Hotpoint HDA2000VBB User guide

This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
55
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
24
25-3/4
MAX.
21-1/2
3-1/4 4 (Adjustable)
34" MIN.
adj. to 35"
24-3/4
23-3/8
Electrical Rating
Voltage AC............................................... 120
Hertz........................................................ 60
Total connected load amperage............. 8.6
Calrod®heater watts max................... 500
For use on adequately wired 120-volt, 15-amp circuit
having 2-wire service with a separate ground wire.
This appliance must be grounded for safe operation.
Note: Dishwasher must not be installed more than
10 feet from sink for proper drainage. All plumbing
and electrical work must be in accordance with
local codes. Dishwasher includes drain hose and
leveling legs.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
Dishwasher Dimensions (in inches)
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Listed by
Underwriters
Laboratories
C
B
Access insert
Panel Thickness
Door insert
Front
of
Panel
Dishwashers Installation
(Pub. 1-G003 pg. 131B) May 12, 1993
Wood Insert Cut-Out Dimensions (in inches)
GE/Hotpoint/RCA
A
1-1/2 1/2
When using GPF325
1/4" custom dishwasher
door and access panel kit.
When using GPF375
3/4" custom dishwasher
door and access panel kit.
1/4
3/4
Panel
Thickness
Kit A B C
GPF325 18-7/8" 23-9/16" 3-11/16 " 1/4"
GPF375 18-15/16" 23-5/8"* 4-1/4" to
3-3/4"**
3/4"
* Bottom of panel must be notched 1-1/2" x 1/2" to clear across panel
** Adjustment required to match adjacent cabinet fronts due
to leveling leg adjustment, 4" nominal
HDA2000V – Hotpoint Built-In Dishwasher
Specification Created 4/11
450159

Features and Benefits
• 4-level PowerScrub™ wash system - Powerful wash cleans dishes thoroughly
• Two-stage filtration with ExtraFine™filter - Extra filtration keeps water clean
• P i r a n h a ™hard food disposer - Grinds food into small particles that are washed away
• HotStart™ option - Provides optimal water temperature for dependable performance
• 64 dBA - motor runs quietly to keep kitchen peaceful
• Pots and Pans cycle - Removes difficult soils from cookware
• ENERGY STAR®Qualified - Meets or exceeds 2011 federal guidelines for energy efficiency for
year-round energy and money savings
• 5 cycles/2 options - Allows you to select the combination that best cleans your dishes
• Up to 12-place setting capacity racking - Provides flexibility to wash a variety of dishes at once
• Model HDA2000VWW – White on white
• Model HDA2000VBB – Black on black
HDA2000TWW_BB
