Hoover Vision HD VHC680F-80 User manual

Instruction Book
Condenser Tumble Dryer
English ®
40006007.qxd 02/07/2009 16:35 Page 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the product . . . . . . . . . . . 3
Safety reminders . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental Issues . . . . . . . . . . . . . . . . . . . . . 5
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical requirements . . . . . . . . . . . . . . . . . . . 6
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the load . . . . . . . . . . . . . . . . 8
Clothes preparation . . . . . . . . . . . . . . . . . . . . . . 8
Sorting the load. . . . . . . . . . . . . . . . . . . . . . . . . 9
Drying advice. . . . . . . . . . . . . . . . . . . . . 10
Do not tumble dry . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and indicators . . . . . . . . . 11
Selecting the Programme . . . . . . . 12
Door and Filter . . . . . . . . . . . . . . . . . . . 14
Opening the door . . . . . . . . . . . . . . . . . . . . . . 14
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Filter care indicator . . . . . . . . . . . . . . . . . . . . . 14
Water container . . . . . . . . . . . . . . . . . . 15
To remove the container . . . . . . . . . . . . . . . . . 15
Condenser . . . . . . . . . . . . . . . . . . . . . . . . 16
To remove the condenser . . . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cancelling and resetting the programme . . . . 18
Cleaning and Routine
Maintenance. . . . . . . . . . . . . . . . . . . . . . 18
Cleaning the dryer . . . . . . . . . . . . . . . . . . . . . . 18
Technical specifications . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . 19
Customer Service. . . . . . . . . . . . . . . . . 20
Hoover Spares . . . . . . . . . . . . . . . . . . . . . . . . . 20
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Your Guarantee . . . . . . . . . . . . . . . . . . 21
Hoovercare. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2
Contents
40006007.qxd 02/07/2009 16:35 Page 2

Introduction
Please read and follow these
instructions carefully and operate the
machine accordingly. This booklet
provides important guidelines for safe
use, installation, maintenance and
some useful advice for best results when using
your machine.
Keep all documentation in a safe place for future
reference or for any future owners
Delivery information
Please check that the following items are
delivered with the appliance:
●Instruction manual
●Guarantee card
●Energy label
Unpacking the Product
1. Cut carefully around the base of the
packaging and up one corner.
2. Remove the polythene sleeve and lift the
dryer off the polystyrene base.
3
Check that no damage has occurred to
the machine during transit. If it has, call
for service by GIAS.
Call 08444 995599
Failure to comply
with the above can
compromise the
safety of the
appliance. You may
be charged for a
service call if a
problem with your
machine is caused
by misuse.
If the appliance is
not running
properly or breaks
down, switch it
off, disconnect the
plug from the
socket and do not
tamper with
the appliance.
Consult GIAS
Service for possible
repair.
Call
08444
995599
Dispose of the packaging safely. Make
sure it is out of the reach of children,
it is a potential source of danger.
40006007.qxd 02/07/2009 16:35 Page 3

4
Installation
●Check that the product has no visible signs of damage before use. If damaged do
not use and please call GIAS Service.
●Do not use adapters, multiple connectors and/or extensions.
●Never install the dryer against curtains and be sure to prevent items from falling
or collecting behind the dryer.
●The appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the tumble dryer.
Use
●This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
●Children should be supervised to ensure that they do not play with the appliance.
●WARNING Misuse of a tumble dryer may create a fire hazard.
●This machine is solely for domestic use, i.e. to dry household textiles and garments.
●This machine should only be used for its intended purpose as described in this
manual. Ensure that the instructions for installation and use are fully understood
before operating the appliance.
●Do not touch the appliance when hands or feet are damp or wet.
●Do not lean on the door when loading the machine or use the door to lift or
move the machine.
●Do not allow children to play with the machine or its controls.
●WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
●WARNING Where the hot surface symbol is located the temperature rise
during operation of the tumble dryer may be in excess of 60 degrees C.
●Remove the plug from the electricity supply. Always remove the plug before
cleaning the appliance.
●Do not continue to use this machine if it appears to be faulty.
●Lint and fluff must not be allowed to collect on the floor around the outside of
the machine.
●The drum inside may be very hot. Always allow the dryer to complete the cool
down period before removing the laundry.
The Laundry
●Do not dry unwashed items in the tumble dryer.
●WARNING Do not tumble dry fabrics treated with dry cleaning fluids.
●WARNING Foam rubber materials can, under certain circumstances, when heated
become ignited by spontaneous combustion. Items such as foam rubber (latex
foam), shower caps, waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads MUST NOT be dried in the tumble dryer.
●Always refer to the laundry care labels for directions on suitability for drying.
Safety reminders
40006007.qxd 02/07/2009 16:35 Page 4

