Hotpoint SA4844CIX Installation and operation manual

1
EN
DAILY REFERENCE GUIDE
THANK YOU FOR PURCHASING AN HOTPOINT
PRODUCT
To receive more comprehensive help and
support, please register your product at
www.hotpoint.eu/register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website docs.hotpoint.eu and following the
instructions on the back of this booklet.
Before using the appliance carefully read the Health and Safety guide
PRODUCT DESCRIPTION
2
3
4
5
8
9
7
6
1
1. Control panel
2. Fan
3. Lamp
4. Side grids
(the level is indicated on the wall of the cooking
compartment)
5. Door
6. Upper heating element / Grill
7. Round heating element
(non-visible)
8. Identification plate
(do not remove)
9. Bottom heating element
(non-visible)
CONTROL PANEL
13245 6
1. SELECTION KNOB
For switching the oven on by
selecting a function. Turn to the
position to switch the oven o.
2. LIGHT
With the oven switched on, press to
turn the oven compartment lamp on
or o.
3. TIME SETTING
For accessing the cooking time
settings, delayed start and timer. For
displaying the time when the oven
is o.
4. DISPLAY
5. ADJUSTMENT BUTTONS
For changing the cooking time
settings.
6. THERMOSTAT KNOB
Turn to select the temperature you
require when activating manual
functions. Automatic functions use
.

2
ACCESSORIES Download the Use and Care Guide from docs.hotpoint.eu for
more information
WIRE SHELF BAKING TRAY
The number and type of accessories may vary depending on which model is purchased. Other accessories can be
purchased separately from the After-sales Service.
USING THE ACCESSORIES
• Insert the wire rack onto the level you require by
holding it tilted slightly upwards and resting the raised
rear side (pointing upwards) down rst. Then slide it
horizontally along the shelf guides as far as possible.
The other accessories, such as the baking tray, are
inserted horizontally by sliding them along the shelf
guides.
• The shelf guides can be removed to facilitate oven
cleaning, by pulling them away from the side walls.
FUNCTIONS Download the Use and Care Guide from docs.hotpoint.eu for
more information
CONVENTIONAL
For cooking any kind of dish on one shelf only.
FORCED AIR
For cooking dierent foods that require the
same cooking temperature on several shelves
(maximum three) at the same time. This function can
be used to cook dierent foods without odours being
transferred from one food to another.
MAXI COOKING
For cooking large joints of meat (above 2.5 kg).
We recommend turning the meat over during
cooking to ensure that both sides brown evenly. We
also recommend basting the joint every so often to
prevent it from drying out excessively.
PIZZA
For baking dierent types and sizes of pizza and
bread. It is a good idea to swap the position of
the baking trays halway though cooking.
GRILL
For grilling steaks, kebabs and sausages,
cooking vegetables au gratin or toasting bread.
When grilling meat, we recommend using a drip tray
to collect the cooking juices: Position the tray on any
of the levels below the wire shelf and add 200 ml of
drinking water.
TURBO GRILL
For roasting large joints of meat (legs, roast
beef, chicken). We recommend using a drip tray
to collect the cooking juices: Position the tray on any
of the levels below the wire shelf and add 200 ml of
drinking water.
RISING
For helping sweet or savoury dough to rise
eectively. Turn the thermostat knob to the
icon to activate this function.
DEFROSTING
For defrosting food more quickly.
ECO FORCED AIR
For cooking roasts and stued roasting joints
on a single shelf. Food is prevented from drying
out excessively by gentle, intermittent air circulation.
When this ECO MODE function is in use, the light
will remain switched o during cooking but can be
switched on again by pressing .
BREAD AUTO
This function automatically selects the ideal
temperature and baking time for bread. For
best results, carefully follow the recipe . Activate the
function when the oven is cold.
PASTRY AUTO
This function automatically selects the ideal
temperature and baking time for cakes. Activate
the function when the oven is cold.
WWW
WWW

