HP RM132UT#ABA User manual

Affordable
Widescreen
Mobility
HP Compaq nx7300 Notebook PC
Optimal combination of features including Intel® Core™2 Duo
processors and 15.4-inch widescreen displays
HP recommends Windows Vista™ Business
The HP Compaq nx7300 offers an affordable, thin
and light mobile office by providing the optimal
combination of features that maximize productivity
without straining your budget.
Productivity on the move
The tools you need to accomplish more in less time.
•Starting at 5.6 lbs (2.54 kg) and 1.2” (30 mm) thin,
the HP Compaq nx7300 provides best-in-class
mobility in a 15.4-inch diagonal widescreen thin
and light notebook.
•Choice of either a 15.4-inch TFT WXGA display
with or without BrightView technology.
•New Intel®Core™Duo7and Core™2 Duo7
processors allow simultaneous use of multiple
applications so you accomplish more in less time.
Power and connectivity on the go
The connectivity and power that keeps you going.
•A variety of wired and wireless4communication
solutions help you stay connected.
•With HP’s selection of extended-life batteries,6 you’ll
get power that goes with you.
HP Professional Innovations
A suite of value-added security, ease-of-use, and
reliability features that helps make HP Business
Notebooks the clear choice for your demanding
mobile needs.
•Security –Solutions to help protect your notebook,
data, and network connections.
−HP ProtectTools is a portfolio of security features
designed to address critical aspects of IT security.
•Ease-of-use –Intuitive and power-saving features
that boost productivity.
−HP Fast Charge Technology charges the primary
battery up to 90% in 90 minutes then charges the
secondary battery to keep you on the go.8
−HP Smart AC Adapter can be shared across HP’s
2006 Business Notebooks and includes surge
protection.1
•Reliability –Built to perform and proven to last.
−HP Mobile Data Protection System helps protect
data during normal use from shock and vibration.

HP Compaq nx7300 Notebook PC
HP recommends Windows Vista™ Business
Operating system Preinstalled
Genuine Windows Vista Business 3214
Genuine Windows Vista Home Basic14
Genuine Windows XP Professional Edition
Genuine Windows XP Home Edition
FreeDOS
Supported
Genuine Windows 2000 (drivers downloadable from http://www.hp.com)
Processor7Intel®Core™2 Duo Processor T5600†(1.83-GHz,667-MHz FSB, 2-MB L2 cache)
Intel®Core™2 Duo Processor T5500†(1.66-GHz,667-MHz FSB, 2-MB L2 cache)
Intel Core Duo Processor T2300†(1.66-GHz,667-MHz FSB, 2-MB L2 cache)
Intel Celeron® M Processor 430†(1.73-GHz, 533-MHz FSB, 1-MB L2 cache)
†Intel’s numbering is not a measurement of higher performance
Chipset Mobile Intel 945GM Express Chipset or Mobile Intel 940GML Express Chipset
Memory DDR2 SDRAM, 667-MHz14, two SODIMM slots supporting dual channel memory9, 512/1024-MB upgradeable to 2048-MB; supports up to 4096-
MB12
Hard drive(s)11 80 or 120-GB 5400 rpm
Removable media 12.7-mm optical drives:, DVD+/-RW SuperMulti with Double Layer2, 24X DVD/CD-RW combo
Display 15.4-inch diagonal WXGA (1280 x 800 resolution and 16 M colors), 15.4-inch WXGA BrightView (1280 x 800 resolution and 16M colors)
Graphics13 Intel Graphics Media Accelerator 950, up to 224-MB shared system memory
Audio PremierSound High Definition Audio w/24-bit audio DAC, line out/headphone jack, microphone jack
Wireless4support Intel PRO/Wireless 3945ABG Network Connection, Broadcom 4311AG 802.11a/b/g WiFi Adapter, Broadcom 4311BG 802.11b/g WiFi
Adapter, Bluetooth™ 2.0, HP Wireless Assistant (select models)
Communications Broadcom 10/100 Ethernet PCI Controller, 56K v.92 modem
Expansion slots 1 Type I/II PC Card slot supports 32-bit CardBus and 16-bit cards
Ports and connectors 3 USB 2.0, VGA, audio in/out, power connector, RJ-11, RJ-45, 1394a, accessory battery connector (no docking connector)
Input devices Full-sized keyboard; Touchpad with scroll zone, two pick buttons
Software HP Mobile Printing Driver for Windows (Windows XP models), HP Backup and Recovery Manager, Sonic Digital Media Plus (select Windows XP
models), Roxio Creator 9(select Windows Vista models) Intervideo WinDVD (select models)
Security HP ProtectTools, DriveLock, Kensington lock slot, Norton Internet Security
Dimensions (h × w × d) 1.2 in (at front)/1.4 in (rear) x 14.1 in x 10.2 in /30 mm (at front)/36mm x 357 mm x 260 mm
Weight Starting at 5.6 lb/2.54 kg
Power 8-cell (69WHr) or 6-cell (43WHr) Lithium-Ion battery, HP 8-cell (52WHr) Extended Life Battery6, 65W HP Smart AC Adapter1, HP Fast Charge
Technology8
Expansion Solutions6Targus Mobile Port Station HP External Multibay II
Warranty One year standard parts and labor limited warranty (upgrades available6), one-year limited warranty on primary battery
1. The new HP Smart A/C Adapters will not be backwards compatible to prior generation notebooks. However, a dongle will be available to support existing notebooks in the field. Older HP adapters will
not be forward compatible to the 2006 HP Business Notebooks. 2. Double Layer discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible
with many existing single-layer DVD drives and players. 3. LightScribe creates a grayscale image similar to black and white photography. LightScribe media required and sold separately. 4. Wireless access
point required and is not included. Availability of public wireless access points limited. Wireless Internet use requires separately purchased Internet service contract. 6. Sold separately or as an optional
feature. 7. Dual Core is a new technology designed to improve performance of certain software products. Check with software provider to determine suitability. Not all customers or software applications will
necessarily benefit from use of this technology. 8. Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does not apply to 9 cell
primary and 12 cell Ultra Capacity batteries. 9. Dual Channel is only supported when the system is configured with DDR2 symmetric memory (i.e. 2x256). 10. Note that DVD-RAM cannot read or write to
2.6-GB Single Sided/5.2-GB Double Sided –Version 1.0 media. 11. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 8GB of memory is reserved for system recovery software.
12. Memory greater than 2-GB requires Mobile Intel 945GM Express Chipset. Above 3-GB, all memory may not be available due to system resource requirements. 13. Shared video memory (UMA) uses part
of the total system memory for video performance. System memory dedicated to video performance is not available for other use by other programs. 14. Certain Windows Vista product features require
advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
© 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without
notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Bluetooth is a
trademark of its proprietor and used by Hewlett-Packard Company under license. Microsoft and Windows are U.S.
registered trademarks of Microsoft Corporation. Windows Vista is either a registered trademark or trademark of
Microsoft Corporation in the United States and/or other countries.. Intel Core and Intel Celeron are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the U.S. and other countries.
To learn more, visit www.hp.com
January 2007
