Hotpoint Ariston ARXXF 125 User manual

GB
1
English,1
Contents
Installation, 2-3
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washing machine
and starting a wash cycle, 4-
Control panel
Indicator lights
Starting a wash cycle
Wash cycles, 6
Table of wash cycles
Personalisation, 7
Setting the temperature
Setting the spin speed
Functions
Detergents and laundry, 8
Detergent dispenser drawer
Bleach cycle
reparing the laundry
Garments requiring special care
Load balancing system
Precautions and tips, 9
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 10
Cutting off the water or electricity supply
Cleaning the washing machine
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 11
Service, 12
GB
ARXXF 12
Instructions for use
WASHING MACHINE
ES
Español,13
PT
Português,2
GR
ÅëëçíéêÜ,37
Downloaded From WashingMachine-Manual.com Manuals

2
GB
Installation
 This instruction manual should be kept in a safe
place for future reference. If the washing machine is
sold, transferred or moved, make sure that the
instruction manual remains with the machine so that
the new owner is able to familiarise himself/herself
with its operation and features.
 Read these instructions carefully: they contain vital
information relating to the safe installation and
operation of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washing machine from its packaging.
2. Make sure that the washing machine has not been
damaged during the transportation process. If it has
been damaged, contact the retailer and do not
proceed any further with the installation process.
3. Remove the 4
protective screws (used
during transportation) and
the rubber washer with
the corresponding
spacer, located on the
rear part of the appliance
(see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need
them again if the washing machine needs to be
moved to another location.
 ackaging materials should not be used as toys for
children.
Levelling
1. Install the washing machine on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or anything else.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or loosening
the adjustable front feet
(see figure); the angle of
inclination, measured in
relation to the worktop,
must not exceed 2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive noise
and prevent it from shifting while it is operating. If it is
placed on carpet or a rug, adjust the feet in such a
way as to allow a sufficient ventilation space
underneath the washing machine.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Connect the supply
pipe by screwing it to a
cold water tab using a 3/4
gas threaded connection
(see figure).
Before performing the
connection, allow the
water to run freely until it
is perfectly clear.
2. Connect the inlet hose
to the washing machine
by screwing it onto the
corresponding water inlet
of the appliance, which is
situated on the top right-
hand side of the rear part
of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
 The water pressure at the tap must fall within the
values indicated in the Technical details table (see
next page).
 If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
 Never use second-hand hoses.
 Use the ones supplied with the machine.
Downloaded From WashingMachine-Manual.com Manuals

GB
3
Technical data
Model ARXXF 125
Dimensions
width 59.5 cm
height 85 cm
depth 53,5 cm
Capacity from 1 to 7 kg
Electrical
connections
please refer to the technical data
plate fixed to the machine
Water connections
maximum pressure 1 M a (10 bar)
minimum pressure 0.05 M a (0.5 bar)
drum capacity 52 litres
Spin speed up to 1200 rotations per minute
Energy rated
programmes
according to
regulation
EN 604 6
programme 7; temperature 60°C;
using a load of 7 kg.
This appliance conforms to the
following EC Directives:
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility) and
subsequent modifications
- 2006/95/CE (Low Voltage)
- 2002/96/EC
65 - 100 cm
Connecting the drain hose
Connect the drain hose,
without bending it, to a
drainage duct or a wall
drain located at a height
between 65 and 100 cm
from the floor;
alternatively, rest it on
the side of a washbasin
or bathtub, fastening the
duct supplied to the tap
(see figure). The free end
of the hose should not
be underwater.
 We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
 the socket is earthed and complies with all
applicable laws;
 the socket is able to withstand the maximum power
load of the appliance as indicated in the Technical
data table (see opposite);
 the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
 the socket is compatible with the plug of the
washing machine. If this is not the case, replace
the socket or the plug.
 The washing machine must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to rain,
storms and other weather conditions.
 When the washing machine has been installed, the
electricity socket must be within easy reach.
 Do not use extension cords or multiple sockets.
 The cable should not be bent or compressed.
 The power supply cable must only be replaced by
authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle 2.
Downloaded From WashingMachine-Manual.com Manuals

4
GB
Detergent dispenser drawer: used to dispense
detergents and washing additives (see Detergents
and laundry).
There is a key which provides a summary of the
available wash cycles inside the detergent dispenser
drawer; this may be consulted at any time.
ON/OFF button with indicator light: switches the
machine on and off.
If the indicator light is illuminated, this indicates that
the machine is switched on.
WASH CYCLE knob: programmes the wash cycles.
During the wash cycle, the knob does not move.
SPIN SPEED button: sets the spin speed or exclude
the spin cycle completely (see Personalisation).
TEMPERATURE button: sets the temperature or the
cold wash cycle (see Personalisation).
DISPLAY: indicates the time remaining for the
selected wash cycle and, if a delayed start has been
programmed, the time remaining until the start of the
wash cycle.
CONTROL PANEL LOCK button with indicator light:
activates or deactivates the control panel lock.
FUNCTION buttons with indicator light: used to
select the available functions. The indicator light
corresponding to the selected function will remain lit.
WASH CYCLE PROGRESS
indicator light s: used
to monitor the progress of the wash cycle.
The illuminated indicator light shows which phase is in
progress.
DOOR LOCKED indicator light: indicates whether
the door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or
temporarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash
orange, while the indicator light for the current wash
cycle phase will remain lit in a fixed manner. If the
DOOR LOCKED indicator light is switched off, the
door may be opened.
To start the wash cycle from the point at which it was
interrupted, press this button again.
Standby mode
This washing machine, in compliance with new
energy saving regulations, is fitted with an automatic
standby system which is enabled after about 30
minutes if no activity is detected. ress the ON-OFF
button briefly and wait for the machine to start up
again.
Description of the washing machine
and starting a wash cycle
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
Control panel
WASH CYCLE PROGRESS
indicator lights
FUNCTION
buttons with
indicator lights
Detergent dispenser drawer
WASH CYCLE
knob
DISPLAY
ON/OFF
button with indicator
light
TEMPERATURE
button
SPIN SPEED
button
CONTROL PANEL LOCK
button with indicator light
Downloaded From WashingMachine-Manual.com Manuals

