Hoover HIFS430B Operation manual

Thank you for purchasing the HOOVER induction hob. Please read this instruction manual
carefully before using the hob and keep it in a safe place for future reference.
OCAKLAR
KULLANIM VE KURULUM TALİMATLARI
INDUKČNÁ VARNÁ DOSKA
SK
T
INDUKČNÍ VARNÁ DESKA CZ
SI
Indukcijska kuhalna plošča
Návod na obsluhu
Návod k obsluze
Navodila za uporabo
IT
Piani cottura
Istruzioni per l’ uso ed istallazione
KOCHFELDER
GEBRAUCHS- UND INSTALLATIONSANLEITUNG
DE
HIFS430B

Safety Warnings
Your safety is important to us. Please read this
information before using your hob.
Installation
Electrical Shock Hazard
•Disconnect the appliance from the mains
electricity supply before carrying out any work
or maintenance on it.
•Connection to a good earth wiring system is
essential and mandatory.
•Alterations to the domestic wiring system must
only be made by a qualified electrician.
•Failure to follow this advice may result in
electrical shock or death.
Cut Hazard
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or
cuts.
Important safety instructions
•Read these instructions carefully before
installing or using this appliance.
•No combustible material or products should be
placed on this appliance at any time.
•Please make this information available to the
person responsible for installing the appliance
EN-1
By placing the CE mark on this product, we are
confirming compliance to all relevant European safety, health
and environmental requirements which are applicable in
legislation for this product.

as it could reduce your installation costs.
•In order to avoid a hazard, this appliance must
be installed according to these instructions for
installation.
•This appliance is to be properly installed and
earthed only by a suitably qualified person.
•This appliance should be connected to a circuit
which incorporates an isolating switch
providing full disconnection from the power
supply.
•Failure to install the appliance correctly could
invalidate any warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
•Do not cook on a broken or cracked hob surface.
If the hob surface should break or crack, switch
the appliance off immediately at the mains power
supply (wall switch) and contact a qualified
technician.
•Switch the hob off at the wall before cleaning or
maintenance.
•Failure to follow this advice may result in
electrical shock or death.
Health Hazard
•This appliance complies with electromagnetic
safety standards.
•However, persons with cardiac pacemakers or
EN-2

other electrical implants (such as insulin
pumps) must consult with their doctor or
implant manufacturer before using this
appliance to make sure that their implants will
not be affected by the electromagnetic field.
•Failure to follow this advice may result in death.
Hot Surface Hazard
•During use, accessible parts of this appliance
will become hot enough to cause burns.
•Do not let your body, clothing or any item other
than suitable cookware contact the Induction
glass until the surface is cool.
•Beware: magnetisable metal objects worn on
the body may become hot in the vicinity of the
cooktop. Gold or silver jewellery will not be
affected.
•Keep children away.
•Handles of saucepans may be hot to touch.
Check saucepan handles do not overhang other
cooking zones that are on. Keep handles out of
reach of children.
•Failure to follow this advice could result in
burns and scalds.
Cut Hazard
•The razor-sharp blade of a hob surface scraper
is exposed when the safety cover is retracted.
Use with extreme care and always store safely
EN-3

and out of reach of children.
•Failure to use caution could result in injury or
cuts.
Important safety instructions
•Never leave the appliance unattended when in
use. Boilover causes smoking and greasy
spillovers that may ignite.
•Never use your appliance as a work or storage
surface.
•Never leave any objects or utensils on the
appliance.
•Do not place or leave any magnetisable objects
(e.g. credit cards, memory cards) or electronic
devices (e.g. computers, MP3 players) near the
appliance, as they may be
affected by its electromagnetic field.
•Never use your appliance for warming or
heating the room.
•After use, always turn off the cooking zones
and the hob as described in this manual(i.e. by
using the touch controls). Do not rely on the
pan detection feature to turn off the cooking
zones when you remove the pans.
•Do not allow children to play with the appliance
or sit, stand, or climb on it.
•Do not store items of interest to children in
cabinets above the appliance. Children
EN-4

