD LENS PIN CONFIGURATION
12
34①③
④②
1. POWER(12V) 2. NO CONNECTION
3. VIDEO SIGNAL 4. GND
Set the select switch to VSD
DC IRIS LENS PIN CONFIGURATION
12
34①③
④②
1. CONTROL- 2. CONTROL+
3. DRIVE+ 4. DRIVE-
Set the select switch to DC
* For the best condition, read lens manual carefully.

②Connect the Lens plug to the Lens connector (SIDE PART)
③LENS SEL. must be set to ALC MODE on OSD menu
-. In case lens has iris amplifier : Set DC LENS on OSD menu
-. In case lens doesn’t have iris amplifier : Set VSD LENS on OSD menu
④Set the S/W on the REAR of the camera to DC or VSD, too.
☞ When connecting Auto iris lens, make sure to use the connector recommended
by manufacturer. (E4-191, Chuo Musen, Japan)
☞After connecting Auto iris lens you may need to set flange back focus.
3.3 Flange back focus adjustment
3.3.1 In case of fixed focus lens
a. Loosen the Set Screw and set the focus ring of lens to infinity ( ∞ ) .
b. Tune the mount adapter to get a clear picture (distance from camera to object is more
than 23m) and fasten the Set Screw.
3.3.2 In case of zoom lens
a. Loosen the Set Screw and set the lens to the maximum telephoto position.
Then turn the focus ring to focus.
☞ in the case of Auto iris lens, shoot a comparatively dark object or reduce the ambient
light so that the Iris is fully open.
b. Set the lens to its maximum wide angle position, and set the focus.
c. Repeat step a and b, until the difference between focusing position a and b is smallest.
d. When the best focusing point is found, fasten the Set Screw.
3.4 Connection of POWER supply
☞ Power source must be checked from the external power supply before power is on.
☞ Power source capacity :
AC24V, more than 500mA
DC12V, more than 500mA
10

4. Remote Control Connection
11
4.1 RS-485 Connection
Serial Cable
RS485 Converter
3
4
TRx+
TRx-
4P Cable
RS485 Converter
TRx+
TRx-
RS485
Connect to Serial Port
+-
CONT
DC 12V
AC 24V -+ GND
4P Cable
1. Red : NC
2. Blue : NC
3. Yellow : TRx+
4. Black : TRx-

5. On Screen Display
12
SETUP
MENU LENS SEL.
WB CONT.
BLC/WDR CONT.
AGC CONT.
SENS UP
DNR
SPECIAL
SAVE & EXIT
EXIT
ELC> / ALC>
ATW> / INDOORE / OUTDOOR / MANUAL> / AWC LOCK /
AWC AUTO / CRLS
OFF / BLC> / ABLC / WDR>
-6dB / 0dB / … / 30dB / 34dB
OFF / 2FLD / … / 256FLD / 512FLD
OFF / 2D-NR> / 3D-NR>
GENERAL SETUP / PZM SETUP / MD SETUP / COMM. SETUP /
IMAGE SETUP / NIGHTSHOT / FACTORY
5.1 Understanding the On-Screen Display
+-
CONT
DC 12V
AC 24V -+ GND
UP BUTTON
RIGHT BUTTON
LEFT BUTTON
SETUP BUTTON
DOWN BUTTON
①Display SETUP MENU
- Press and hold the MENU button for 2 seconds to display the SETUP MENU.
- Press the UP or DOWN button to select a menu item.
②Move from SETUP MENU to submenu
- Press + or – button to enter the selected submenu.
- Press the UP or DOWN button to select a menu item.
* If you don’t operate any key for 20sec, OSD will appears on the monitor.
<< SETUP MENU >>
LENS SEL. ELC >
WB CONT. ATW >
BLC/WDR CONT. OFF
AGC CONT. 24dB
SENS UP 8FLD
DNR OFF
SPECIAL
SAVE & EXIT
EXIT
<Fig.5-1 SETUP MENU>
5.2
5.3
5.4
5.5
5.6
5.7
5.8

