Hotpoint EG94 User manual

Instructions for Installation and Use
60cm slot-in double oven Dual Fuel cooker
EG94
To the Installer:
Before installation, fill in the product details on the back cover of this book.
The information can be found on the rating plate.
To the User:
You must read the instructions prior to installing and using the appliance and
then retain them for future reference.

Contents
Page
Introduction
Safety Information 4-5
Features 6
The Controls 7-9
The Cooking Modes in your Cooker 10-11
Electronic Clock & Automatic Cooking Feature 12-15
Temperature Conversion Chart 16
Hotplate 17-18
Solarplus Grill 19-20
Top Oven – Conventional Cooking 21
Top Oven Cooking Temperature Charts 22-2
Main Oven – The Intelligent Cooking System 24
Main Oven Cooking Temperature Charts 25-27
Care and Cleaning 28- 0
If something goes wrong / If it still won’t work 1- 2
Installation - 8
Hotpoint Service Cover 9
Key Contacts back page
2
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important
details on the safe and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind,
make sure this Book is also provided so the new owner can become familiar with the
appliance and safety warnings.

Introduction
This appliance conforms to the following EEC Directives:
Gas Appliances
90/ 96/EEC
Low Voltage Equipment
7 /2 /EEC
9 /68/EEC
Electromagnetic Compatibility
89/ 6/EEC
92/ 1/EEC
9 /68/EEC
The cooker must be installed in accordance with the regulations in force and only used in
a well ventilated space.
To help you make the best use of your cooker, PLEASE READ THIS BOOKLET CAREFULLY.
Your new cooker is guaranteed and will give lasting service. The guarantee is only
applicable if the cooker has been installed in accordance with the Installation Instructions.
The cooker is designed specifically for domestic use and responsibility will not be
accepted for use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a window or
use an extractor fan) and that persons who may be sensitive to the odour avoid any
fumes.
It is suggested that any pets be removed from the room until the smell has ceased. This
odour is due to any temporary finish and also any moisture absorbed by the insulation.
Our policy is one of continual improvement in design and development, therefore strict
accuracy of illustrations and descriptions cannot be guaranteed.

afety Information
4
PLEA E READ THE PRECAUTION BELOW BEFORE U ING YOUR APPLIANCE.
●Always understand the controls prior to using the appliance.
●Always turn controls off when not in use.
●Always stand back when opening an oven door to allow any build up of steam or heat
to disperse.
●Always use dry good quality oven gloves when removing items from the ovens/grill.
●Always take care when removing items from the top oven/grill when the main oven is on,
as the contents may be hot.
●Always keep the oven/grill door closed when the appliance is notin use.
●Always place pans centrally over the hotplate burners and position them so that the
handles cannot accidentally be caught or knocked or become heated by other burners.
●Always keep the cooker clean, as a build up of grease or fat from cooking can cause a
fire.
●Always allow the cooker to cool before cleaning.
●Always f ollow the basic principles of food handling and hygiene to prevent the possibility
of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always turn off the electricity supply before cleaning or replacing the oven lamp.
●Always refer servicing to CORGI registered appliance service engineers.
Always

afety Information
5
●Never leave children unsupervised where the cooker is installed as all surfaces will be
hot during and after its use.
●Never allow anyone to sit on or stand on any part of the cooker.
●
Never store items above the cooker that children may attempt to reach.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the appliance,
or in cabinets immediately above or next to the appliance.
●Never place flammable or plastic items on or near the hotplates.
●Never fill a deep fat frying pan more than 1/ full of oil, and never use a lid.
DO NOT LEAVE DEEP FAT FRYING PAN UNATTENDED WHILE COOKING.
●Never use proprietary spillage collectors on the hotplate.
●Never use the appliance as a room heater.
●Never dry clothes or place any items over or near to the hotplate or oven/grill doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never wear garments with long flowing sleeves whilst cooking.
Never
NOTE: The use of a gas cooking appliance results in the production of heat and moisture
in the room in which it is installed. Always ensure that the kitchen is well ventilated; keep
natural ventilation holes open or install a mechanical ventilation device (mechanical
extractor hood).
In particular when using more than one hotplate burner, open a window if a mechanical
ventilation device is not operating.

Features
6
Control panel
Timer
Grill pan and
food support
Meat pan
and food
support
Gas Burner
Gas Burner
Gas Wok Burner
Gas Burner
Top Oven/Grill
rod shelf
‘Stay Clean’ liners
Oven
fan
Main oven
rod shelf
Main oven seal
split at these corners
Model number &
Serial number label
Removable
Inner door glass
Removable
Inner door glass
Solarplus Grill
‘Stay Clean’ liners
Top Oven door
Top Oven wire
work shelf support
Main Oven wire
work shelf support
Telescopic meat
pan runners
Oven Light
Main Oven
door
Ignition button
Oven light
Door Switch
NOTE: To keep the controls cool when the appliance is used, a flow of air may be blown
from beneath the control panel. If the appliance is still warm, this cooling fan will run
on when all controls have been turned off. This is normal and is not a fault.
The fan will stop once the appliance has cooled.
NOTE: Children should not be allowed to play with the appliance or tamper with the controls.
WARNING: DO NOT touch the oven doors when the oven is in use, as these
areas can become hot.