climbing on the hob could be seriously injured.
•Do not leave children alone or unattended in
the area where the appliance is in use.
•Children or persons with a disability which
limits their ability to use the appliance should
have a responsible and competent person to
instruct them in its use. The instructor should
be satisfied that they can use the appliance
without danger to themselves or their
surroundings.
•Do not repair or replace any part of the
appliance unless specifically recommended in
the manual. All other servicing should be done
by a qualified technician.
•Do not use a steam cleaner to clean your hob.
•Do not place or drop heavy objects on your hob.
•Do not stand on your hob top.
•Do not use pans with jagged edges or drag pans
across the Induction glass surface as this can
scratch the glass.
•Do not use scourers or any other harsh
abrasive cleaning agents to clean your cooktop,
as these can scratch the Induction glass.
•If the power supply cable is damaged, it must
only be replaced by a qualified technician.
•This appliance is designed for domestic use
only.
•This appliance can be used by children aged
from 8 years and above and persons with
EN-5

reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance
shall not be made by children without
supervision.
•WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water,
but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
•Metallic objects such as knives, forks, spoons
and lids should not be placed on the hob
surface since they can get hot.
•After use, switch off the hob element by its
control and do not rely on the pan detector.
•The appliance is not intended to be operated by
means of an external timer or separate
remote-control system.
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
EN-6

Product Overview
Top View
1. max. 1800/3000 W zone
7. Glass plate
8. Control
EN-7
2. max. 1800/3000 W zone
3. max. 1800/3000 W zone
4. max. 1800/3000 W zone
5 - 6. Flexible zone. 3000/4000 W

Control Pane
1. Power / Timer slider touch control
2. Heating zone selection controls
3. keylock control
4. ON/OFF control
5. keep warm control
6. Boost control
7. Timer control
EN-8

A Word on Induction Cooking
Induction cooking is a safe, advanced, efficient, and economical cooking
technology. It works by electromagnetic vibrations generating heat directly in the
pan, rather than indirectly through heating the glass surface. The glass becomes
hot only because the pan eventually warms it up.
Before using your New Induction Hob
•Read this guide, taking special note of the ‘Safety Warnings’ section.
•Remove any protective film that may still be on your Induction hob.
Using the Touch Controls
•The controls respond to touch, so you don’t need to apply any pressure.
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin film of water may make the
controls difficult to operate.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
EN-9

Choosing the right Cookware
•Only use cookware with a base suitable for induction
cooking. Look for the induction symbol on the
packaging or on the bottom of the pan.
•You can check whether your cookware is suitable by carrying out
a magnet test. Move a magnet towards the base of the pan. If it
is attracted, the pan is suitable for induction.
•If you do not have a magnet:
1. Put some water in the pan you want to check.
2. Follow the steps under ‘To start cooking’.
3. If does not flash in the display and the water is heating, the pan is suitable.
•Cookware made from the following materials is not suitable: pure stainless steel, aluminium or
copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Use pans whose diameter is as large as the
graphic of the zone selected. Using a pot a slightly wider energy will be used at its
maximum efficiency. If you use smaller pot efficiency could be less than expected.
Pot less than 140 mm could be undetected by the hob. Always centre your pan on
the cooking zone.
Always lift pans off the Induction hob –do not slide, or they may scratch the glass.
EN-10

Pan Dimension
The cooking zones are, up to a limit, automatically adapted to the diameter of the
pan. However the bottom of this pan must have a minimum of diameter according
to the corresponding cooking zone. To obtain the best efficiency of your hob,
please place the pan in the centre of the cooking zone.
Cooking zone
The base diameter of induction cookware
Minimum (mm)
Maximum (mm)
1,2,3,4
140
220
Flexible zone
220
220x400
EN-11

Using your Induction Hob
To start cooking
1. Touch the ON/OFF control.
After power on, the buzzer beeps once, timer control
show ““ ，heating zone selection controls show
““or““or““, indicating that the induction
hob has entered the state of standby mode.
2. Place a suitable pan on the cooking zone that
you wish to use.
•Make sure the bottom of the pan and the surface
of the cooking zone are clean and dry.
3.Touching the heating zone selection control,
and a indicator upon you touched will flash
4. Adjust heat setting by touching the slider control.
•If you don’t choose a heat setting within 1
minute, the Induction hob will automatically
switch off. You will need to start again at step 1.
•You can modify the heat setting at any time
during cooking.
EN-12

If the display flashes alternately with the heat
setting
This means that:
•you have not placed a pan on the correct cooking zone or,
•the pan you’re using is not suitable for induction cooking or,
•the pan is too small or not properly centred on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn off after 1 minute if no suitable pan is placed
on it.
When you have finished cooking
1. Touching the heating zone selection
control that you wish to switch off
2. Turn the cooking zone off by touching the slider
to the left. Make sure the display shows”0”
3. Turn the whole cooktop off by touching the
ON/OFF control.
4. Beware of hot surfaces
H will show which cooking zone is hot to touch. It will disappear when the
surface has cooled down to a safe temperature. It can also be used as an
energy saving function if you want to heat further pans, use the hotplate
that is still hot.
EN-13

