Hoshizaki Temp Guard RH3-SSB-GD Manual

OCT. 16, 2003
PARTS LIST
ISSUED: MARCH 8, 1999
REACH-INS
Reliability is a
beautiful thingTM
REVISED:
TempGuard
TM
Model
ITEM #: 71180
RH3-SSB-GD

HA
2
RH3-SSB-GD K-0 SEPT., 2000
N-6 MAY, 2003

HA
3
MATERIALABBREVIATIONS
ALUMINUM
AL = Aluminum
COPPER
CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide=Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride
RUBBER
VN = VinylNitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Synthetic rubber
EPH = Epichlorohydrin
STEEL
G.S = Galvanized steel
S.S = Stainless steel
P.S = Plated steel
PAS = Primed steel
AUXILIARYCODE
Ex.1 H-0 (Note) - = Part deleted.
x = Part deleted and replaced
Each year of production is assigned by "o" part (interchangeable).
a letter; "H" indicates 1998 ("I" is skipped)
"J" indicates 1999, etc. o = New (interchangeable) part for "x"
Ex.2 H-1 in the same auxiliary code.
Each time a part is changed non-interchangeably
in a year, this number advances.

HA
4
RH3-SSB-GD A. REACH-IN K-0, N-6
CC1
FF1
E
D
66a 7
11a
4a4
5
5a
2b 2c
2a2
B2 B3
B1B
8b 9
8a10
33a
8b 9
8a8
11b 11c
11a11
2d

HA
5
MODEL: RH3-SSB-GD TITLE:A. REACH-IN
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
B REFRIGERATION ASSEMBLY - 1A0497A01 1 1
B1 BOLT ASSEMBLY 8X45 437889-01 6 6
B2 HEX BOLT 8X70 7B01-0870 2 2
B3 WASHER 8 7W21-0800 2 2
C CONTROL PANEL ASSEMBLY - 2A1234A03 1 1
C1 T2 SCREW 4X8, SS 7P32-0408 10 10
D BODY–FINAL - 2A1133A03 1 1
E LABEL LOCATION - 3A1059G05 1 1
F PANEL-FRONT HINGED ASSEMBLY - 2A2011A03 1 1
F1 T2 SCREW 4X8, SS 7P32-0408 4 4
1 GUSSET-FRAME GS 3A1520-01 1 -
GS 4A2845-01 1
1a T2 SCREW 4X8, SS 7P32-0408 4 4
2 PANEL-SIDE, TOP SS 2A1800-01 2 2
2a TRUSS HEAD SCREW 5X10 7C32-0510 2 2
2b TAPER COLLAR SS 4H0171-01 2 2
2c SCREW COUNTERSUNK 5X20, SS 7C42-0520 2 2
2d BRACKET – HINGE GS 4A2306-01 2 2
3 FRAME-SIDE TOP GS 2A1803-01 2 2
3a TRUSS HEAD SCREW 5X10 7C32-0510 8 8
4 TOP UL COVER GS 2A1118-02 1 1
4a T2 SCREW 4X8, SS 7P32-0408 7 7
5 REAR UL COVER GS 2A1117-01 1 1
5a T2 SCREW 4X8, SS 7P32-0408 7 7
6 WIRE CLAMP PS 4A0809-03 1 1
6a T2 SCREW 4X8, SS 7P32-0408 1 1
7 POWER CORDSET - 4A1543-01 1 1
8 DISTRIBUTOR-AIR TOP ABS 1A0152-03 1 1
8a T2 SCREW 4X8, SS, SS 7P32-0408 14 14
9 GASKET L=1061 4A0808L02 2 2

HA
6
MODEL: RH3-SSB-GD TITLE:A. REACH-IN
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
10 DISTRIBUTOR-AIR TOP ABS 1A0152-04 1 1
11 DIVERTER-AIR 2A1965-01 1 1
11a T2 SCREW 4X8, SS, SS 7P32-0408 2 2
11b TAPERCOLLAR SS 4H0171-01 2 2
11c SCREW COUNTERSUNK 5X20, SS 7C42-0520 2 2

HA
7
RH3-SSB-GD B. REFRIGERATION SYSTEM (1/2) K-0, N-6
HH1
LL1
GG1
21
12
2
1
34
35
30
9
10
JJ1
7
34 34a 34b

HA
8
23a23
24a24
22
820
K1 K
31
17 18 19
15 15a 16
14
RH3-SSB-GD B. REFRIGERATION SYSTEM (2/2) K-0
Detail
29
27
13
28
25 26
36

HA
9
23a23
24a24
22
820
K1 K
31
17 18 19
15 15a 16
14
RH3-SSB-GD B. REFRIGERATION SYSTEM (2/2) N-6
Detail
29
27
13
28
25 26
36

