Hotpoint DF55 Operating instructions

USER & INSTALLATION
INSTRUCTIONS
for MODELS
DF56
DF55

Contents...
2
Retention of this Instruction Book...
This Instruction Book must be kept handy for reference as it contains important details on the safe
and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind, make sure
this Book is also provided so the new owner can become familiar with the appliance and safety
warnings.
Recycling & Disposal Information...
As part of our continued commitment to helping the environment, we reserve the right to use
quality recycled components to keep down customer costs and minimise material wastage.
Please dispose of packaging and old appliances carefully.
To minimise risk of injury to children, remove the door, plug and cut mains cable
off flush with the appliance, dispose of separately to ensure that the appliance can
no longer be plugged into a mains socket.
Electricity Supply / Safety Information......... 3
Safety............................................................................4
Installation: .........................................................5-6
Getting to Know your Appliance.......................7
The Controls.......................................................... 8
Programme Guide and Table...........................9-11
Before Using your Appliance:
Adjust the Water Softener................................ 12
Filling the Special Salt Container................... 13
Filling the Rinse Aid Container....................... 14
Detergents...........................................................14-15
What Can I Wash.................................................. 16
Loading your Dishwasher...............................17-18
Care & Maintenance.........................................19-20
Troubleshooting.......................................................21
Important Information....................................... 22
Guarantee................................................................ 23
After Sales Service................................................ 24
Key Contacts...............................................Back Page

Electrical Supply...
3
WARNING: This appliance must be earthed.
Fuses
Your appliance comes fitted with a plug and
a 13A fuse. If you need to replace the fuse,
only those rated at 13A and ASTA approved
to BS1362 should be used. If you lose the
fuse cover, a replacement may be obtained
from your local authorised Service Centre or
Electricity company. Correct replacement is
identified by colour coding or the marking
on base of plug.
WARNING: Do not use plug unless fuse cover is
fitted.
Changing the Plug
Cut off and dispose of the supplied plug if it
does not fit your socket.
WARNING: To avoid a shock hazard do not
insert the discarded plug into a socket
anywhere else.
IMPORTANT: WIRES IN THE MAINS LEAD ARE
COLOURED IN ACCORDANCE WITH THE
FOLLOWING CODE:
Green/Yellow - Earth
Blue - Neutral
Brown - Live
If you change the plug, the colour of wires
in the mains lead may not correspond with
the terminal markings in the plug, which if
not coloured, could be:
EARTH ‘E’ or
NEUTRAL ‘N’
LIVE ‘L’
Changing the Mains Lead
A special lead can be ordered from Service
UK: 08709 066 066 or
Republic of Ireland: 1850 302 220
If you have damaged the existing lead or
require a longer one a charge will be made.
It is strongly advised that this work is
carried out by a qualified electrician.
If the domestic wiring includes a residual
current-operated circuit breaker, ensure that
it conforms to the latest regulations.
Safety Information...
At the time of delivery...
All functions of your dishwasher have been
thoroughly tested at the factory. A small
number of water marks may have been left
as a result, they will disappear when the
appliance is used for the first time.
WARNING: The dishwasher must not be
connected to the electricity supply while
installation is being carried out.
- This appliance should only be
connected to a 230/240V AC source,
via a properly installed earthed socket.
- Use the dishwasher solely in a domestic
environment.
- Do not stand or place heavy objects on
the door when it is open, this could
damage the door or cause the appliance
to tip forward.
If your family includes children...
- Do not allow children to play with the
appliance or tamper with the controls.
- Keep detergents and rinse aids away
from children. Keep children away from
the open door of a dishwasher, there
could still be some detergent left inside.
The dishwasher meets all the requirements
set out by the regulations in force concerning
safety and electrical equipment.
Any technical checks should be conducted
exclusively by a trained and authorised
technician: Repairs carried out by
unauthorised persons will invalidate the
guarantee, as well as posing a potential haz-
ard to the user.
The manufacturer declines all responsibility
for damage to persons or property resulting
from failure to observe the above precautions,
from tampering with even a single
component or from the use of non original
spare parts.

