hopf FG8101G01 Guide

Because every fraction of a second counts ■
FG8101G01
Technical Documentation

FG8101G01
Technical Documentation
Page 2 of 49 Version: 01.02; Date: 18.11.2022
1Table of Contents
1Table of Contents...........................................................2
2 List of Figures.................................................................5
3 Change History...............................................................5
4 Preliminary Remarks......................................................6
4.1 Conformity data........................................................................... 7
4.2 Signal words for warnings........................................................... 8
5 Safety instructions..........................................................9
5.1 Intended Use............................................................................. 10
6 Device description........................................................11
6.1 Extension board positions......................................................... 12
6.2 PSU - Power Supply Unit.......................................................... 13
6.3 MC - Management Controller Board......................................... 13
6.4 TDC - Time Domain Controller Board....................................... 13
6.5 SP - Service Provider................................................................ 13
6.6 Minimal configuration of a FG8101G01..................................... 14
6.7 Front cover................................................................................ 14
6.7.1 LEDs..................................................................................................... 15
6.7.2 Button................................................................................................... 15
6.7.3 Display.................................................................................................. 15
7 System mounting FG8101G01.....................................18

FG8101G01
Technical Documentation
Page 3 of 49 Version: 01.02; Date: 18.11.2022
8 Connection of the supply and data lines.......................19
9 Extension boards..........................................................20
9.1 Mounting of extension boards................................................... 20
9.2 Dismounting of extension boards.............................................. 22
9.3 Supported extension boards..................................................... 23
9.3.1 FG8901P01 - PSU 85-264VAC / 125-250VDC.................................... 23
9.3.1.1 Connection..............................................................................................23
9.3.1.2 Status LEDs of extension boards ............................................................24
9.3.2 FG8901P02 - PSU 18-36VDC ............................................................. 25
9.3.2.1 Connection..............................................................................................25
9.3.2.2 Status LEDs of extension boards ............................................................26
9.3.3 FG8901P03 - PSU 36-76VDC ............................................................. 27
9.3.3.1 Connection..............................................................................................27
9.3.3.2 Status LEDs of extension boards ............................................................28
9.3.4 FG8901P04 - PSU 60-160VDC ........................................................... 29
9.3.4.1 Connection..............................................................................................29
9.3.4.2 Status LEDs of extension boards ............................................................30
9.3.5 FG8702G01 - MC, TDC und SP functionality ...................................... 31
9.3.5.1 Status LEDs of extension boards ............................................................32
9.3.6 FG8702G02 - MC, TDC und SP functionality ...................................... 33
9.3.6.1 Status LEDs of extension boards ............................................................34
9.3.7 FG8702G03 - MC, TDC und SP functionality ...................................... 35
9.3.7.1 Status LEDs of extension boards ............................................................36
9.3.8 FG8801N02 - SP functionality.............................................................. 37
9.3.8.1 Status LEDs of extension boards ............................................................37

FG8101G01
Technical Documentation
Page 4 of 49 Version: 01.02; Date: 18.11.2022
10 Commissioning...........................................................38
11 Maintenance...............................................................39
12 Troubleshooting..........................................................39
12.1 Procedure ............................................................................... 39
13 Repair.........................................................................40
13.1 Fan replacement..................................................................... 41
14 Technical Specifications.............................................44

FG8101G01
Technical Documentation
Page 5 of 49 Version: 01.02; Date: 18.11.2022
2List of Figures
Figure 1........................................................................................................................................................ 12
Figure 2........................................................................................................................................................ 14
Figure 3........................................................................................................................................................ 18
Figure 4........................................................................................................................................................ 20
Figure 5........................................................................................................................................................ 20
Figure 6........................................................................................................................................................ 21
Figure 7........................................................................................................................................................ 23
Figure 8........................................................................................................................................................ 25
Figure 9........................................................................................................................................................ 27
Figure 10...................................................................................................................................................... 29
Figure 11...................................................................................................................................................... 31
Figure 12...................................................................................................................................................... 33
Figure 13...................................................................................................................................................... 35
Figure 14...................................................................................................................................................... 37
Figure 15...................................................................................................................................................... 41
Figure 16...................................................................................................................................................... 42
Figure 17...................................................................................................................................................... 43
3Change History
Version
Date
Editor
Change Description
01.00
23.09.2021
POM
Creating Document
01.01
28.01.2022
POD
Revision of the safety instructions
01.03
14.11.2022
POM
Formatting revised; Added new extension boards

FG8101G01
Technical Documentation
Page 6 of 49 Version: 01.02; Date: 18.11.2022
4Preliminary Remarks
This document describes the functions, operation, mounting and commissioning of the
FG8101G01 product, as well as the hot-plug extension boards that can be used.
WARNING
Read the instructions completely. This will help you to
avoid hazards and errors.
The product information contains important information
on the intended use, installation and start-up.
Keep the product information in a suitable place where
it can be accessed for maintenance and repair.

