HP ProBook 4430s User manual

Durable metal design and options
Ideal for small- and medium-size businesses, the HP ProBook
s-series balances functionality with style and affordability.
Durability starts with high-strength precision-formed aluminum
that is deeply anodized to create a rich, smudge- and wear-
resistant HP DuraFinish in a stylish metallic silver color. And
you can choose between two easy-to-view 14.0- o r 15. 6 -inch
diagonal HD1displays for the configuration that best suits your
needs.
Complete set of security features
From preboot BIOS authentication to password management
with credential manager and drive encryption, HP provides a
complete security tool to support users’ needs. HP ProtectTools2
is easy to use, robust, and can be centrally managed. Plus, the
HP Fingerprint Sensor3and optional HP Face Recognition2,3
make it easy to log in to your PC.
Powerful connections
With integrated WWAN4and HP Connection Manager, you
can be connected in more places business takes you. With the
6-cell and optional 9-cell (4530s only) batteries5and HP
Power Assistant,6you gain great battery run time in a truly
mobile experience.
The new USB 3.0 connector lets you share and transfer files
faster than the previous USB 2.0 connector version.
Advanced multimedia support
The notebook comes loaded with the new ArcSoft TotalMedia
Suite that allows you to play, edit, and create video and audio
files. Experience life in high-definition1with the HDMI port that
allows you to connect directly to high-definition displays.1,3,7
SRS Premium Sound seamlessly reduces background noise
during video conferencing8with the optional HD Webcam1,3,8
and dramatically improves the sound coming from your
speakers or headphones.
Incredible performance
The new Intel architecture features 2nd generation Intel®
C o r e ™ i 7, 9 i5,9 and i39dual- and quad-core processors and
Intel®Celeron processors. Whether you’re creating or
consuming content, you gain the power to quickly edit,
transfer, and share content without being tied down to a desk.
Built to simplify
With HP QuickWeb10 you can tap into fast, convenient and
more secure access to the Internet, email, contacts, and
calendar at the touch of a button without long boot-up times.
HP QuickWeb10 also delivers strong security for business
needs via mail encryption and enhances user authentication
with support for passwords and biometrics.
ProBook 4430s and 4530s
Notebook PC
Business Partner
HP’s s-series business notebooks combine a
great ID and metal finish with a wide
breadth of security solutions, advanced
multimedia features, Intel technology, and
two display size options.
Windows®. Life without WallsTM. HP recommends Windows 7.

SPECIFICATIONS
Operating system
Preinstalled:
Genuine Windows®7 Professional11
Genuine Windows 7 Home Premium11
Genuine Windows 7 Home Basic11
Genuine Windows Vista Home Basic12
SUSE Linux Enterprise Desktop 11
FreeDOS
Supported:
Genuine Windows XP Professional
Certified:
SUSE Linux Enterprise Desktop
Processor 2
nd
generation Intel
®
Core™ i7 mobile processors
9
with Turbo Boost Technology;
13
2
nd
generation Intel
®
Core™ i5 mobile processors
9
with Turbo
Boost Technology;13 2nd generation Intel®Core™ i3 mobile processors,9 Intel®Celeron processor
Chipset Mobile Intel HM65 Express Chipset
Memory DDR3 SDRAM, 1333 MHz, two slots supporting dual-channel memory,
14
2/4 GB SODIMMs, up to 8 GB total
15
Internal Storage
16
320/500/750 GB 7200 rpm SMART SATA II HDD, 320 GB 5400 rpm SMART SATA II HDD; HP 3D DriveGuard
2
Removable Storage F ix e d 12. 7-mm SATA optical drive: Blu-ray RW DVD+/-RW SuperMulti DL LightScribe Drive,
3 ,17,18
DVD+/–RW SuperMulti DL LightScribe Drive (with
ROM option),3 ,18 DVD-ROM Drive (4530s only),3or weight saver
Display HP 4430s: 14.0-inch diagonal LED-backlit HD
1
anti-glare (1366 x 768)
