Honeywell Dolphin 99EXLG Series User manual

Dolphin™99EX
Mobile Computers for Use in Hazardous Locations
Dolphin 99EXLGX-XXXXXXXI
Dolphin 99EXLWX-XXXXXXXI
Dolphin 99EXL0X-XXXXXXXI
with Windows
®
Embedded Handheld 6.5
Quick Start Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases
consult Honeywell to determine whether any such changes have
been made. The information in this publication does not represent
a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material.
This document contains proprietary information that is protected
by copyright. All rights are reserved. No part of this document may
be photocopied, reproduced, or translated into another language
without the prior written consent of HII.
Web Address: www.honeywellaidc.com
Trademarks
Dolphin is a trademark or registered trademark of Hand Held
Products, Inc. in the United States and/or other countries.
Microsoft, Windows, Windows Mobile, Windows Embedded
Handheld, Windows 7, Windows Vista, Windows XP, Windows
Mobile Device Center, ActiveSync, and the Windows logo are
trademarks or registered trademarks of Microsoft Corporation.
TORX is a trademark or registered trademark of Textron Inc.
MicroSD and microSDHC are trademarks or registered
trademarks of SD-3C, LLC in the United States and/or other
countries.
Other product names or marks mentioned in this document may be
trademarks or registered trademarks of other companies and are
the property of their respective owners.
©2012-2013 Honeywell International Inc. All rights reserved.

1
This documentation is only relevant for Dolphin 99EX
models intended for use in potentially explosive
atmospheres (Models 99EXXXX-XXXXXXXI). See
Equipment for Use in Potentially Explosive Atmospheres
(see page 28).
Before you attempt to use, charge, or replace the battery in the
terminal, carefully read all the information under Equipment for
Use in Hazardous Locations (see below).
Out of the Box
Verify that the carton contains the following items:
• Dolphin mobile computer (the terminal)
• Main battery pack
• Quick Start Guide
• I/O Cover
Note: If you ordered accessories for your terminal, verify that they are
also included with the order.
Be sure to keep the original packaging in the event that the
Dolphin terminal should need to be returned for service.
Equipment for Use in Hazardous Locations
Dolphin 99EX models are designed for use with standard
battery pack, part number 99EX-BTSC-2 (Li-poly 3.7V,
11.3 watt hour) and extended battery pack, part number
99EX-BTEC-2 (Li-ion 3.7V, 18.5 watt hour), manufactured
for Honeywell International Inc.
Note: Dolphin 99EX models intended for use in hazardous locations
are identifiable by specific labeling located on the back panel of
the device, see page 5 for label locations.
!

2
Routine operator inspections should occur to check
for possible terminal damage and to ensure the
presence of the I/O cover before using the terminal in
areas known to be hazardous.
The following warnings apply to 99EXXXX-XXXXXXXI
models (refer to see Equipment for Use in Potentially
Explosive Atmospheres on page 28. for agency approval
by country).
Note: Replace only with battery pack model 99EX-BTSC (PN 99EX-
BTSC-2) or 99EX-BTEC (PN 99EX-BTEC-2), manufactured for
Honeywell International Inc.
CAUTION - DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE.
ATTENTION - RISQUE D'EXPLOSION SI LA PILE N'EST PAS
REMPLACEÉ CORRECTEMENT. REMPLACIER
UNIQUEMENT PAR UNE PILE DE TYPE IDENTIQUE OU
ÉQUIVALENT.
WARNING - EXPLOSION HAZARD - BATTERIES MUST
ONLY BE CHANGED IN AN AREA KNOWN TO BE
NON-HAZARDOUS.
AVERTISSEMENT - RISQUE D'EXPLOSION-AFIN D'EVITER
TOUT RISQUE D'EXPLOSION, S'ASSURER QUE
L'EMPLACEMENT EST DESIGNE NON DANGEREUX AVANT
DE CHANGER LA BATTER I E.
Warning: Explosion hazard. Do not disconnect battery unless
the area is known to be free of ignitable concentrations.
Warning: Explosion Hazard. Charge the battery only in an area
known to be non-hazardous.
Warning: Explosion Hazard. Do not replace components unless
power has been switched off or the area is known to be non-
hazardous.
Warning: Substitution of any components may impair suitability.
!
!
!
!
!
!

