Hoover 094HLEV9TG User manual

EN

2
Thank you for choosing this product.
We are proud to offer the ideal product for
you and the best complete range of home
appliances for your daily routine.
Please read and follow these
instructions carefully and operate the
machine accordingly. This booklet provides
important guidelines for safe use,
installation, maintenance and some useful
advice for best results when using your
machine. Keep all documentation in a safe
place for future reference or for any future
owners.
Please check that the following items are
delivered with the appliance:
•
Instruction manual
•
Guarantee card
•
Energy label
Check that no damage has occurred to the
machine during transit. If it as, call for
service by Customer Service Centre.
Failure to comply with the above can
compromise the safety of the appliance.
You may be charged for a service call if a
problem with your machine is caused by
misuse or by incorrect installation.
To contact the Service, ensure that you
have the unique 16
-
character code
available, also called the "serial number".
This code is a unique code for your
product, printed on the sticker that can be
found inside the door opening.
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re
-
used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:

WEEE should not be treated as
household
waste;

WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one
-to-
one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.
1.
GENERAL SAFETY RULES
2.
VENTILATION
3.
DOOR AND FILTER
4.
PRACTICAL HINTS
5.
QUICK USER GUIDE
6.
CONTROLS AND PROGRAMMES
7.
TROUBLESHOOTING AND WARRANTY
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
Environmental conditions
Contents

3
EN
1. GENERAL SAFETY
RULES
This appliance is intended to
be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
Children should be supervised
to ensure that they do not play
with the appliance.
Children of less than 3 years
should be kept away unless
continuously supervised.
This machine is solely for
domestic use, i.e. to dry
household textiles and garments.
Ensure that the instructions for
installation and use are fully
understood before operating
the appliance.
Do not touch the appliance
when hands or feet are damp
or wet.
Do not lean on the door when
loading the machine or use the
door to lift or move the machine.
Do not continue to use this
machine if it appears to be faulty.
WARNING
M
isuse of a tumble dryer may
create a fire hazard.

4
The tumble dryer is not to be
used if industrial chemicals
have been used for cleaning.
 Lint and fluff must not be allowed
to collect on the floor around the
outside of the machine.
Always remove the plug before
cleaning the appliance.
The drum inside may be very
hot. Always allow the dryer to
complete the cool down period
before removing the laundry.
The final part of a tumble dryer
cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.
WARNING
N
ever stop a tumble dryer
before the end of the drying
cycle unless all items are
quickly removed and spread
out so that the heat is
dissipated.
WARNING:
Where the hot surface
symbol
is located the
temperature rise during
operation of the tumble
dryer may be in excess of 60
degrees C.
WARNING
D
o not use the product if the
fluff filter is not in position or
is damaged; fluff could be
ignited.

5
EN
Do not install the product in a
low temperature room or in a
room where there is a risk of
frost occurring. At temperature
around freezing point the
product may not be able to
operate properly: there is a risk
of damage if the water is
allowed to freeze in the
hydraulic circuit (valves, hoses,
pumps). For a better product
performance the ambient room
temperature must be between
5-35°C. Please note that
operating in cold condition
(between +2 and +5°C) might
simply some water condensation
and water drops on floor.
In cases where the dryer is
installed on top of a washing
machine, a suitable stacking kit
must be used according to the
configuration of your appliance:
- Stacking kit "standard size": for
washing machine with
minimum depth of 44 cm;
- Stacking kit "slim size": for
washing machine with
minimum depth of 40 cm.
- Universal stacking kit with
sliding: for washing machine
with minimum depth of
47 cm.
The stacking kit shall be
obtainable from service. The
instructions for installation and
any fixing attachments, are
provided with the stacking kit.
NEVER install the dryer up
near curtains.
The appliance must not be
installed behind a lockable door,
a sliding door or a door with a
hinge on the opposite side to
that of the tumble dryer, in
such way that a full opening of
the tumble dryer door is restricted.
For your safety, the appliance
must be correctly installed. If
there is any doubt about installation,
call Service for advice.
Once the machine is in place
the feet should be adjusted to
ensure that the machine is
level.
The technical details (supply
voltage and power input) are
indicated on the product rating
plate.
Electrical connections and
safety instructions
Installation

6
Make sure that the electrical
system is earthed, complies
with all applicable law and that
the (electricity) socket is
compatible with the plug of the
appliance. Otherwise, seek
qualified professional assistance.
Do not use adapters, multiple
connectors and/or extensions.
The plug should be accessible
for disconnection after the
appliance has been installed.
Do not plug the machine in and
switch it on at the mains until
the installation is completed.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Adequate ventilation must be
provided in the room where the
tumble dryer is located to
prevent gases from appliances
burning other fuels, including
open fires, being drawn into
the room during operation of
the tumble dryer.