HP 4530s: 15.6-inch diagonal LED-backlit HD1anti-glare (1366 x 768)
Graphics19
Integrated: Intel
®
HD
1
Graphics 3000 (not available w/Celeron processor); Intel
®
HD
1
Graphics
Audio/Visual
High Definition Audio (SRS Premium Sound), stereo speakers, stereo headphone/line out, stereo microphone in, optional 720p HD Webcam1,3,8 with
dual-array microphones (models without optional webcam have single integrated microphone)
Wireless Support Optional HP un2430 EV-DO/HSPA Mobile Broadband (planned to be available 2Q 2011);
3,20
802.11b/g/n,3,21 802.11a/b/g/n3,21 with BT combo card, 802.11b/g/n3,21 with BT combo card; HP Connection Manager 4.0
Communications Integrated Realtek Ethernet (10/100/1000),
22
optional 56K V.92 modem
3
Ports and Connectors (3) USB 2.0 ports, (1) USB 3.0 port, (1) VGA, (1) HDMI, (1) stereo microphone in, (1) stereo headphone/line out, (1) power connector,
(1) RJ-11/modem, (1) RJ-45/Ethernet
Expansion Slots
(1) ExpressCard/34 slot, (1) SD 3.0 HS Media Card Reader (6-in-1)
Input Device Full-sized, spill-resistant keyboard with drains, touchpad with scroll zone and gestures support; integrated numeric keypad (4530s only);
launch buttons (wireless on/off, HP QuickWeb,10 and power); multimedia control keys (Fn+key)
Software
(Windows OS only)
HP Power Assistant,
6
HP Recovery Manager, HP Support Assistant, HP QuickWeb,
10
Microsoft
®
Office 2010 Preloaded—Purchase Key,
23
ArcSoft Total
Media Suite, HP Connection Manager 4.0, HP Day Starter,24 HP SoftPaq Download Manager, Norton Internet Security 2011,25 Skype,26 optional GPS
(not available at product introduction)3,27
Security
Standard: HP ProtectTools,2Device Access Manager, Enhanced Pre-Boot Security, HP Spare Key, HP Disk Sanitizer,28 Drive Encryption for
HP ProtectTools,2Credential Manager for HP ProtectTools,2File Sanitizer for HP ProtectTools,28 Kensington Lock slot, Norton Internet Security 2011,25
HP Fingerprint Sensor,3
Optional: LoJack Pro ready,29 Intel AT Support ready30
Dimensions
(h x w x d)
HP 4430s: 1.11 in (at front) x 13.00 in x 9.27 in/2.81 cm (at front) x 33.90 cm x 23.50 cm
HP 4530s: 1.13 in (at front) x 14.76 in x 10.10 in/2.87 cm (at front) x 37.40 cm x 25.60 cm
Weight
HP 4430s: Starting at 4.51 lb (2.04 kg) without optical drive; 4.85 lb (2.20 kg) with optical drive
31
HP 4530s: Starting at 5.22 lb (2.36 kg) without optical drive; 5.55 lb (2.51 kg) with optical drive31
Power 9-cell (93-WHr) Lithium-Ion battery (4530s only),
5
6-cell (47-WHr) Lithium-Ion battery;
5
65W HP Smart AC Adapter; HP Fast Charge
32
Expansion Solutions HP USB 2.0 Docking Station,
3
HP Essential USB Port Replicator
3
Warranty
Limited 1-year warranty options available; 1-year limited warranty on primary battery. Optional HP Care Pack Services
33
are extended service contracts
which go beyond your standard warranties.
For more details visit: www.hp.com/go/lookuptool.
ProBook 4430s and 4530s
Notebook PC
Windows®. Life without Walls TM.
HP recommends Windows 7.
Windows®. Life without WallsTM.
HP recommends Windows 7.

Optional 720P Webcam
1,3,8
Touchpad with
Gestures support
Full-size keyboard
(integrated numeric keypad
on 4530s)
14.0- or 15.6-inch HD
1
display
HP Fingerprint Sensor1
VGA port
HDMI port
USB 3.0 port
Scratch-resistant
aluminum surface
6-in-1 Media
Card Reader
ProBook 4430s and 4530s
Notebook PC
Windows®. Life without WallsTM.
HP recommends Windows 7.

© 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for
HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft, and Windows are
trademarks of the Microsoft group of companies. Intel, the Intel logo, Intel Core and Core Inside are trademarks or registered trademarks of Intel Corporation
or its subsidiaries in the United States and other countries. To learn more, visit www.hp.com
4AA3-2701ENA, Created January 2011; Updated February 2011
1HD content required to view HD images.