5
●Clothes should be spin dried or thoroughly wrung before they are put into the
tumble dryer. Clothes that are dripping wet should NOT be put into the dryer.
●Lighters and matches must not be left in pockets and NEVER use flammable
liquids near the machine.
●Glass fibre curtains should NEVER be put in this machine. Skin irritation may
occur if other garments are contaminated with the glass fibres.
●Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in
the tumble dryer.
●Fabric softeners, or similar products, should be used as specified by the fabric
softener instructions.
Environmental Issues
●All packaging materials used are environmentally-friendly and recyclable. Please
help dispose of the packaging via environmentally-friendly means. Your local
council will be able to give you details of current means of disposal.
●To ensure safety when disposing of an old tumble dryer disconnect the mains
plug from the socket, cut the mains power cable and destroy this together with
the plug. To prevent children shutting themselves in the machine break the door
hinges or the door lock.
GIAS Service
● To ensure the continued safe and efficient operation of this appliance we
recommend that any servicing or repairs are only carried out by an authorised
GIAS service engineer.
European directive 2002/96/EC
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE).
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
The symbol on the product indicates that this product may
not be treated as household waste. Instead it shall be
handed over to the applicable collection point for the
recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment, recovery
and recycling of this product, please contact your local city
office, your household waste disposal service or the shop
where you purchased the product.
40006007.qxd 02/07/2009 16:36 Page 5

6
Electrical requirements
Tumble dryers are supplied to operate at a
voltage of 230-240V, 50 Hz single phase. Check
that the supply circuit is rated to at least 13A.
This appliance is fitted with a moulded-on non-
rewireable plug which is already equipped with a
BS 1362 ASTA approved 13A fuse. Any
replacement must be the same rating and
specification. If the fuse cover is lost, do not use
the plug until it is replaced.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the appliance
must be of the same type.
Do not use multiple adapters and/or extension
leads.
The plug should be accessible for disconnection
after the appliance has been installed.
The wires in the mains lead are coloured in
accordance with the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive
89/336/EEC, 73/23/EEC and subsequent amendments.
Adjusting the feet
Once the machine is in place the feet should be
adjusted to ensure that the machine is level.
You may be
charged for a
service call if a
problem with
your machine is
caused by
incorrect
installation.
If the mains cord
on this appliance
is damaged, it
must be replaced
by a special cord
which is ONLY
obtainable from
the GIAS spares
service. It must
be installed by a
competent
person.
Call
08443
712758
Installation
Do not plug the machine in and
switch it on at the mains until the
installation is completed.
40006007.qxd 02/07/2009 16:36 Page 6

Adequate ventilation must be provided in the
room where the tumble dryer is located to
prevent gases from appliances burning other
fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
●Exhaust air must not be discharged into a
flue which is used for exhausting fumes
from appliances burning gas or other fuels.
●Check regularly that the air flowing through
the dryer is not restricted.
●Check the fluff filter after use, and clean, if
necessary.
●The inlet and outlets should be kept free
from obstructions. To ensure adequate
ventilation the space between the bottom
of the machine and the floor must not be
obstructed. There should be a gap of at
least 12mm between the machine and any
obstructions.
●Prevent items from falling or collecting
behind the dryer as these may obstruct the
air inlet and outlet.
●NEVER install the dryer up against curtains.
Ventilation
AIR OUTLETS
AIR OUTLETS IN THE BASE
AIR INLET VENTS
For your safety,
this dryer must
be correctly
installed.
If there is any
doubt about
installation, call
the national GIAS
Service number
for advice.
08444
995599
(Eire 0818
2000021)
7
40006007.qxd 02/07/2009 16:36 Page 7

