Hosiden Besson Banshee Excel Lite Xenon Dimensions
11 St. Joseph’s Trading Estate, St. Joseph’s Close, Brighton & Hove, East Sussex BN3 7EZ, England.
The new Banshee Excel LiteTM combines the
aesthetics of the Excel Sounder with the very
latest strobe technology to create an extremely
efficient Xenon Sounder/ Beacon combination.
Available in a wide range of colours
the Banshee Excel Lite will
meet the majority of Fire
and Security applications
where dual notification
is required. The unit
has the option of
independent or
combined operation.
Manufactured in
a Flame Retardant
Polymer in a choice
of Base colours and
5 Lens colour options.
The Banshee Excel
Lite utilises the same
easy push and twist
bayonet fixing as the Banshee Excel
and the original MT Banshee.
• EN54 - 3 pending
approval CPD, LPC & VdS
• Ultra low current
consumption
• 32 user selectable tones
• Choice of 3 volume
levels
• Rated IP66 or IP45
• Installation via side
& rear cable entry
• Easy push & twist
lockable bayonet
mounting
• Temperature range from
–20 to +700C
• Simple in & out wiring
blocks
• Full range of accessories
available
Banshee Excel Lite Xenon
TM
Colours available
No. Sound Frequencies and Patterns code Description EN54-3 Typ SPL@1m Typ Current
12345 28Vdc on axis mA
see notes 12V 24V 12V 24V
1 800Hz to 950Hz swept at 120Hz 00000 Banshee Buzz LF - 94 100 6 12
2 800Hz to 950Hz swept at 9Hz 10000 Banshee Fast Sweep LF 394 100 6 12
3 800Hz to 950Hz swept at 3Hz 01000 Banshee Slow Sweep LF - 94 100 6 12
4 Continuous at 850Hz 11000 Banshee Continuous LF - 94 100 6 12
5 830Hz to 970Hz swept at 9Hz 00100 Banshee Fast Sweep LF (New) - 93 100 6 12
6 800Hz to 970Hz swept at 1Hz 10100 Medium Sweep LF 394 100 6 12
7 Continuous at 970Hz 01100 Continuous LF - 94 99 6 13
8 Intermittant at 950Hz 1sec on, 1sec off 11100 Backup Alarm LF - 93 99 7 14
9 Alternating 800Hz/1000Hz, 0.5sec each sound 00010 Alternate LF - 94 100 6 13
10 800Hz/1000Hz swept at 0.5sec 10010 Medium Sweep LF - 94 100 6 12
11 Alternating tones 800/950Hz at 3Hz 01010 Alternate LF - 94 101 6 12
12 2400Hz to 2900Hz at 120Hz 11010 Banshee buzz HF - 102 109 16 35
13 2400Hz to 2900Hz at 9Hz 00110 Banshee Fast Sweep HF - 103 110 17 35
14 2400Hz to 2900Hz at 3Hz 10110 Banshee Slow Sweep HF - 103 110 17 35
15 Continuous2900Hz 01110 Banshee Continuous HF - 103 109 19 39
16 2450Hz to 3100Hz swept at 9Hz 11110 Banshee Fast Sweep HF (New) - 103 109 18 36
17 Intermittant at 2900Hz 1sec on, 1sec off 00001 Backup Alarm HF - 103 109 18 36
18 Alternating tones 2400/2900Hz at 3Hz 10001 Alternate HF - 104 110 16 36
19 500Hz rising to 1200Hz over 3.5, silence 0.5sec 01001 Slow Whoop 395 101 6 12
20 1200Hz falling to 500Hz over 1sec, silence 10ms 11001 Din Tone (DK) 393 100 5 10
21 554Hz for 100ms and 440Hz for 400ms 00101 French Fire Sound 390 96 4 7
22 420Hz repeating 0.625sec on, 0.625sec off 10101 Australian Alert Signal - 89 94 3 6
23 500Hz rising to 1200Hz over 3.75sec on, 0.25sec off 01101 Australian Evacuation Signal - 95 101 6 12
24 950Hz for 0.5sec on 0.5sec off, for 3 phases, silence for 1.5sec 11101 US Temporal Tone LF - 93 99 5 10
25 2900Hz for 0.5sec on 0.5sec off, for 3 phases, silence for 1.5sec 00011 US Temporal Tone HF - 103 109 13 26
26 Intermittant 660Hz 150ms on, 150ms off 10011 Swedish Tone (Fire) - 90 96 3 6
27 Continuous 660Hz 01011 Swedish Tone (All Clear) - 91 97 5 9
28 Intermittant 970Hz 500ms on, 500ms off 11011 ISO8201 LF - 90 96 5 10
29 Intermittant 2900Hz 500ms on, 500ms off 00111 ISO8201 HF - 103 109 13 27
30 Yodel 800Hz/1000Hz, 0.25sec each frequency 10111 BT Banshee (FP1063.1) - 94 100 6 12
31 Continuous 1000Hz 01111 BT Banshee (FP1063.1) - 88 94 6 14
32 Bell Tone 11111 Bell Tone - 94 99 12 25
• Volume control providing up to 20dB attenuation. All frequencies are nominal.
• Column EN54-3 shows tones approved under the construction Product Directive.
• Specifications with an* have not been verified to be EN54-3 compliant.
• Polar diagram information is available in the technical manual 85***99MD, available on request.
Banshee Excel Lite XenonTM
Sound Output Table
Every care has been taken in the preparation of this product release but no liability whatsoever can be accepted for the use of the information contained
therein. Hosiden Besson Ltd reserve the right to change or amend any design features in line with our policy of continuing development and improvement.
Iss 2
Deep base with
IP66 mounting
accessory
Shallow base
Specification
Termination: 1 x 8 way terminal block.
Screw terminals for 0.28mm2
to 2.5mm2wire conductor
EN54-3 Voltage Range: 24VDC (20VDC to 28VDC)
Operating Voltage Range: 9VDC to 30VDC*
Tone Current Consumption: See Sound output table
Tone Synchronisation: Synchronised start
Flash Rate: 1/Sec
Flash Current Consumption: 90mA @ 12VDC
40mA @ 24VDC
Operating Temperature: -20°C to +55°C
Case Material: ABS
Environment Category: Type A
IP Rating:* Shallow Base IP45
Deep Base IP66
Units meet minimum requirements of IP21C Shallow Base
& IP33C Deepbase in accordance with EN54-3
Installation
All installation to be carried out by a competent person
IP66 Deep Base Moulding (weatherproof).
• To maintain IP rating when using a Deep Base, use wall mounting
bracket Part Number: MM08728. Do not drill fixing holes in deep
base. Use suitably rated 20mm cable glands to fit cables or conduit
via side knock-outs. Fit ‘O’-Ring seal between lens and base.
Non-IP66 Deep Base.
• Knock out the conduit/cable gland holes in side of deep base.
• Fit conduit or 20mm cable glands then screw the base to the
mounting surface or BESA box.
Shallow Base Moulding.
• Drill mounting holes in the bottom of Base for screw fixings.
• Route cable through rear hole or side knock-outs.
• Screw the base to the mounting surface or BESA box.
All fixings.
• Connect unit as shown in connection diagram (Left). Note: If
independent supplies are required for the sounder and the beacon
elements, remove LK1 and LK2.
• Place the Excel Lite onto the base and turn clockwise to retain.
• To remove the Excel Lite turn unit counter-clockwise.
• Where applicable, fit the security screw through the hole in the
side of the lens assembly.
Sound selection 1 to 5, output level
7 & 8, 6 not used
Connection diagram
