HORNER HE-XT100 User manual

MAN0868-01 12 October 2007 PAGE 1
HE-XT100 Specifications/Installation
1 Specifications
HE-XT100 Specifications
General Specifications
Required
Power
(Steady State) 130 mA @ 24 VDC
Required
Power (Inrush) 30 A for 1 ms @ 24 VDC
Primary Power
Range 10 – 30 VDC
Relative
Humidity 5 to 95% Non-condensing
Clock Accuracy +/- One Minute/Month at 20C
Operating
Temperature -10°C to +60°C
Terminal Type Screw Type, 5 mm Removable
Weight 12 oz. (340.19 g)
CE
UL
See Compliance Table at :
http://www.heapg.com/Support/compliance.htm
2 Panel Cut-Out and Dimensions
Note: Max. panel thickness: 5 mm.
Refer to XLt User Manual (MAN0863) for panel box information and
a handy checklist of requirements.
Note: The tolerance to meet NEMA standards is ±0.005” (0.1 mm).
3 Ports / Connectors / Cables
Note: The case of the XLt is black, but for clarity, it is shown in a lighter gray color.
XLT OCS Model: HE-
X
T100
3.622 [92mm]
3.622 [92mm]
001XLE002
Power Connector
Power Up:
Connect to Earth Ground.
Apply 10 - 30 VDC.
Screen lights up.
Torque rating 4.5 – 7 Lb-In
CAN Connector
Use the CAN Connector when
using CsCAN network.
Torque rating 4.5 – 7 Lb-In
To Remove Back Cover:
Unscrew 4 screws located on
the back of the unit and lift lid.
CAUTION: Do not over tighten
screws when screwing the lid
back on.
Memory Slot:
Uses Removable Memory fo
r
data logging, screen captures,
program loading and recipes.
Horner Part No.: HE-MC1
Serial Communications:
MJ1: (RS-232 / RS-485) Use fo
r
Cscape programming and
A
pplication-Defined
Communications.
MJ2: (RS-232 / RS-485) Use fo
r
A
pplication-Defined
Communications.
Want More Information?
To download the XLt User Manual
(MAN0863), refer to Technical
Support in this document.
MJ1
(RS-232 / RS-485)
MJ2
(RS-232 / RS-485)
Memory Slot
NET 1
(CsCAN)
Powe
r
DIP
Switch

PAGE 2 12 October 2007 MAN0868-01
HE-XT100 Specifications / Installation
4 Wiring and Jumpers
Wire according to the type of inputs / outputs used, and select the
appropriate jumper option.
•Use Only Copper Conductors in Field Wiring, 60/75° C
a. External DIP Switch Settings
5 Safety
6 Technical Support
For assistance and manual updates, contact Technical Support at the following locations:
North America:
[phone]
http://www.heapg.com
email: [e-mail]
Europe:
(+) 353-21-4321-266
http://www.horner-apg.com
email: [email protected]
Wiring Specifications
For CAN wiring, use the
following wire type or equivalent:
Belden 3084, 24 AWG or larger.
Pin MJ1 Pins MJ2 Pins
Signal Direction Signal Direction
8 TXD OUT TXD OUT
7 RXD IN RXD IN
6 0 V Ground 0 V Ground
5 NC No
Connect NC No Connect
4 RTS OUT TX- OUT
3 CTS IN TX+ OUT
2 RX- /
TX- IN / OUT RX- IN
1 RX+ /
TX+ IN / OUT RX+ IN
1
8
Serial Communications:
MJ1: (RS-232 / RS-485) Use for Cscape programming and
A
pplication-Defined Communications.
MJ2: (RS-232 / RS-485) Use for Application-Defined
Communications.
A
s seen when looking at the top of the XLt unit :
Factory Use
(default – none)
MJ2 Termination
(default – none)
MJ1 Termination
(default – none)
001XLE037-R1
Warning: Consult
user documentation.
Warning: Electrical
Shock Hazard.
WARNING: To avoid the risk of electric shock or burns, always
connect the safety (or earth) ground before making any other
connections.
WARNING: To reduce the risk of fire, electrical shock, or physical
injury it is strongly recommended to fuse the voltage measurement
inputs. Be sure to locate fuses as close to the source as possible.
WARNING: Replace fuse with the same type and rating to provide
protection against risk of fire and shock hazards.
WARNING: In the event of repeated failure, do not replace the
fuse again as a repeated failure indicates a defective condition that
will not clear by replacing the fuse.
WARNING: Only qualified electrical personnel familiar with the
construction and operation of this equipment and the hazards
involved should install, adjust, operate, or service this equipment.
Read and understand this manual and other applicable manuals in
their entirety before proceeding. Failure to observe this precaution
could result in severe bodily injury or loss of life.
When found on the product, the following symbols specify:
All applicable codes and standards need to be followed in the
installation of this product.
Adhere to the following safety precautions whenever any type o
f
connection is made to the module:
Connect the safety (earth) ground on the power connector first
before making any other connections.
When connecting to electric circuits or pulse-initiating equipment,
open their related breakers.
Do not make connections to live power lines.
Make connections to the module first; then connect to the circuit to
be monitored.
Route power wires in a safe manner in accordance with good
practice and local codes.
Wear proper personal protective equipment including safet
y
glasses and insulated gloves when making connections to powe
r
circuits.
Ensure hands, shoes, and floor are dry before making any
connection to a power line.
Make sure the unit is turned OFF before making connection to
terminals.
Make sure all circuits are de-energized before making connections.
Before each use, inspect all cables for breaks or cracks in the
insulation. Replace immediately if defective.
The DIP Switches are used fo
r
termination of the RS-485 ports.
The XLt is shipped un-terminated.
To terminate, select one of the DIP
Switches and configure it based upon
the option that is desired.
