Honeywell T87F User manual

T87F
Universal Thermostat
Application
The T87F Universal Thermostat provides temperature
control for 24 to 30 Vac residential heating, cooling or
heating-cooling systems. For heating systems, the T87F
mounts on the wallplate provided. For cooling only, or
heating-cooling, use the 137421A Heating-Cooling Wall-
plate (included) with remote switching, or order the Q539
Subbase, which provides switching at the thermostat loca-
tion.
The spdt switch makes one set of contacts on a tem-
perature fall to operate the heating system. The other set of
contacts make on a temperature rise to operate the cooling
system when the T87F is used to control cooling.
Heat anticipation is adjustable, 0.1 to 1.2A.
Mercury Notice
This control contains mercury in a sealed tube. Do not
place control in the trash at the end of its useful life.
If this control is replacing a control that contains mercury
in a sealed tube, do not place your old control in the trash.
Contact your local waste management authority for
instructions regarding recycling and the proper disposal
of this control, or of an old control containing mercury in
a sealed tube.
Installation and Setting
WHEN INSTALLING THIS PRODUCT…
1. Read these instructions carefully. Failure to fol-
low them could damage the product or cause a hazardous
condition.
2. Check the ratings given in the instructions and on
the product to make sure the product is suitable for your
application.
3. Installer must be a trained, experienced service
technician.
4. After installation is complete, check out product
operation as provided in these instructions.
CAUTION
1. Disconnect the power supply before begin-
ning installation to prevent electrical shock
or equipment damage.
2. Do not short across coil terminals on relay.
This may burn out the heat anticipation.
M3375
NOTE: The T87F was carefully adjusted at the factory.
Handle the thermostat carefully; rough handling may
decrease its accuracy.
LOCATION
Select a location about 1.5 m [5 ft.] above the floor in an
area with good air circulation at average temperature.
Do not mount thermostat where it may be affected by—
—drafts or dead spots behind doors and in corners.
—hot or cold air from ducts.
—radiant heat from the sun or appliances.
—concealed pipes and chimneys.
—unheated (uncooled) areas behind the thermostat.
MOUNTING WALLPLATE OR SUBBASE (Fig. 2)
IMPORTANT:
1. Use spirit level to accurately level the wallplate or
subbase as in Fig. 1. Inaccurate leveling may cause
thermostat control deviation.
2. When using the T87F with a Q539 Subbase, follow
the mounting and wiring instructions included with
the subbase.
1. Place the wallplate on the wall at the desired loca-
tion. Pull the thermostat cable through the entrance hole.
2. Fasten wallplate. Do not tighten the screws.
3. Level according to Fig. 1; then tighten screws.
4. After wiring wallplate, plug hole to prevent drafts
from affecting thermostat.
NOTE: To mount T87 Thermostat on an outlet box, order
129044A Adapter Ring Assembly.
Fig. 1—Leveling wallplate or subbase with
spirit level.
SPIRIT
LEVEL LEVELING
POSTS (2)
MOUNTING
SLOTS
M3319A
OPENING FOR
THERMOSTAT
WIRING
SUPER TRADELINE
®U.S. Registered Trademark
Copyright © 2002 Honeywell • • All Rights Reserved
60-1175-3

