Installation
Electrical Requirements
For your own safety, we recommend that your cooker
is installed by a competent person such as one who
is registered with NICEIC (National Inspection
Council for Electrical Installation Contracting) The
cooker should be installed in accordance with the
latest edition of the IEE Regulations
Warning: This appliance must be earthed.
Electrical Connections
The installer must check that the voltage shown on
the rating plate corresponds with the house
electricity supply The cooker must be supplied via
a suitable double pole isolating switch, having a
contact separation of at least 3mm in all poles
placed in a readily accessible position adjacent to
the cooker If the cooker is to be wired into a
connector unit, this may be positioned behind the
cooker providing the following requirements are met:
i) The connector unit must not project from the wall
more than 25mm
ii) The top of the connector must not be more than
130mm above floor level
Remove the terminal cover at the rear base of the
cooker Pass the cable through the cable clamp and
connect to the appropriate terminals provided
Allow sufficient cable for any future servicing
Tighten the screws on the cable clamp and replace
the cover Make main connections in the connector
unit or cooker control unit This appliance conforms
to B S EN 55014 regarding suppression of Radio
and Television reception interference
A double Pole control switch having a minimum
rating of 32 amps should be used to feed the cooker
using a suitably rated cable Where a hob is fitted
adjacent to or over the cooker, a 45 amp Double
Pole control switch should be used to feed both
units via separate suitably rated cables
We recommend a minimum of 4mm2 PVC insulated
twin and earth cable conforming to B S 6004 for
connection of each appliance
In all cases adhere to routing details (see fig. 5 .
This appliance must not be installed over any other
appliance that generates heat such as a plinth heater
Note: Due to many different types of installation, a
mains cable is not supplied with this product. The
installer will fit the correct type and length of cable.
GENERAL
The appliance is designed to be mounted on a floor
between two adjacent cabinets
The cabinets must be securely fixed to the wall and
the cooker securely fixed to the cabinets
This cooker must not be used free standing
Note; This cooker must not be fitted on a platform
FINAL INSTALLATION
aEnsure that the adjacent cabinets and the gap
between them have dimensions in accordance with
the diagram
bAssemble the plastic plugs provided into the fixing
brackets See diagram
cFix the fixing brackets to the sides of the adjacent
cabinets so that the centre line of the brackets are
570mm above the top of the plinth line and the front
face of the plastic plug is level with the front face
of the cabinet sides See diagram
dAdjust the feet on the cooker to their minimum
position, ie full screwed in
eSlide the cooker centrall into the space between
the cabinets ensuring the following:
i) The gap between the cabinet sides and the
cooker is even along the length of the cabinet
sides
ii) The cable is routed awa from an vents in the
rear panel and is not trapped between the cooker
and the wall, adjacent cabinets or under the feet
fAdjust the feet using an open ended spanner until
the bottom of the cooker door is in line with the top
of the plinth Using a spirit level, check that the
cooker is level in all directions
gCheck that the plinth can be fitted If necessar re
- adjust the feet and check that the cooker is level
Then lock the feet into position b tightening the
lock nut using an open ended spanner
hOpen the top oven door and fix the cooker to the
brackets through the holes in the side trims
iFix the plinth in position
jEnsure that there is a minimum gap of 1mm
between the cooker side trim and the adjacent
cabinet doors or drawer fronts
kIf a hob is to be installed directl above the cooker
it must not project downwards more than 20mm
below the underside of the work top An projection
of more than 10mm must not project more than
500mm from the wall
Fig. 5