FG8101G01
Technical Documentation
Page 7 of 49 Version: 01.02; Date: 18.11.2022
4.1 Conformity data
CE conformity
This device complies with the requirements of the EU Directives
2014/30/EU "Electromagnetic Compatibility" and 2014/35/EU "Low
Voltage Directive".
For this purpose, the device bears the CE marking
(CE = Communautés Européennes = European Communities).
The CE indicates to the control authorities that the product complies
with the requirements of the EU Directive - in particular with regard to
health protection and safety of users and consumers - and may be
freely placed on the Community market.
UKCA- conformity
This device complies with the requirements of the Directives
S.I. 2012/3032 "The Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment Regulations 2012“,
S.I. 2016/1091 "The Electromagnetic Compatibility Regulations 2016"
and S.I. 2016/1101 "The Electrical Equipment (Safety) Regulations
2016". For this purpose, the device bears the CE marking
The UKCA indicates to the control authorities that the product
complies with the requirements of the Directive - in particular with
regard to health protection and safety of users and consumers - and
may be freely placed on the UK market.

FG8101G01
Technical Documentation
Page 8 of 49 Version: 01.02; Date: 18.11.2022
4.2 Signal words for warnings
This document is not a complete list of all safety measures required for operation of the
product. However, it does contain information that you must observe for your personal
safety and to prevent damage to property. The instructions are presented as follows,
depending on the degree of danger:
ISO 7000-0434A
Allgemeines Warnzeichen
Vorsicht / Caution
DANGER
The signal word denotes a hazard with a high degree of risk
which, if not avoided, will result in death or serious injury.
WARNING
The signal word indicates a hazard with a medium level of risk
which, if not avoided, may result in death or serious injury.
CAUTION
The signal word indicates a hazard with a low level of risk that, if
not avoided, could result in a minor or moderate injury.
IEC 60417-6042
Vorsicht, Risiko eines
elektrischen Schlages /
Caution, risk of electric shock
DANGER
The signal word indicates a hazard with electrical voltage with a
high degree of risk.
Danger of Electric Shock!
IEC 60417-5041
Vorsicht, heiße Oberfläche /
Caution, hot surface
CAUTION
The signal word indicates a hazard with high device temperatures
Risk of burns
During operation, high device temperatures may occur depending
on the operating parameters and type.
Allow the unit to cool down before starting maintenance work.
IEC 60417-6222
Allgemeine Information, Hilfe
/ Information, general; help,
Note
A note in the sense of these instructions is important information
about the product or the respective part of the instructions to
which special attention is to be drawn.

FG8101G01
Technical Documentation
Page 9 of 49 Version: 01.02; Date: 18.11.2022
5Safety instructions
Note
The product information is intended exclusively for qualified electricians.
This document is not a complete list of all safety measures required for
operation of the product. However, it does contain information that you must
observe for your personal safety and to avoid damage to property. The notes
are presented as follows, depending on the degree of danger:
Note
Assembly, installation, commissioning and repairs of electrical devices may
only be carried out by a qualified electrician.
It is essential to observe the safety regulations and generally applicable
technical rules relevant to the installation location.
Observe the applicable standards and regulations for system installation.
Prevent malfunctions and thus avoid personal injury and damage to property.
CAUTION
Damage to the device due to overvoltage
Ensure that the power supply is correct.
Take suitable lightning protection measures to ensure that the permitted
voltage is not exceeded at the connections.
DANGER
Danger of Electric Shock
The device is operated with dangerous voltages.
It is imperative that you observe the installation instructions for the respective
extension boards.

FG8101G01
Technical Documentation
Page 10 of 49 Version: 01.02; Date: 18.11.2022
5.1 Intended Use
The equipment may only be operated under the ambient conditions described in this
document.
Correct and safe operation of the product requires the following:
A proper transport
Proper storage, installation and assembly
Proper operation and maintenance
When operating electrical equipment, certain parts are inevitably under dangerous
voltage, or may have elevated temperatures.
If not handled properly, death, serious injury or property damage may result.
The equipment must be grounded at the ground terminal before any connections
are made.
Dangerous voltages may be present in all circuit parts connected to the power
supply.
Note
The manufacturer accepts no liability for applications that deviate from or go
beyond the intended use.

