Hosen HS­-LW0610 User manual

HosenlightingTechnologyLimited



RGBW8W6PCSIndoorWallWasher
UserManual
HSLW0610


SupportTelep hon e :+86‐20‐37707017
SupportEmail:[email protected](QQ、Skype)
Website:http://www.hosenlighting.com

Copyright:ThedataatHosenlightingTechn ology Limitedcommontoall,toprohibitany
unauthorizedcopying,printinganddissemination.




HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent1Page，Total7Page(s)
Contents
Contents ............................................................................................................................................1
1.PackingList................................................................................................................................1
2.SchematicDiagram....................................................................................................................1
3.ProductFeatures .......................................................................................................................2
4.Specifications ............................................................................................................................2
4.1.PhysicalSpecifications...................................................................................................2
4.2.ElectricalSpecifications.................................................................................................2
5.InstallationMethod...................................................................................................................2
5.1.InstallationSteps ...........................................................................................................2
5.2.FixtureLinking...............................................................................................................3
5.3.ACPower .......................................................................................................................3
6.SafetyInstructions.....................................................................................................................3
7.OperationInstruction................................................................................................................3
8.Maintenanceandcleaning........................................................................................................4
9.Warranty ...................................................................................................................................4
10.TechnicalSupport..................................................................................................................5
11.Disclaimer..............................................................................................................................5
12.Appendix ...............................................................................................................................5
12.1.LEDDisplayExplanation ............................................................................................5
12.2.DMXChannelExplanation.........................................................................................6
13.AmendmentLog....................................................................................................................7



1. PackingList
¾RGBW4In18W6PCSIndoorWallWasher1pcs
¾UserManual1pcs
2. SchematicDiagram


HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent2Page，Total7Page(s)
3. ProductFeatures
¾Unlimitedprogrammingeffects
¾Speciallightingeffect
¾32‐bitcolor(16.7millioncolorcombinations)
¾Modular&highlyportable
¾Notechnicalexperiencerequired
¾Quickandeasyinstallation
¾Moreaffordablethananyexistingsolutions
¾Sealedforlong,durablelifetime
¾Nobulbstoreplace
¾Indooruseinwelltemperaterooms
4. Specifications
4.1. PhysicalSpecifications
ProductSeries:TraditionalStageLighting
ItemNo.:HS‐LW0610
Size:380LX68WX155H
NetWeight:2.3Kg
GrossWeight:3.0Kg
LEDs:RGBW4in1LED8W/PCStotal6pcs
Beam:□25°
Color:White
Material:Aluminum、Iron、Plastic
Controlmode:Auto‐runmode,DMX‐512mode,Soundactivemode
DMXChannels:3/7CH
ProtectLevel:IP30
Noise:55db1m
WorkingTemperature:‐25℃~+45℃
4.2. ElectricalSpecifications
Power:48W
Voltage:AC100‐240V50/60Hz
Fans:DC:24V0.17A6cm
ServiceLife:50000hour
Gray Level:256
5. InstallationMethod
5.1. InstallationSteps
1. Pleasehandthislightintothesuitableplacewithsuitableangel(ifoperatethelightin
externalplace,pleaseremembertogetsomewater‐proofcovertoprotectthem.).
2. Toconnectthesignalcable,plugonesideintoINsocketinthebackoflightandpluganother

HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent3Page，Total7Page(s)
sideintoOUTsignalconnectorintheDMX512board(signalinput:1=>Ground,2=>Data,
3=>data+).
3. Toconnectthecableandputintopower,themthelightstaysinthestatustoreceivethe
operationsignallike:Music,Automatic,andDMX512ect.Takenote:Pleaseoutoffthe
powerlineifyouwillnotoperateitforacertaintime.
5.2. FixtureLinking
TorunyourlightshowsofoneormorefixturesusingDMX‐512controllerortorun
synchronizedshowsontwoormorefixturesinmaster/slaveoperatingmode,youneedDMX
cablestolinktheunitsfromDMXINtoDMXOUT.
Notice:thelengthofsignalcablesshouldbewithin100meters,topreventthesignal
interferencebyotherappliancesbecauseofthelongsignalcables.


5.3. ACPower
Thefixtureisdesignedtoworkon100‐240V50/60Hz.Beforeapplyingpowertoaunit,check
thatthesourcevoltagematchestheunit’srequirement.
6. SafetyInstructions
This device has left the factory in perfect condition .in order to maintain this condition and to
ensure a safe operation , it is absolutely necessary for the user to follow the safety instructions
and warning notes written in this user manual
ÎIfthedevicehasbeenexposedtotemperaturechangesduetoenvironmentalchanges,do
notswitchitonimmediately.Thearisingcondensationcoulddamagethedevice.Leavethe
deviceswitchedoffuntilithasreachedroomtemperature.Thisdevicefallsunder
protection‐classI.Therefore,itisessentialthatthedevicebeearthed.
ÎTheelectricconnectionmustcarryoutbyqualifiedperson.
ÎThedeviceshallonlybeusedwithratevoltageandfrequency
ÎMakesurethepowercordisnevercrimpedordamagedbysharpedges.ifthiswouldbethe
case,replacementofthecablemustbedonebyanauthorizeddealer.
ÎAlwaysdisconnectfromthemains,whenthedeviceisnotinuseorbeforecleaningit.only
handlethepowercordbytheplug.Neverpullouttheplugbytuggingthepowercord
ÎDuringinitialstart‐upsomesmokeorsmellmayarise.thisisanormalprocessanddoesnot
necessarilymeanthatthedeviceisdefective,itshoulddecreasegradually.
7. OperationInstruction
ÎDon’tturnonthefixtureifit’sbeenthroughseveretemperaturedifferencelikeafter
transportationbecauseitmightdamagethelightduetotheenvironmentchanges.Somake
suretooperatethefixtureuntilitisinnormaltemperature.
ÎThislightshouldbekeepawayfromstrongshakingduringanytransportationormovement.
ÎDon’texposethefixtureinoverheat,moistureorenvironmentwithtoomuchdustwhen
installingit.Anddon’tlayanypowercablesonthefloor.Oritmightcauseelectronicshock

HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent4Page，Total7Page(s)
tothepeople.
ÎMakesuretheinstallationplaceisingoodsafetyconditionbeforeinstallingthefixture.
ÎMakesurethelensareingoodcondition.It’srecommendedtoreplacetheunitsifthereare
anydamagesorseverescratch
ÎMakesurethefixtureisoperatedbyqualifiedpersonnelwhoknowthefixturebeforeusing.
ÎKeeptheoriginalpackagesifanysecondshipmentisneeded.
ÎDon’ttrytochangethefixtureswithoutanyinstructionbythemanufacturerorthe
appointedrepairingagencies.
ÎInisnotinwarrantyrangeifthereareanymalfunctionfromnotfollowingtheusermanual
tooperateoranyillegaloperation,likeshockshortcircuit,electronicshock,lampbroke,etc.

8. Maintenanceandcleaning
The following points have to be considered during the inspection:
1. Allscrewsforinstallingthedevicesorpartsofthedevicehavetobetightlyconnectedand
mustnotbecorroded.
2. Theremustnotbeanydeformationsonthehousing.Fixationsandinstallationspots(ceiling,
suspension,trussing).
3. Mechanicallymovedpartsmustnotshowanytracesofwearingandmustnotrotatewith
unbalances.
4. Theelectricpowersupplycablesmustnotshowanydamage,materialfatigueorsediments.

Furtherinstructionsdependingontheinstallationspotandusagehavetobeadheringbyaskilled
installerandanysafetyproblemshavetoberemoved.

In order to make the lights in good condition and extend the life time .we suggest a regular cleaning
to the lights
1. Cleantheinsideandoutsidelenseachweektoavoidtheweaknessofthelightsdueto
accumulationofdust.
2. Cleanthefaneachweek.
3. Adetailedelectriccheckbyapprovedelectricalengineereachthreemonths,makesurethat
thecircuitcontactsareingoodcondition,preventthepoorcontactofcircuitfrom
overheating.

Werecommendafrequentcleaningofthedevicepleaseuseamoist,lint‐freecloth.Neveruse
alcoholorsolvents
Therearenoserviceablepartsinsidethedevicepleaserefertotheinstructionsunder
“installationinstructions”.

Should you need any spare parts , please order genuine parts
from you local dealer.
9. Warranty
ÎTheproductshave1yearstandardwarranty,wepromisetoprovidetechnicalsupportfor
thewholelife.
ÎArtificialdamageisnotinwarranty.
ÎFactoryrepair.Iftheelectroniccomponentsaredamaged,pleaseretainitthenexchangeit
withmanufacturertimely. Buyersbearthefreight.
ÎPowercable,DMXcableandoutercasingarenotinwarranty.


HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent5Page，Total7Page(s)
10. TechnicalSupport
SupportTelep hon e :+86‐20‐37707017
SupportEmail:[email protected](QQ、MSNassame)
Website:http://www.hosenlighting.com


WorkingTime:(BeiJingTime)
MondaytoFriday08:00~12:0013:30~17:3018:30~20:30
Saturday09:00~12:0013:30~17:00
Note:alltherestofChina'sholidays!
SupportTelep hon e :+86‐20‐37707017
SupportEmail:[email protected](QQ、MSNassame)

11. Disclaimer
Whileeverycarehasbeentakenwiththedetailsonthisspecificationsheet,wetakeno
responsibilityforanyinaccuraciescausedduringinstallation.Wereservetherighttochange
thesespecificationswithoutnoticetoalwaysensurethatthecustomerisreceivingasuperior
product.

12. Appendix
12.1. LEDDisplayExplanation


Turn on the main power, press “MENU” entering into main MENU, press “ UP”/
“DOWN” （+/-）to choose sub-menu, then press “SETUP”.

HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent6Page，Total7Page(s)


12.2. DMXChannelExplanation

CHANNEL Value
Function
Autorun Mode CH1= 0-127
CH1 0-127 Autorun mode (open)
0 OFF
1-64 Color fade effect
65-128 Color jump change effect
129-192
Sound active mode 1
CH2
193-255
Sound active mode 2
CH3 0--255 Speed of autorun

Overall mode CH1= 128-255
CH1 128-255
Overall mode (open)
0-128 Dimmer for all color
CH2 129-255
Strobe
CH3 0--255 All red dimmer
CH4 0-255 All green dimmer

HosenlightingTechnologyLimited
RGBW4In18W6PCSIndoorWallWasherCurrent7Page，Total7Page(s)
CH5 0-255 All blue dimmer
CH6 0-255 All white dimmer
CH7 0-255 Strobe speed

13. AmendmentLog
Ver.:1.0.12.122012‐12‐12Createthemanualfortheproduct.
Ver.:1.0.13.04022013‐04‐02ModifiedLEDs8W/PCS