GB
Indicator lights
The indicator lights provide important information.
This is what they can tell you:
Wash cycle phase indicator lights
As the WASH CYCLE knob is rotated, the indicator
lights illuminate, indicating the stages which will be
performed by the machine in accordance with the
selected wash cycle.
Once the desired wash cycle has been selected and
has begun, the indicator lights switch on one by one
to indicate which phase of the cycle is currently in
progress.
Function buttons and corresponding indicator
lights
When a function is selected, the corresponding
indicator light will illuminate.
If the selected function is not compatible with the
programmed wash cycle, the corresponding indicator
light will flash, a sound signal will be emitted and the
function will not be activated.
If a function which is incompatible with another
function selected previously, only the most recent
selection will remain active.
Temperature indicator light
When a temperature value is selected, the
corresponding indicator light will illuminate.
Spin indicator light
When a spin value is selected, the corresponding
indicator light will illuminate.
Control panel lock indicator light
To activate the control panel lock, press and hold the
button for approximately 2 seconds. When the
indicator light is illuminated, the control panel is
locked. This means it is possible to prevent wash
cycles from being modified accidentally, especially
where there are children in the home.
To deactivate the control panel lock, press and hold
the button for approximately 2 seconds.
Door locked indicator light
If this indicator light is on, the appliance door is locked
to prevent it from being opened accidentally; to avoid
any damage, wait for the indicator light to switch off
before you open the appliance door.
N.B. If the DELAY TIMER function is activated, the door
cannot be opened; pause the machine by pressing the
START/ AUSE button if you wish to open it.
 If the START/ AUSE indicator light (orange) flashes
rapidly at the same time as the function indicator
light, this indicates a problem has occurred (see
Troubleshooting).
Starting a wash cycle
1. Turn the washing machine on by pressing the ON/OFF button. All the indicator lights will turn on for a few
seconds, then only the indicator lights relative to the selected programme settings will remain lit and the START/
AUSE indicator light will flash.
2. Load the laundry and close the door.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see Personalisation).
5. Set the spin speed (see Personalisation).
6. Measure out the detergent and washing additives (see Detergents and laundry).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit
in a fixed manner, in green.
To cancel the set wash cycle, pause the machine by pressing the START/ AUSE button and select a new cycle.
9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch
off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make
sure the drum dries completely. Switch the washing machine off by pressing the ON/OFF button.
Wash
Rinse
Spin
Drain no spin
End of wash cycle
Downloaded From WashingMachine-Manual.com Manuals

6
GB
Special wash cycles
Sanitizing cycle (wash cycle 7). A high-temperature hygienic wash cycle (over 60°C) which requires the use of bleach.
our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled
Detergent dispenser drawer).
Goodnight cycle (wash cycle 8). This is a silent cycle which can be run at night, when the electricity prices are lower.
The wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while there is still water
in the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the machine will perform the spin
cycle and drain the water automatically after 8 hours.
Baby cycle (wash cycle 9). This wash cycle can be used to remove the soiling typically caused by babies, while ensuring
that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering allergies. The
cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and optimising the effect
of special disinfecting additives added to the detergent.
At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end the cycle
press the START/ AUSE button.
Mix 30(wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30 minutes and
therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 3 kg.
Mix 15 (wash cycle 6) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15 minutes and
therefore saves both energy and time. By selecting this wash cycle (6 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 1.5 kg.
Wash cycles
The information contained in the table is intended as a guide only.
For all Test Instit tes:
1) Test wash cycle in compliance with reg lation EN 60456: set wash cycle 7 with a temperat re of 60°C.
2) Long wash cycle for cottons: set wash cycle 2 with a temperat re of 40°C.
3) Short wash cycle for cottons: set wash cycle 3 with a temperat re of 40°C.
Wash cycles
Table of wash cycles
Description of the wash cycle
Max.
temp.
(°C)
Max.
speed
(rpm)
Detergents Max.
load
(kg)
Cycle
d ration
Bleach Wash Fabric
softener
Special cycles
7Sanitizing cycle: Extremely soiled whites. 90° 1200 ll l 7
7Sanitizing cycle (1): Heavily soiled whites and resistant colours. 60° 1200 -ll 7
8Goodnigt cycle: Lightly soiled delicate colours. 40° 800 -ll 4
9Baby cycle: Heavily soiled delicate colours. 40° 800 -ll 2
10 Shirts 40° 600 -ll 2
11 Silk/C rtains: For garments in silk and viscose, lingerie. 30° 0 -ll 1
12 Wool: For wool, cashmere, etc. 40° 600 -ll1,5
Everyday wash cycles (Daily)
1Cotton + Prewash 90°: Extremely soiled whites. 90° 1200 -ll 7
2Cotton: Heavily soiled whites and resistant colours. 60° 1200 ll l 7
2Cotton (2): Heavily soiled whites and delicate colours. 40° 1200 ll l 7
3Colo red Cottons (3): Lightly soiled whites and delicate colours. 40° 1200 ll l 7
4Synthetics resistents: Heavily soiled resistant colours. 60° 800 -ll 3
4Synthetics delicates: Lightly soiled resistant colours. 40° 800 -ll 3
Mix 30': To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 -ll 3
6Mix 15': To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 -ll1,5
Partials wash cycles
ARinse -1200 - - l7
BSpin -1200 - - - 7
CLight spin -800 - - - 3
DDrain no spin -0- - - 7
The duration of the wash cycles can be checked on the display.
Downloaded From WashingMachine-Manual.com Manuals