Install the rear of the appliance
close to a wall or vertical surface.
There should be a gap of at
least 12 mm between the
machine and any obstrubtions.
The inlet and outlet air should
be kept clear of obstruction.
Make sure carpets or rugs
do not obstruct the base or any
of the ventilation openings.

Prevent items from falling or
collecting behind the dryer as
these may obstruct the air inlet
and outlet.
Exhaust air must not be
discharged into a flue which is
used for exhausting fumes
from appliances burning gas or
other fuels.
Check regularly that the air
flowing around the dryer is not
restricted, avoiding accumulation
of dust and lint.
Ventilation
WARNING
The appliance must not be
supplied through an external
switching device, such as a
timer, or connected to a circuit
that is regularly switched on
and off by a utility.

7
EN
Check frequently the fluff filter
after use, and clean, if necessary.
* Air inlet.
** Air outlet.
Always refer to the laundry
care labels for directions on
suitability for drying.
Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
Do not dry unwashed items in
the tumble dryer.
Clothes should be spin dried or
thoroughly wrung before they
are put into the tumble dryer.
Clothes that are dripping wet
should not be put into the dryer.
Glass fibre curtains should
NEVER be put in this machine.
Skin irritation may occur if other
garments are contaminated with
the glass fibres.
Items that have been soiled
with substances such as cooking
oil, acetone, alcohol, petrol,
kerosene, spot removers,
turpentine, waxes and wax
removers should be washed in
hot water with an extra amount
of detergent before being dried
in the tumble dryer.
WARNING
Do not tumble dry fabrics
treated with dry cleaning
fluids.
WARNING
Foam rubber materials can
,
under certain circumstances,
when heated become ignited
by spontaneous combustion.
Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes
or pillows fitted with foam
rubber pad
s MUST NOT be
dried in the tumble dryer.
The Laundry

8
 Remove all objects from pockets
such as lighters and matches.
Lighters and matches must not
be left in pockets and NEVER
use flammable liquids near the
machine.
Maximum load drying weight:
see energy label.
 To consult the product technical
specification please refer to the
manufacturer website.

9
EN
2. VENTILATION
It is essential to use a venting hose to
carry the hot moist air away from the
dryer unless the dryer is situated in an
open space with a good air flow around it.
Recirculation of the moist air will prevent
the efficient operation of the dryer.
The hose is assembled to the machine as
shown.
The hose may be fitted through a wall or
through an open door or window. The
hose is 110 mm in diameter and will
extend 1,8 meters.
The following guidelines should be followed
when installing the exhaust hose.
Do not use two hoses joined together as
the drying performance will be reduced.

Do not restrict the flow of air through the
hose e.g. by kinking it or fitting a smaller
diameter connector to mount to a wall
opening.
Avoid the hose making U shaped curves
as this will restrict the flow of air and
increase the chance that water will collect
in the hose.
Check the hose regularly to remove any
build-up of fluff or water that may have
collected in it.
The following diagrams give examples of
good and bad installations.
H max
20 inches
(50.80 cm)
WARNING
The installation should prevent air
flowing back into the machine through
the exhaust hose. The machine could
be damaged electrically, and its safety
compromised, if the exhaust hose air
is allowed to re-enter the tumble dryer.
Installation of the exhaust hose

10
3. DOOR AND FILTER
Pull on handle to open the door.
To restart the appliance, close the door
and press the programme start button.
Filter cleaning indicator light
It lights up when the cleaning of the filter is
requested: check the filter and eventually
clean it.
If the laundry is not drying check that the
filter is not clogged.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint from filter using your
fingertips or a soft brush, a cloth or under
water running.
4. Snap the filter together and push back
into place.
To clean the lint filter
WARNING
Clean the filter before every cycle.
If you clean filter under water, remember
to dry it.
WARNING
Do not use the tumble dryer without
the filter.
To maintain the efficiency of the dryer
check th
at the lint filter is clean before
each drying cycle.
Clogged filter could increase the
drying time and cause damages and
expensive cleaning operation.
Filter
WARNING
When the tumble dryer is in use the
drum and door may be VERY HOT.
Door

