This Server Delivers:
Powerful, high-availability
superservers for the
enterprise
HP NetServer LX Pro Series
HP’s most powerful network
servers deliver industry-leading
performance and availability for
business-critical environments
without a high-end price tag.
Like all HP NetServers, the
HP NetServer LX Pro and LXe Pro
come with advanced management
tools to increase uptime and ease
administration.
Plus, with a choice of two configu-
rations, the HP NetServer LXe Pro
and LX Pro, you can optimize
for your needs today and easily
expand your solution as your
needs grow over time.
For mission-critical datacenter
environments, HP offers a separate
family of rack-optimized servers,
the HP NetServer LXr Pro, and its
accompanying mass storage, the
HP NetServer Rack Storage/8.
All HP products are backed
with HP’s legendary quality,
reliability, and a broad range
of support options.
•Four-wayPentium®Prosymmetricmultiprocessing(SMP)
supportingupto4GBErrorCheckingandCorrecting(ECC)memory
•DualPCIpeerbusesformaximumI/Othroughout
•TwoPCIUltra/WideSCSIcontrollers
•AtotaloftenI/Oslots—noneshared
•6(LXePro)or12(LXPro)hot-swapshelvessupportupto109GB
internalstorage
•ECCmemorywitherrorreporting
• HP NetRAID three-channel PCI Ultra/Wide SCSI Disk Array Controller
forsuperiordataprotection
•Modularhot-swapredundantpowersupply(LXPro—Standard,
LXePro—Optional)
•Redundantfanstoreducedowntimeduetofanfailures
• Certifiedandsupportedinindustry-standardMicrosoft®Cluster
Server(MSCS)
•Built-inAutomaticServerRestart(ASR),temperature,and
voltagemonitoring
•HPNetServerNavigatorbootableCD-ROMwitheasy-to-use
toolstoconfigure,install,andmanagetheHPNetServerLXPro
andLXePro
•HPNetServerAssistantservermanagementsoftwarefor
proactivealertingandproblemresolution
•HPOpenViewforWindows®networkmanagementsoftwarefor
networkmapping,alarmmanagement,andsecurity
•OptionalHPRemoteAssistantcardforremotediagnosticsand
environmentalmonitoring
• LargenumberofoptionalHPbackupsolutions
Scalable,superserver
performance
Maximumsystem
uptimeanddata
protection
Simplifiedserverand
networkmanagement
data sheet

HP NetServer LX Pro Series Optional:DIMMMemoryBoard
forgreaterthan2GBupto4GB
or
Standard:SIMMMemoryBoard
forupto2GB
1–2Processorboards
PentiumPro166MHz
PentiumPro200MHz
2CPU/Board
Slotfor2ndprocessorboard
Rearpanel:
• 2Serialports
• 1Parallelport
• 1Videoport
Hot-swap
redundant
powersupply
• standardonLXPro
• optionalonLXePro
4EISAslots
2IntegratedPCI
Ultra/WideSCSIcontrollers
6PCIbusmasterslots
Redundantfans
1.44MBFlexiblediskdrive
Controlpanel:
• On/offswitch
• Keyboardlock
• Resetbutton
Statusindicatorlights:
• Powersupply
• Fans
• Diskdrive
Keylock
3 5.25''
Shelves
LXPro:12hot-swap
diskmodulesstandard
LXePro:6hot-swap
diskmodulesstandard
CD-ROM
PERFORMANCE
AVAILABILITY
MANAGEABILITY
HP’s MAP strategy ensures that your enterprise networking solution
delivers the highest levels of Manageability, Availability, and
Performance, all backed with industry-leading support. So you can
count on optimum, easy-to-achieve results over the life of your
server. Maximum system uptime and data protection in your
business-critical environment. And the most advanced technology
available today—with plenty of headroom for future growth.

