Hoover Nextra7 HSV172 User manual

Instruction Book
Vented Tumble Dryer
®
40004480.qxd 15/05/2006 19:34 Page 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . 3
Safety reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
European Directive 2002/96/EC. . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation of the Discharge Hose . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the load . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Clothes preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sorting the load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Drying advice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Do not tumble dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and indicators . . . . . . . . . . . . . . . . . . . . . 11
Door and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter care indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning and Routine Maintenance . . . . . . . . 14
Cleaning the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hoover Spares. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Your Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Hoovercare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2
Contents
40004480.qxd 15/05/2006 19:34 Page 2

Please read and follow these instructions carefully and
operate the machine accordingly. This booklet provides
important guidelines for safe use, installation, maintenance
and some useful advice for best results when using your
machine.
Keep all documentation in a safe place for future reference or
for any future owners.
Delivery information
Please check that the following items are delivered with the
appliance:
●Instruction manual
●Guarantee card
●Vent kit and instructions
●Energy label
Remove the machine from its packaging close to the final
location of the machine.
1. Cut carefully around the base of the packaging and up
one corner.
2. Remove the polythene sleeve and lift the dryer off the
polystyrene base.
3
Check that no damage
has occurred to the
machine during transit.
If it has, call for service
by GIAS.
Call
08705 400 600
If the appliance is not
running properly or
breaks down, switch it
off, disconnect the plug
from the socket and do
not tamper with
the appliance.
Consult GIAS Service
for possible repair.
Call
08705 400 600
Failure to comply with
the above can
compromise the safety
of the appliance. You
may be charged for a
service call if a problem
with your machine is
caused by misuse.
Introduction
Unpacking the product
Dispose of the
packaging safely. Make
sure it is out of the
reach of children, it is a
potential source of
danger.
40004480.qxd 15/05/2006 19:34 Page 3

Installation
●Check that the product has no visible signs of damage
before use. If damaged do not use and please call our
national number: 08705 400 600.
●Do not use adapters, multiple connectors and/or extensions.
●This machine should not be installed in a bathroom or
shower room.
●Never install the dryer against curtains and be sure to
prevent items from falling or collecting behind the dryer.
●The appliance must not be installed behind a lockable door,
a sliding door or a door with a hinge on the opposite side
of the door to that of the tumble dryer.
Use
●WARNING Misuse of a tumble dryer may create a fire
hazard.
●This machine is solely for domestic use, i.e. to dry
household textiles and garments.
●This machine should only be used for its intended purpose
as described in this manual. Ensure that the instructions for
installation and use are fully understood before operating
the appliance.
●Do not touch the appliance when hands or feet are damp
or wet.
●Do not lean on the door when loading the machine or use
the door to lift or move the machine.
●Do not allow children to play with the machine or its
controls.
●WARNING Do not use the product if the fluff filter is not in
position or is damaged; fluff could be ignited.
●WARNING Where the hot surface symbol is located
the temperature rise during operation of the tumble dryer
may be in excess of 60 degrees C.
●Remove the plug from the electricity supply. Always remove
the plug before cleaning the appliance.
●Do not continue to use this machine if it appears to be
faulty.
●Lint and fluff must not be allowed to collect on the floor
around the outside of the machine.
●The drum inside may be very hot. Always allow the dryer to
complete the cool down period before removing the
laundry.
The Laundry
●WARNING Do not tumble dry fabrics treated with dry
cleaning fluids.
●WARNING Foam rubber materials can, under certain
circumstances, when heated become ignited by
4
Safety reminders
40004480.qxd 15/05/2006 19:34 Page 4

spontaneous combustion. Foam plastic, foam rubber and
rubber-like material are not suitable for tumble drying.
Articles made from these materials MUST NOT be placed in
the dryer.
●Always refer to the laundry care labels for directions on
suitability for drying.
●Clothes should be spin dried or thoroughly wrung before
they are put into the tumble dryer. Clothes that are
dripping wet should NOT be put into the dryer.
●Lighters and matches must not be left in pockets and
NEVER use flammable liquids near the machine.
●Glass fibre curtains should NEVER be put in this machine.
Skin irritation may occur if other garments are
contaminated with the glass fibres.
●Garments treated or contaminated with flammable
cleaning sprays or liquids such as petrol, cooking oil or
aerosol sprays MUST NOT be put in this machine.
Enviromental Issues
●All packaging materials used are environmentally-friendly
and recyclable. Please help dispose of the packaging via
environmentally-friendly means. Your local council will be
able to give you details of current means of disposal.
●To ensure safety when disposing of an old tumble dryer
disconnect the mains plug from the socket, cut the mains
power cable and destroy this together with the plug. To
prevent children shutting themselves in the machine break
the door hinges or the door lock.
GIAS Service
●To ensure the continued safe and efficient operation of this
appliance we recommend that any servicing or repairs are
only carried out by an authorised GIAS service engineer.
European Directive 2002/96/EC
This appliance is marked according to the European Directive
2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this product may not
be treated as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of electrical
and electronic equipment
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
5
40004480.qxd 15/05/2006 19:35 Page 5