HA
10
MODEL: RH3-SSB-GD TITLE:B. REFRIGERATION ASSEMBLY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
G CONDENSER ASSEMBLY - 2A1458A01 1 1
G1 T2 SCREW 4X8, SS 7P32-0408 4 4
H EVAPORATOR ASSEMBLY - 2A1509A02 1 1
H1 T2 SCREW 4X8, SS, SS 7P32-0408 2 2
J EVAPORATOR SHROUD ASSEMBLY - 3A1009G01 1 1
J1 TRUSS HEAD SCREW 4X16, SS 7C32-0416 2 2
K EVAPORATOR DRAIN PAN ASSEMBLY - 4A0679A02 1 x1
- 4A0679A03 o1
K1 T2 SCREW 4X8, SS 7P32-0408 6 6
L CONTROL BOX ASSEMBLY - 2A1785A01 1 1
L1 TRUSS HEAD SCREW 4X16 7C32-0416 4 4
1 COMPRESSOR - 4A2125-01 1 1
2 SPACER 027-0072-02 434404-01 4 4
3 GROMMET 027-0073-00 434403-01 4 4
4 BOLT - 437889-01 4 4
5 - - -
6 - - -
7 EVAPORATOR CASE COVER - 2A1086G01 1 1
8 COMPRESSOR – CONDENSER ASSEMBLY - 3A1607G01 1 1
9 PROCESS TUBE - 3A1783G01 1 1
10 TEV ASSEMBLY - 3A1346G02 1 1
11 - - - 1 1
12 TUBE COND-DRIER CU 4A2115-01 1 1
13 PIPE-EVAP DRAIN PVC 3A0143-01 1 1
14 THERMISTOR-CABINET - 4A1429-02 1 1
15 THERMISTOR BRACKET (A) ABS 433964-01 1 1
15a TRUSS HEAD SCREW 4X16, SS 7C32-0416 2 2
16 THERMISTOR BRACKET (B) SS 433920-01 1 1
17 ELBOW-TUBING PP 4A0711-01 1 1
18 BUSHING SB-750-625 420470-13 1 1

HA
11
MODEL: RH3-SSB-GD TITLE:B. REFRIGERATION SYSTEM
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
19 VINYL HOSE L=350 7730I3812 1 1
20 THERMOSTAT-CLEAN FILTER 37TJ32 4A0484-01 1 1
21 FILTER-CONDENSER - 3A0277-03 1 1
22 DRIER C-05E73 4A0924-01 1 1
23 DRIER STAND GS 4A1945-01 1 x1
GS 4A0949-01 o1
23a T2 SCREW 4X8, SS 7P32-0408 2 2
24 DRIER-BRACKET GS 4A0806-01 1 1
24a T2 SCREW 4X8, SS 7P32-0408 2 2
25 EXP VALVE COVER (A) PE FOAM 3A0372-01 1 1
26 COVER-EXP VALVE PE FOAM 3A1495-01 1 1
27 HOLDER-EXP VALVE 1/2 SS 3A0112-01 1 1
28 SEAL-REF TUBING NP 4A1908-01 2 2
29 HOSE CLAMP 6808 443461-01 1 1
30 ELBOW CU 419753-02 1 1
31 ELBOW CU 419753-01 1 1
32 WIRE TIE (TWIST) 232-160607-00-0101 4A1223-01 4 4
33 FOAM TAPE L=300 8208-0005 1 1
34 DRAW LATCH 97-50-224-11 4A1710-01 4 4
34a T2 SCREW 4X8, SS 7P32-0408 8 8
34b TRUSS HEAD SCREW 4X16, SS 7C32-0416 4 4
35 SUCTION LINE ASSEMBLY - 3A1606G01 1 1
36 PRESSURE SWITCH SHOWN ON COND.
ASSEMBLY
3A0335-01 -
ACB-2UB25 4A2516-02 1

HA
12
RH3-SSB-GD C.CONTROL PANEL ASSEMBLY K-0, N-6
12
12
7a
12
12
1
14
15
15
11
11
10
10
11
23
64
7
9
5
88a
14
15
17 18
16
17
14
13