GB
7
Setting the temperature
By pressing the TEM ERATURE button to set the wash temperature (see Table of wash cycles).
The temperature may be lowered, or even set to a cold wash ( ).
The washing machine will automatically prevent you from selecting a temperature which is higher than the
maximum value set for each wash cycle.
Setting the spin speed
By pressing the S IN S EED button to set the spin speed for the selected wash cycle.
The maximum spin speeds available for each wash cycle are as follows:
Wash cycles Maxim m spin speed
Cottons 1200 rpm
Synthetics 800 rpm
Wool 600 rpm
Silk drain only
The spin speed may be lowered, or the spin cycle can be excluded altogether by selecting the symbol .
The washing machine will automatically prevent you from selecting a spin speed which is higher than the
maximum speed set for each wash cycle.
Functions
The various wash functions available with this washing machine will help to achieve the desired results, every time.
To activate the functions:
1. ress the button corresponding to the desired function;
2. the function is enabled when the corresponding indicator light is illuminated.
Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in
conjunction with the selected wash cycle.
Delay timer
To set a delayed start for the selected wash cycle, press the button repeatedly until the desired delay time is
displayed (this may be between 1 hour and 24 hours).
To disable the function press the button until the text is displayed.
N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.
This option is enabled with all programmes.
Super Wash
Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle
duration, this function offers a high-performance wash.
 This function may not be used in conjunction with wash cycles 5, 6, 7, 11, 12, A, B, C, D.
Extra rinse
By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is
particularly useful for sensitive skin.
 This function may not be used in conjunction with wash cycles 5, 6, B, C, D.
Easy iron
By selecting this function, the wash and spin cycles will be modified in order to reduce the formation of creases. At
the end of the cycle the washing machine will perform slow rotations of the drum; the EASY IRON and START/
AUSE indicator lights will flash (orange) and the phase will remain lit in a fixed manner. To end the cycle, press
the START/ AUSE button or the EASY IRON button.
For the Silk wash cycle, the machine will end the cycle while the laundry is soaking, the EASY IRON and START/
AUSE indicator lights will flash (orange) and the RINSE phase will remain lit in a fixed manner. To drain the water
so that the laundry may be removed, press the START/ AUSE button or the EASY IRON button.
 This function may not be used in conjunction with wash cycles 5, 6, 7, 8, 9, 12, B, C, D.
Personalisation
Downloaded From WashingMachine-Manual.com Manuals

8
GB
Detergents and laundry
Detergent dispenser drawer
Good washing results also depend on the correct
dose of detergent: adding too much detergent will not
necessarily result in a more efficient wash, and may in
fact cause build up on the inside of your appliance
and contribute to environmental pollution.
 Do not use hand washing detergents because these
create too much foam.
Open the detergent
dispenser drawer and
pour in the detergent or
washing additive, as
follows.
compartment 1: Pre-wash detergent (powder)
Before pouring in the detergent, make sure that extra
compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in immediately
prior to the start of the wash cycle.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow the grid.
extra compartment 4: Bleach
Bleach cycle
Bleaching may only be performed in conjunction with
wash cycles 2, 3, 7.
our the bleach into extra compartment 4; pour the
detergent and softener into the corresponding
compartments, then select one of the
abovementioned wash cycles.
This option is recommended only for very soiled
cotton garments.
Preparing the laundry
 Divide the laundry according to:
- the type of fabric/the symbol on the label.
- the colours: separate coloured garments from
whites
 Empty all garment pockets and check the buttons.
 Do not exceed the listed values, which refer to the
weight of the laundry when dry:
Durable fabrics: max. 7 kg
Synthetic fabrics: max. 3 kg
Delicate fabrics: max. 2 kg
Wool: max. 1,5 kg
MAX
1
2
4
3
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1200 g
1 towel 150-250 g
Garments requiring special care
Shirts: use special wash cycle 10 to wash shirts in
various fabrics and colours.
It guarantees maximum care is taken of the garments
and minimises the formation of creases.
Silk: use special wash cycle 11 to wash all silk
garments. We recommend the use of special
detergent which has been designed to wash delicate
clothes.
Curtains: fold curtains and place them in a pillow
case or mesh bag. Use wash cycle 11.
Wool: Hotpoint/Ariston is the only washing machine
manufacturer to have been awarded the prestigious
Woolmark latinum Care endorsement (M.0508) by
the Woolmark Company, which means that all
woollen garments may be washed in the washing
machine, even those which state hand wash only
on the label. Wash cycle 12 therefore offers
complete peace of mind when washing woollen
garments in the washing machine (max. load 1,5 kg)
and guarantees optimal performance.
Load balancing system
Before every spin cycle, to avoid excessive vibrations
and to distribute the load in a uniform manner, the
drum rotates continuously at a speed which is slightly
greater than the washing rotation speed. If, after
several attempts, the load is not balanced correctly,
the machine spins at a reduced spin speed. If the
load is excessively unbalanced, the washing machine
performs the distribution process instead of spinning.
To encourage improved load distribution and balance,
we recommend small and large garments are mixed
in the load.
Downloaded From WashingMachine-Manual.com Manuals

GB
9
Precautions and tips
 This washing machine was designed and
constructed in accordance with international safety
regulations. The following information is provided for
safety reasons and must therefore be read carefully.
General safety
 This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
 This appliance was designed for domestic use only.
 Do not touch the machine when barefoot or with
wet or damp hands or feet.
 Do not pull on the power supply cable when
unplugging the appliance from the electricity
socket. Hold the plug and pull.
 Do not open the detergent dispenser drawer while
the machine is in operation.
 Do not touch the drained water as it may reach
extremely high temperatures.
 Never force the porthole door. This could damage
the safety lock mechanism designed to prevent
accidental opening.
 If the appliance breaks down, do not under any
circumstances access the internal mechanisms in
an attempt to repair it yourself.
 Always keep children well away from the appliance
while it is operating.
 The door can become quite hot during the wash cycle.
 If the appliance has to be moved, work in a group
of two or three people and handle it with the utmost
care. Never try to do this alone, because the
appliance is very heavy.
 Before loading laundry into the washing machine,
make sure the drum is empty.
Disposal
 Disposing of the packaging materials: observe local
regulations so that the packaging may be re-used.
 The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
Opening the porthole door manually
In the event that it is not possible to open the
porthole door due to a powercut, and if you wish to
remove the laundry, proceed as follows:
1. remove the plug from
the electrical socket.
2. make sure the water
level inside the machine is
lower than the door
opening; if it is not, remove
excess water using the
drain hose, collecting it in a
bucket as indicated in the
figure.
3. using a screwdriver,
remove the cover panel on
the lower front part of the
washing machine (see
figure).
4. pull outwards using the tab as indicated in the
figure, until the plastic tie-rod is freed from its stop
position; pull downwards and open the door at the
same time.
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
20
The crossed out "wheeled bin" symbol on the
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.
Downloaded From WashingMachine-Manual.com Manuals