Safety...
4
This manual forms an integral part of the
appliance. It must always be kept handy for
reference. Read through all the instructions
contained in this manual before using the
dishwasher.
Installation must be performed by a
qualified technician, in compliance with the
regulations in force, including the
prevention and elimination of radio
frequency interference.
●The dishwasher is designed for washing
and drying dishes, any other use shall be
considered improper. The manufacturer
declines all responsibility for uses other
than those described above.
The rating plate, featuring the technical
data, serial number and markings, is visibly
positioned on the inner edge of the door.
DO NOT remove the rating plate.
●Separate the various packaging
materials and dispose of safely - DO NOT
leave discarded packaging material
around the home.
●The mains plug must be easily
accessible after installation.
●In the event of any damage to the
power cord have it replaced by a
qualified technician.
●If the dishwasher is installed on a
carpeted or covered floor, ensure that
the openings on the underside are not
obstructed.
The dishwasher is intended for use by
adults. DO NOT allow children to come
near or play with the controls.
Keep children away from detergents and
clear of the dishwasher door when open.
Keep all packaging materials away from
children.
●DO NOT use solvents such as alcohol or
turpentine which may cause an
explosion.
●DO NOT load dishes to wash that are
soiled with ash, wax or paints.
●DO NOT lean, sit or stand on any part of
the dishwasher - this could cause injury
and/or damage the appliance.
●DO NOT drink any water residues from
inside the dishwasher.

Installation...
5
CONNECT TO A DRAINAGE SYSTEM...
WARNING
●Connect your dishwasher drain hose to
pipes which connect to the foul drain
system, and not to surface water drains.
IMPORTANT NOTES
For the correct operation of your
dishwasher, it is essential to comply with
the following information.
Standpipe
Ensure that the hose is not pushed too far
down the standpipe.
If the end of your drain
hose is fitted with ‘retaining
flaps’, ensure that they are
inserted fully into the
standpipe.This will prevent
the pipe from jumping out
during installation and
machine use.
DO NOT position the standpipe near an
electrical outlet.
ENSURE that the drain hose is not kinked
and it is routed as shown in the diagram.
The standpipe should be connected to:
a) A discharge stack-pipe
b) An external gulley OR
c) A sink waste.
The standpipe should have a bore of at
least 38mm (11/2"). It should be installed as
shown, have a trap fitted and must dis-
charge into the same drain system as your
household sink.
It must NOT be connected to a surface
water drain.
Sink Waste System
For under sink drainage:
Before connecting the drain hose,
remove any internal restrictions - This
will prevent a build up of debris which
could cause a blockage.
Remove any restrictions from the waste
spigot and ensure that the sealing
bung is removed.The hose should be
routed, such that it is raised to a
minimum height of 800mm (31/2")
Note: Ensure the sink outlet pipe has a
minimum diameter of 32mm.
1. Untie the end of the GREY drainage
hose from the rear of the appliance.
2. Reposition ‘Hooked End Support’ as
required along GREY drainage hose.
3. If fitting an under sink waste disposal
unit, cut out the membrane, bung or
blanking plug.
4. Attach the GREY drainage hose to
the under sink waste disposal unit
securely, using the clip and rubber
tube supplied.
Ensure the drain hose is securely attached,
to prevent it coming away while the
machine is in use and causing a flood.

Installation...
6
CONNECT TO THE WATER SUPPLY...
●For your machine to operate correctly
it requires water pressures in the range
of 6-150 psi (100-1000 KPa). Most
cold water supplies will be in this
range.
NOTE: Low water pressure will lead to
excessively long fill times or no fill.
●Ensure that the new hose supplied is
connected and the old hose is disposed
of safely.
●Before connecting hose to the cold
water supply ensure the filter gauze is
fitted in the filler hose connector.
WARNING
●Ensure the fill hose is NOT kinked.
Note: Do not over tighten the hose
connector. Hand tight is sufficient.
●Tap connections (if applicable) - A
range of adapters are available to suit
your tap.
WARNING
●Do not connect appliance to a single
outlet instantaneous water heater or
an electric heater.
Remember you may be charged for a
service call if a problem with your
appliance is caused by incorrect
installation or misuse.
CHECKLIST...
When you have installed your appliance,
ensure it is ready to use by following this
Check List:
1. Dispose of packaging safely, see
‘Recycling Information’ on page 2.
2. Position appliance close to
electrical/water supply.
3. Connect supplied hose to appliance
water supply, confirm water is flowing
before connecting to the appliance
inlet valve.
4. Untie drainage hose at rear of
appliance and connect to either a
standpipe or sink waste drainage
system see ‘Connect to a Drainage
System’.
5. Untie mains lead at rear of appliance
and plug into electrical supply via a
switched socket, see ‘Electrical Supply’
on page 3.
6. Position appliance, taking care not to
kink or damage hose at rear of
appliance.
7. Stabilise the appliance by adjusting the
feet.
8. Turn on the water supply to the
appliance.
9. Switch on at plug socket.
Your appliance is now ready for use, refer to
‘Getting to know your Appliance’ on page 7 to
familiarise yourself with the appliance.