2Microsoft Windows required.
3Sold separately or as an optional feature.
4Wireless use requires separately purchased service contract. Check with local service provider for coverage area and availability in your area. Limited to mobile network
operator coverage areas. Separately purchased mobile network operator service is required.
5Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality and power management settings. The maximum
capacity of the battery will naturally decrease with time and usage. See MobileMark07 battery benchmark www.bapco.com/products/mobilemark2007 for additional details.
6Power calculations and cost calculations are estimates. Results will vary based on variables, which include information provided by the user, time PC is in different power states
(on, standby, hibernate, off), time PC is on battery or AC, hardware configuration, variable electricity rates, and utilities provider. HP advises customers to use information
reported by HP Power Assistant for reference only and to validate impact in their environment. Environmental calculations were based on U.S. EPA eGrid 2007 data found at
www.epa.gov/egrid/. Regional results will vary. Microsoft Windows required.
7HDMI cable sold separately.
8Internet service required.
9Dual/Quad Core is a new technology designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use
of this technology. 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled
for Intel®64 architecture. Processors will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your
hardware and software configurations. Intel's numbering is not a measurement of higher performance.
10 HP QuickWeb is accessible when the notebook is off in Windows Vista, or Windows 7-based systems. Internet access is required. Timing may vary depending on the system
configuration. To enable the feature following the removal of the battery, reboot the notebook prior to subsequent use.
11 Systems may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Not all features are available in all editions of
Windows 7. See www.microsoft.com/windows/windows-7/ for details.
12 Certain Windows Vista product features require advanced or additional hardware. See www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on
your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
13 Intel®Turbo Boost 2.0 technology requires a PC with a processor with Intel Turbo Boost 2.0 capability. Intel Turbo Boost 2.0 performance varies depending on hardware,
software and overall system configuration. See www.intel.com/technology/turboboost for more information.
14 Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
15 Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to
system resource requirements.
16 For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 15 GB of memory is reserved for system recovery software.
17 As HD DVD and Blu-ray are new formats containing new technologies, certain discs, digital connections, compatibility and/or performance issues may arise, and do not
constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some HD-DVD titles to play, they may require a DVI or HDMI digital connection
and your display may require HDCP support. This HD-DVD drive does not support writing to ultra-high speed CDRW media (16X to 32X advertised performance).
18 Double-layer discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer DVD
drives and players. LightScribe media required and sold separately. LightScribe creates a monochrome image. Note that DVD-RAM cannot read or write to 2.6-GB single-
sided/5.2-GB double-sided—version 1.0 media. Don’t copy copyright-protected materials.
19 Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use by other
programs.
20 Gobi technology requires separately purchased wireless data service contracts. Check with local service provider for coverage and availability in your area. Broadband
connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability.
Connection speeds will vary due to location, environment, network conditions, and other factors.
21 Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited.
22 The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1
Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
23 Includes reduced functionality versions of Word and Excel. Purchase of Product Key required to activate full Office 2010 suite available at participating resellers/retailers and
www.office.com.
24 Requires Microsoft Outlook. User must opt-in to activate feature.
25 Internet access required. This product may include Norton or McAfee software. First 60 days included. Subscription required for live updates afterward.
26 Internet access required.
27 GPS access requires an unobstructed path to multiple satellites. Performance may be affected if/when used inside of buildings, bridges or heavily congested metropolitan areas.
Requires separately purchased GPS navigation software available from multiple GPS applications.
28 For the use cases outlined in the DOD 5220.22-M Supplement.
29 The Computrace Agent is shipped turned off and must be activated by customers when they purchase a subscription. Subscriptions can be purchased for terms ranging from one
to five years. Service is limited, check with Absolute Software for service availability outside of North America. For more information, visit www.absolute.com.
30 Intel AT security requires a separately purchased Absolute Computrace service subscription and must be activated and configured. Check with Absolute for availability in your
country. Intel and HP assume no liability for lost or stolen data and/or systems or any other damages resulting therefrom. See www.intel.com/technology/anti-theft/.
31 Weight will vary by configuration.
32 Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does not apply to the 9-cell battery. When the PC is
powered on, charge time may increase and will vary based on the workload of the notebook PC.
33 Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations
apply. For details, visit www.hp.com/go/lookuptool.