11
EN
4. PRACTICAL HINTS
Before using the tumble dryer for the first
time:
Please read this instruction book
thoroughly.
Remove all items packed inside drum.
Wipe the inside of the drum and door with
a damp cloth to remove any dust which
may have settled in transit.
Make sure that the laundry you are going to
dry is suitable for drying in a tumble dryer,
as shown by the care symbols on each
item. Check that all fastenings are closed
and that pockets are empty. Turn the
articles inside out. Place clothes loosely in
the drum to make sure that they don't get
tangled.
Silk, nylon stockings, delicate embroidery,
fabrics with metallic decorations, garments
with PVC or leather trimmings.
Only put into the tumble dryer laundry which
has been thoroughly wrung or spin-dried.
The drier the laundry the shorter the drying
time thus saving electricity.
ALWAYS
Check that the filter is clean before every
drying cycle.
NEVER
Put dripping wet items into the tumble
dryer, this may damage the appliance.
By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature
only.
Do not tumble dry.
If the item does not have a care label it
must be assumed that it is not suitable for
tumble drying.

By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).

By type of fabric
Cottons/linen: Towels, cotton jersey, bed
and table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.
WARNING
Do not overload the drum, large items
when wet exceed the maximum
admissible clothes load (for example:
sleeping bags, duvets).
Sort the load as follows
Energy saving
During the last 15 minutes the load is
always tumbled in cool air.
WARNING
Do not dry articles which have been
treated with a dry cleaning fluid or
rubber clothes (danger of fire or
explosion).
Do not tumble dry
Clothes preparation

12
Clean the filter after every drying cycle.
After each period of use, wipe the inside
of the drum and leave the door open for a
while to allow circulation of air to dry it.

Wipe the outside of the machine and the
door with a soft cloth.

DO NOT use abrasive pads or cleaning
agents.

To prevent the door sticking or the
buildup of fluff clean the inner door and
gasket
with a damp cloth after every drying
cycle.
WARNING
For electrical data refer to the rating
label on the front of the dryer cabinet
(with the door open).
WARNING
Always switch off and remove the plug
from the electricity supply before
cleaning this appliance.
WARNING
The drum, door and load may be very
hot.
Cleaning the dryer

13
EN
5. QUICK USER GUIDE
1. Open the door and load the drum with
laundry. Ensure that garments do not
hinder closure of the door.
2. Gently close the door pushing it slowly
until you hear the door 'click' shut.
3. Turn the Programme Selector dial to
select the required drying programme
(see the table of programmes).
4. Press the programme start button. The
dryer will start automatically.
5. If the door is opened during the
programme to check the laundry, it is
necessary to press programme start
to recommence drying after the door
has been closed.
6. When the cycle is nearing completion
the machine will enter the cool down
phase, the clothes will be tumbled in
cool air allowing the load to cool down.
7. Following the completion of the cycle
the drum will rotate intermittently to
minimize creasing. This will continue
until the machine is switched OFF or the
door is opened.
Power input / Power current fuse amp/
Supply voltage: see rating plate.
Maximum load: see energy label.
Energy class: see energy label.
6. CONTROLS AND
PROGRAMMES
A
PROGRAMME SELECTOR with
OFF position
B
START/PAUSE button
C
DELAY START button
D
TIME SELECTION button
E
DRYING SELECTION button
F
START PAUSE indicator light
G
TIME SELECTION indicator
lights
H
DRYING SELECTION indicator
lights
I
DELAY START TIME / DRYING
STAGE indicator lights
L
FILTER CLEANING indicator light
M
ONE TOUCH area
Technical data
Do not open the door during the
automatic programmes in order to
obtain a proper drying.