13
5.2 AE mode setting
ELC: for a manual lens
ALC: for an automatic iris lens (DC or VSD)
LENS SEL. ELC> / ALC>
<< AE SETUP >>
CONTROL AUTO
SHUTTER --
LEVEL ADJ. --
BRIGHTNESS 30
SAVE & EXIT
EXIT
5.2.1 ELC mode
①Electronic iris control
AUTO: Iris operates electronic exposure automatically.
MANUAL: Iris is fixed by SHUTTER value.
CONTROL AUTO / MANUAL
②Shutter speed control
This field is not adjustable when the camera is set to
AUTO.
SHUTTER 1/53(1/63)1/120(1/100)1/250
…1/10000
③ELC brightness adjustment
BRIGHTNESS 0 ~ 100
<Fig.5-2 ELC Setting>
<< AE SETUP >>
CONTROL DC
SHUTTER 1/63
LEVEL ADJ. COMPLETED
BRIGHTNESS 40
SAVE & EXIT
EXIT
5.2.2 ALC mode
①Lens type select
CONTROL DC / VSD
②Shutter speed control
This field is not adjustable when the camera is set to
AUTO.
SHUTTER 1/53(1/63)1/120(1/100)1/250
…1/10000
③Lens level adjustment
Adjust level for DC / VSD lens. While it is adjusting,
it displays “ADJUSTING”, after it is completed, it
displays “COMPLETED”.
LEVEL ADJ. ADJUSTING COMPLETED
☞Do not use this adjustment in the dark.
④ALC brightness adjustment
BRIGHTNESS 0 ~ 100
<Fig.5-3 ALC Setting>

14
5.3 White Balance mode setting
ATW (Auto Trace White Balance Mode)
Feedback system that automatically aligns the white
balance (2,500°K ~ 8,000°K).
INOOR
General indoor scenes preset (3200°K)
OUTDOOR
Preset for outside environments and high contrast
scenes where the camera is focused on the darker
(5400°K)
MANUAL
White Balance can be moved on black body curve
manually.
AWC LOCK / AWC AUTO
Performs faster action than ATW mode without an
operating range
CRLS (Color Rolling-less Mode)
Reduces color rolling under the office environments
with fluorescent light.
WB CONT. ATW> INDOOR OUTDOOR
MANUAL> AWC LOCK>
AWC AUTO CRLS
<< WB SETUP >>
CONTROL AUTO
RED 0
BLUE 0
SAVE & EXIT
EXIT
<Fig.5-4 WB Setting>
5.3.1 ATW
In ATW mode, change of RED and BLUE value means
White shift to reddish or bluish.
CONTROL AUTO
RED -127 ~ 127
BLUE -127 ~ 127
5.3.2 MANUAL
CONTROL R/B
RED UP STOP
BLUE DOWN STOP
☞Press + or – button to adjust RED or BLUE gain.
While pressing the button, it displays “UP” or “DOWN”.
5.3.3 AWC LOCK
CONTROL PUSH LOCK
RED --
BLUE --
☞While pressing + or – button, it displays “PUSH”.
☞Submenu can be entered as Fig.5-4 when one of
ATW, MANUAL, AWC LOCK is selected.

15
5.4 Backlight Compensation setting
Prevents the object in the center of the image from
darkening (silhouette effect) when there is excessive
light from behind.
BLC/WDR CONT. OFF BLC> ABLC WDR>
<< BLC SETUP >>
WEIGHT 8
AREA SEL.
SAVE & EXIT
EXIT
5.4.1 BLC
WEIGHT 0 ~ 15
Place the cursor on AREA SEL.,
and press + or – button. It shows Fig.5-6.
BLC AREA SET
0
0 0 0
<Fig.5-5 BLC Setting>
<Fig.5-6 BLC Area Setting>
- : excessive light area
0 : the subject area
5.4.2 WDR
WDR (Wide Dynamic Range) is one of Backlight
Compensation, you can watch not only the object
in the center but also the objects around clearly.
LONG-TERM REF. 0 ~ 255
SHORT-TERM REF. 0 ~ 255
HL COMP. 0 ~ 63
The higher HL COMP. value, you can see the bright
area clearly.
☞LONG-TERM REF. & SHORT-TERM REF. are the
weight of WDR operation. If you change the value
excessively, WDR may not operate.
<< WDR SETUP >>
LONG-TERM REF. 24
SHORT-TERM REF. 62
HL COMP. 0
SAVE & EXIT
EXIT
<Fig.5-7 WDR Setting>

