Hotpoint RGA624PF User instructions

Specification Revised 10/03
430211
®
RGA624PF – Hotpoint 24" Free-Standing Gas Range
Dimensions (in inches) Installation Information (in inches)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before
installing, consult installation
instructions packed with product
for current dimensional data.
Note: LP conversion kit is NOT
required for this model.
24 26*
36
39-3/4
39-1/2
*Depth including up-front
angled control panel.
0
6
22
24-3/8
2
35
30" Min.
24-3/8
Electrical
Connection
Area
Recommended gas
hook-up locations behind
range. Gas fittings and
shut-off valve should
not protrude more than
2" from the wall to allow
range to fit against the wall.
Check local codes
before making
connections
13"
Max.
36
18
18" Min.
9
3
33
Recommended gas and electric supply locations.
All Hotpoint ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
CERTIFIED

Specification Revised 10/03
430211
®
RGA624PF – Hotpoint 24" Free-Standing Gas Range
Features and Benefits
•Recessed Lift-Up Cooktop with Easy-Clean Subtop
• Standard Clean Oven
• 4 Standard Burners
• Rectangular Burner Grates
• Standing-Pilot Ignition System
• Push-To-Turn Controls
• Separate Broiler Drawer (with Tip-Down Door)
• Model RGA624PFWH – White