10
GB
Care and maintenance
Cutting off the water and electricity
supplies
 Turn off the water tap after every wash cycle. This
will limit wear on the hydraulic system inside the
washing machine and help to prevent leaks.
 Unplug the washing machine when cleaning it and
during all maintenance work.
Cleaning the washing machine
The outer parts and rubber components of the
appliance can be cleaned using a soft cloth soaked
in lukewarm soapy water. Do not use solvents or
abrasives.
Cleaning the detergent dispenser
drawer
Remove the dispenser
by raising it and pulling it
out (see figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for the door and drum of your
appliance
 Always leave the porthole door ajar in order to
prevent unpleasant odours from forming.
Cleaning the pump
The washing machine is fitted with a self-cleaning
pump which does not require any maintenance.
Sometimes, small items (such as coins or buttons)
may fall into the pre-chamber which protects the
pump, situated in its bottom part.
 Make sure the wash cycle has finished and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front part of
the washing machine
(see figure);
2. unscrew the lid by
rotating it anti-clockwise
(see figure) a little water
may trickle out. This is
perfectly normal;
3. clean the inside thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the inlet hose at least once a year. If there are
any cracks, it should be replaced immediately: during
the wash cycles, water pressure is very strong and a
cracked hose could easily split open.
 Never use second-hand hoses.
1
2
Downloaded From WashingMachine-Manual.com Manuals

GB
11
Troubleshooting
Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see Assistance),
make sure that the problem cannot be not solved easily using the following list.
Problem:
The washing machine does not
switch on.
The wash cycle does not start.
The washing machine does not
take in water (the indicator light
for the first wash cycle stage
flashes rapidly).
The washing machine
continuously takes in and drains
water.
The washing machine does not
drain or spin.
The washing machine vibrates a
lot during the spin cycle.
The washing machine leaks.
The START/PAUSE indicator light
(orange) and the function
indicator lights flash rapidly.
There is too much foam.
Possible causes / Solutions:
 The appliance is not plugged into the socket fully, or is not making contact.
 There is no power in the house.
 The washing machine door is not closed properly.
 The ON/OFF button has not been pressed.
 The START/ AUSE button has not been pressed.
 The water tap has not been opened.
 A delayed start has been set (using the Delay Timer, see Personalisation).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap has not been opened.
 There is no water supply in the house.
 The pressure is too low.
 The START/ AUSE button has not been pressed.
 The drain hose is not fitted at a height between 65 and 100 cm from the
floor (see Installation).
 The free end of the hose is under water (see Installation).
 The wall drainage system is not fitted with a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and contact the Assistance Service. If the dwelling is
on one of the upper floors of a building, there may be problems relating to
water drainage, causing the washing machine to fill with water and drain
continuously. Special anti-draining valves are available in shops and help to
avoid this inconvenience.
 The wash cycle does not include draining: some wash cycles require the
drain phase to be started manually.
 The EASY IRON function has been activated: To complete the wash cycle,
press the START/ AUSE button (Personalisation).
 The drain hose is bent (see Installation).
 The drainage duct is clogged.
 The drum was not unlocked correctly during installation (see Installation).
 The washing machine is not level (see Installation).
 The washing machine is trapped between cabinets and walls (see Installation).
 The water inlet hose is not screwed on properly (see Installation).
 The detergent dispenser drawer is blocked (for cleaning instructions, see Care
and maintenance).
 The drain hose is not fixed properly (see Installation).
 Switch off the machine and unplug it, wait for approximately 1 minute and
then switch it back on again.
If the problem persists, contact the Technical Assistance Service.
 The detergent is not suitable for machine washing (it should display the text
for washing machines or hand and machine wash, or the like).
 Too much detergent was used.
Downloaded From WashingMachine-Manual.com Manuals

12
GB
Service
Before calling for Assistance:
Check whether you can solve the problem alone (see Troubleshooting);
 Restart the programme to check whether the problem has been solved;
 If this is not the case, contact an authorised Technical Assistance Centre using the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised technicians.
Have the following information to hand:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate applied to the rear of the washing machine, and can also
be found on the front of the appliance by opening the door.
Downloaded From WashingMachine-Manual.com Manuals

ES
13
Español
Sumario
Instalación, 14-15
Desembalaje y nivelación
Conexiones hidráulicas y eléctricas
Primer ciclo de lavado
Datos técnicos
Descripción de la lavadora y comienzo
de un programa, 1 -17
Panel de control
Pilotos
Poner en marcha un programa
Programas, 18
Tabla de programas
Personalizaciones, 19
Seleccionar la temperatura
Seleccionar el centrifugado
unciones
Detergentes y ropa, 20
Contenedor de detergentes
Ciclo de blanqueo
Preparar la ropa
Prendas especiales
Sistema de equilibrado de la carga
Precauciones y consejos, 21
Seguridad general
Eliminaciones
Apertura manual de la puerta
Mantenimiento y cuidados,22
Interrumpir el agua y la corriente eléctrica
Limpiar la lavadora
Limpiar el contenedor de detergentes
Cuidar la puerta y el cesto
Limpiar la bomba
Controlar el tubo de alimentación de agua
Anomalías y soluciones, 23
Asistencia, 24
ES
ARXXF 125
Manual de instrucciones
LAVADORA
Downloaded From WashingMachine-Manual.com Manuals