Electrical requirements
Tumble dryers are supplied to operate at a voltage of
230-240V, 50 Hz single phase. Check that the supply circuit is
rated to at least 13A.
This appliance is fitted with a moulded-on non-rewireable plug
which is already equipped with a BS 1362 ASTA approved 13A
fuse. Any replacement must be the same rating and
specification. If the fuse cover is lost, do not use the plug until
it is replaced.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the appliance must be of
the same type.
Do not use multiple adapters and/or extension leads.
The plug should be accessible for disconnection after the
appliance has been installed.
The wires in the mains lead are coloured in accordance with
the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive 89/336/EEC,
73/23/EEC and subsequent amendments.
Adjusting the feet
Once the machine is in place the feet should be adjusted to
ensure that the machine is level.
Adjust the four feet to ensure the machine is firm and level.
6
Installation
Do not plug the
machine in and switch
it on at the mains until
the installation is
completed.
You may be charged for
a service call if a
problem with your
machine is caused by
incorrect installation.
If the mains cord on
this appliance is
damaged, it must be
replaced by a special
cord which is ONLY
obtainable from the
Hoover spares service.
It must be installed by a
competent person.
Call
01204 556111
40004480.qxd 15/05/2006 19:35 Page 6

Adequate ventilation must be provided in the room where the
tumble dryer is located to prevent gases from appliances
burning other fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
●Exhaust air must not be discharged into a flue which is
used for exhausting fumes from appliances burning gas or
other fuels.
●Check regularly that the air flowing through the dryer is
not restricted.
●Check the fluff filter after use, and clean, if necessary.
●The inlet and outlets should be kept free from
obstructions. To ensure adequate ventilation the space
between the bottom of the machine and the floor must
not be obstructed. There should be a gap of at least
12mm between the machine and any obstructions.
●Prevent items from falling or collecting behind the dryer
as these may obstruct the air inlet and outlet.
●NEVER install the dryer up against curtains.
Installation of the
Discharge Hose
It is essential to use a venting hose to carry the hot moist air
away from the dryer unless the dryer is situated in a open
space with a good air flow around it. Re-recirculation of the
moist air will prevent the efficient operation of the dryer.
The hose is assembled to the machine as shown opposite.
The hose may be fitted through a wall or through an open
door or window. The hose is 110mm in diameter and will
extend 1.8 meters.
The following guidelines should be followed when installing
the discharge hose.
●Do not use two hoses joined together as the drying
performance will be reduced.
7
Ventilation
For your safety, this dryer must be correctly installed.
If there is any doubt about installation, call the national GIAS Service
number for advice.
08705 400 600
(Eire 018301 666)
40004480.qxd 15/05/2006 19:35 Page 7

●Do not restrict the flow of air through the hose e.g. by kinking it or fitting a smaller diameter
connector to mount to a wall opening.
●Avoid the hose making U shaped curves as this will restrict the flow of air and increase the chance
that water will collect in the hose.
●Check the hose regularly to remove any build-up of fluff or water that may have collected in it.
The following diagrams give examples of good and bad installations.
8
40004480.qxd 15/05/2006 19:35 Page 8

Before using the tumble dryer for the first time:
●Please read this instruction book thoroughly.
●Remove all items packed inside drum.
●Wipe the inside of the drum and door with a damp cloth
to remove any dust which may have settled in transit.
Clothes preparation
Make sure that the laundry you are going to dry is suitable for
drying in a tumble dryer, as shown by the care symbols on each
item.
Check that all fastenings are closed and that pockets are
empty. Turn the articles inside out. Place clothes loosely in the
drum to make sure that they don’t get tangled.
Maximum drying weight
●Cottons Max. 7 kg
●Synthetics Max. 3.5 kg
Sort the load as follows:
●By care symbols
These can be found on the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it must be
assumed that it is not suitable for tumble drying.
●By amount and thickness
Whenever the load is bigger than the dryer capacity,
separate clothes according to thickness (e.g. towels from
thin underwear).
●By type of fabric
Cottons/linen: Towels, cotton jersey, bed and table linen.
Synthetics: Blouses, shirts, overalls, etc. made of polyester
or polyamid, as well as for cotton/synthetic mixes.
●By drying level
Sort into: iron dry, cupboard dry, etc. For delicate articles
press the ‘ACRYLIC/SYNTHETIC’ button to select low
drying temperature.
9
Preparing the load
Do not overload the
drum, large items when
wet can exceed the
maximum admissible
clothes load
(for example: sleeping
bags, duvets).
40004480.qxd 15/05/2006 19:36 Page 9

