HHWWRR4400AA DDIIMMEENNSSIIOONNSS
W x D x H
WORK OP REFRIGERA ORS
Warranty
Valid in Unit d Stat s, Canada, Pu rto Rico, & U.S. T rritori s. Contact factory for warranty in
oth r countri s.
Two Year - Parts & Labor on ntir machin .
Five Year - Parts on: Compr ssor.
HWR40/68/96A
HHWWRR6688AA DDIIMMEENNSSIIOONNSS
W x D x H
68 x 32.3 x 39.9*
*with 6" cast rs
Item #
Project:
Qty:
Hoshizaki r s rv s th right to chang sp cifications without notic .
HWR40A
Shown
40.25 x 32.3 x 39.9*
*with 6" cast rs
EMPGUARD®Self-Contained Worktop Refrigerators with EverCheck®Controls
HWR96A
Shown
*AutoCad availabl on KCL
HHWWRR9966AA DDIIMMEENNSSIIOONNSS
W x D x H
95.8 x 32.3 x 39.9*
*with 6" cast rs
HWR68A
Shown
•Stainless steel interior and exterior top, front, sides and bottom with galvanized steel back for long life,
durability and easy maintenance. The stainless steel top includes a 4" backsplash
•(2) heavy duty epoxy shelves per section are standard, mounted on stainless steel pilasters, shelves are
adjustable in 1" increments
•Cabinet door perimeter heater provides condensation control in high humidity environments and is
equipped with a back-up heater should the primary heater fail
•Cabinet and doors are insulated with 23/8" CFC free, foamed-in-place polyurethane
•6" heavy duty casters (2 with brakes) are standard
•Doors are constructed of high-grade 300 series stainless steel inside and out
•Doors are self-closing with a stay open feature at 105°
•Stepped door design protects door gasket when product is removed from the cabinet; Snap in
magnetic door gaskets are durable and easily removed
•Door hinging is reversible at the factory
•High-efficiency refrigeration system is designed with a large capacity condenser and evaporator
resulting in lower overall power consumption; Evaporator coil is coated for extended life
•TempGuard's®EverCheck® controls monitor high and low temperatures, high pressure, clean filter and
cabinet temperature functions and provide visual alarms to alert operator to possible problems
•Cartridge-style refrigeration system is easily removable from the main unit for ease of service
•Refrigeration system is equipped with solid state digital controls (Fahrenheit or Celsius display)
•Refrigeration system is designed to maintain proper temperatures with "zero" clearance on ends and at rear
•Defrost cycles are time initiated - temperature terminated
•Removable, cleanable air filter protects condenser and reduces cleaning requirements
•Hot gas condensate evaporator is standard
•nits equipped with 8' - 6" cord and plug
•Refrigerant: R-134A with capillary tube controls
* The HWR40A, HWR68A and HWR96A worktop refrigerators are ENERGY STAR ertified.
**
HWR40/68/96A
5/08
Item # 13168
*

115/60/1
5.0
15.0
5 - 15P
3.2
449
1442 (1/5HP)
104 - 126
45° - 100°F
21° to 53°F
R-134A
Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Pea htree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki. om Printed in U.S.A.
HWR40/68/96A
WORK OP REFRIGERA ORS
O P I O N S
• 6" Legs • Bull nose top (front & rear)
• Additional epoxy shelves • Tray pan rack slides
(accommodates 18" x 26" pans)
• Drawers (two high, two 6" deep • Reversible hinging (factory
12" x 20" pans/drawer) modification)
• Stainless steel back
5.6"
DOOR SWING
DIMENSIONS/CAPACI Y
Model #
Interior Stor ge
C p city (CF)
Over ll Width
Over ll Depth
Height
(including 6" casters)
Depth with
Door open t 90°
Door Opening Width
Door Opening Height
Adjust ble Shelves
Shelf Dimensions
(W x D)
Cr ted Shipping Weight
Cr ted Height
Cr ted Width
Cr ted Depth
HWR40A
ELEC RICAL & REFRIGERA ION DA A
Model #
Volt ge
Amper ge
HACR Bre ker
Electric l Connection
(NEMA)
*Energy Consumption
(kwh/day)
* He t Rejection
(BTU/Hr.)
Approxim te Nomin l
Compressor BTU/Hr.(HP)
Volt ge R nge
Ambient Temp. R nge
Control Setpoint R nge
*Refriger nt
8.5 ft3
40.25"
32.3"
39.9"
56.8"
22.5"
24.3"
2
22.4" x 24.6"
317 l
40.5"
44.25"
35.5"
18.8 ft3
68"
32.3"
39.9"
56.8"
22.5"
24.3"
4
25" x 24.6"
443 l
40.5"
72"
35.5"
HWR68A
115/60/1
5.0
15.0
5 - 15P
4.5
638
1442 (1/5HP)
104 - 126
45° - 100°F
21° to 53°F
R-134A
HWR40A HWR68A
PLAN VIEW (ALL UNITS)
SIDE VIEW (ALL UNITS)
HWR40A
HWR96A
56.8"
66.3"
56.8"
24.5" 24.5"
5.6"
7.4"
30"
30" 24.3"
35.9"
5.9"
27"
32.3"
1.9"
35.9"
30"
* Based on 100°F am ient cycling at setpoint
22.5"
40.25"
4"
2"
39.9"
25.6"
DDIIMMEENNSSIIOONNSS
W x D x H
HWR40A
40.25 x 32.3 x 39.9*
HWR68A
68 x 32.3 x 39.9*
HWR96A
95.8 x 32.3 x 39.9*
*with 6" cast rs
WO R K TO P R E F R I G E R ATO R S
• 1 section worktop refrigerator
• 2 section worktop refrigerator
• 3 section worktop refrigerator
29.1 ft3
95.8"
32.3"
39.9"
56.8"
22.5"
24.3"
6
25.9" x 24.6"
561 l
40.5"
99.8"
35.5"
HWR96A
115/60/1
6.0
15.0
5 - 15P
5.2
740
2010 (1/4HP)
104 - 126
45° - 100°F
21° to 53°F
R-134A
HWR96A
40.25" 68" 95.8"
HWR40A HWR68A HWR96A
56.8"
24.5"
7.4"
94"
5.6"
25.6" 25.6" 25.6"
HWR68A