Getting to Know your Appliance...
7
1
2
7
10
8
6
5
4
39
1. Upper Basket 6. Detergent Compartment.
2. Upper Spray Arm. 7. Rating Plate.
3. Filters. 8. Rinse Aid Container.
4. Lower Basket. 9. Lower Spray Arm.
5. Cutlery Rack. 10. Salt Container, with level indicator.
Interior...

The Controls...
8
WARNING:
CHILDREN SHOULD NOT BE ALLOWED TO PLAY WITH THE APPLIANCE OR TAMPER
WITH THE CONTROLS.
All the controls are grouped on the front panel.
1Washing programme selector
2On/Off button
3Recessed door handle
4ECONOMY 55˚ button
5SUPER button (Model DF56 only)
6Salt refill warning light
(Model DF56 only)
7Rinse Aid warning light
(Model DF56 only)
54 2 3 6 7 1

Programme Guide...
9
Setting the Wash Programme and
Switching On:
To select the most suitable programme for
the dishes to be washed, refer to the
PROGRAMME TABLE (see next page).
The table shows the most appropriate
programme according to item and degree
of soiling.
After using the table to identify the most
appropriate PROGRAMME SELECTION. Set
the selector (1) to the programme of your
choice by aligning the pointer with the
programme letter.
After loading the dishwasher and choosing
the wash programme:
●press the ON/OFF button (2).
Cancelling the current programme:
To cancel the programme in progress, the
programme must be switched off by
pressing the ON/OFF button (2).
Turn the wash programme selector to A:
Prewash and wait for the dishwasher to
start. On completion of the programme,
switch off the dishwasher by pressing the
ON/OFF button (2).
Changing the programme:
To cancel the programme in progress, the
dishwasher must be switched off by
pressing the ON/OFF button (2).
Turn the wash programme selector to the
programme required and switch the dish-
washer on again by pressing the ON/OFF
button (2). The dishwasher will carry out
the new programme automatically.
End of cycle:
At the end of the washing programme the
selector will be on one of the STOP markers,
depending on the programme carried out.
Switch off the dishwasher by pressing the
ON/OFF button (2).
Reference standard EN 50242
TABLE FOR CERTIFICATION BODIES
Reference programme (*) Selector on 3
12 place settings
B
30g
Depending on the
Model 3/4 or 4/6
Load
Type of detergent
Amount of detergent
Rinse aid setting
Before starting a wash programme, make
sure that:
●The water supply tap is open.
●The correct amount of detergent has
been added to the dispenser.
● The baskets have been loaded correctly.
●The spray arms can rotate freely and
without obstruction.
●The dishwasher door is securely closed.

10
PROGRAMME TABLE
PROGRAMME
PRE WASH A
45˚
COLD
COLD
-
-
65˚
----
30
30
30
30
25
10 + 25
2
165˚
65˚ YES
6 minutes
1 hour
50 minutes
1 hour
40 minutes
1 hour
36 minutes
4-
22 1.65
1.45
1.28
1.4
1.24
1.1
18
18
16
16
13
1 hour
1 hour
30 minutes
1 hour
32 minutes
YES
YES
YES
YES
YES
65˚
65˚
65˚
65˚
1
1
1
1
65˚
55˚
65˚
55˚
45˚
COLD
-
-
PREVENT DRIED ON RESIDUE,
PRIOR TO A WASH PROGRAMME
VERY HEAVILY SOILED PANS
AND DISHES, INCLUDING DRIED
ON RESIDUE
HEAVILY SOILED PANS AND
DISHES, INCLUDING DRIED ON
RESIDUE
NORMALLY SOILED PANS AND
DISHES, INCLUDING DRIED ON
RESIDUE
NORMALLY SOILED PANS AND
DISHES
SLIGHTLY SOILED PANS AND
DISHES
LIGHTLY SOILED PANS AND
DISHES
(*) Reference programme as EN 50242 standard
--
✓
✓
✓
-
-
--
-
-
-
-
-
B
B
B
C
C
D
INTENSIVE WASH
HEAVY WASH
ECONOMY
HEAVY WASH
NORMAL WASH
ECONOMY
NORMAL (*)
QUICK WASH
PROGRAMME
SELECTOR
POSITION
PROGRAMME SEQUENCE
DURATION
AMOUNT
OF
DETERGENT
CONSUMPTION
ELECTABLE
OPTION
55˚C SUPER
(DF56 only)
WHEN PROGRAMME
SHOULD BE USED
Water
(litres)
COLD RINSE
HOT RINSE
DRYING
PREWASH
WASH
Power
(Kwh)
- Not present (button position )
✓Present (button position )