FG8101G01
Technical Documentation
Page 11 of 49 Version: 01.02; Date: 18.11.2022
6Device description
The FG8101G01 is a modular time reference system, which can serve most different
application cases by the supported hot-plug extension boards (in the following text only
called extension board/s).
A distinction is made between four functionalities that can be provided by extension
boards:
Power Supply Unit (PSU): Power supplyextension, which supplies the FG8101G01
with power.
Management Controller (MC for short): Management extension, with which the
FG8101G01 and all its extension boards can be managed.
Time Domain Controller (TDC for short): Time source extension, extension boards
with this functionality have a connector for a time source and supply the
FG8101G01 and the rest of the extension boards with a highly accurate time signal
Service Provider (SP for short): process the time signals provided by the TDCs and
thus generate a time output for the customer
Note
An extension board can provide more than one functionality.

FG8101G01
Technical Documentation
Page 12 of 49 Version: 01.02; Date: 18.11.2022
6.1 Extension board positions
Figure 1
Figure 1 shows the rear panel of the FG8101G01, with labels for the individual positions
for extension boards from POS1 to POS8. The following table lists the functionalities that
are supported on the individual positions:
CAUTION
Extension boards positions
Extension boards fulfil their proper function only at the designated insertion
position in the system. However, if an extension boards is incorrectly
positioned, the rest of the system behaviour is not affected.

FG8101G01
Technical Documentation
Page 13 of 49 Version: 01.02; Date: 18.11.2022
6.2 PSU - Power Supply Unit
Up to 2 PSUs are supported in FG8101G01. A PSU converts the voltage on its supply
voltage input connector(s) to the device internal supply voltage.
If two PSUs are operated in one FG8101G01, then a 1 out of 2 redundancy is obtained.
6.3 MC - Management Controller Board
In FG8101G01 one MC is supported. The MC distributes the configuration and updates
and collects the status of the FG8101G01 and the remaining extension boards via the
internal management bus. Additionally, the MC provides parts of the collected status via
the display of the FG8101G01.
6.4 TDC - Time Domain Controller Board
In FG8101G01 up to 2 TDCs are supported. One TDC processes the time signal
connected to the corresponding connector of the TDC extension boards, converts it to an
internal protocol, which is routed to the FG8101G01 and the remaining extension boards
via a TDC interface.
FG8101G01 has two TDC interfaces, each of which is routed to all extension boards in
the FG8101G01.
6.5 SP - Service Provider
In FG8101G01 up to 6 SP are supported. A SP synchronizes to one of the two TDC
interfaces and thus generates its time output (e.g. NTP).
Each SP can also synchronize to both TDC interfaces of the FG8101G01 and thus
generate its time output. Which TDC interface is the primary synchronization source of a
SP can be configured per SP.

FG8101G01
Technical Documentation
Page 14 of 49 Version: 01.02; Date: 18.11.2022
6.6 Minimal configuration of a FG8101G01
To operate a FG8101G01 as a time reference system the following functions must be
provided at least once by an extension board in the FG8101G01: PSU, MC, TDC, SP
Note: The MC functionality is only needed for the management (configuration and
monitoring) of the FG8101G01 and the extension boards and for the data indication on
the display of the FG8101G01. If the extension board with MC functionality is pulled out
of the FG8101G01 or fails due to a defect, then the time output of the extension boards
with SP functionality is not affected as long as one extension board with PSU and one
with TDC functionality are still operated in the FG8101G01.
6.7 Front cover
Figure 2
Figure 2 shows the various elements of the front panel:
1… LEDs of the front panel
2… Display of the front panel
3… Button of the front panel
2
1
3

FG8101G01
Technical Documentation
Page 15 of 49 Version: 01.02; Date: 18.11.2022
6.7.1 LEDs
The LEDs show the current status of the FG8101G01.
If only the red LED is on, then there is an error in the FG8101G01 or at an extension
board.
If only the yellow LED is on, then there is a warning in the FG8101G01 or on an extension
board, but no error.
If only the green LED is on, then there are no errors or warnings in the FG8101G01 or at
the extension boards.
If all three LEDs are on, then no extension board with MC functionality is accessible from
the FG8101G01 (this is the case, for example, if the extension board with MC functionality
is booting).
Additionally, in the first 6 seconds after a reboot of the FG8101G01 aLED test is executed,
where always 2 LEDs are on at the same time. Starting with yellow and red, green and
red, green and yellow, then the run is performed one more time. Each combination is
displayed for one second.
6.7.2 Button
The button can be used to switch between the different screens on the display.
If the button is pressed briefly (100 to 500ms), the display switches to the next screen.
If the button remains pressed, an event is triggered every 500ms that simulates a short
button press. This way you can quickly scroll through all screens.
6.7.3 Display
With the help of the display the article and serial numbers of the FG8101G01 and the
extension boards can be queried, as well as basic information of the individual extension
boards.