Before using the tumble dryer for the first time:
●Please read this instruction book thoroughly.
●Remove all items packed inside drum.
●Wipe the inside of the drum and door with
a damp cloth to remove any dust which may
have settled in transit.
Clothes preparation
Make sure that the laundry you are going to dry
is suitable for drying in a tumble dryer, as shown
by the care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out.
Place clothes loosely in the drum to make sure
that they don't get tangled.
Maximum drying weight
●Cottons Max. 8 kg
●Synthetics Max. 4 kg
8
Preparing the load
Do not overload
the drum, large
items when wet
can exceed the
maximum
admissible
clothes load
(for example:
sleeping bags,
duvets).
40006007.qxd 02/07/2009 16:36 Page 8

Sort the load as follows:
●By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it
must be assumed that it is not suitable
for tumble drying.
●By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
●By type of fabric
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.
●By drying level
Sort into: iron dry, cupboard dry, etc. For
delicate articles press the Delicates button to
select low drying temperature.
9
40006007.qxd 02/07/2009 16:36 Page 9

10
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic
decorations, garments with PVC or leather
trimmings, training shoes, bulky items such as
sleeping bags, etc.
Energy saving
Only put into the tumble dryer laundry which has
been thoroughly wrung or spin-dried. The drier
the laundry the shorter the drying time thus
saving electricity.
ALWAYS
●Try to dry the maximum weight of laundry,
this will save time and electricity.
●Check that the filter is clean before every
drying cycle.
NEVER
●Exceed the maximum weight, this will waste
time and electricity.
●Put dripping wet items into the tumble
dryer, this may damage the appliance.
Drying advice
IMPORTANT: Do
not dry articles
which have been
treated with a
dry cleaning fluid
or rubber clothes
(danger of fire or
explosion).
During the last
15 minutes the
load is always
tumbled in cool
air.
40006007.qxd 02/07/2009 16:36 Page 10

Control panel and indicator lights
Programme Selector – Select the required programme
Delay Start button – Allows the user to delay the start of the drying cycle (see
details of Operation on page 17)
Start/Pause button – Press Start/Pause to commence the selected drying
programme
Delicates button – Press to reduce the heat level for delicate items, the
indicator above the button will light up. To change the heat setting the
programme must be reset
Low Heat – Indicator light ON
High Heat – Indicator light OFF
Empty Water indicator – lights when the water container is full
Filter Care indicator – lights when the filter needs cleaning
Progress display
DRY – When the programme is selected the DRY indicator will flash, when the
programme starts the DRY indicator will light up.
– Indicator lights when there is a short time left until completion of the
programme. At this stage of the drying cycle the machine enters the Cool
Down phase.
The length of the Cool Down phase varies between 10 and 15 minutes
depending on the programme.
END – Indicator lights when the programme is finished.
11
Controls and indicators
DELICATES
BUTTON
EMPTY WATER
INDICATOR
FILTER CARE
INDICATOR
PROGRAMME
SELECTOR
DELAY START
BUTTON
PROGRESS
DISPLAY
START/PAUSE
BUTTON
40006007.qxd 02/07/2009 16:36 Page 11

12
Selecting a Programme
The Hoover Sensor Dry machine gives many options for drying the laundry to
suit all circumstances.
The table on the next page lists the programmes and the function of each
programme.
Note: The sensor may not detect a small load of small articles. For small loads
and separate items or pre-dried fabrics with low moisture content, use the
timed programmes. Set the programme between 30 and 75 minutes
depending on the load size and dryness required, and select high or low heat
depending upon the fabric type.
If the sensor does not detect the item the dryer will only operate for 10
minutes before going into cooldown.
If the load is too large or too wet to tumble dry the dryer will automatically
go into cooldown after approximately 3 hours.
40006007.qxd 02/07/2009 16:36 Page 12