3
I/O Cover
All 99EX models intended for use in potentially explosive
atmospheres are shipped with an I/O Cover installed over
the I/O connector.
The I/O Cover must be included on all 99EXXXX-XXXXXXXI
models used in hazardous environments to meet compliance
requirements.
Removing the I/O Cover
You should carefully read all warnings starting on page 2
before attempting to remove the I/O cover.
Warning: Explosion Hazard. Do not use external connectors in
areas known to be hazardous.
Warning: Explosion Hazard. Do not use the terminal in areas
known to be hazardous if the I/O cover is damaged, missing or
not properly installed (e.g., missing M2 screws).
Warning: Explosion Hazard. Do not use the terminal in areas
known to be hazardous if the terminal is damaged, for example:
a crack in the display or enclosure, missing keypad buttons or
side buttons, or the terminal battery well seal is missing or
cracked.
!
!
!
I/O Cover
M2 Screws, Qty. 2
!
1
2

4
Front Panel
Note: Your Dolphin model may differ from the models illustrated;
however, the features are standard for all 99EX models unless
otherwise indicated.
Power Key
Front Speaker
Navigation Keys
Microphone
I/O Connector
Note: Dolphin 99EX models intended for use in
potentially explosive atmospheres include an I/O
Cover (shown below). See page 3 for additional
information.
General
Notification
LED
Touch Panel Display
Volume
Button
Right Button
Scan Key
Charge Indicator LED
I/O Cover

5
Back Panel
Left Button
IRDA Port
Battery Door
Stylus Fastener
Hand
Strap
Stylus
Slot
Protective SIM/Memory
Card Door
Rear Speaker
Flashlight/
Camera Flash
Color Camera
Image/Scan Engine
Window
BatteryWell
Battery Door Release
T6 TORX®
Screw
Hand Strap
Hook
Label Areas
BatteryWell
Seal

6
Available Keyboards
1
SCAN
VOL
PG
TAB
ESC
SEND END
ENT
☼
3
456
7
.
+-/\
;—
:
0,#
*@
89
DEF
GHI JKL MNO
PQRS TU V WXYZ
F1
F5 F2 F6 F3
F7 F4 F8
SFT SP BKSP DEL
ALT
CTRL ALPHA
2ABC
7
SCAN
VOL PG
TAB
ESC
SEND END
ENT
☼
9
456
1
.
+-/\
;:—
0,#
@
*
23
F1
F5 F2 F6 F3
F7 F4 F8
SFT SP BKSP DEL
ALT
CTRL ALPHA
8DEF
GHI JKL MNO
PQRS TU V WXYZ
ABC
34-Key Numeric
(Calculator) Keyboard
34-Key Alpha/Numeric
Keyboard

7
ALT
CTRL
NUM
AB C D E
F G H I J
K L M N O
P Q R S T
UVWX Y
Z
1
+
@
#
*
F1 F2 F3 F4 F5
F6 F7 F8 F9 F10
F15F14F13F12F11
F17 F18 F19 F20F16
F21 F22 F23 F24 F25
23
456
789
.0
SFT SP BKSP
,
SCAN
VOL PG
TAB
ESC
SEND END
ENT
☼
ALT
CTRL
A
123
456
789
0
BCDE
FGH IJ
KL MNO
PQRST
UV WX Y
Z
SFT
#
!
?
;
@
$&
—
~`
.
,
*
F6 F7 F8 F9 F10
F15F14F13F12F11
F17 F18 F19 F20F16
F21 F22 F23 F24 F25
BKSP
SP
DEL
+
-()
=
:
‘
SCAN
VOL PG
TAB
ESC
ENT
☼
F1 F2 F3 F4 F5
55-Key Full Alpha/
Numeric Keyboard
43-Key Alpha/Numeric
Keyboard

8
Install the Main Battery Pack
The 99EX is shipped with the battery packaged separate
from the terminal. Follow the steps below to install the
main battery. For information on how to remove the
battery, see page 9.
Before you attempt to use, charge, or replace the battery in
the terminal, carefully read all the information under
Equipment for Use in Hazardous Locations (see page 1).
1. Release the hook securing the hand strap to the back
panel of the terminal.
2. Remove the battery door by lifting up the latches near
the base of the battery door.
3. Insert the battery into the battery well.
Ensure all components are dry prior to placing the battery in
the terminal. Mating wet components may cause damage not
covered by the warranty.
4. Replace the battery door. Apply pressure to engage
the door latch. The battery door must be installed
prior to powering the unit.
5. Reattach the hand strap.
!
!
2
3