Performance
Processor Intel®Pentium®Pro200MHzprocessorwithupto4-waymultiprocessing
ProcessorUpgrade Modularupgradestodualandquadsymmetricmultiprocessing
Cache 512KBor1MBwrite-backcacheperprocessor
ECCMemory • 128MB/512MBECCmemoryexpandableto4GB(usingoptionalDIMMMemory)
• SIMMMemoryincluded(expandableto2GB)
MassStorageSubsystem • Front-accessible,half-heightshelves(17—LXPro,9—LXePro)
• One3.5-inchflexiblediskdrive(included)
• OneCD-ROM(included)
• Threestandardhalf-height
• Twelvehot-swap(LXPro);Sixhot-swapupgradabletotwelvehot-swap(LXePro)
• DualSCSIbackplanesforinternaldiskduplexing
I/OArchitecture • DualpeerPCIbuses
• I2Ooptimized
• TwoPCIUltra/WideSCSIcontrollersintegratedonthesystemboard
I/OExpansion TenI/Oexpansionslots:SixPCIbusmaster,FourEISA
Video • Integrated1024x768,256-color,noninterlaced
• 1MBstandardvideomemory
• SuperVGAdriversavailablewithoperatingsystemorfromHPelectronicsupportservices
CD-ROM OneCD-ROMdriveincluded
FlexibleDiskDrive One1.44MBflexiblediskdriveincluded
Availability
PowerSupplies • LXePro:Onepowermodulestandard;modularupgradetoredundantpowersupply
• LXPro:Threepowermodulesstandard
• Modularhot-swapuniversalvoltageRedundantPowerSupply(allowscontinuoususage
ofserverduringreplacementoffailedpowersupplymodule)
DiskArrayController • Hot-swapandhot-sparecapabilities
(withModel1Array) • SupportforRAID0,1,3,5,10,30,50
• HPNetRAIDthree-channelPCIUltra/WideSCSIDiskArrayControllerprovidesprotectionof
business-criticaldata
Cooling Redundantfansprovidefault-tolerantcoolingforinternalcomponents;superiorairflowdesign
ClusterSupport SupportsHP’sHigh-Availabilitysolution,whichisbuiltaroundtheserverindustry-standard
MicrosoftClusterServer(MSCS)
UltraSCSIController TwoPCIUltra/WideSCSIcontrollersintegratedonsystemboard
Manageability
InstallationandMonitoring HPNetServerNavigatorbootableCD-ROMincludes:
• Automated,menu-driveninstallationandconfigurationapplicationthathelpsyouinstall,
configure/reconfigure,andoptimizetheperformanceoftheHPNetServerLXProandLXePro
• HPNetServerAssistantsoftwarethatprovidesmonitoring,proactivealerting,andproblem
identificationforsubsystemssuchasredundantpowersupplies,SCSIcontrollers,harddiskdrives,
ECCmemory,anduninterruptiblepowersupplies
• HPOpenViewforWindows,theindustry-leadingnetworkmanagementplatform
• Integration to leadingenterprisesystemmanagementtoolssuchasHP OpenView™and
ComputerAssociates’TNG
Rackmounting Rackmountableinstandard19-inchracktosavefloorspaceinmulti-serverenvironments
RemoteSystemManagement Optionalremotemanagementsolutionfor“lightsout”servermanagement
Serviceability • Castersformobility,removableforrackmounting
• FLASHBIOSsupportforquicksystemBIOSupdates
• Removablesideandtopcoversforeasysystemmaintenance
Features

Flexibility
SupportedOperatingSystems Banyan®VINES®;IBM®OS/2®WarpServerandWarpServerSMP;Microsoft®Windows®NT™Server;
Novell®NetWare®andIntranetWare™;SCO®OpenServer™and UnixWare™
Security and Safety
SystemSecurity • Startuppassword
• Keyboardlockbuttonwithoptionalscreenblanking
Service and Support
Warranty • 3-year,next-business-day,on-sitelimitedwarrantyfromHPorauthorizedresellers
(standardbusinesshours)worldwide
SupportOptions • Optional4-hourresponseduringstandardbusinesshours,or24hoursaday,7daysaweek
availableasHPSupportPackfromresellers
• Freetelephonesupportforbasicsetup,installation,andtroubleshootinginU.S.,Canada,and
Europeduringwarranty
• LANSupportandComprehensiveNetworkSupportavailableasHPSupportPackfromresellers
• Site preparation and installationservicesavailableasHP SupportPackfromresellers
Other Specifications
OperatingTemperature 41°to95°F(5°to35°C)
OperatingHumidity 20%to80%noncondensing
AcousticEmissions Soundlevel(LpA):<58dB(A)
PowerSupply Auto-ranging90to140VAC,or180to264VACat47–63Hz
PowerAvailability 790Wcontinuous
PowerConsumption 1200/1440Wmaximum(LXPro)continuouswith110/220Vsupply
SystemDimensions 24.6"Hx16.6"Wx25.4"D;(63cmx42.5cmx65cm)
SystemWeight 131–187lb(59–85kg),dependingonconfiguration
Regulatory Compliance
ElectromagneticCompliance • CISPR22ClassB(International)
• EN55022ClassB(EUCountries)
• EN50082-1,GenericImmunity
(EUCountries),includes:IEC801-2,ESD;IEC801-3,RI;IEC801-4,FT
• FCCClassBVerified(USA)*
• C-Tick(Australia)
• BCI<PClassB(Taiwan)
• MofCClassA(Korea)
• VCCIClass2(Japan)
• ENG1000-3-2HarmonicCurrent
• ENG1000-3-3VoltageFluctuationandFlicker
SafetyCompliance • CSACertified(Canada,FileLR106647)
• EN60950Compliance(International)
• TÜVCertified(Germany)
• ULListed(USA,FileE139742)
*FCCIDB94HPLS106
Features

Accessories
Product Accessory* Product No.