16
5.5 AGC setting
Adjust maximum value of AGC gain
AGC CONT. -6dB 0dB …30dB 34dB
5.6 Sens up setting
Compensate low illumination condition.
Adjust the maximum integration fields to get a brighter
dynamic image. The scene will be slower than when
set to OFF. The larger this field, the greater the noise
of the image. For more dynamic range,
adjust the SENS UP and increase AGC.
SENS UP OFF 2FLD 4FLD …128FLD
256FLD 512FLD
5.7 Digital Noise Reduction setting
The background noise in the low light level increases
automatically as the level of gain changes.
2D-NR or 3D-NR can decrease digital noise.
DNR OFF 2D-NR> 3D-NR>
2D-NR and 3D-NR have a submenu, you can set the
DNR level.
In case of 2D-NR, LEVEL 1 ~ 6
In case of 3D-NR, LEVEL 1 ~ 31
☞The higher the level in 3D-NR,
the greater the level of noise is reduced,
however there will be an increase in the ghost image.
5.8 Special Setup
<< SPECIAL SETUP >>
GENERAL SETUP
PZM SETUP
MD SETUP OFF
COMM. SETUP
IMAGE SETUP
NIGHTSHOT OFF
FACTORY
SAVE & EXIT
RETURN
<Fig.5-8 Special Setup>
5.8.1 General Setup
<< GENERAL SETUP >>
SYNC. 20
BURST 100
SHARPNESS 8
GAMMA 4
SAVE & EXIT
RETURN
<Fig.5-9 General Setup>
①Sync. signal level setting
SYNC. 0 ~ 50
②Burst signal level setting
BURST 0 ~ 255
③Sharpness level setting
SHARPNESS 0 ~ 15
④Gamma setting
GAMMA 0 ~ 8

17
5.8.2 Privacy Zone Masking setting
PZM (Privacy Zone Masking) is to hide the selected view
for privacy protection.
<< PZM SETUP >>
ZONE NUMBER 1
DISPLAY OFF
SIZE SET
ALPHA 1
MOSAIC OFF
COLOR BLUE
SAVE & EXIT
RETURN
<Fig.5-10 PZM Setup>
①PZM zone setting
ZONE NUMBER 1 ~ 16
②PZM Display setting
DISPLAY OFF ON
③PZM size setting
Press + or – button to set PZM size and position.
- set the PZM size using direction buttons
(+,-,UP,DOWN)
- press MENU button in order to change the position.
- set the PZM position using direction buttons.
- press the MENU button more than 2 seconds
to exit size and position setting menu.
④PZM alpha blending setting
ALPHA 0 ~ 3
⑤Mosaic function setting
MOSAIC OFF ON
⑥PZM color
COLOR BLUE GREEN YELLOW CYAN
MAGENTA BLACK D.GRAY 
L.GRAY WHITE RED
5.8.3 Motion Detection setting
The camera detects an object's movement by sensing
disparity of outline.
<< MD SETUP >>
AREA SEL.
SENSITIVITY 128
DISPLAY TRACE
BRIGHTNESS 8
SAVE & EXIT
RETURN
<Fig.5-11 MD Setup>
①AREA SEL.
In AREA SEL. menu, you can set zone, function
off/on, frame size.
②Sensitivity setting
If the value is lower, it has higher sensitivity.
SENSITIVITY 0 ~ 255
③Display setting
TRACE: display the trace with small squares when
object’s movement is detected.
FRAME: display the zone when object’s movement
is detected in the zone.
DISPLAY TRACE FRAME
④Brightness setting
BRIGHTNESS 0 ~ 15