3
EN
FIRST USE
1. SET THE TIME
You will need to set the time when you switch on the
appliance for the rst time: press until the icon and
the two digits for the hour start ashing on the display.
Use or to set the minutes and press to conrm.
The two digits for the minutes will start ashing. Use
or to set the minutes and press to conrm.
Please note: When the icon is flashing, for example
following lengthy power outages, you will need to reset the
time.
2. HEAT THE OVEN
A new oven may release odours that have been left
behind during manufacturing: this is completely
normal.
Before starting to cook food, we therefore recommend
heating the oven with it empty in order to remove any
possible odours.
Remove any protective cardboard or transparent lm
from the oven and remove any accessories from inside
it.
Heat the oven to 250 °C for about one hour, preferably
using the “Maxicooking”function. The oven must be
empty during this time.
Follow the instructions for setting the function correctly.
Please note: It is advisable to air the room after using the
appliance for the first time.
DAILY USE
1. SELECT A FUNCTION
To select a function, turn the selection knob to the
symbol for the function you require: the display will
light up and an audible signal will sound.
2. ACTIVATE A FUNCTION
MANUAL
To start the function you have selected, turn the
thermostat knob to set the temperature you require.
Please note: During cooking you can change the function
by turning the selection knob or adjust the temperature by
turning the thermostat knob. The function will not start if
the thermostat knob is on . You can set the cooking time,
cooking end time (only if you set a cooking time) and a
timer.
AUTOMATIC
To start the automatic function you have selected
(“Bread” or “Dessert”), keep the thermostat knob at the
position for automatic functions ( ).
To nish cooking, turn the selection knob to position .
Please note: You can set the cooking end time and timer.
RISING
To start the “Rising” function, turn the thermostat knob
to the relevant symbol; if the oven is set to a dierent
temperature, the function will not start.
Please note: You can set the cooking time, cooking end time
(only if you set a cooking time) and a timer.
3. PREHEATING
Once the function starts, an audible signal and
a ashing icon on the display indicate that the
preheating phase has been activated.
At the end of this phase, an audible signal and the xed
icon on the display will indicate that the oven has
reached the set temperature: at this point, place the
food inside and proceed with cooking.
Please note: Placing the food in the oven before preheating
has finished may have an adverse effect on the final cooking
result.
. PROGRAMMING COOKING
You will need to select a function before you can start
programming cooking.
DURATION
Keep pressing until the icon and “00:00” start
ashing on the display.
Use or to set the cooking time you require and then
press to conrm.
Activate the function by turning the thermostat knob
to the temperature you require: an audible signal will
sound and the display will indicate that cooking is
complete.
Please note: to cancel the cooking time you have set, keep
pressing until the icon starts flashing on the display,
then use to reset the cooking time to “00:00”.
This cooking time includes a preheating phase.

4
PROGRAMMING THE END COOKING TIME / DELAYED
START
After a cooking time has been set, starting the function
can be delayed by programming its end time: press
until the icon and the current time start ashing on
the display.
Use or to set the time you want cooking to end and
press to conrm. Activate the function by turning the
thermostat knob to the temperature you require: the
function will remain paused until it starts automatically
after the period of time that has been calculated in
order for cooking to nish at the time you have set.
Please note: To cancel the setting, switch the oven off by
turning the selection knob to position “ ”.
. SETTING THE TIMER
This option does not interrupt or program cooking but
allows you to use the display as a timer, either during
while a function is active or when the oven is o.
Keep pressing until the icon and “00:00” start
ashing on the display.
Use or to set the time you require and press to
conrm.
An audible signal will sound once the timer has nished
counting down the selected time.
Please note: To cancel the timer, keep pressing until the
icon starts flashing, then use to reset the time to“00:00”.

5
EN
COOKING TABLE
RECIPE FUNCTION PREHEAT TEMPERATURE
(°C)
DURATION
(MIN) LEVEL AND ACCESSORIES
Leavened cakes
Yes 160 - 180 30 - 90 2 / 3
Yes 160 - 180 30 - 90 41
Filled cakes
(cheese cake, strudel, fruit pie)
Yes 160–200 35-90 2
Yes 160 – 200 40 - 90 42
Biscuits / tartlets
Yes 160 - 180 20 - 45 3
Yes 150 – 170 20 - 45 42
Yes 150 - 170 20 - 45 53 1
Choux buns
Yes 180 - 210 30 - 40 3
Yes 180 - 200 35 - 45 42
Yes 180 - 200 35 - 45 53 1
Meringues
Yes 90 150 - 200 3
Yes 90 140 - 200 42
Yes 90 140 - 200 53 1
Pizza / Bread
Yes 190 - 250 15 - 50 1 / 2
Yes 190 - 250 20-50 42
Bread —— 60
2
Frozen pizza
Yes 250 10 - 20 3
Yes 230 - 250 10 - 25 42
Salty cakes
(vegetable pie, quiche)
Yes 180 - 200 40-55 3
Yes 180 - 200 45 - 60 42
Yes 180 - 200 45 - 60 531
Vol-au-vents / puff pastry crackers
— 190 - 200 20 - 30 3
— 180 - 190 20 - 40 42
— 180 - 190 20 - 40 531
Lasagne / baked pasta / cannelloni / flans Yes 190 - 200 45 - 65 2
Lamb / Veal / Beef / Pork 1 kg Yes 190 - 200 80 - 110 3