Memory • 16MBSIMM(60ns) D4891A
• 32MBSIMM(60ns) D4892A
• 64MBSIMM(60ns) D4290A
• 128MBSIMM(60ns) D4893A
• 512MBDIMMKit(includesfour128MBDIMMs) D4968A
• DIMMmemoryboardwith512MB(forconfigurationsrequiring D4967A
greaterthan2GBandupto4GBmemory)
Processor,ProcessorBoard • HPNetServerLXPro6/166processorupgrade(6/166CPUchip) D4288A
Upgrades • HPNetServerLXPro6/166processorboard D4286A
• HPNetServerLXPro6/200processorupgrade(6/200CPUchip) D4867A
• HPNetServerLXPro6/200processorboard D4866A
• HPNetServerLXPro6/2001MBdualprocessorupgradecard(two6/2001MBCPUchips) D4966A
HPNetServerLXeUpgrades • HPNetServer LXe power supply module D4292A
• HPNetServerLXehot-swapstorageupgrade D4927A
StorageDevices • 2.1GBFastSCSI-2diskdrive(commontray)1D2077A
• 4.2GBFastSCSI-2diskdrive(commontray)1D3341A
• 2.1GBhot-swapUltraSCSI-2diskmodule D3582C
• 4.2GBhot-swapUltraSCSI-2diskmodule D3583C
• 9.1GBhot-swapUltraSCSI-2diskmodule D4289A
• 4.2GB,10,000rpmhot-swapUltraSCSIdiskmodule D4903A
• 1.2MB,5.25-inchflexiblediskdrive1D2036A
• CD-ROM,3.5-inchSCSI-21,2 D2992B
• HPNetServerhot-swaptray3D3349B
• HPNetServerLXe/LXProSCSIinternalcablekit D4282A
• 3.5-inchharddiskdrivemountingtrays(3-pack–non-hot-swap)1D2198A
• Tape/DAT/CD-ROMmountingtrays(3-pack–nofrontpanel)1D2199A
ExternalStorageCabinet • HPNetServerRackStorage/8 D4902A
• HPNetServerStorageSystem/6 D3604B
DiskArrayController HPNetRAIDPCIDiskArrayControllercard4D4943A
BackupStorage • HPSureStoreDAT24e,24GBexternaltapedrive C1556A
• HPSureStoreDAT24x6e,144GBexternalAutoloader C1559A
• HPSureStoreDLT30e,30GBexternalDLT C1549A
• HPSureStoreDLT40e,40GBexternalDLT C1579A
• HPSureStoreDLTLibrary4115r(rackmount)withoneDLT4000 drive, C5151F
15slots,300GBnativecapacity,andupto600GBcompressedcapacity
• HPSureStoreDLTLibrary4215r(rackmount)withtwoDLT4000 drives, C5153F
15slots,300GBnativecapacity,andupto600GBcompressedcapacity
NetworkInterfaceCards • HPDeskDirect10/100VGPCIadapter J2585B
• HPDeskDirect10/100TXPCIadapter J3171A
RemoteManagement HPRemoteAssistantCard D2967C5/D2968C6/D2969C7
Monitor UltraVGA15-inchdisplay D2825A
UninterruptiblePowerSupply OptimizedrackmountUPSdevices, customized fortheHPrackenvironment, are availablefromAPC.Foradditional
information,contactyourlocalAPC reseller, or see APC’swebpageathttp://www.apcc.com/english/allys/prtnr/hp
HPNetServerRacks* • HPNetServerLXProRackmountkit J1455A
• 15"UniversalMonitorRackmountkit E7708A
• 2-meterrackwithsidepanelsandreardoors,quartzcolor J1487B
• 2-meterrackonly(withoutsidepanelsorreardoor),quartzcolor J1488A
• HPBallastweightkit C2790A
• HPConsoleSwitch8-port J1497A
• Fillerpanel,1U(setof6) E7725A
*For a complete list of all accessories and configuration guidelines, download HP NetServer Order Assistant,
HP NetServer Rack-Optimized Ordering Guide, and HP NetServer Rack Assistant from http://www.hp.com/go/netserver
1For use in standard half-height shelf only 5For use in regions other than North and South America,
Three shelves available Europe, and Asia Pacific
2Standard on all models 6For use in North and South America
3For selected non-HP drives only 7For use in Europe and Asia Pacific