14
ES
Instalación
 Es importante conservar este manual para poder
consultarlo en cualquier momento. En caso de venta,
de cesión o de traslado, verifique que permanezca
junto con la lavadora para informar al nuevo
propietario sobre el funcionamiento y brindar las
correspondientes advertencias.
 Lea atentamente las instrucciones: ellas contienen
importante información sobre la instalación, el uso y la
seguridad.
Desembalaje y nivelación
Desembalaje
1. Desembale la lavadora.
2. Controle que la lavadora no haya sufrido daños
durante el transporte. Si estuviera dañada no la
conecte y llame al revendedor.
3. Quite los 4 tornillos de
protección para el
transporte y la arandela
de goma con el
correspondiente
distanciador ubicados en
la parte posterior (ver la
figura).
4. Cubra los orificios con los tapones de plástico
suministrados con el aparato.
5. Conserve todas las piezas: cuando la lavadora
deba ser transportada nuevamente, deberán volver a
colocarse.
 Los embalajes no son juguetes para los niños.
Nivelación
1. Instale la lavadora sobre un piso plano y rígido, sin
apoyarla en las paredes, muebles ni en ningún otro
aparato.
2. Si el piso no está
perfectamente horizontal,
compense las
irregularidades
desenroscando o
enroscando las patas
delanteras (ver la figura);
el ángulo de inclinación
medido sobre la superfi-
cie de trabajo, no debe
superar los 2º.
Una cuidadosa nivelación brinda estabilidad a la
máquina y evita vibraciones, ruidos y desplazamientos
durante el funcionamiento. Cuando se instala sobre
moquetas o alfombras, regule los pies para conservar
debajo de la lavadora un espacio suficiente para la
ventilación.
Conexiones hidráulicas y eléctricas
Conexión del tubo de alimentación de agua
1. Conectar el tubo de
tubo enroscándolo a un
grifo de agua fría con la
boca roscada de 3/4 gas
(ver la figura).
Antes de conectarlo,
haga correr el agua hasta
que esté límpida.
2. Conecte el tubo de
alimentación a la
lavadora enroscándolo en
la toma de agua
correspondiente ubicada
en la parte posterior
derecha (arriba) (ver la
figura).
3. Controle que en el tubo no hayan pliegues ni
estrangulaciones.
 La presión de agua del grifo debe estar
comprendida dentro de los valores contenidos en la
tabla de Datos técnicos (ver la página
correspondiente).
 Si la longitud del tubo de alimentación no es la
suficiente, diríjase a un negocio especializado o a un
técnico autorizado.
 No utilice nunca tubos ya usados.
 Utilice los suministrados con la máquina.
Downloaded From WashingMachine-Manual.com Manuals

ES
15
65 - 100 cm
Conexión del tubo de descarga
Conecte el tubo de
descarga, sin plegarlo, a
una tubería de descarga
o a una descarga de
pared colocadas a una
altura del piso entre 65 y
100 cm;
o apóyelo en el borde de
un lavamanos o de una
bañera, uniendo la guía
suministrada con el
aparato, al grifo (ver la
figura). El extremo libre
del tubo de descarga no
debe permanecer
sumergido en el agua.
 No se aconseja utilizar tubos de prolongación, si
fuera indispensable hacerlo, la prolongación debe
tener el mismo diámetro del tubo original y no superar
los 150 cm.
Conexión eléctrica
Antes de enchufar el aparato, verifique que:
 la toma tenga la conexión a tierra y haya sido
hecha según las normas legales;
 la toma sea capaz de soportar la carga máxima de
potencia de la máquina indicada en la tabla de
Datos técnicos (ver al costado);
 la tensión de alimentación esté comprendida dentro
de los valores indicados en la tabla de Datos
técnicos (ver al costado);
 la toma sea compatible con el enchufe de la
lavadora. Si no es así, sustituya la toma o el
enchufe.
 La lavadora no debe ser instalada al aire libre, ni
siquiera si el lugar está reparado, ya que es muy
peligroso dejarla expuesta a la lluvia o a las
tormentas.
 Una vez instalada la lavadora, la toma de corriente
debe ser fácilmente accesible.
 No utilice prolongaciones ni conexiones múltiples.
 El cable no debe estar plegado ni sufrir
compresiones.
 El cable de alimentación debe ser sustituido sólo
por técnicos autorizados.
¡Atención! La empresa fabricante declina toda
responsabilidad en caso de que estas normas no
sean respetadas.
Primer ciclo de lavado
Después de la instalación y antes del uso, realice un
ciclo de lavado con detergente y sin ropa,
seleccionando el programa 2.
Datos técnicos
Modelo ARXX 125
Dimensiones
ancho 59,5 cm.
altura 85 cm.
profundidad 53,5 cm.
Capacidad de 1 a 7 kg.
Conexiones
eléctricas
ver la placa de características
técnicas aplicada en la máquina
Conexiones
hídricas
presión máxima 1 MPa (10 bar)
presión mínima 0,05 MPa (0,5 bar)
capacidad del cesto 52 litros
Velocidad de
centrifugado máxima 1200 r.p.m.
Programas de
control según la
norma EN 045
programa 7; temperatura 60ºC;
efectuado con 7 kg. de carga.
Esta máquina cumple con lo
establecido por las siguientes
Directivas de la Comunidad:
- 89/336/CEE del 03/05/89
(Compatibilidad Electromagnética) y
sucesivas modificaciones
- 2002/96/CE
- 2006/95/CE (Baja Tensión)
Downloaded From WashingMachine-Manual.com Manuals