6
RECIPE FUNCTION PREHEAT TEMPERATURE
(°C)
DURATION
(MIN) LEVEL AND ACCESSORIES
Roast pork with crackling 2 kg Yes 180 - 190 110 - 150 2
Chicken / Rabbit / Duck 1 kg Yes 200 - 230 50 - 100 2
Turkey / Goose 3 kg — 190 - 200 100 - 160 2
Baked whole fish (fillet, whole) Yes 170 - 190 30 - 45 2
Stuffed vegetables
(tomatoes, courgettes, aubergines) Yes 180 - 200 50 - 70 2
Toasted bread — 250 2 - 6 5
Fish fillets / slices — 230 - 250 15 - 30* 43
Sausages / kebabs / spare ribs / hambur-
gers — 250 15 - 30* 54
Roast chicken 1-1.3 kg Yes 200 - 220 55 - 70** 21
Roast beef rare 1 kg Yes 200 - 210 35 - 50** 3
Leg of lamb / knuckle Yes 200 - 210 60 - 90** 3
Roast potatoes Yes 200 - 210 35 - 55** 3
Vegetable gratin — 200 - 210 25 - 55 3
Meat & Potatoes Yes 190 - 200 45 - 100*** 41
Fish & Vegetables Yes 180 30 - 50*** 41
Lasagne and meat Yes 200 50 - 100*** 41
Complete meal: Fruit tart (level 5) / lasagne
(level 3) / meat (level 1) Yes 180 - 190 40 - 120*** 531
Roast meat / stuffed roasting joints — 170 – 180 100 - 150 2
The time indicated does not include the preheating phase: we recommend inserting the food in the oven and setting the
cooking time only after the required temperature has been reached.
* Turn food halfway through cooking.
** Turn food two-thirds of the way through cooking (if
necessary).
*** Estimated length of time: Dishes can be removed
from the oven at different times depending on personal
preference.
WWW Download the Use and Care Guide from
docs.hotpoint.eu for the table of tested recipes, compiled
for the certification authorities in accordance with the
standard IEC 60350-1
FUNCTIONS
Conventional Grill Turbo Grill Pizza Forced Air Maxi Cooking Bread Auto Eco Forced Air
ACCESSORIES Wire rack Baking pan or baking tray on
wire rack
Baking tray / Drip tray or
baking tray on wire rack Baking tray / Drip tray Baking tray / Drip tray with
200 ml of water