60-1175—3 2
Fig. 2—Mounting wallplate or subbase to wall.
WALL PLATE
SHOWN
THERMOSTAT CABLE
ENTRANCE HOLES
COVER RING
MOLDED
LEVELING
POST
NO. 4 X 1 INCH
SHEET METAL SCREWS (2) ADD T87F AS
SHOWN ON OUTLET
BOX MOUNTING
WIRING
All wiring must comply with local electrical codes and
ordinances. Disconnect power supply before connecting
wiring to prevent electrical shock or equipment damage.
The T87F is adaptable to most 2-wire, 24 to 30 volt
heating systems, and to most 3-wire, 24 to 30 volt heating
systems controlled by a Series 10 Thermostat. The follow-
ing hookups are typical applications. See Figs. 3-6. When
using the T87F for cooling control, refer to the hookups in
the Q539 Subbase instructions.
For variations of these systems, refer to the installation
instructions of the controlled equipment.
After wiring the wallplate, plug the hole to prevent
drafts that may affect the thermostat.
Fig. 3—T87F used for 2-wire, spst control of
heating only in a typical oil system. Low
voltage power for the control circuit is supplied
by a transformer in the oil primary control.
R
Y
W
BURNER
MOTOR
FAN
MOTOR
1POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
IGNITION
OIL VALVE
WHITE
ORANGE
BLACK
R8184G
THERMOSTAT
CAD CELL
L1 (HOT)
L2
LIMIT
FAN
COMBINATION FAN
AND LIMIT CONTROL
2R8184 PROTECTORELAY OIL PRIMARY CONTAINS
INTERNAL TRANSFORMER.
M6105
T
2
1
T
F
F
Fig. 4—T87F used for 2-wire, spst control of
heating only in a typical gas system.
R
W
1
L1
(HOT)
L2
FAN
MOTOR
COMBINATION
FAN AND LIGHT
CONTROL
LIMIT FAN
TRANSFORMER
GAS VALVE
T87F
TH
TH TR
TR
M5318
1POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
Y
Fig. 5—T87F replacing a series 10 thermostat
connected to a 3-wire, open-contact, high-limit
control.
Fig. 6—T87F used for series 20, 3-wire, spdt
control of low-voltage motors and electric
radiator valves. Used in applications where
thermostat makes contact on both a rise and
fall in room temperature.
1
L1
(HOT)
L2
1
3-WIRE SPDT
VALUE OR MOTOR
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED. M5319
R
W
Y
T87F
POWER
SUPPLY
W
R
B
TR
RED
WHITE
BLUE
MOUNTING THERMOSTAT TO WALLPLATE
OR SUBBASE
To remove standard cover; pull ring outward with
fingertips, pressing lightly on dial with thumbs.
To remove locking cover; loosen the three screws
along the cover edge with the Allen wrench supplied.
Remove the cover as indicated above.
Remove and discard the plastic insert protecting the
mercury switch.
Align the thermostat over the wallplate and tighten the
three captive mounting screws. These captive screws
complete the electrical connections to the thermostat.
Adjust heat anticipator to match current rating of primary
control. See Fig. 7.
THERMOSTAT
M6102
RY
W
LOW LIMIT
OPERATING CONTROL JUMPER
SERIES 10 OPEN
CIRCUIT HIGH LIMIT
TO THERMOSTAT
CONNECTIONS ON
SERIES 10 VALVE
AT BURNER
BB
WW
RR

360-1175—3
HEAT ANTICIPATOR SETTING
If the T87F is used for 3-wire, spdt, heating-only
(series 20) control (Fig. 6), set the heat anticipator for 1.2
(far left end of scale). A fixed resistor type heater is
provided in the 137421A Wallplate for this application.
For other control applications, proceed as follows.
Adjust anticipator to match current rating of primary
control. Rating is usually stamped on the control name-
plate. Move the indicator to the marking that matches this
rating. Indicator may be moved with fingers or pencil point
through hole shown in Fig. 7. If the current rating is not
given, proceed as follows before mounting the thermostat:
1. Connect an ac ammeter of appropriate range (0 to
2.0A, for example) between the R and W terminals on the
wallplate or subbase.
2. Let the system operate for one minute before reading
the ammeter.
3. Move the anticipator indicator to match the amme-
ter reading.
A slightly higher setting to obtain longer burner-on
times (fewer cycles per hour) may be desirable on some
systems.
RECALIBRATION
The T87F is calibrated at the factory and no recali-
bration should be necessary. If the thermostat is accurately
leveled and still appears to be out of calibration, order
104994A Calibration Wrench. Instructions for recalibrating
are furnished with the wrench.
Fig. 7—Setting heat anticipator current rating.
Checkout
HEATING
Turn down temperature setting to lowest point. If sub-
base or remote switching is used, move system switch to
HEAT position. Raise temperature setting until heating
equipment starts. This point should be at room temperature
as indicated on the thermometer. Turn back dial slowly.
Heating equipment should stop when dial has been turned
below room temperature.
COOLING
CAUTION
1. Do not operate cooling if outdoor temperature
is below 10°C [50°F]. Refer to manufac-
turer’s recommendations.
2. Allow 5-minute off-time after compressor has
been run to avoid compressor damage.
If T87F controls cooling, move system switch (if used)
to call for COOL and lower setting until cooling equipment
starts. Raise setting above room temperature and cooling
system should shut down. Make certain all equipment
responds properly to the thermostat.
LONGER
.15 .12
.2
.6
.8
1.0
.5
.4
.3
HOLE SUITABLE FOR
PENCIL POINT
TO MOVE INDICATOR HEAT
ANTICIPATOR
INDICATOR
SCALE
M1368
