HP LC2640N Instruction Manual

6Connect an S-video
Device
7Connect a Composite
Device
5Connect a Component
(YPbPr) Device
2Connect Speaker Cables 3Connect Subwoofer
(optional)
1Attach Speaker Cables to TV
10 Remote Control 11 Turn On
8Analog Video from PC
HP LC2640N (26") HD Ready LCD Television
HP LC3040N (30") HD Ready LCD Television
Start Here
■Identify the type of connectors your home
entertainment equipment uses, then go to the
corresponding step on this poster and follow
those directions. (Example: To connect a cable
or satellite set-top-box which connects via
S-video cabling, refer to step 6, Connect an
S-video device.)
■Refer to the user documentation for advanced
connections.
■Apply power to all components and then to
the TV.
■Finally, refer to the section titled “First Time
Setup for Channels” in your user
documentation to finalize your TV setup.
Contents
■HP LCD TV with stand
■Speakerbars (2)
■Documentation kit
■Remote control
with AA batteries (2)
■Speaker cables (2)
■Antenna cable
■AC power cable
■DVI cable
■VGA cable
■Component cable
■S-video cable
■Composite cable
The information in this document is subject to change without notice.
4Connect a PC or Other
Device by DVI
9Outdoor Antenna
Connection
Connectors are located on the back of the TV, under the back panel.
Remove rear door before making connections.
b
a
DVI
VGA
Once the power cable is connected, turn on TV by
pressing PWR on the remote control.
Refer to the section in the user documentation titled
“First Time Setup for Channels” to complete TV setup.
Refer to the user documentation for advanced connections.
OUT
R PbYPrL
Component Video Outputs S-video Outputs Composite Video Outputs
Wall
Coaxial
Cable
Signal