7
EN
MAINTENANCE AND
CLEANING
Download the Use and Care Guide from docs.hotpoint.eu for
more information
Do not use steam cleaners.
Use protective gloves during all operations.
Carry out the required operations with the oven
cold.
Disconnect the oven from the power supply.
Do not use wire wool, abrasive scourers or
abrasive/corrosive cleaning agents, as these could
damage the surfaces of the appliance.
EXTERIOR SURFACES
. Clean surfaces with a damp microbre cloth. If they
are very dirty, add a few drops of pH-neutral detergent.
Finish o with a dry cloth.
. Do not use corrosive or abrasive detergents. If any of
these products inadvertently comes into contact with
the surfaces of the appliance, clean immediately with a
damp microbre cloth.
INTERIOR SURFACES
. This oven is equipped with special catalytic panels
that facilitate cleaning of the cooking compartment
thanks to their special self-cleaning coating, which is
highly porous and able to absorb grease and grime.
After every use, leave the oven to cool and then clean
it, preferably while it is still warm, to remove any
deposits or stains caused by food residues. To dry any
condensation that has formed as a result of cooking
foods with a high water content, leave the oven to cool
completely and then wipe it with a cloth or sponge.
. Clean the glass in the door with a suitable liquid
detergent.
. The door can be easily removed and retted to
facilitate cleaning of the glass WWW .
• The top heating element of the grill can be lowered to
clean the upper pane of the oven: Extract the heating
element from its seating, then lower it. To return the
heating element to its position, lift it up, pull it slightly
towards you and make sure that the tab support is in its
proper seating.
ACCESSORIES
Soak the accessories in a washing-up liquid solution
after use, handling them with oven gloves if they
are still hot. Food residues can be removed using a
washing-up brush or a sponge.
REMOVING AND REFITTING THE DOOR
1. To remove the door, open it fully and lower the
catches until they are in the unlock position.
2. Close the door as much as you can.
Take a rm hold of the door with both hands – do not
hold it by the handle.
Simply remove the door by continuing to close it
while pulling it upwards (a) at the same time until it is
released from its seating (b).
~60°
a
b
~15°
Put the door to one side, resting it on a soft surface.
3. To ret the door, move it towards the oven, aligning
the hooks of the hinges with their seating and securing
the upper part onto its seating.
4. Lower the door and then open it fully. Lower the
catches into their original position: Make sure that you
lower them down completely.
5. Try closing the door and check to make sure that it
lines up with the control panel. If it does not, repeat the
steps above.
CLICK&CLEAN - CLEANING THE GLASS
1. After removing the door and resting it on a
soft surface with the handle facing downwards,
simultaneously press the two retaining clips and
remove the upper edge of the door by pulling it
towards you.
2. Lift and rmly hold the inner glass with both hands,
remove it and place it on a soft surface before cleaning
it.
3. To correctly reposition the inner door glass, ensure
that the letter "R" is visible on the left corner.
First insert the long side of the glass indicated by “R”
into the support seats, then lower it into position.
4. Ret the upper edge: a click will indicate correct
positioning. Make sure the seal is secure before retting
the door.
WWW

8
TROUBLESHOOTING Download the Use and Care Guide from docs.hotpoint.eu for
more information
Problem Possible cause Solution
The oven is not working.
Disconnection from the mains
electricity.
Fault.
Make sure that the oven is connected
to the main electricity supply.
Turn off the oven and restart it to see if
the fault persists.
The display shows the letter “F”
followed by a number. Software fault.
Contact you nearest Client After-sales
Service Centre and state the number
following the letter“F”.
USEFUL TIPS Download the Use and Care Guide from docs.hotpoint.eu for more information
HOW TO READ THE COOKING TABLE
The table indicates the best function to use for any
given food, to be cooked on one or more shelves at the
same time. Cooking times start from the moment food
is placed in the oven, excluding pre-heating (where
required). Cooking temperatures and times are purely
for guidance and will depend on the amount of food
and type of accessory used. Please use the lowest
recommended settings to begin with and, if the food
is not cooked enough, then switch to higher settings.
Please use the accessories supplied and preferably
dark-coloured metal cake tins and baking trays. You
can also use Pyrex pans and accessories or ones made
from china, but bear in mind that cooking times will be
slightly longer.
COOKING DIFFERENT FOODS AT THE SAME TIME
Using the “Forced Air” function, you can cook dierent
foods which require the same cooking temperature at
the same time (for example: sh and vegetables), using
dierent shelves. Remove the food which requires a
shorter cooking time and leave the food which requires
a longer cooking time in the oven.
BREAD AUTO FUNCTION
For best results you should carefully follow the
instructions, using the recipe for mixing 1000 g of
dough: 600 g of our, 360 g of water, 11 g of salt, 25 g of
fresh yeast (or two packets of yeast powder).
For optimal rising, allow about 90 minutes at room
temperature or 60 minutes in the oven using the
“Rising” function.
Put the dough into the (cold) oven, pour 100 cc of
cold drinking water on to the bottom of the oven and
activate the “Bread Auto” function. After cooking, leave
the dough to stand on a wire shelf until completely
cooled.
PRODUCT FICHE
WWW The product che with energy data of this
appliance can be downloaded from the website
docs.hotpoint.eu
HOW TO OBTAIN THE USE AND CARE GUIDE
>WWW Download the Use and Care Guide
from our website docs.hotpoint.eu (you can
use this QR Code), specifying the product’s
commercial code.
> Alternatively, contact our Client After-sales Service
CONTACTING OUR AFTER-SALES SERVICE
You can nd our
contact details in the
warranty manual. When
contacting our Client
After-sales Service,
please state the codes
provided on your
product’s identication
plate.
WWW
WWW
Model: xxxXXXXxx
X
X
XX
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
XX
X
X
X
X
XX
X
X
X
XXX
X
X
XXXXXX XXXXXX XXXXX XXXXXXX
400011159409