FG8101G01
Technical Documentation
Page 16 of 49 Version: 01.02; Date: 18.11.2022
In the first 6 seconds after a reboot of the FG8101G01 a display test is performed, where
the backlight of the display is switched on and off and each of the 40x2 blocks of the
display is shown alternately empty and full.
After the display test, the FG8101G01 screen showing the part number and serial number
of the FG8101G01 on the display is shown for 30 seconds and the backlight is turned on.
Then the display goes into the IDLE state.
In the IDLE state all of the 40x2 blocks of the display are blank and the backlight is off. By
a short press of the button, depending on whether an extension board with MC
functionality is accessible from the FG8101G01, either the FG8101G01 screen (extension
board with MC functionality not accessible) or the TDC screen (extension board with MC
functionality accessible) is displayed.
The TDC screen displays the time information of the two TDC positions in the
FG8101G01. If there is no extension board with TDC function on POS2, then "TD1 -" is
displayed in the first line. If there is no extension board with TDC function on POS 6, then
"TD2 -" is displayed in the second line. Otherwise, the two lines will first display the
accuracy, then the date and time, as well as summer and winter time and leap second
changeover status from the corresponding TDC position. This screen is active for 30
seconds, then the display changes to the IDLE state unless the button is pressed within
the 30 seconds, in which case the display changes to the POS14 screen.
The POS14 screen displays the part numbers of the extension boards plugged into POS1
through POS4. This screen is active for 30 seconds, then the display will change to the
IDLE state unless the button is pressed within the 30 seconds, then it will change to the
POS58 screen.
The POS58 screen displays the part numbers of the extension boards plugged into POS5
through POS8. This screen is active for 30 seconds, then the display will change to the
IDLE state unless the button is pressed within the 30 seconds, then it will change to the
POS1 screen.

FG8101G01
Technical Documentation
Page 17 of 49 Version: 01.02; Date: 18.11.2022
The POS1 screen displays the part number of the extension board that is in POS1 and
status information that depends on the extension board type. This screen is active for 30
seconds, then the display changes to the IDLE state, unless the button is pressed within
the 30 seconds, then it changes to the POS2 screen.
The POS2 through POS8 screens are identical to the POS1 screen. The only differences
are the position for which they display the information and which screen is changed to by
pressing the button. It will always change to the next position number and from the POS8
screen it will change to the FG8101G01 screen.
If the button on the FG8101G01 screen is pressed within 30 seconds, the system changes
to the TDC screen, otherwise to the IDLE state.

FG8101G01
Technical Documentation
Page 18 of 49 Version: 01.02; Date: 18.11.2022
7System mounting FG8101G01
FG8101G01 is designed for installation in a 19" control cabinet. The following steps must
be carried out for installation in the 19" control cabinet:
CAUTION
Thermic
The lateral ventilation openings on the left and right must not be covered.
Otherwise, the ventilation is ineffective and the maximum permissible
operating temperature of the device may be exceeded due to insufficient
convection and/or thermal coupling with surrounding devices.
Fire protection must be ensured in the installed state.
Insert the FG8101G01 into the 19" control cabinet and screw it tight to the front
retaining brackets with 4 screws.
FG8101G01 must be connected to at least one of the two grounding screws
for potential equalization (the positions of the grounding screws are shown in Figure
3). A grounding cable with at least 1.5mm² must be used.
Figure 3
Note
Protection class 1
The system is a protection class 1 device and may only be operated with a
grounded connection.

FG8101G01
Technical Documentation
Page 19 of 49 Version: 01.02; Date: 18.11.2022
8Connection of the supply and data
lines
The FG8101G01 time reference system is designed for operation on hazardous voltages.
WARNING
Failure to follow the safety instructions in this manual can result in serious
personal injury and property damage.
Observe the safety instructions attached to the device.
The following must be observed before connecting to the power supply:
A grounding cable must be connected to the ground connection of the device.
Proper and undamaged supply line routing must be ensured.
The power supply should be connected with a short, low-inductance cable.
Ensure that all supply cables are laid without damage.

FG8101G01
Technical Documentation
Page 20 of 49 Version: 01.02; Date: 18.11.2022
9Extension boards
9.1 Mounting of extension boards
To mount an extension board, the blind cover of the corresponding position must be
removed first. To do this, the two captive screws of the blind cover must be removed
from the FG8101G01.
Figure 4
Figure 4 shows a FG8101G01 with the blind covers of POS1 and POS2 removed.
Then the extension board must be inserted into the desired position.
For POS2 to POS4 and POS6 to POS8, the circuit board of the extension board must be
inserted between the guides of the corresponding position (see Figure 5)
Figure 5