13
Programme
Bone Dry
Extra Dry
Cupboard Dry
Iron Dry
Wool Finish
Relax
Rapid
150'
120'
90'
75'
60'
45'
30'
Refresh
Description
Select the degree of dryness that you require.
This ranges from Bone Dry for bath towels and
bathrobes, through Cupboard Dry for items that will be
put away without ironing, to the programme that
leaves the laundry suitable for ironing.
A gentle programme specially created to get woollens
softer after air-drying.
This delicate warm air cycle, lasting 12 minutes, can
also be used to get woollens 'refreshed' after being
stored in the wardrobe.
The Relax programme provides a conditioning and
anticrease function. The dryer will heat the load for 9
minutes followed by a 3 minute cool down period and
is especially good for garments which may have been
left for some time prior to ironing, in a linen basket for
example. Garments may also become stiffened when
dried outside on a washing line or inside on radiators.
This programme relaxes the creases in the fabric
making ironing quicker and easier.
The rapid programme allows a drying cycle to be
completed quickly. This is an ideal programme for
having dry, refreshed and ready-to-wear clothes in less
than 40'. This special programme constantly monitors
the dryness and temperature in the drum thanks to the
sensor using, using the exact time and energy you
need! The machine finishes the cycle when the
cupboard dry level is reached. The stated cycle length
could vary according to fabric types, load size and
residual moisture in the garments.
The maximum load is 2kg and the programme is
suitable for all types of fabric where tumble drying is
appropriate.
150 minutes of drying
120 minutes of drying
90 minutes of drying
75 minutes of drying
60 minutes of drying
45 minutes of drying
30 minutes of drying
Tumbling the laundry in cool air for 20 minutes
40006007.qxd 02/07/2009 16:36 Page 13

14
Opening the door
Pull on handle to open the door.
To restart the dryer, close the door and press the
Start/Pause button.
Filter
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or
your fingertips.
4. Snap the filter together and push back into
place.
Filter Care Indicator
lights when the filter needs cleaning.
If the laundry is not drying check that the filter is
not clogged.
Door and Filter
WARNING!
When the tumble dryer is in use the
drum and door may be VERY HOT.
Never stop a tumble dryer before
the end of the drying cycle unless
all items are quickly removed and
spread out so that the heat is
dissipated.
DO NOT USE WATER TO CLEAN THE
FILTER
40006007.qxd 02/07/2009 16:36 Page 14

The water removed from the laundry during the
drying cycle is collected in a container at the
bottom of the dryer.
When the container is full the ‘Full’ indicator on
the control panel will light, and the container
MUST be emptied. However, we recommend that
the container is emptied after each drying cycle.
NOTE: Very little water will collect during the
first few cycles of a new machine as an internal
reservoir is filled first.
To remove the container
1. Gently pull the bottom of the kickplate so
that it unclips from the dryer. The top
section can then be unhinged allowing the
kickplate to be completely removed.
2. Pull firmly on the handgrip and slide the
water container out of the dryer.
Support the container with both hands. When
full, the water container will weigh about 4kg.
3. Open the lid located on the top of the
container and empty the water.
4. Refit the lid and slide the water container
back into position. PUSH FIRMLY INTO
PLACE.
5. Refit the kickplate by engaging the hinges
at the top and 'snapping' the lower clips
into place.
15
Water Container
40006007.qxd 02/07/2009 16:36 Page 15

16
Important: Always switch off and remove the
plug from the electricity supply before cleaning
the condenser.
To maintain the efficiency of the dryer regularly
check that the condenser is clean.
To remove the
condenser
1. Remove the kickplate (see page 15).
2. Turn the two locking levers anti-clockwise
and pull out the condenser.
3. Pull out the condenser unit.
4. Gently remove any dust or fluff with a cloth,
then wash the unit by holding it under a
running tap turning it so that water flows
between the plates, to remove any dust or
fluff.
5. Refit the condenser ensuring it is in the
correct way (as indicated by the arrow) and
pushed firmly into place. Lock the two levers
by turning them clockwise.
6. Refit the kickplate.
Condenser
40006007.qxd 02/07/2009 16:36 Page 16

17
1. Open the door and load the drum with
laundry. Ensure that garments do not hinder
closure of the door.
2. Gently close the door pushing it slowly until
you hear the door 'click' shut.
3. Turn the Programme Selector dial to select
the required drying programme (see
Programme Guide).
4. If drying synthetics, acrylics or delicate items,
press the Delicates button to reduce the
heat level.
The light next to the push button will light
up when the machine is in low heat setting.
To deselect in the first few minutes of the
programme, press the Delicates button,
after this time reset the machine to change
the setting.
5. Press the Start/Pause button. The dryer will
start automatically and the DRY indicator
will be continuously lit.
6. If the door is opened during the programme
to check the laundry, it is necessary to press
Start/Pause to recommence drying after the
door has been closed.
7. When the cycle is nearing completion the
machine will enter the cool down phase, the
clothes will be tumbled in cool air allowing
the load to cool down.
8. When the programme is complete the END
indicator will light.
9. Following the completion of the cycle the
drum will rotate intermittently to minimize
creasing. This will continue until the
machine is switched OFF or the door is
opened.
Operation
WARNING!
The drum, door
and load may be
very hot.
40006007.qxd 02/07/2009 16:36 Page 17

