Installing Your Sorrento HotSpot Hot Tub
On purchasing your spa you gave us an estimated month of delivery, within the next few days our
installation department will contact you in writing with information regarding your delivery date. If
you have not received a letter within 14 days please call our installation department on 01934
708786.
To enable us to complete your delivery as smoothly as possible, please ensure the following
arrangements are made:
Electrical Supply
Your electrician will need to provide a 16amp MK Masterseal waterproof socket near the spa and a
RCD to protect the consumer unit. This system will allow your spa to be automatically switched
back on after power cuts. Alternatively you could use a MK56301 Masterseal RCD socket, which is
both waterproof and a RCD protector, but will not automatically reset after power cuts.
To comply with BS7671 legislation as of the 1st January 2005 a competent electrician registered
with one of the following must carry out all electrical work: BRE Certification Ltd (ECA & IEE);
British Standards Institution; ELECSA Ltd; NICEIC Certification Services Ltd or Zurich Certification
Limited. Your electrician should give you a certificate once the work has been completed and this
should be available for our technicians to see.
Base
Ideally the spa should be sited on a base of 4" thick reinforced concrete, although this is an ideal
it is not strictly necessary. HotSpot Spas are structurally very solid and could be put on any flat
level surface; even grass if that is what you want to do. The worst that can happen is over time
the spa will sink a little and the water may appear to be higher on one side of the spa than the
other, it may also mean that removal of the drain plugs may be more difficult, this could be
rectified if it happens by removing a section lawn and earth.
The base should be a minimum of 6ft 9" x 6ft 9", should be flat and have a slope of approx one
inch per 10ft to allow water to disperse. If you intend to bury your cable please ensure it is buried
at least 450mm deep encased in high impact duct of preferably 32mm or 25mm diameter
(available from B & Q). Bring the duct up to either the left hand or right hand electrical cut-outs.
(See spa diagram). Please ensure a line of string runs through the duct to allow us to pull our
supply through the duct. The instructions for bases may change if you are having a spa
mounted/free standing building installed. Please consult building installation instructions if this is
the case.
If, temporarily, you want to site the spa on an existing patio or concrete base please ensure it is
flat with no undulations and if possible have a slope of approx one inch per 10ft to allow water to
disperse and that it will happily hold the weight of the spa once filled with water (weight of spa
when filled with water is 1630kg). We are unable to jack the spa to make it flat as this could
weaken the under-structure and will invalidate your guarantee.
If you have decided to site your spa indoors please remember that the spa will produce steam
from the sanitised water and we would therefore suggest that you or your designated third party

(builder, architect etc), consider any ventilation, extraction and/or drainage that may be required.
Our staff are happy to assist wherever possible but they cannot provide professional build advice.
Equipment Compartment
Access should be maintained to the front of the spa. i.e. the side where main controls are. A
minimum of 24" is required. The removable panels provide entry to the spa's equipment for
periodic spa care and maintenance.
Cover Cradle®
If you are having a Cover Cradle® fitted to your spa please allow a 26" gap for this to operate.
On the Sorrento the Cover Cradle® operates both from side to side.
Cover Mate®
If you are having a Cover Mate® fitted to your spa please allow a 18" gap for this to operate. On
the Sorrento the Cover Mate® operates both from side to side. Your Cover Mate® can also
operate in the same was as a Cover Buddy, in this case only a 9" gap is required.
Cover Buddy
If you are having a Cover Buddy fitted to your spa please allow a 9" gap for this to operate. On
the Sorrento the Cover Buddy operates both from side to side.
Sinking Of Spas
If you intend to sink your spa at all please ensure adequate drainage and access, please refer to
sinking instructions or call our installation department, inattention to this could invalidate your
warranty.
Spa Building or Gazebo
If you are having a lip mounted or free standing building with your spa please refer to the
separate installation instructions as the addition of a building may change the required size of
your base and could influence where you site your spa. If you have not been given these
instructions please call our installation department or your sales person and they will send a copy
to you.
Access/Delivery
Access should be clear for our technicians to push your spa on a wheeled dolly (trolley) from the
delivery vehicle to the site for the spa, please measure any alleyways or tight spots bearing in
mind obstructions such as steps, low roof overhangs, drainpipes, window seals, tight turns or
anything that could obstruct the delivery route. Your La Palma Spa, when in the trolley, will need
a minimum access width of 38" and a minimum access height of 84". Spas are very heavy and
even an 8" step requires thought.
If your delivery does require the use of a commercial crane (other than our vehicle mounted Hiab)
we must point out that this will be at your cost and your responsibility to arrange unless written
agreement is given to the contrary. We recommend that you investigate the addition of insurance
when booking the crane.
Payment of Balance
Payment of balance is due prior to or on the day of delivery, payment can be made by:

obankers draft or building society cheque - made payable to "Bristol/Plymouth
Limited"
obank transfer (4 days before delivery) - please call 01934 875745 for details
odebit card - please call 01934 875745 to pay by debit card
Unfortunately we are no longer able to accept personal or company cheques unless
full payment is made prior to delivery and is fully cleared (to ensure cleared funds
please post your cheque to Head Office 10 days before delivery).
We only accept credit card payments of the balance by prior agreement and there is a
2.5% commission charged for this service.
If payment is not been made on or before the day of delivery we reserve the right to
remove the goods until payment is received. All goods remain the property of
Bristol/Plymouth Limited until full payment is received.
If you have any queries or require further information regarding the delivery of your spa please
contact your Sales Person or the Installation Department.
We look forward to having you in "Hot Water" very soon.

Please Note: All dimensions are approximate; measure your spa before making critical design or
pathway decisions.

Instructions and Advice for Sinking HotSpot Spas into Gardens & Decks
If you intend to sink your spa please read the following carefully.
This information applies to all HotSpot models.
Dig the hole and lay a 5" (13cm) reinforced concrete base with a slight slope dropping towards
the hatch end of 1 inch over 10ft to the surface and a soak away at the removable hatch end. It is
essential that the soak away is sufficient to ensure your pit cannot become waterlogged and that
it is accessible to ensure it can be kept free of debris. It maybe advisable to install a submersible
pump with a float switch as a secondary defence against your pit flooding. Your warranty will not
cover flooded electrical components.
All HotSpot spas can be sunk to be flush fit - the decking can go just under the shell lip. N.B.
arrangements must be made for a removable section of the decking to allow access to the
equipment compartments and panels.
When sinking the Sorrento Spa access is also required to the side panels to the right of the
equipment compartment.
Please ensure the electrical requirements meet those shown in the Pre-Delivery Instructions you
were given at the time of purchase. All electrical fittings must be accessible at the removable
hatch end of the pit.
Always consult a builder or contractor for professional advice.
If you have any questions or queries regarding sinking your spa please contact your sales person
or our installation department.