HA
13
MODEL: RH3-SSB-GD TITLE:C. CONTROL PANEL ASSEMBLY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
1 PANEL-CONTROL (PAINTED GD) - 3A1572G01 1 x1
- 1A0632G01 o1
2 LABEL-DISPLAY - 4A1558-01 1 1
3 MOUNT-DISPLAY BOARD PC 3A0823-01 1 1
4 BOARD-DISPLAY 3287A000 2A0883-01 1 1
5 NYLON SCREW 50M030050G006 4A1397-01 4 4
6 PALNUT SR 125004 4A1398-01 6 6
7 BOARD COVER GS 3A1060-01 1 1
7a T2 SCREW 4X8, SS 7P32-0408 2 2
8 CONTROL PANEL COVER GS 3A1066-01 1 1
8a T2 SCREW 4X8, SS 7P32-0408 2 2
9 RIBBON CABLE D-HA-104 4A1106-02 1 1
10 PLUG-HOLE PE 4A0420-02 3 3
11 LOCKING HOLE PLUG 2663(BLACK) 4A0586-04 3 3
12 LOCKING HOLE PLUG 2703(BLACK) 4A0586-03 6 6
13 SWITCH-ROCKER 1801-1102 4A0418-01 1 1
14 STRAIN RELIEF - 4A2148-02 3 3
15 WASHER - 4A2147-01 6 6
16 GROMMET STRIP L=36 4A1341L01 1 1
17 GROMMET STRIP L=66 4A1341L01 3 3
18 GROMMET STRIP L=340 4A1341L01 1 1

HA
14
MM1
N
213
45
6
10
11
RH3-SSB-GD D. BODY-FINAL K-0, N-6
7
7a 812
9

HA
15
MODEL: RH3-SSB-GD TITLE:D. BODY-FINAL
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
M BODY-PREFINAL - 2A1132A03 1 1
M1 TRUSS HEAD SCREW 5X10, SS 7C32-0510 18 18
N MULLION-VERTICAL - 2A1289A02 2 2
1 GLASSDOOR (RIGHT) - 2A1720-01 2 2
2 GLASSDOOR (LEFT) - 2A1730-01 1 1
3 CANOE CLIP 254-090301-00-0108 4A0629-01 8 8
4 BRACKET CORNER SS 4A0350-01 8 x8
SS 4A2655-01 o8
5 - - -
6 COVER-CORNER ABS 3A0221-01 8 x8
ABS 3A1751-01 o8
7 WIRE CLAMP PS 4A0809-02 3 3
7a TRUSS HEAD SCREW 4X6 7C32-0406 3 3
8 HINGE-TOP GLASSDOOR (RIGHT) SS 3A1568-01 2 2
9 HINGE-BOTTOM GLASSDOOR (RIGHT) SS 3A1569-01 2 2
10 HINGE-TOP GLASSDOOR (LEFT) SS 3A1550-01 1 1
11 HINGE-BOTTOM GLASSDOOR (LEFT) SS 3A1551-01 1 1
12 PIN, TORQUE 15-10320-0001 4A2071-01 2 2

HA
16
RH3-SSB-GD E. LABEL LOCATION K-0, N-6
6
4
2
9
3
5
10
8
7
A
DETAIL A

HA
17
MODEL: RH3-SSB-GD TITLE:E. LABEL LOCATION
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
1 - - -
2 WIRING LABEL PVC FILM 2A1787-01 1 1
3 LABEL-R404A - 4A0960-01 1 1
4 LABEL-PENGUIN-HA (L) - 4A0526-02 1 1
5 LABEL-ON/OFF PVC FILM 4A0522-01 1 1
6 EMBLEM-HOSHIZAKI - 4A0560-01 1 1
7 LABEL-DISPLAY INFO PVC FILM 3A1413-01 1 1
8 LABEL-DOOR HEATER SWITCH PVC FILM 4A1039-01 1 1
9 CAUTION LABEL PVC FILM 4A1931-01 1 1
10 LABEL-GLASS DOOR HEATER SWITCH PVC FILM 4A2076-01 1 1

HA
18
RH3-SSB-GD F. PANEL - FRONT HINGED ASSEMBLY K-0, N-6
4
2
3a
1
3

HA
19
MODEL: RH3-SSB-GD TITLE:F. PANEL-FRONT HINGED ASSEMBLY
INDEX
NO.
DESCRIPTION
MATERIAL OR
MODEL
PART
NUMBER
REQUIRED NUMBER
NUMBER K-0 N-6
1 HINGE-FRONT PANEL (L) GS 4A2153-01 1 1
2 HINGE-FRONT PANEL (R) GS 4A2154-01 1 1
3 CHANNEL-HINGE GS 4A2170-01 2 2
3A TRUSS HEAD SCREW 5X8 7C32-0508 4 4
4 PANEL-FRONT SS 1A0286-01 1 -
1A0624-03 1

HA
20
RH3-SSB-GD G. CONDENSER ASSEMBLY K-0
5
3
4 6 6a 89
12
15
16
17 17a
1
13
22a
77a
10
11
13a
14 14a