Do not tumble dry:
Woollens, silk, delicate fabrics, nylon stockings, delicate
embroidery, fabrics with metallic decorations, garments with
PVC or leather trimmings, training shoes, bulky items such as
sleeping bags, etc.
Energy saving
Only put into the tumble dryer laundry which has been
thoroughly wrung or spin-dried. The drier the laundry the
shorter the drying time thus saving electricity.
ALWAYS
●Try to dry the maximum weight of laundry, this will save
time and electricity.
●Check that the filter is clean before every drying cycle.
NEVER
●Exceed the maximum weight, this will waste time and
electricity.
●Put dripping wet items into the tumble dryer, this may
damage the appliance.
10
Drying advice
During the last 15 minutes the load
is always tumbled in cool air.
IMPORTANT: Do not dry
articles which have
been treated with a dry
cleaning fluid or rubber
clothes (danger of fire
or explosion).
40004480.qxd 15/05/2006 19:36 Page 10

Control panel and indicator lights
‘ON’ Button and Indicator – press to switch on, the indicator
will light.
‘ACRYLIC/SYNTHETIC’ Button – press to reduce the heat level
for delicate items, press again to select high temperature.
HIGH heat setting
LOW heat setting
‘DRYING TIME’ Selector – selects the drying time or the Fast
Iron option.
‘FILTER CARE’ Indicator – lights when the filter needs cleaning.
11
Controls and indicators
ACRYLIC/SYNTHETIC
BUTTON
ON
BUTTON
FILTER CARE
INDICATOR
DRYING TIME
SELECTOR
40004480.qxd 15/05/2006 19:36 Page 11

Opening the door
Pull on handle to open the door.
To restart the dryer, close the door and press the On button.
Filter
IMPORTANT: To maintain the efficiency of the dryer check that
the fluff filter is clean before each drying cycle.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or your fingertips.
4. Snap the filter together and push back into place.
Filter Care Indicator
Lights when the filter needs cleaning.
If the laundry is not drying check that the filter is not clogged.
The indicator will also light when the venting hose is blocked
or kinked.
12
Door and Filter
WARNING!
When the tumble dryer is in use the drum
and door may be VERY HOT.
40004480.qxd 15/05/2006 19:36 Page 12

Refer to the Drying guide table or the fabric labels to select
the most suitable programme.
●Open the door and load the drum with laundry. Ensure
that garments do not hinder closure of the door.
●If drying delicate items press the ‘ACRYLIC/SYNTHETIC’
button to reduce the heat level. Press again on
completion, to select high temperature.
HIGH heat setting
LOW heat setting
●Turn the ‘DRYING TIME’ Selector until the required drying
time aligns with the dial.
●The Fast Iron programme provides a conditioning and
anti-crease function. The dryer will heat the load for 8
minutes followed by a 2 minute cool down period and is
especially good for garments which may have been left
for some time prior to ironing, in a linen basket for
example. Garments may also become stiffened when
dried outside on a washing line or inside on radiators. The
Fast Iron process relaxes the creases in the fabric making
ironing quicker and easier.
●Gently close the door pushing it slowly until you hear the
door ‘click’ shut.
●Press the ‘ON’ button. The indicator will light and the
drying cycle begins.
●The load is dried by tumbling in thermostatically
controlled warm air. Cool air is used for the last 15
minutes to reduce creasing and cool the load ready for
handling.
●When the program is fully completed the drum will stop
rotating and the dial will point to 0.
●Open the door and remove the load.
●Clean the filter after every drying cycle to ensure
maximum dryer efficiency.
13
Operation
WARNING!
The drum, door and
load may be very hot.
40004480.qxd 15/05/2006 19:36 Page 13

Cleaning the dryer
●Clean the filter after every drying cycle.
●After each period of use, wipe the inside of the drum and
leave the door open for a while to allow circulation of air
to dry it.
●Wipe the outside of the machine and the door with a soft
cloth.
●DO NOT use abrasive pads or cleaning agents.
●To prevent the door sticking or the build up of fluff
periodically clean the inner door and gasket with a damp
cloth.
Technical specifications
Drum capacity 115 litres
Maximum load 7 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band C
14
Cleaning and Routine Maintenance
IMPORTANT
Always switch off and
remove the plug from
the electricity supply
before cleaning this
appliance.
For electrical data
refer to the rating
label on the front of
the dryer cabinet
(with the door open).
40004480.qxd 15/05/2006 19:36 Page 14