1
ES
Contenedor de detergentes: para cargar
detergentes y aditivos (ver Detergentes y ropa).
Dentro del contenedor de detergentes se encuentra
la leyenda con la cual se puede consultar, en todo
momento, un esquema sintético de los programas.
Botón y piloto de ENCENDIDO/APAGADO: para
encender y apagar la máquina.
El piloto iluminado indica que la máquina está
encendida.
Mando de PROGRAMAS: para elegir los programas.
Durante el funcionamiento del programa el mando no
se mueve.
Botón CENTRIFUGADO: para seleccionar el
centrifugado o excluirlo (ver Personalizaciones).
Botón TEMPERATURA: para seleccionar la tempera-
tura o el lavado en frío (ver Personalizaciones).
PANTALLA: para visualizar el tiempo residual del
ciclo de lavado seleccionado y, si se ha fijado un
comienzo retrasado, el tiempo que falta para que
comience el lavado.
Botón y piloto deBLOQUEO DE BOTONES: para
activar o desactivar el bloqueo del panel de mandos.
Botones con pilotos de FUNCIÓN: para seleccionar
las funciones disponibles. El piloto correspondiente a
la función seleccionada permanecerá encendido.
Pilotos DE AVANCE DEL CICLO: para seguir el
estado de avance del programa de lavado.
El piloto encendido indica la fase en curso.
Piloto PUERTA BLOQUEADA: para saber si la
puerta se puede abrir (ver la página correspondiente).
Botón con piloto PUESTA EN MARCHA/PAUSA: se
utiliza para poner en marcha los programas o
interrumpirlos momentáneamente.
Nota: Presione este botón para poner en pausa el
lavado en curso, el piloto correspondiente centelleará
con color anaranjado mientras que el de la fase en
curso permanecerá encendido en forma fija. Si el
piloto PUERTA BLOQUEADA está apagado, se
podrá abrir la puerta.
Para que el lavado se reanude a partir del momento
en el cual fue interrumpido, presione nuevamente
este botón.
Modalidad de stand by
Esta lavasecadora está en conformidad con las
nuevas normativas vinculadas al ahorro energético.
Está dotada de un sistema de auto-apagado (stand
by) que, en caso de no funcionamiento, se activa
pasados aproximadamente 30 minutos. Presionar
brevemente el botón ON/O y esperar que la
máquina se active.
Descripción de la lavadora y
comienzo de un programa
Panel de control
Pilotos DE AVANCE
DEL CICLO
PANTALLA
Mando de
PROGRAMAS
Contenedor de detergentes
Botones con
pilotos
FUNCIÓN
Botón y piloto de
ENCENDIDO/
APAGADO
Botón
TEMPERATURA
Piloto
PUERTA
BLOQUEADA
Botón con piloto
PUESTA EN
MARCHA/
PAUSA
Botón
CENTRIFUGADO
Botón y piloto de
BLOQUEO DE
BOTONES
Downloaded From WashingMachine-Manual.com Manuals

ES
17
Pilotos
Los pilotos suministran información importante.
He aquí lo que nos dicen:
Pilotos fase en curso
Girando el mando PROGRAMAS, los pilotos se
iluminarán indicando las fases que la máquina
realizará según el programa elegido.
Una vez seleccionado y puesto en marcha el ciclo de
lavado deseado, las luces testigo se encenderán
progresivamente para indicar su estado de avance:
Botones de función y pilotos correspondientes
Seleccionando una función, el piloto correspondiente
se iluminará.
Si la función seleccionada no es compatible con el
programa elegido, el piloto correspondiente
centelleará, se emitirá una señal sonora y la función
no se activará.
Cuando se seleccione una función incompatible con
otra seleccionada precedentemente, permanecerá
activa sólo la última elección realizada.
Pilotos de temperatura
Seleccionando un valor de temperatura, el piloto
correspondiente se iluminará.
Pilotos de centrifugado
Seleccionando un valor de centrifugado, el piloto
correspondiente se iluminará.
Piloto de bloqueo de botones
Para "activar" el bloqueo del panel de control,
mantenga presionado el botón durante 2 segundos
aproximadamente. El piloto encendido indica que el
panel de control está bloqueado. De este modo, se
evitan modificaciones accidentales de los programas,
sobre todo si en la casa hay niños.
Para "desactivar" el bloqueo del panel de control,
mantenga presionado el botón durante 2 segundos
aproximadamente.
Piloto puerta bloqueada:
El piloto encendido indica que la puerta está
bloqueada para impedir aperturas accidentales; antes
de abrir la puerta es necesario esperar que dicho
piloto se apague, de este modo se evitarán daños.
Nota: si la función Programador inicio programa
está activada, la puerta no se puede abrir, para
abrirla se debe poner en pausa la máquina
presionando el botón PUESTA EN MARCHA/PAUSA.
 El centelleo rápido del piloto PUESTA EN MARCHA/PAUSA
(anaranjado) simultáneamente con el de las funciones indica
una anomalía (ver Anomalías y soluciones).
Poner en marcha un programa
1. Encienda la lavadora pulsando el botón ENCENDIDO/APAGADO. Todos los pilotos se encenderán durante algunos
segundos, luego permanecerán encendidos sólo los pilotos correspondientes a las configuraciones para el programa
seleccionado y centelleará el piloto PUESTA EN MARCHA/PAUSA.
2. Cargue la ropa y cierre la puerta.
3. Seleccione el programa deseado con el mando de PROGRAMAS.
4. ije la temperatura de lavado (ver Personalizaciones).
5. ije la velocidad de centrifugado (ver Personalizaciones).
6. Vierta detergente y aditivos (ver Detergentes y ropa).
7. Seleccione las funciones deseadas.
8. Ponga en marcha el programa presionando el botón PUESTA EN MARCHA/PAUSA y el piloto correspondiente
permanecerá encendido, fijo y de color verde. Para anular el ciclo seleccionado ponga en pausa la máquina
presionando el botón PUESTA EN MARCHA/PAUSA y elija un nuevo ciclo.
9. Al final del programa se iluminará el piloto . El piloto PUERTA BLOQUEADA se apagará indicando que la
puerta se puede abrir. Extraiga la ropa y deje la puerta semicerrada para permitir que el cesto se seque.
Apague la lavadora presionando el botón ENCENDIDO/APAGADO.
Lavado
Aclarado
Centrifugado
Descarga
in del Lavado
Downloaded From WashingMachine-Manual.com Manuals