9
6. Connect the terminal to one of the 99EX series
charging peripherals to charge the main battery pack.
We recommend use of Honeywell Li-poly or Li-ion battery
packs. Use of any non-Honeywell battery may result in
damage not covered by the warranty.
Battery Error Notification
If your terminal displays the following indicators, replace
the battery with a new Honeywell battery pack.
Note: Replace only with battery pack model 99EX-BTSC (PN 99EX-
BTSC-2) or 99EX-BTEC (PN 99EX-BTEC-2), manufactured for
Honeywell International Inc.
• appears in the Title bar at the top of the touch panel
display.
• The General Notification LED flashes red.
• A notification appears on the Tile bar at the bottom of
the touch panel display.
Removing the Main Battery Pack
Before you attempt to use, charge, or replace the battery in
the terminal, carefully read all the information under
Equipment for Use in Hazardous Locations (see page 1).
When removing a battery from the terminal, put the device
in Suspend Mode (see page 12) before removing the
battery door. Once the battery door is removed, wait at
least 3 seconds before removing the main battery. This
process allows the device to shut down properly and to
maintain memory during the battery swap.
!
!

10
Battery Pack Use and Disposal
The following are general guidelines for the safe use and
disposal of batteries:
• Do not disassemble or open, crush, bend or deform,
puncture or shred.
• Do not modify or remanufacture, attempt to insert
foreign objects into the battery, immerse or expose to
water or other liquids, expose to fire, explosion or other
hazard.
• Improper battery use may result in a fire, explosion or
other hazard.
• We recommend use of Honeywell Li-poly or Li-ion
battery packs. Use of any non-Honeywell battery may
pose a personal hazard to the user.
• Only use the battery for the system for which it is
specified. Do not use a battery in any other manner
outside its intended use in Dolphin terminals and
peripherals.
• Only use the battery with a charging system that has
been qualified with the system per standard IEEE-Std-
1725-2006. Use of an unqualified battery or charger
may present a risk of fire, explosion, leakage, or other
hazard.
• Replace the battery only with another battery that has
been qualified with the system per this standard, IEEE-
Std-1725-2006. Use of an unqualified battery may
present a risk of fire, explosion, leakage or other
hazard.
• Replace defective batteries immediately; using a
defective battery could damage the Dolphin terminal.

11
• Never throw a used battery in the trash. Promptly
dispose of used batteries in accordance with local
regulations.
• Do not short-circuit a battery or throw it into a fire; it can
explode and cause severe personal injury. Do not
allow metallic conductive objects to contact battery
terminals.
• If you observe that the Honeywell battery supplied is
physically damaged, please send it to Honeywell
International Inc. or an authorized service center for
inspection. Refer to Technical Assistance on page 29.
• Avoid dropping the terminal or battery. If the terminal
or battery is dropped, especially on a hard surface, and
the user suspects damage, send it to a Honeywell
International Inc. or an authorized service center for
inspection. Refer to Technical Assistance on page 29.
• If you are not sure the battery or charger is working
properly, send it to Honeywell International Inc. or an
authorized service center for inspection.
• Excessive discharge can degrade battery
performance. Recharge the battery when your terminal
indicates low battery power.
• Although your battery can be recharged many times,
the battery life is limited. Replace it after the battery is
unable to hold an adequate charge.

12
Suspend Mode
The terminal goes into Suspend Mode automatically when
the terminal is inactive for a programmed period of time.
You can program this time on the Advance tab of the
Power System Setting. For additional information, refer to
the
Dolphin 99EX Mobile Computers for Use in Hazardous
Locations User’s Guide located on the Web at
www.honeywellaidc.com.
To put the terminal into Suspend Mode manually, press
the Power key and the screen goes blank.
To wake the terminal from Suspend Mode, press the
Power key or SCAN key .
Note: You should always put the terminal in suspend mode before
removing the battery door. For information on how to remove the
battery see page 9.
SCAN