Using the Boost function
Actived the boost function
1. Touching the heating zone selection control
2. Touching the boost control , the zone indicator shows “b”and the power
reach Max.
Cancel the Boost function
1. Touching the heating zone selection control
that you wish to cancel the boost function
2. a: Touching the boost control “”, then the cooking zone will revert to its
original setting.
b: Touching the slider control, then the cooking zone will revert to the level
you select.
OR
EN-14

•The function can work in all cooking zones
• The cooking zone returns to its original setting after 5 minutes.
• As the boost function of 1st cooking zone is activated ,the 2nd cooking zone is
limited under level 2 automatically. vice versa
• If the original heat setting equals b, it will return to 15 after 5 minutes
Using the Keep Warm function
Actived the keep warm function
1. Touching the heating zone selection control
2. Touching the keep warm control ,the zone indicator shows “|”.
Cancel the keep warm function
Annuler la fonction de conservation au chaud
1. Touching the heating zone selection control
EN-15

2. a:Touching the slider control, then the cooking zone will revert to the level
you select.
b: Touching the function control such as , then the cooking zone will
revert to the level you previously selected.
FLEXIBLE AREA
• This area can be used as a single zone or as two different zones, accordingly to
the cooking needs anytime.
• Flexible area is made of two independent inductors that can be controlled
separately. When working as a single zone, a cookware is moved from one zone
to the other one within the flexible area keeping the same power level of the zone
where the cookware originally was placed, and the part that is not covered by
cookware is automatically switched off.
•Important：Make sure to place the cookwares centered on the single cooking
zone. In case of big pot,oval,rectangular and elongated pans make sure to place
the pans centered on the cooking zone covering both cross.
Examples of good pot placement and bad pot placement.
EN-16

As big zone
1. To activate the flexible area as a single big zone, simply press the dedicated
keys.
2. The power setting works as any other normal area.
3. If the pot is moved from the front to the rear part (or viceversa),the flexible
area detects automatically the new position, keeping the same power.
4. To add a further pot, press again the dedicated keys, in order to detect the
cookware.
As two independent zones
To use the flexible area as two different zones with different power settings, press
the dedicated keys.
EN-17

Locking the Controls
•You can lock the controls to prevent unintended use (for example children
accidentally turning the cooking zones on).
•When the controls are locked, all the controls except the ON/OFF control are
disabled.
To lock the controls
Touch the keylock control. The timer indicator will show “Loc“
To unlock the controls
1. Touch and hold the keylock control for a while.
2. You can now start using your Induction hob.
When the hob is in the lock mode, all the controls are disable except the
ON/OFF , you can always turn the induction hob off with the ON/OFF
control in an emergency, but you shall unlock the hob first in the next
operation.
Over-Temperature Protection
A temperature sensor equipped can monitor the temperature inside the Induction
hob. When an excessive temperature is monitored, the Induction hob will stop
operation automatically.
Detection of Small Articles
When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other
small item (e.g. knife, fork, key) has been left on the hob, the zone automatically
go on to standby in 1 minute. The fan will keep cooling down the induction hob for
a further 1 minute.
Auto Shutdown Protection
Auto shut down is a safety protection function for your induction hob. It shuts
down automatically if ever you forget to turn off your cooking. The default working
times for various power levels are shown in the below table: .
Power level
Keep warm
1~5
6~10
11~14
15
Default working timer (hour)
2
8
4
2
1
When the pot is removed, the induction hob can stop heating immediately and the
hob automatically switch off after 2 minutes.
People with a heart pace maker should consult with their doctor before
using this unit.
EN-18

Using the Timer
You can use the timer in two different ways:
•You can use it as a minute minder. In this case, the timer will not turn any
cooking zone off when the set time is up.
•You can set it to turn cooking zones off after the set time is up.
•You can set the timer for up to 99 minutes.
Using the Timer as a Minute Minder
If you are not selecting any cooking zone
1. Make sure the cooktop is turned on.
Note: you can use the minute minder even if you’re not selecting any cooking
zone.
2. Touch timer control , the “0：10”will show in the
timer display where touched and the “0”flashes.
3. Set the time by touching the slider control. (e.g. 6)
4.Touch timer control again, the “1”will flash.
5. set the time by touching the slider control (e.g.9), now the timer you set is 56
minutes.
EN-19