Programme Guide...
11
To save on energy...
●Always try to run the dishwasher fully
loaded.
●Do not wash the dishes in running
water.
●Use the washing programme that is
most appropriate for each type of load.
To cut down on detergent consumption...
The phosphates contained in dishwasher
detergents are harmful to the environment.
To avoid using excessive amounts of
detergent and to save electricity, observe
the following:
●Separate the more delicate items from
dishes that are more resistant to
aggressive detergents and high
temperatures.
● Do not pour the detergent directly onto
the dishes.
Removing the dishes:
At the end of the washing programme, wait
at least 20 minutes before removing the
dishes, to allow them to cool down.
To prevent any water droplets on the upper
basket from dripping onto the dishes in the
lower basket, it is advisable to unload the
lower basket first - and the remove the
upper basket.

Before Using your Appliance...
12
Before using your Dishwasher you must carry
out the following steps to ensure you obtain
the best possible wash performance from
your appliance.
Follow these 4 steps:
- Adjust the Water Softener.
- Fill the Salt Container.
- Fill the Rinse Aid Container.
- Add detergent.
ADJUSTING THE WATER SOFTENER...
The dishwasher is equipped with a device for
the user to adjust the water softening system,
according to the hardness of the water supply.
The adjustment selector can be found inside
the plastic locking ring located on right hand
interior wall. This allows adjustment to 5
settings:
●In order to rinse dishes and glasses
satisfactorily, the dishwasher requires
soft water i.e containing little or no
lime, otherwise water stains are left
behind on crockery and glasses etc. If
the tap water exceeds a certain level of
hardness, it must be softened, ie.
decalcified, so that it can be used in the
dishwasher.
●The dishwasher is equipped with an
automatic softening system which uses
a special regenerating salt to reduce the
hardness of the water. The dishwasher is
factory set for water hardness level 3
(average hardness 41-60˚dF - 24-31˚dH).
●In order to ensure that the correct
amount of salt is being used to
regenerate the water softener, the
dishwasher is equipped with an
electronic device for adjusting the water
softening setting.The setting may be
adjusted electronically. To set this
correctly the hardness of your water
needs to be ascertained.
WATER HARDNESS TABLE:
●Contact your local water board for
information on the water hardness for
your area.
When using water of medium hardness, the
regenerating salt container should be
refilled after approximately 20 wash cycles.
The salt container can hold approximately
1.7Kg of salt in grains.
SETTING WATER HARDNESS
N. 1 NO SALT 0 - 4˚dH (0 - 7˚dF)
N. 1 5 - 9˚dH (8 - 15˚dF)
N. 2 10 - 22˚dH (16 - 37˚dF)
N. 3 23 - 29˚dH (38 - 50˚dF)
N. 4 30 - 35˚dH (51 - 60˚dF)
N. 5 36 - 41˚dH (61 - 70˚dF)
adjustment selector