What might be the cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run
through the following checklist. A charge will be made if the
machine is found to be working or has been installed
incorrectly or used incorrectly. If the problem persists after
completing the recommended checks, please call the GIAS
Service (tel: [phone]), they may be able to assist you
over the telephone.
Drying time is too long/clothes are not dry
enough…
●Have you selected the correct drying time/programme?
●Were the clothes too wet? Were the clothes thoroughly
wrung or spin-dried?
●Does the filter need cleaning?
●Is the dryer overloaded?
●Is the venting hose kinked or blocked?
●Has the ‘ACRYLIC/SYNTHETIC’ option been selected from a
previous cycle?
The dryer does not operate…
●Is there a working electricity supply to the dryer? Check
using another appliance such as a table lamp.
●Is the plug properly connected to the mains supply?
●Is there a power failure?
●Has the fuse blown?
●Is the door fully closed?
●Is the dryer switched on, both at the mains supply and at
the machine?
●Has the drying time or the programme been selected?
●Has the machine been switched on again after opening
the door?
The dryer is noisy…
●Switch off the dryer and contact the GIAS service number
08705 400 600 for advice.
The Filter Care Indicator is on…
●Does the filter need cleaning?
●Is the venting hose kinked or blocked?
15
Troubleshooting
40004480.qxd 15/05/2006 19:36 Page 15

Note:
If the supply cord on this appliance is damaged, it must be
replaced by a special cord which is only available from GIAS
Service or an authorised Hoover Dealer.
Should there still be a problem with your dryer after
completing all the recommended checks, please call the
national GIAS Service number for advice. They may be able to
assist you over the telephone or arrange for a suitable
appointment for an engineer to call under the terms of your
guarantee. However, a charge may be made if any of the
following applies to your machine:
●Is found to be in working order.
●Has not been installed in accordance with the installation
instructions.
●Has been used incorrectly.
HOOVER Spares
Always use genuine Hoover spares, available direct from GIAS
Service.
GIAS Service
For service and repairs call your local engineer on our national
number.
16
Customer Service
Phone GIAS on
08705 400 600
Eire-018301 666
GIAS Service - Tel: [phone]
Support Service for Eire - Tel: [phone]
Hoover Spares Service
Tel: [phone]
40004480.qxd 15/05/2006 19:36 Page 16

For a period of one year from the date of purchase the
appliance is covered by a guarantee which allows you to call
GIAS Service free of charge.
Remember to send off the guarantee certificate for validation
within 10 days of the date of purchase.
You should retain the receipt issued by the retailer when you
purchased the machine to show to the call out engineer,
should you need to consult one.
If your appliance shows signs of a defect or is not working
properly, before you contact GIAS Service we recommend you
carry out the checks detailed within the Troubleshooting
section.
If the problem with the appliance persists after completing all
the recommended checks, please dial the GIAS Service number.
You will be connected directly to GIAS. It is important you tell
the GIAS advisor your product's model number and serial
number, which you will find on the rating label (16 characters,
beginning with the number 3), found on the front of the
appliance (door area). By doing this, your enquiry will be
responded to more efficiently.
Hoover guarantees all parts of this product for 5 years from
the date of purchase. During that time Hoover will replace or
repair all defective parts free of charge, except for parts
subject to fair wear and tear such as belts. The call out fee and
labour costs are chargeable after the first 12 months. To
qualify for benefits under the guarantee, you must be able to
provide proof of date of purchase and the appliance must
have been installed and used in accordance with the
instructions described in this manual. Consequential losses and
accidental damage to the machine is not covered by the
guarantee.
Hoover cannot be responsible for the results of using this
machine for any purposes other than those described in this
manual.
This guarantee does not affect your statutory or common law
rights.
Note: If repair work has been completed by an unauthorised
engineer the product guarantee may become invalid.
Hoovercare
To maintain your Hoover product in peak condition you may
wish to take out a Hoovercare policy, which for an annual
payment provides a comprehensive maintenance and repair
scheme. For more information please call 08705 400 600.
The Hoovercare scheme is not available in Eire.
17
Your Guarantee
40004480.qxd 15/05/2006 19:36 Page 17

The manufacturer declines all responsibility in the event of any
printing mistakes in this booklet. The manufacturer also
reserves the right to make appropriate modifications to its
products without changing the essential characteristics.
18
40004480.qxd 15/05/2006 19:36 Page 18

40004480.qxd 15/05/2006 19:36 Page 19

40004480
40004480.qxd 15/05/2006 19:36 Page 20