14
Rotating the programme selector in both
directions it's possible to select the
desired drying programme.
To cancel the selections or switch off the
appliance rotate the programme selector
on OFF (remember to unplug the
appliance).
Press the START/PAUSE button to start
the programme set with the programme
knob (the corresponding indicator light
will light up).
Moreover, if you want to modify the
chosen programme, press the desired
options buttons and then press START/
PAUSE button to start the cycle.
After switching on the appliance, wait a
few seconds for the programme to start
running.
PROGRAMME DURATION
When a programme is selected the
appliance calculates the time to the end
of the selected programme based upon a
standard loading but, during the cycle, the
appliance corrects the time to the
humidity level of the load.
PROGRAMME END
The "END" indicator light will light up at
the end of the programme, it is now
possible to open the door.
At the end of the cycle, turn off the
appliance by turning the programme
selector to the OFF position.
PAUSING THE MACHINE
Press the START/PAUSE button (the
corresponding indicator light will flash,
showing that the machine is paused).
Press the START/PAUSE button again to
re-start the programme from the point it
had been paused at.
CANCELLING THE SET PROGRAMME
To cancel the programme, turn the
programme selector to the OFF position.
If there is a break in the power supply
whilst the machine is operating, when
the power is restored, by pressing the
START/PAUSE button, the machine will
restart from the beginning of the phase it
was in when the power was lost.
Appliance start time can be set with this
button, delaying the start by 3, 6or 9
hours.
DELAY START button
The programme selector must
ALWAYS be put in the OFF
position at
the end of the
drying cycle before a
new one can be selected.
Only the options compatible with the
set programme can be selected.
Close the porthole BEFORE pressing
the START/PAUSE button.
START/PAUSE button
PROGRAMME SELECTOR with
OFF position
WARNING
Don’t touch the buttons while inserting
the plug because the machines
calibrates the systems during the first
seconds: touching the buttons
, the
machine couldn’t work property. In
this case, remove the plug and repeat
the operation.

15
EN
Proceed as follows to set a delayed start:
- Select a programme.
- Press the DELAY START button (each
time the button is pressed the start will
be delayed by 3, 6 or 9hours
respectively and the corresponding time
indicator light will light up).
- Press START/PAUSE button to
commence the delay start operation
(the indicator light associated with the
selected delay start time will blink). At
the end of the required time delay the
programme will start.
It is possible to cancel the DELAY
START by turning the programme
selector to OFF.
To set a timed drying, press this button
until the corresponding indicator light to
the desired duration will light on.
It's possible transform a cycle from
automatic to timed, up to 3 minutes after
the start of the cycle.
After this selection to reset the automatic
drying functioning is necessary to switch
off the dryer.
In case of incompatibility, all indicator
lights flash quickly for 3 times.
This button allows to set the desired
dryness level editable option up to 3
minutes after the starting of the cycle:
Ready to Iron: it leaves the garments
slightly wet to facilitate ironing.
Dry Hanger: to get garment ready to
be hang.
Dry wardrobe: for laundry that can be
directly stored.
Extra-dry: to get completely dry
garments, ideal for full load.
This appliances is equipped with Drying
Manager function. On automatic cycles,
each level of intermediate drying, prior to
the reaching the selected one, is indicated
by flashing the light indicator corresponding
to the degree of drying reached.
In case of incompatibility, all indicator
lights flash quickly for 3 times.
It lights up when the START/PAUSE button
has been pressed.
The indicator lights are illuminated to show
the duration selected by the relevant button.
The indicator lights display the degrees
of dryness that can be selected by the
relevant button.
Each time the DELAY START button is
pressed the indicator lights show how
many hours of delay you chosen (3, 6 or
9hours) and the countdown until the end
of it.
DELAY START TIME / DRYING
STAGE indicator lights
DRYING SELECTION indicator
lights
TIME SELECTION indicator lights
START PAUSE indicator light
DRYING SELECTION button
TIME SELECTION button
Opening of the porthole with delayed
start set, after re-
closing the porthole,
press START/PAUSE
again to resume
the counting.