13
FILLING THE SPECIAL SALT
CONTAINER...
Note:
Only use recommended Dishwasher salt or
granular salt.
DO NOTuse everyday table salt, cooking
salt or road salt as they contain insoluble
substances which could harm the
Dishwasher.
How the salt works:
While washing is taking place, salt is
automatically rinsed out of the salt
container into the water softener where it
dissolves the lime in the water.The
dissolved lime is pumped out of the
dishwasher.The water softener system is
then ready for the next load.This process of
regeneration can only function when the
salt is dissolved in water.
The container is situated at the bottom of
the dishwasher.
You will need to remove the lower basket
for access.
● You should fill just before starting the
programme.
●Unscrew the lid of the salt container,
turning it anti-clockwise to remove.
Before using the dishwasher for the
first time, pour approximately 1 litre of
water into the salt container.
●Use the supplied funnel to fill salt to the
top of the container. As you tip in the
salt some of the water is displaced and
drains away.
When you have done this, clean off any
remnants of salt from the area around
the neck of the container. Always make
sure that the cap is replaced securely
ensuring that it is not cross-threaded.
Information:
Add salt when required as advised in
the chart on the previous page.
Refill the salt container before starting
the wash programme.
In this way the excess saline solution
will be immediately washed away by
the water, the prolonged presence of
salt water inside the tank may lead to
corrosion.
When using the dishwasher for the first
time, in addition to the salt it is also
necessary to add ONE litre of water to
the container.
WARNING:
DO NOT pour detergent into the special
Salt Container.This will destroy the
water softener.
Each time the salt container is refilled,
make sure that the cap is securely
closed.
The mixture of water and detergent
must never penetrate the salt
container, as this would compromise
the operation of the regeneration
system. In the event of this occurring,
the guarantee will be invalidated.

14
The detergent and rinse aid dispensers are
situated on the inner part of the door: the
detergent dispenser is on the left and the
rinse aid dispenser is on the right.
FILLING THE RINSE AID CONTAINER...
The purpose of Rinse Aid is to help the
dishes dry faster and to prevent formation
of water marks on tableware and utensils,
and to ensure that glasses are clean and
sparkling.
Rinse Aid is consumed during the washing
process and needs adding when required.
- Open the door. Rotate the rinse aid
container cap anticlockwise by 1/4of a
turn and remove it.
- Add the rinse aid until the container is
full (approximately 140cc). The level
indicator on the side should be
completely obscured.
Refill the rinse aid when the optical level
indicator becomes clear again, or when
the rinse aid warning light illuminates
(Model DF56 only).
- Replace the cap, turn clockwise and
ensure it is securely closed.
- Use a cloth to remove any spillage.
Important:
Only use rinse aids intended for use in
domestic dishwasher's,
Adjusting the amount of Rinse Aid...
The amount of rinse aid added to the water
can be varied by adjusting the control.The
rinse aid control has been factory set for
medium water hardness.
Do not alter the setting of the rinse aid
control unless streaks or water marks are
left on the dishes.
To adjust the rinse aid setting, rotate the
dispenser cap through a quarter turn in an
anti-clockwise direction and remove it. Use
a screwdriver to turn the rinse aid control to
the required position. Replace the cap
securely turning clockwise.
RINSE AID CONTROL
●The amount of rinse aid needs to be
increased if the appear dull or you can
see circular stains.
●The amount of rinse aid needs to be
reduced if the dishes are sticky or you
can see whit streaks.
DETERGENTS...
Information about detergents:
You can use any brand of liquid or powder
detergent, as well as tablets, that have
specifically designed for use in domestic
dishwasher's.
DO NOT use normal washing up liquid.
There are three types of dishwasher
detergent available:
1. those containing phosphates and
chlorine.
2. those containing phosphates but no
chlorine.
3. those containing neither phosphates
nor chlorine.
When a phosphate-free detergent is used in
conjunction with hard water, there is a
greater possibility that white marks will be
left behind on crockery and glasses etc.
These can be avoided by pouring an
increased amount of detergent into the
dispenser.
Chlorine-free detergents have a reduced
bleaching effect.This can mean that tea
stains are not completely removed or that
plastic items become discoloured.
This can be resolved by:
- selecting a higher temperature
programme, or
- increasing the amount of detergent, or
- using a detergent that contains
chlorine.
Check detergent packaging labels to
determine whether a particular product is
suitable for use with silverware.
RINSE AID WARNING LIGHT (Model DF56)