4Standard on array models. For use with internal
storage in Model 1, must order D4963A cable kit

HP SupportPacks
3-year, 4-hour response (standard business hours) H5520A
24-hours-a-day, 3-year, 7-days-a-week response H5521A
Installation and Configuration H5751A
LAN Support, 5 incidents H5570A
LAN Support, 5 incidents, 24-hours-a-day,
7-days-a-week response H5571A
LAN Support, 10 incidents H5572A
LAN Support, 10 incidents, 24-hours-a-day,
7-days-a-week response H5573A
Comprehensive Network Support, standard hours H5576A
Comprehensive Network Support, 24-hours-a-day,
7-days-a-week, response H5577A
Banyan and VINES are registered trademarks of
Banyan Systems Inc. OpenView is a trademark of
Hewlett-Packard Company. IBM and OS/2 are
registered trademarks of IBM Corporation. Microsoft
and Windows are registered trademarks of, and
Windows NT is a trademark of, Microsoft Corporation.
Novell and NetWare are registered trademarks of,
and IntranetWare is a trademark of, Novell Inc. Intel,
Pentium, and the Intel Inside logo are registered
trademarks of Intel Corporation. SCO is a registered
trademark of, and OpenServer and UnixWare are
trademarks of, the Santa Cruz Operation.
HP NetServer LX Pro Series
Configuration and Models
ECC Hot-Swap Redundant
Model Processor Cache Memory Shelves Power Supply Product No.
HPNetServerLXePro6/166 Model1 PentiumPro166MHz 512KB 64MB 6 Optional D4878B
Model1Array1PentiumPro166MHz 512KB 64MB 6 Optional D4924B
HPNetServerLXePro6/200 Model1 PentiumPro200MHz 512KB 64MB 6 Optional D4920B
Model1Array1PentiumPro200MHz 512KB 64MB 6 Optional D4925B
HPNetServerLXPro6/166SMP Model1Array1DualPentiumPro166MHz 512KB 128MB 12 Standard D4269B
HPNetServerLXPro6/200 Model1 PentiumPro200MHz 512KB 64MB 12 Standard D4311B
Model1Array1PentiumPro200MHz 512KB 64MB 12 Standard D4312B
HPNetServerLXPro6/200SMP Model1Array1DualPentiumPro200MHz 512KB 128MB 12 Standard D4315B
Model1Array1DualPentiumPro200MHz 512KB 512MB 12 Standard D4958B
HPNetServerLXPro Model1Array1Pentium Pro 200MHz 1MB 512MB 12 Standard D4964B
6/2001MBSMP
HPNetServerLXProDualProcessor — PentiumPro200MHz 1MB — — — D4966A
UpgradeCardwithtwoCPUchips
HPNetServerLXPro6/166 — PentiumPro166MHz 512KB — — — D4288A
ProcessorUpgrade
HPNetServerLXPro6/166 — — — — — — D4286A
ProcessorBoard
HPNetServerLXPro6/200 — PentiumPro200MHz 512KB — — — D4867A
ProcessorUpgrade
HPNetServerLXPro6/200 — — — — — — D4866A
ProcessorBoard
HPNetServerLXePower — — — — — — D4292A
SupplyModule
HPNetServerLXeHot-Swap — — — — — — D4927A
StorageUpgrade
1 AllModel 1Array modelsinclude aPCI DiskArray Controller
Information in this document is subject to
change without notice.
©Copyright Hewlett-Packard Company 1997.
All Rights Reserved. Reproduction, adaptation,
or translation without prior written permission
is prohibited except as allowed under the
copyright laws.
Printed in USA M0897
For Additional Information
HP WWWeb server http://www.hp.com/go
/netserver
HP NetServer FTP server ftp://ftp.netserver.hp.com
HP NetServer BBS 1-408-553-3500
HP FAX Response system 1-208-344-4809 (worldwide
from fax only)