18
ES
Programas
os datos contenidos en la tabla tienen un valor indicativo.
Para todos los Test Institutes:
1) Progra a de control según la nor a EN 60456: seleccione el progra a 7 con una te peratura de 60ºC.
2) Progra a algodón largo: seleccione el progra a 2 con una te peratura de 40ºC.
3) Progra a algodón corto: seleccione el progra a 3 con una te peratura de 40ºC.
Progra as
Tabla de programas
Descripción del Progra a
Te p .
ax.
(°C)
Velocidad
áx.
(r.p. .)
Detergentes Carga
áx.
(Kg.)
Duración
del ciclo
Blanqu-
eador Lavado Suavi- zante
Programas Especiales
7Ciclo Desinfectante: ropa blanca muy sucia. 90° 1200 lll
7
7Ciclo Desinfectante (1): blancos y colores resistentes muy sucios. 60° 1200 -ll
7
8Ciclo Buenas Noches: colores delicados poco sucios. 40° 800 -ll
4
9Baby cycle: colores delicados muy sucios. 40° 800 -ll
2
10 Ca isas 40° 600 -ll
2
11 Seda/Cortinas: para prendas de seda, viscosa, lencería.30° 0 -ll
1
12 Lana: para lana, cachemira, etc. 40° 600 -ll
1,5
Diario (programas para todos los días)
1Prelavado Algodón 90°C: blancos sumamente sucios. 90° 1200 -ll
7
2Algodón: blancos y colores resistentes muy sucios. 60° 1200 lll
7
2Algodón (2): blancos y colores delicados muy sucios. 40° 1200 lll
7
3Algodón de color (3): blancos poco sucios y colores delicados. 40° 1200 lll
7
4Sintético: colores resistentes muy sucios. 60° 800 -ll
3
4Sintético: colores resistentes poco sucios. 40° 800 -ll
3
5Mix 30': para refrescar rápidamente prendas poco sucias (no se
aconseja utilizarlo para lana, seda y prendas para lavar a mano). 30° 800 -ll
3
Mix 15': para refrescar rápidamente prendas poco sucias (no se
aconseja utilizarlo para lana, seda y prendas para lavar a mano). 30° 800 -ll
1,5
Programas Parciales
AAclarado Algodón -1200 - - l7
BCentrifugado Rápido -1200 - - - 7
CCentrifugado Delicado -800 - - - 3
DDescarga -0- - - 7
Se puede controlar la duración de los programas de lavado en la pantalla.
Programas particulares
Ciclo Desinfectante (programa 7). Un programa higienizante con elevadas temperaturas, prevé el uso del
blanqueador con temperaturas mayores que 60ºC.
Para blanquear vierta el blanqueador, los detergentes y los
aditivos en los compartimentos correspondientes (ver el párrafo Contenedor de detergentes).
Ciclo Buenas noches (programa 8). Es un ciclo silencioso que puede trabajar de noche cuando la tarifa
energética es menor. El programa ha sido estudiado para prendas sintéticas y de algodón. Al final del ciclo, la
máquina se detiene con el agua en la cuba; para realizar el centrifugado y la descarga presione el botón PUESTA
EN MARCHA/PAUSA, de lo contrario, después de 8 horas, la máquina los realizará automáticamente.
Baby Cycle (programa 9). Programa capaz de eliminar la suciedad característica de los niños pero garantizando la
eliminación del detergente de las prendas para evitar problemas de alergia en la piel delicada de los niños. El ciclo
ha sido estudiado para disminuir la carga bacteriana utilizando una mayor cantidad de agua y optimizando el
efecto de aditivos específicos higienizantes agregados al detergente.
Al finalizar el lavado, la máquina realizará lentas rotaciones del cesto para evitar la formación de arrugas; para
terminar el ciclo, presione el botón PUESTA EN MARCHA/PAUSA.
Mix 30' (programa 5) fue estudiado para lavar prendas ligeramente sucias y en poco tiempo: dura sólo 30 minutos
y de esa manera permite ahorrar energía y tiempo. Seleccionando el programa (5 a 30ºC) es posible lavar
conjuntamente tejidos de distinto tipo (excluidas lana y seda), con una carga máxima de 3 kg.
Mix 15' (programa 6) fue estudiado para lavar prendas ligeramente sucias y en poco tiempo: dura sólo 15 minutos
y de esa manera permite ahorrar energía y tiempo. Seleccionando el programa (6 a 30ºC) es posible lavar
conjuntamente tejidos de distinto tipo (excluidas lana y seda), con una carga máxima de 1,5 kg.
Downloaded From WashingMachine-Manual.com Manuals