15
Adding the detergent...
With the exception of the Prewash
programme, you will need to add detergent
before every washing cycle.
To open the detergent dispenser lid, lightly
press button ‘P’. Add the detergent and
close the lid carefully.
During the washing cycle the dispenser will
be opened automatically.
It is important to use detergent specially
designed for domestic dishwashers.
We recommend Glist 3 in 1 for use in this
(or your new) dishwasher...
Brilliant cleaning is guaranteed with
Glist 3 in 1.
Hotpoint only recommends Glist 3 in 1
Dishwasher tablets to give outstanding
cleaning and care.
It is important to use detergent specially
designed for domestic dishwashers.
(Always follow the manufacturers
instructions.)
Glist 3 in 1 advanced dishwasher tablets
with active enzymes are the ideal way to
protect and care for your dishwasher, while
getting your dishes sparkling clean.
Softer Water
Built in salt action softens water, helping to
prevent the build up of limescale in the
dishwasher and improve the cleaning
result*.
Cleaner Dishes
With unique active enzymes in the cleaning
phase Glist 3 in 1 breaks down even the
hard to shift foodstuffs and grease, leaving
the dishes spotless and the dishwasher
clean too.
Sparkling Results
The built-in Glist rinse agent ensures the
dishes are free from water marks and
smears and even the glasses will come out
glistening.
If you have any questions regarding
Glist 3 in 1, please contact the hotline on
0800 216 730.
*If you live in an area particularly prone to
very hard water ( 35˚f) Glist and Hotpoint
recommend that you continue to keep your
dishwasher salt topped up.

16
Items not suitable for the dishwasher:
●Cutlery and tableware made from
wood or part wood-They become
faded and unsightly in appearance.
●Avoid washing horn-handled and
bronze cutlery in the machine.
●Delicate/decorative glassware and
vases, special antique or irreplaceable
china - the decorative patterns printed
on these objects will not be dishwasher
proof.
●Plastic objects that are not resistant to
hot water.
●Copper and Pewter utensils.
●Aluminium and silver objects.
●Decorative patterns printed on the
surface of crockery, glasses etc.
●Some types of glass can become
opaque in appearance after they have
been washed too many times in a
dishwasher.
●Highly absorbent materials such as,
sponges and towels should never be
placed in a dishwasher.
If in any doubt, check with the manufacturer
of the China, pan(s) and cutlery on their
suitability for dishwasher's.
WARNING: Dishes or cutlery that have been
soiled by tobacco ash, wax, lubricating grease
or paint, should not be put in the dishwasher.
Our recommendation:
In future, only purchase table or kitchen-
ware that has been confirmed as being
dishwasher proof.
What can I Wash...

Your dishwasher is designed to take 12
standard place settings.
There is no one correct method for loading
the dishwasher. The upper and lower
baskets are designed to give the maximum
flexibility possible to cope with the variety
of cups, glasses, dishware, pots, pans and
utensils - not to mention your oven fittings
or teapot, which might be put into the
dishwasher.
Loading
●First remove all coarse food remains
which could block the filter or damage
the wash pump.
●Arrange all items so that water can
drain away, as you would on a draining
board.
●Large or heavily soiled items should go
in the lower basket. The lower basket
plate rack can be folded down to
accommodate larger items. The upper
basket can be adjusted to allow for
large items in the lower basket .
Smaller, delicate items (eg. glasses)
should go in the top basket.
●Arrange plates so that they are not
touching and water can flow freely
between them.
●Tall, narrow receptacles should be
placed in the centre of the baskets,
directly over the spray.
●Long stemmed glasses should lean
against the cup rack, not against
dishware.
●Cutlery should be distributed at
random in the cutlery basket with
handles down (except if the handles
are very thin and could drop through
the basket).
●Long cutlery, such as ladles and knives
should be laid horizontally across the
filled cutlery basket.
●Pots and pans with baked on areas
should first be soaked and then
arranged, upside down in the lower
basket, so that the water jets can have
direct access to the dirty areas.
●After loading check that the upper
spray arm is free to rotate by giving it
a spin with your hand.
WARNING:
ALWAYS CHECK THAT PLASTIC AND
WOODEN ITEMS ARE SECURELY PLACED
AND ARE WEIGHTED DOWN WITH
HEAVIER OBJECTS SO THAT THEY CANNOT
BECOME DISLODGED.
TAKE EXTRA CARE WHEN LOADING AND
UNLOADING SHARP ITEMS SUCH AS
KNIVES.
LOADING the Upper Basket...
It is recommended to load the upper
basket with small or medium sized
items such as glasses, small plates, tea
or coffee cups, shallow bowls and light
objects made from heat resistant
plastic. If the upper basket is used in
the lowest position, it can also be
loaded with serving dishes, provided
they are only slightly soiled.
To make full use of the space available
the top basket has two plastic grids
that can be lifted to make room for tall
glasses such as stem glasses.
Load the dishes with the top side
facing forwards, cups and concave
containers should always be loaded
with the opening facing down. The left
side of the basket can be loaded with
cups and glasses on two levels. In the
centre section, plates and saucers can
be loaded vertically into the supports
provided.
Upper Basket Loading Examples:
17
Loading your Dishwasher...