18
Cancelling and resetting the
programme
To cancel a programme press the Start/Pause button for 3 seconds. The DRY
light will flash to indicate that it has been reset.
Start Delay
The Delay Start Function allows the user to delay the start of the drying cycle by
6 or 9 hours.
When the function is first selected the display will show a delay of 6 hours, a
subsequent press of the button will increase the delay to 9 hours.
To commence the programme press Start/Pause and the appliance will complete
the drying cycle at the end of this time. The 6 or 9 hour indicator light will flash
to indicate that the start delay is in progress.
Cleaning the dryer
●Clean the filter and empty the water
container after every drying cycle.
●Regularly clean the condenser.
●After each period of use, wipe the inside of
the drum and leave the door open for a
while to allow circulation of air to dry it.
●Wipe the outside of the machine and the
door with a soft cloth.
●DO NOT use abrasive pads or cleaning agents.
●To prevent the door sticking or the build up
of fluff periodically clean the inner door and
gasket with a damp cloth.
Technical specifications
Drum capacity 115 litres
Maximum load 8 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band C
IMPORTANT
Always switch
off and remove
the plug from
the electricity
supply before
cleaning this
appliance.
For electrical data
refer to the
rating label on
the front of the
dryer cabinet
(with the door
open).
Cleaning and Routine
Maintenance
40006007.qxd 02/07/2009 16:36 Page 18

19
What might be the cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run through the
following checklist. A charge will be made if the machine is found to be
working or has been installed incorrectly or used incorrectly. If the problem
persists after completing the recommended checks, please call the GIAS Service
(tel: [phone]), they may be able to assist you over the telephone.
Drying time is too long/clothes are not dry enough…
●Have you selected the correct drying time/programme?
●Were the clothes too wet? Were the clothes thoroughly wrung or spin-
dried?
●Does the filter need cleaning?
●Does the condenser need cleaning?
●Is the dryer overloaded?
●Are the inlets, outlets and base of the dryer free from obstructions?
●Has the ‘Delicates’ option been selected from a previous cycle?
The dryer does not operate…
●Is there a working electricity supply to the dryer? Check using another
appliance such as a table lamp.
●Is the plug properly connected to the mains supply?
●Is there a power failure?
●Has the fuse blown?
●Is the door fully closed?
●Is the dryer switched on, both at the mains supply and at the machine?
●Has the drying time or the programme been selected?
●Has the machine been switched on again after opening the door?
●Has the dryer stopped operating because the water tray is full and needs
emptying?
The dryer is noisy…
●Switch off the dryer and contact the GIAS service number 08444 995599
for advice.
The Filter Care Indicator is on…
●Does the filter need cleaning?
●Does the condenser need cleaning?
Empty Water Indicator is on…
●Does the water container need emptying?
Troubleshooting
40006007.qxd 02/07/2009 16:36 Page 19

Should there still be a problem with your dryer
after completing all the recommended checks,
please call the national GIAS Service number for
advice. They may be able to assist you over the
telephone or arrange for a suitable appointment
for an engineer to call under the terms of your
guarantee. However, a charge may be made if
any of the following applies to your machine:
●Is found to be in working order.
●Has not been installed in accordance with
the installation instructions.
●Has been used incorrectly.
HOOVER Spares
Always use genuine Hoover spares, available
direct from GIAS Service.
GIAS Service
For service and repairs call your local engineer on
our national number.
20
Customer Service
Phone GIAS on
08444 995599
Eire – 0818 2000021
Hoover
Spares
Service
Tel: 08443
712758
If the supply cord
on this appliance
is damaged, it
must be replaced
by a special cord
which is only
available from
GIAS Service or
an authorised
Hoover Dealer.
40006007.qxd 02/07/2009 16:36 Page 20