13
Charging the Dolphin
All Dolphin 99EX model terminals are designed for use
with the following 99EX charging devices and cables:
99EX-HB, 99EX-EHB, 99EX-NB, 99EX-CB, 99EX-DEX,
99EX-RS232, 99EX-USB, and 99EX-USBH.
Warning: Dolphin charging peripherals are not designed for
use in hazardous locations. Before you attempt to use,
charge, or replace the battery in the terminal, carefully read all
the information under “Equipment for Use in Hazardous
Locations” on page 1.
Ensure all components are dry prior to mating terminals/
batteries with peripheral devices. Mating wet components
may cause damage not covered by the warranty.
Note: The communications/charging circuits connected to the
equipment provide the transient protection set at a level not
exceeding 140% of the peak rated voltage value of the IO
terminal.
Connect the terminal to one of
the 99EX series charging
peripherals to charge the main
battery.
The charging time for the main
battery pack is 4 hours for the
standard battery or 6 hours for
the extended battery.
Honeywell recommends
charging the Dolphin terminal
for at least 24 hours prior to
initial use to ensure the internal
backup battery is fully charged.
We recommend use of Honeywell peripherals, power cables,
and power adapters. Use of any non-Honeywell peripherals,
cables, or power adapters may cause damage not covered by
the warranty.
!
!
AUX
Battery
Well
!

14
HomeBase (Model 99EX-HB)
The 99EX-HB charger is designed for use with standard
battery pack, part number 99EX-BTSC-2 (Li-poly 3.7V,
11.3 watt hour) and extended battery pack, part number
99EX-BTEC-2 (Li-ion 3.7V, 18.5 watt hour) manufactured
for Honeywell International Inc. and all Dolphin 99EX
model terminals.
Warning: The HomeBase is not designed for use in
hazardous locations. Before you attempt to use, charge, or
replace the battery in the terminal, carefully read all the
information under “Equipment for Use in Hazardous
Locations” on page 1.
Use only a UL Listed power supply, which has been
qualified by Honeywell with output rated at 12VDC, and
3 amps with the device.
Front Panel
Back Panel
!
Power/Dock
LED
AUX Battery LED
COMM LED
USB Port
Serial Port DC Power
Jack

15
HomeBase LED Indicators
Red The HomeBase has power but no
terminal is docked.
Green The HomeBase has power and the
terminal is properly seated in the
base.
Orange The auxiliary battery is charging.
Green The auxiliary battery has completed
charging and is ready for use.
Red
Flashing The internal temperature of the auxiliary battery is too hot or there is
a battery error. Charge the auxiliary
battery in a cooler environment or
replace the battery with a new
Honeywell battery (PN 99EX-BTEC-2
or 99EX-BTSC-2).
Serial Port Communication
Red Serial data is being sent from the host
device to the base.
Green Serial data is being sent from the
base to the host device.
Orange Serial data is being sent in both
directions at the same time.
USB Port Communication
Green A USB connection is established with
the host workstation.

16
Charging/Communication Cables
Warning: The Charging/Communication Cables (Models
99EX-DEX, 99EX-RS232, 99EX-USB, 99EX-USBH) are not
designed for use in hazardous locations.
Use only a UL Listed power supply, which has been
qualified by Honeywell with output rated at 5VDC and
3 amps with the device.
!
USB
Connector
RS232 Connector
Host Device
Or
Power Cable
COMM
Cable
Plug Adapter
Or
RS232, DEX
A/V Connector
Dolphin 99EX

17
LED Indicators
There are two light emitting diodes (LEDs) located to the
left and right of the Honeywell logo above the LCD display.
The General Notification LED (right) flashes and
illuminates during resets, scanning/imaging and taking a
picture. This LED can be programmed by various software
applications.
The Charge Indicator LED (left) illuminates when the
Power Tools BattMon application is enabled and the
device is on AC charge. For more information, please
consult the
Dolphin Power Tools User’s Guide for
Windows Embedded Handheld 6.5.
Client
Device
Power
Cable
Plug Adapter Dolphin
99EX

18
Battery Status Indicator
The Dolphin’s battery status is indicated at the top of the
touch screen in the Title Bar.
Before you attempt to use, charge, or replace the battery in the
terminal, carefully read all the information under “Equipment for
Use in Hazardous Locations” on page 1.
The battery is charging. The terminal is using an
external power source.
The battery has a full charge.
The battery has a high charge.
The battery has a medium charge.
The battery has a low charge.
The battery has a very low charge. Charge the
battery.
A battery error has occurred. Replace the main
battery pack with a new Honeywell battery pack.
!