The controls
7
Switch on the electricity supply to the cooker at the Cooker Control Unit.
Gas Hob Controls
Main Oven Light
Cooling Fan
Press the ignition button and then push in and turn the control
knob of the chosen burner anti-clockwise to the large flame symbol.
Continue to press the ignition button until the sparks light the gas.
Turn the control knob anti-clockwise to reduce the heat input.
Only turn the control between the large flame symbol and the small
flame symbol when adjusting the setting.
To turn off, turn the control knob fully clockwise to the symbol ‘O’,
its off position.
The main oven light can be switched on, when the oven is not in use,
by pressing the oven light button on the display. The oven light will
also operate whenever the main oven door is opened.
NOTE: The oven light can be switched off when the door is opened
by pressing the oven light button on the display, or by
closing the door.
The cooling fan operates with the ovens and grill. The fan will
operate at full speed for a few seconds and then reduce to a lower
speed. The cooling fan will only increase to full speed if the
temperature inside the cooker reaches above a certain limit.
Main
Oven
Control
Timer
Top
Oven
Control
Ignition
Button
Grill
Control
Gas Hob Controls

The controls
8
Grill Control -
Top Oven
Top Oven Control
Notes
The grill control will not operate unless the top oven control is in
the ‘O’ off position.
The grill control provides fully variable heat control for either the
twin grill or single (left hand side) grill by selecting any number
between 1 & 4.
When turned clockwise the twin grill will be switched on and any
power setting from 1 - 4 can be selected. The power level numbers
are indicated on the control knob.
When turned anti-clockwise the single grill will be switched on and
any power setting from 1 - 4 can be selected.
The power level numbers are indicated on the control knob.
The off position is identified by an ‘O’.
This control switches on the top and bottom heating elements in
the top oven. The temperature in the oven can be set anywhere
between 100˚C and 220˚C.
The top oven ON indicator (TOP) and the top oven preheat
temperature indicator ( symbol) will be on the display (bottom
left hand corner).
The top oven preheat temperature indicator ( symbol) will switch
OFF and an audible tone will sound when the top oven has reached
the required temperature.
When in operation the oven light will be illuminated.
The off position is identified by an ‘O’.
If both the top oven and grill controls are turned on together, the
(TOP) and ( symbol) will flash on the display. The cooker will
continue to operate in the function which was selected first.
-+
Main Oven Select
control
Time / Mode
Minute
Minder
Set
Time
End
Time
Cooking
Duration
+/- Control
Knob
Main Oven
Light
Main Oven:
- Recommended
Shelf Position
and
- Preheat
Temperature
Indicator
Top Oven:
- ‘ON’ Indicator
and
- Preheat
Temperature
Indicator
Main Oven Functions (1-7):
Top Oven
control
1.FAN
OVEN
2.TRADITIONAL
OVEN
3.ROAST
MEAT
4.ROAST
CHICKEN
5.FISH
6.BREAD
7.CAKES
Grill
control
continued...

The controls
9
Main Oven Control
Adjusting the Main
Oven Temperature
The Main Oven
Cooking Functions
This control switches on the top and rear heating elements at
various times in the main oven, dependent on which mode has been
set. The temperature of the main oven can be set anywhere
between 80˚C and 2 0˚C in cooking modes 1 - 5.
The main oven preheat temperature indicator ( symbol) will be on
the display (middle, left hand side).
The main oven preheat temperature indicator ( symbol) will switch
OFF and an audible tone will sound when the main oven has reached
the required temperature.
The main oven has eight cooking functions. Use the main oven
control to select the cooking mode you require. The display will show
the function you have selected, across the top (1 - 7) with the
eighth function being shown on the clock display as ‘(RISE)’.
When a program is set (position 1 - 5), the display will automatically
suggest a cooking temperature. If you wish you can use the +/-
control knob to change the suggested temperature to one of your
own choice, within a range which is suitable for the particular
cooking mode.
continued...

10
The Cooking Modes in your Cooker
Your new cooker is equipped with a number of different cooking modes:
Conventional Heating (Top Oven)
- with upper and lower heat. This system is particularly suitable for
roasting and baking on one shelf only.
Variable Grilling (Top Oven)
- the oven can also be used for conventional grilling with a full or
half width fully controllable grill.
Note: The Top Oven door should be open when grilling.
Fan Oven (Main Oven)
- the fan oven operates by constantly blowing heated air, from an
element wrapped around the fan, into the oven. This gives improved
efficiency and in general, enables the use of lower temperatures
for cooking. It also means that there is less need to be particular
about shelf positions and that you can bake at more than one level
simultaneously (Batch Baking).
Traditional (Main Oven)
- the upper and rear heating elements are switched on in this
position. The traditional oven brings an outstanding level of
temperature distribution and reduced consumption. In traditional
cooking use only one rack to ensure good heat distribution. By using
the various shelf positions available you can balance the quantity of
heat between the upper and lower part. If cooking requires more
heat from below or above, use the lower or higher shelves respectively.
Roast Meat (Main Oven)
- specially created for cooking joints of meat. This mode raises the
temperature in the oven to a very high heat for the first part of the
cooking cycle, to seal the outside of the joint and retain the juices
of the meat throughout cooking. After this the temperature is
reduced to the set temperature using each heating element in turn
to guarantee a homogeneous temperature for the cooking period.
A temperature is suggested on this mode but this can be altered
using the '+/-' control knob.
Roast Chicken (Main Oven)
- specially created for cooking excellent roast poultry. This mode
can be used to roast chickens, duck, turkey and other poultry to
perfection. Each heating element is used in the cycle to guarantee a
homogeneous temperature within the oven.
A temperature is suggested on this mode but this can be altered
using the '+/-' control knob.
