Hp Bh10 User manual

HP Bluetooth Headphones

1.0 Version：September 2019

Micro USB charging port

Power on/off

Microphone

LED indicator

3.5mm audio cable

Volume -/ last song

Volume +/ next song

Multifunction button

(Play/Pause/Answer/Hang up)

Printed in China

Product Induction

1.Headphone* 1

2.USB cable *1

3.Instruction *1

4.Warranty card *1

1.BK Chipest, 5.0 Versions, Low power, High transmission,Support for multiple

protocols.

2.High quality wireless Bluetooth streaming allows you to enjoy strong music

andbid farewell to messy cable shackles.

3.Closed back cover structure eliminates sound leakage and retains sound

detailsto bring you broad bass feeling.

4.Soft leather earrings are skin-friendly and breathless, andeven if you wear

headphones for a long time, you feel comfortable.

5.Foldable design is easy for you, easy to carry , with music anytime, anywhere.

6.The keystroke operation is simple, the function is perfect, and the incoming call

tentacles are accessible.

7.The two Bluetooth devices can be connected at the same time, and the working

andentertainment can be switched at any time.

1.Product name: HP BH10

2.Horn size: 040mm

3.Horn impedance: 329±15%

4.Sensitivity: 115±3dB (at 1kHz/1mw, With IEC60711 Coupler)

5.Rated power of horn: 10mw

6.USB cable: 0.3m (medium 3.2pvc 2-core charging cable - black)

7.Call time: 20H

8.Music time: 70% volume playing no less than 22H; 50% volume play no less

than 25H

9.Standby time: 100H

10.Headphone size: 183*168* 77.9mm (7. 2*6.61*3.07in); Weight: 270g (9.52 oz)

Schematic diagram of products and accessories

First: Charging

Second：AUX IN audio input

Thired: Power on/Power off

When it is used for the first time (or not used for a long time), please make sure to

charge the headset before use.

In the process of use, if you see the red light flashing, it means the battery of the

headset is too low, please immediately charge. When the red light is long and

bright, it means that the battery is in charge. When the red light is off, it means

that the battery is fully charged.

When using this function, it is unnecessary to turn on the earphone

power, insert the 3.5mm end of the audio source into the AUX IN hole L,

and the other end of the 3.5mm plug into the output hole of the audio

source of the player (such as computer, MP3, mobile phone)The

headsetThe tabletMobile computer

Function

Power on

Power off

Pairing

Pairing success

Operation

Move down

Move upward

Boot automatically into

Bluetooth mode

Connected

LED Indicator

Blue light flash

Lamp out

Red&Blue lights flicker alternately

Blue light flashes slowly

on/off

6 940252 364632

The product description

Product introduction Instructions

Specifications

Complete set of products

Mobile phone Computer FlatHeadset

notice:1. When the volume of the earphone is turned up to the maximum/minimum,

you will hear"didi" prompt sound

2. When using 3.5mm audio cable, the headset enters the wired mode and

is turned off. The operation button has no function.Music playback and

call can be used normally

Fifth:Music Operation

Sixth:Dialing operation

Function

Play/pause

volume+

volume-

Prev song

Next song

Function

Answer calls

Hang up phone

Reject a call

Operation

Short press key

Long press key

Warning tone

No warning tone

Warning tone

No warning tone

Operation

Short press key

Long press key