ES
19
Seleccionar la temperatura
Presionando el botón TEMPERATURA se selecciona la temperatura de lavado (ver la Tabla de programas).
La temperatura se puede disminuir hasta el lavado en frío ( ).
La máquina impedirá automáticamente seleccionar una temperatura mayor que la máxima prevista para cada
programa.
Seleccionar el centrifugado
Presionando el botón CENTRI UGADO se selecciona la velocidad de centrifugado del programa seleccionado.
Las velocidades máximas previstas para los programas son:
Progra as Velocidad áxi a
Algodón 1200 r.p.m.
Sintéticos 800 r.p.m.
Lana 600 r.p.m.
Seda sólo descarga
Se puede disminuir la velocidad de centrifugado o excluirlo seleccionando el símbolo .
La máquina impedirá automáticamente efectuar un centrifugado a una velocidad mayor que la máxima prevista
para cada programa.
Funciones
Las distintas funciones de lavado previstas por la lavadora permiten obtener la limpieza y el blanco deseados.
Para activar las funciones:
1. presione el botón correspondiente a la función deseada;
2. el encendido del piloto correspondiente indica que la función está activa.
Nota: El centelleo rápido del piloto indica que la función correspondiente no se puede seleccionar para el programa elegido.
Programador inicio programa
Para seleccionar el comienzo retrasado del programa elegido, presione varias veces el botón hasta visualizar el
retraso deseado (de 1 a 24 hs.)
Para desactivar la función, presione el botón hasta visualizar el mensaje .
Nota: Una vez presionado el botón PUESTA EN MARCHA/PAUSA, se puede modificar el valor del retraso sólo
disminuyéndolo.
Se puede utilizar en todos los programas.
Super wash
Gracias al uso de una mayor cantidad de agua en la fase inicial del ciclo y al empleo de mayor tiempo, dicha
función garantiza un lavado con óptimos resultados.
No se puede activar con los programas 5, 6, 7, 11, 12, A, B, C, D.
Aclarado extra
Al elegir esta función aumentará la eficacia del aclarado y se asegurará la máxima eliminación del detergente. Es
útil para pieles particularmente sensibles.
No se puede activar con los programas 5, 6, B, C, D.
Plancha fácil
Cuando se selecciona esta función, el lavado y el centrifugado se modificarán oportunamente para disminuir la
formación de arrugas. Al finalizar el ciclo, la lavadora realizará lentas rotaciones del cesto; el piloto de la función
PLANCHA ÁCIL y el de PUESTA EN MARCHA/PAUSA centellearán (anaranjado) y el de la fase permanecerá
encendido en forma fija. Para finalizar el ciclo se deberá presionar el botón PUESTA EN MARCHA/PAUSA o el
botón PLANCHA ÁCIL.
En el programa Seda la máquina terminará el ciclo dejando la ropa en remojo, el piloto de la función PLANCHA
ÁCIL y el de PUESTA EN MARCHA/PAUSA centellearán (anaranjado) y el de la fase ACLARADO permanecerá
encendido en forma fija. Para descargar el agua y poder sacar la ropa, es necesario presionar el botón PUESTA
EN MARCHA/PAUSA o el botón PLANCHA ÁCIL.
No se puede activar con los programas 5, 6, 7, 8, 9, 12, B, C, D.
Personalizaciones
Downloaded From WashingMachine-Manual.com Manuals

20
ES
Detergentes y ropa
Contenedor de detergentes
El buen resultado del lavado depende también de la
correcta dosificación del detergente: si se excede la
cantidad, no se lava de manera más eficaz, sino que
se contribuye a encostrar las partes internas de la
lavadora y a contaminar el medio ambiente.
 No use detergentes para el lavado a mano porque
producen demasiada espuma.
Extraiga el contenedor de
detergentes e introduzca
el detergente o el aditivo
de la siguiente manera:
cubeta 1: Detergente para prelavado (en polvo)
Antes de verter el detergente, verifique que no esté
colocada la cubeta adicional 4.
cubeta 2: Detergente para lavado (en polvo o
líquido)
El detergente líquido se debe verter sólo antes de la
puesta en marcha.
cubeta 3: Aditivos (suavizante, etc.)
El suavizante no se debe volcar fuera de la rejilla.
cubeta adicional 4: Blanqueador
Ciclo de blanqueo
El blanqueo se puede realizar sólo con los programas
2, 3, 7.
Vierta el blanqueador en la cubeta adicional 4, el
detergente y el suavizante en las correspondientes
cubetas y luego seleccione uno de los programas
indicados.
Es adecuado sólo para prendas de algodón muy
sucias.
Preparar la ropa
 Subdivida la ropa según:
- el tipo de tejido / el símbolo en la etiqueta.
- los colores: separe las prendas de color y las
blancas.
 Vacíe los bolsillos y controle los botones.
 No supere los valores indicados, referidos al peso
de la ropa seca:
Tejidos resistentes: max 7 kg.
Tejidos sintéticos: max 3 kg.
Tejidos delicados: max 2 kg.
Lana: max 1,5 kg.
MAX
1
2
4
3
¿Cuánto pesa la ropa?
1 sábana 400/500 g
1 funda 150/200 g
1 mantel 400/500 g
1 albornoz 900/1200 g
1 toalla 150/250 g
Prendas especiales
Camisas: para lavar camisas de distintos tipos de
telas y color, utilice el programa 10. Garantiza su
máximo cuidado minimizando la formación de
arrugas.
Seda: utilice el programa correspondiente 11 para
lavar todas las prendas de seda. Se aconseja el uso
de un detergente específico para prendas delicadas.
Cortinas: pliéguelas y colóquelas dentro de una
funda o de una bolsa de red. Utilice el programa 11.
Lana: Hotpoint/Ariston es la única lavadora que ha
obtenido el prestigioso reconocimiento Woolmark
Platinum Care (M.0508) otorgado por The Woolmark
Company que certifica el lavado en lavadora de todas
las prendas de lana, incluidas aquellas que contienen
la etiqueta sólo lavado a mano . En
consecuencia, con el programa 12 se puede utilizar
la lavadora con total tranquilidad para lavar todas sus
prendas de lana (máx. 1,5 kg) garantizando la
obtención de los mejores resultados.
Sistema de equilibrado de la carga
Antes de cada centrifugado, para evitar vibraciones
excesivas y para distribuir la carga de modo uniforme,
el cesto realiza rotaciones a una velocidad ligeramente
superior a la del lavado. Si después de varios intentos,
la carga todavía no está correctamente equilibrada, la
máquina realiza el centrifugado a una velocidad inferior
a la prevista. Cuando existe un excesivo desequilibrio,
la lavadora realiza la distribución antes que el
centrifugado. Para obtener una mejor distribución de la
carga y su correcto equilibrado, se aconseja mezclar
prendas grandes y pequeñas.
Downloaded From WashingMachine-Manual.com Manuals