ADJUSTING THE UPPER BASKET...
The upper basket can be adjusted in two
positions, according to your needs and to
allow for the height of dishes in the lower
basket.
Pull out version:
●Pull the basket out fully.
●Remove the stop ‘E’ first releasing it as
shown.
●Push the guide to free the wheels.
●Lift the basket and insert the lower pair
of wheels into the guide, depending on
the setting required.
●Return the stop ‘E’ to its original
position.
LOADING the Lower Basket...
The lower basket receives the full force
of the lower spray arm and should
therefore be used for the ‘toughest’
items with a heavier degree of soiling.
All types and combinations of loads are
permitted, provided that the dishes,
pots and pans are arranged with all the
soiled surfaces exposed to the water
jets coming from the bottom.
Carefully load flat plates, soup dishes,
dessert and serving dishes, positioning
them vertically. Pots, pans and their
covers must be loaded upside down.
When loading soup plates and dessert
bowls be sure to leave a gap between
them.
Lower Basket Loading Examples:
CUTLERY BASKET...
The cutlery should be arranged in an order-
ly manner inside the cutlery basket - with
handles pointing downwards.
Take care during loading to avoid injury
from the knife blades.
The basket is suitable for all types of cutlery,
except those long enough to interfere with
the upper spray arm.
Ladles, wooden spoons and cooking knives
can be placed in the upper basket, making
sure that the knife blades do not protrude
from the basket.
18
Loading your Dishwasher...

Before carrying out any work, always
disconnect the dishwasher from the
electrical power supply.
Regular inspection and maintenance helps to
prevent problems from occurring. You should
therefore carefully inspect the inside of your
dishwasher from time to time.
Overall condition of appliance.
- Clean the outer surfaces and door lining
of the dishwasher regularly using a soft
cloth moistened with water or with a
detergent which is suitable for painted
surfaces. Clean he door gaskets with a
damp sponge. Avoid the use of acidic
or abrasive detergents.
- Periodically (once or twice a year) it is
advisable to clean the tank and gaskets,
using a soft cloth and water to remove
any deposits.
- Check that no grease or scale has
accumulated on the inside of the
dishwasher.
If you discover any deposits:
- Clean the interior of the dishwasher
thoroughly with a detergent solution.
Cleaning the Filter Unit.
The filters prevent large particles of food in
the water from reaching the pump.These
particles may occasionally block the filters.
- It is advisable to periodically check the
centre filter ‘C’ and if necessary to clean
it. To remove the filter, grip the tabs, turn
anticlockwise and lift upwards.
- Push the centre filter ‘D’ from the
underside to remove it from the micro-
filter.
- Separate the two parts which make up
the plastic filter by pressing the body of
the filter in the position shown by the
arrows.
- Remove the centre filter by lifting it
upwards.
The filters should be cleaned carefully under
running water using a stiff brush.
- Carefully replace the filters by following
the above instructions in reverse order.
Cleaning the Water Intake Filter.
The water intake filter, located at the outlet of
the water supply tap, needs to be cleaned
periodically.
Turn OFF the water supply tap, unscrew the
water intake hose to remove from the tap.
Clean the filter carefully, under running water.
Relocate the filter and carefully screw the
water intake hose onto the tap.
Care and Maintenance...
19

Spray arms.
The spray arms can be easily removed for
periodic cleaning of the nozzles, to prevent
possible blockage.
- To remove the upper spray arm, unscrew
locking ring ‘R’.
- To remove the lower spray arm, hold
centrally and simply lift it up.
- Clean both spray arms under running
water.
- Re-fit the spray arms. Check that spray
arms turn freely.
Care and Maintenance...
20