18
5.8.3.1 MD area selection
Select AREA SEL. and press + or – button to enter
submenu. It will show as in Fig.5-12.
<< MD ZONE SETUP >>
ZONE 1
FUNCTION OFF
SIZE SET
SAVE & EXIT
RETURN
<Fig.5-12 MD Zone Setup>
①MD Zone setting
This zone is effective when MD DISPLAY is FRAME.
ZONE 1 ~ 4
②Function setting
FUNCTION OFF ON
③MD frame size setting
Press + or – button to set MD frame size and position.
- set the MD frame size using direction buttons
(+,-,UP,DOWN)
- press MENU button in order to change the position.
- set the MD frame position using direction buttons.
- press the MENU button and hold for more than
2 seconds to exit size and position setting menu.
5.8.4 Communication setting
In order to use remote control through RS-485, set the
values properly.
<< COMMUNICATION SETUP >>
CAMERA ID 1
BAUDRATE 9600
PROTOCOL DEFAULT
SAVE & EXIT
RETURN
<Fig.5-13 Comm. Setup>
①Camera ID setting
CAMERA ID 0 ~ 255
②Baudrate setting
BAUDRATE 2400 4800 9600 19200
38400 57600
③Protocol setting
PROTOCOL DEFAULT PELCO KD6 VCL

19
5.8.5 Image setting
Select IMAGE SETUP and press + or – button to enter
submenu. It will show as in Fig.5-14.
<< IMAGE SETUP >>
MIRROR OFF
D.ZOOM OFF
H.RES 6
SAVE & EXIT
RETURN
<Fig.5-14 Image Setup>
①Mirror setting
MIRROR OFF H.MIR V.MIR FLIP
②Digital Zoom setting
To use this function, set D.ZOOM to ON and
exit OSD MENU pressing SAVE & EXIT.
Maximum zoom is up to x256.
UP button: ZOOM IN, DOWN button: ZOOM OUT
D.ZOOM OFF ON
③High Resolution level setting
H.RES OFF 1 …8
<< NIGHTSHOT SETUP >>
DWELL 5
D2N LEVEL 5
N2D LEVEL 5
BURST OFF
COLOR B/W
SAVE & EXIT
RETURN
<Fig.5-15 Nightshot Setup>
5.8.6 Software Day & Night mode setting
The NIGHTSHOT SETUP allows to set the camera
reaction under low light illumination and switch mode
between Day and Night modes.
AUTO – Day and Night modes change by auto
detecting luminance.
ON – Night mode
OFF – Day mode
NIGHTSHOT OFF AUTO> ON
①Dwell time setting
DWELL 1 ~ 30
②Day to Night level setting
D2N LEVEL 0 ~ 10
③Night to Day level setting
N2D LEVEL 0 ~ 10
④Burst signal setting
BURST OFF ON
⑤Color setting
COLOR B/W COLOR
Fig.5-15 is the submenu of NIGHTSHOT AUTO.
5.8.7 Factory Default
All changed settings are returned to shipping condition.
For Initialization, select “FACTORY”
and push + or - button.
☞caution
1. Keep in mind that this mode reset all changed data
back to shipping condition.
2. Some menu such as LENS SEL, CAMERA ID, etc are
not initialized.

6. Specifications
MODEL HCC-960N-VR HCC-960P-VR HCC-965P-VR
Image Pick-up Device 1/3” Sony Super HAD Ⅱ(520,000pixels) 1/3” Sony Super HAD Ⅱ(610,000pixels)
Effective pixels 976H * 494V (480,000pixels) 976H * 582V (570,000pixels)
Scanning system 525 Lines 2:1 Interlace 625 Lines 2:1 Interlace
Sync system Internal
Scanning frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50.0Hz(V)
Horizontal Resolution More than 650 TV Lines
Minimum illumination Less than 0.1lx (F1.2, 50IRE, AGC 34dB)
Less than 0.001lx (F1.2, 50IRE, AGC 34dB, 512FLD)
Electronic Shutter Auto (1/60~100,000sec), Manual (8steps) Auto (1/50~100,000sec), Manual (8steps)
S/N Ratio More than 50dB
AGC -6 ~ 34dB (7steps)
White Balance ATW, INDOOR, OUTDOOR, MANUAL, AWC LOCK, AWC AUTO, CRLS
BLC OFF / BLC / ABLC / WDR
Privacy Zone Masking Max. 16 zones (Alpha, Mosaic, Color)
Digital Noise Reduction OFF / 2D-NR / 3D-NR
Motion Detection Trace / Frame
Day & Night Mode Software Day & Night
Gamma Correction 0 ~ 8 (9steps)
Digital Zoom Max. x256
ALC EE / VSD / DC
Video Output Composite Video Signal 1Vp-p, BNC Output
Camera Control RS-485
Lens Mount C / CS Mount
20