16
When a programme is running, the
indicator lights will light in sequence to
indicate the current phase:
DRYING CYCLE
It lights up when the drying cycle is
running
.
COOLING
It lights up when the cycle is in the
cooling phase
.
END CYCLE
It lights up when the cycle is done.
It lights up when the cleaning of the filter is
requested.
FILTER CLEANING indicator light

17
EN
This appliance is equipped with One Touch
technology that allows you to interact, via
the App, with smartphones based on
Android operating system and equipped
with compatible NFC (Near Field
Communication) function.
Download on your smartphone the
Hoover Wizard App.
HOW TO USE ONE TOUCH
FIRST TIME - Machine registration
Enter the "Settings" menu of your
Android smartphone and activate the
NFC function inside the "Wireless &
Networks" menu.
Turn the knob to the One Touch position
to enable the sensor on the dashboard.
Open the App, create the user profile and
register the appliance following the
instructions on the phone display or the
"Quick Guide" attached on the machine.
NEXT TIME – Regular usage
Every time you want to manage the
machine through the App, first you have
to enable the One Touch mode by
turning the knob to the One Touch
indicator.
Make sure you have unlocked your phone
(from stand-by mode) and you have
activated the NFC function; following the
steps mentioned earlier.
If you want to start a cycle, load the
laundry and close the door.
Select the desired function in the App
(e.g.: starting a programme).
Follow the instructions on the phone
display, KEEPING IT ON the One Touch
logo on the machine dashboard, when
requested to do so by the App.
Depending on the smartphone model
and its Android OS version, the
process of the NFC activation may be
different. Refer to the smartphone
manual for more details.
Get all the details of the One Touch
functions, browsing the App in DEMO
mode.
The Hoover Wizard App is available
for devices running both Android and
iOS, both for tablets and for
smartphones. However, you can
interact with the machine and take
advantage of the potential offered
by One Touch only with Android
smartphones equipped with NFC
technology, according to following
functional scheme:
Android smartphone
with compatible NFC
technology
Interaction with the
machine + contents
Android smartphone
without NFC technology
Contents only
Android Tablet Contents only
Apple iPhone Contents only
Apple iPad Contents only
ONE TOUCH

18
NOTES:
The management and the control of the
machine via App is only possible "by
proximity": it is therefore not possible to
perform remote operations (e.g.:
from
another room ; outside of the house).
The replacement of some components of
the smartphone (e.g. back cover, battery,
etc...) with non-
original ones, could result
in the NFC antenna removal, preventing
the full use of the App.
Thick cases or metallic stickers on
your smartphone could affect or
prevent the transmission of data
between machine and telephone. If
necessary, remove them.
If you do not know the position of
your NFC antenna, slightly move the
smartphone in a circular motion over
the One Touch logo until the App
confirms the connection. In order for
the data transfer to be successful, it is
essential TO KEEP THE SMARTPHONE
ON
THE DASHBOARD DURING THESE
FEW SECONDS OF THE PROCEDURE;
a message on the device will inform
about the correct outcome of the
operation and advise you when it is
possible to move the smartphone
away.
Place your smartphone so that the
NFC antenna on its back matches
the positio
n of the One Touch logo
on the appliance (as illustrated below).

19
EN
The standard cycle COTTON DRY ( )
is the most energy efficient and best suited
for drying normal wet cotton laundry.
The table in last page shows the
approximate time and energy consumption
of the main drying programmes.
Maximum Drying Weight
Cottons
Max. capacity
declared
Synthetics or
Delicates
Max. 4 kg
Power consumption of off-mode: 0,40 W
Power consumption of left-on mode: 0,75 W
EN 61121 - Programme To Use
- STANDARD DRY COTTON
- IRON DRY COTTON
(WHITES - Ready to Iron)
- EASY-CARE TEXTILE
(SYNTHETICS - Dry Hanger)
WARNING
The real duration of drying cycle
depends by the starting humidity level
of the laundry due to spin speed, type
and amount of load, cleanliness of
filters and ambient temperature.
WARNING
Clean the filter before every cycle.
Information for Test Laboratory
Drying Guide

20
PROGRAMMES
Selectable Options
CAPACITY
(kg)
DRYING
TIME (min)
-
-
2 *
6 Max 220’
-
-
Full *
Full *
4 *
-
4 *
-
2,5 *
4 *
-
-
4 *
-
-
1 *
--1 70’
-4 Max 220’
-
-
2,5 12'
-
-
2,5 20'
Customizable setting that interacts with the App on your smartphone and to
download the cycles (see the dedicated section). The factory sets the default
programme Cotton.
* The real duration of drying cycle depends by the starting humidity level of the laundry due to spin
speed, type and amount of load, cleanliness of filters and ambient temperature.
Table of programmes
