HPE HPE D6020 Manual

HPE FlexNetwork MSR Router Series
Comware 7 Fundamentals Command Reference
Part number: 5200-2363
Software version: MSR-CMW710-R0411
Document version: 6W101-20161114

© Copyright 2016 Hewlett Packard Enterprise Development LP
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the
United States and other countries.
Microsoft® and Windows® are trademarks of the Microsoft group of companies.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java and Oracle are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.

i
Contents
Basic CLI commands ········································································1
alias····································································································································1
display | { begin | exclude | include }··························································································2
display | by-linenum···············································································································3
display >······························································································································4
display >>····························································································································5
display alias ·························································································································6
display history-command ········································································································7
display history-command all ····································································································7
display hotkey·······················································································································8
hotkey·································································································································9
quit··································································································································· 10
repeat ······························································································································· 11
return································································································································ 12
screen-length disable··········································································································· 12
system-view ······················································································································· 13
RBAC commands···········································································14
description ························································································································· 14
display role························································································································· 14
display role feature ·············································································································· 22
display role feature-group ····································································································· 25
feature ······························································································································ 27
interface policy deny ············································································································ 28
permit interface··················································································································· 29
permit security-zone ············································································································ 30
permit vlan························································································································· 32
permit vpn-instance ············································································································· 33
role··································································································································· 34
role default-role enable········································································································· 35
role feature-group················································································································ 36
rule··································································································································· 37
security-zone policy deny······································································································ 41
super ································································································································ 42
super authentication-mode···································································································· 43
super default role ················································································································ 44
super password ·················································································································· 44
vlan policy deny ·················································································································· 45
vpn-instance policy deny······································································································· 46
Login management commands ·························································48
activation-key ····················································································································· 48
authentication-mode ············································································································ 50
auto-execute command········································································································ 51
command accounting··········································································································· 53
command authorization ········································································································ 53
databits ····························································································································· 54
display line························································································································· 55
display telnet client·············································································································· 58
display user-interface··········································································································· 58
display users······················································································································ 61
escape-key ························································································································ 62
flow-control ························································································································ 63
free line····························································································································· 64
free user-interface ··············································································································· 67
history-command max-size···································································································· 69
idle-timeout ························································································································ 70

ii
ip alias ······························································································································ 70
line··································································································································· 71
line class ··························································································································· 74
lock ·································································································································· 76
lock-key····························································································································· 77
lock reauthentication············································································································ 78
parity ································································································································ 79
protocol inbound ················································································································· 79
redirect disconnect ·············································································································· 81
redirect enable···················································································································· 82
redirect listen-port················································································································ 82
redirect passthrough············································································································ 83
redirect refuse-negotiation····································································································· 84
redirect timeout··················································································································· 84
screen-length ····················································································································· 85
send ································································································································· 86
set authentication password ·································································································· 88
shell·································································································································· 89
speed································································································································ 90
stopbit-error intolerance········································································································ 91
stopbits ····························································································································· 91
telnet ································································································································ 92
telnet client source··············································································································· 93
telnet ipv6·························································································································· 93
telnet server acl ·················································································································· 94
telnet server dscp················································································································ 95
telnet server enable ············································································································· 96
telnet server ipv6 acl············································································································ 96
telnet server ipv6 dscp ········································································································· 97
telnet server ipv6 port··········································································································· 98
telnet server port················································································································· 98
terminal type ······················································································································ 99
user-interface ····················································································································· 99
user-interface class············································································································ 102
user-role·························································································································· 105
FTP commands ··········································································· 107
FTP server commands·············································································································· 107
display ftp-server··············································································································· 107
display ftp-user ················································································································· 108
free ftp user······················································································································ 108
free ftp user-ip ·················································································································· 109
free ftp user-ip ipv6············································································································ 109
ftp server acl ···················································································································· 110
ftp server dscp·················································································································· 111
ftp server enable ··············································································································· 111
ftp server ipv6 dscp············································································································ 112
ftp server ssl-server-policy ·································································································· 112
ftp timeout························································································································ 113
FTP client commands ··············································································································· 113
append···························································································································· 114
ascii································································································································ 114
binary······························································································································ 115
bye································································································································· 115
cd··································································································································· 116
cdup ······························································································································· 117
close······························································································································· 117
debug ····························································································································· 118
delete······························································································································ 118
dir··································································································································· 119
disconnect ······················································································································· 120
display ftp client source ······································································································ 120

iii
ftp··································································································································· 121
ftp client ipv6 source·········································································································· 122
ftp client source················································································································· 123
ftp ipv6···························································································································· 123
get·································································································································· 124
help································································································································ 126
lcd·································································································································· 126
ls···································································································································· 127
mkdir ······························································································································ 128
newer······························································································································ 129
open······························································································································· 129
passive···························································································································· 130
put·································································································································· 131
pwd ································································································································ 132
quit································································································································· 132
reget······························································································································· 133
rename···························································································································· 133
reset······························································································································· 134
restart ····························································································································· 134
rhelp······························································································································· 135
rmdir······························································································································· 137
rstatus····························································································································· 137
status······························································································································ 139
system ···························································································································· 140
user································································································································ 140
verbose··························································································································· 141
? ···································································································································· 142
TFTP commands ········································································· 143
tftp·································································································································· 143
tftp client ipv6 source ········································································································· 144
tftp client source················································································································ 145
tftp ipv6 ··························································································································· 146
tftp-server acl ··················································································································· 147
tftp-server ipv6 acl············································································································· 148
File system management commands················································ 149
auto-copy destination-directory ···························································································· 150
auto-copy source-directory·································································································· 151
cd··································································································································· 152
copy ······························································································································· 153
delete······························································································································ 156
dir··································································································································· 158
file prompt························································································································ 161
fixdisk ····························································································································· 161
format ····························································································································· 162
gunzip····························································································································· 162
gzip ································································································································ 163
md5sum ·························································································································· 164
mkdir ······························································································································ 164
more······························································································································· 165
mount ····························································································································· 167
move ······························································································································ 168
pwd ································································································································ 168
rename···························································································································· 169
reset recycle-bin················································································································ 169
rmdir······························································································································· 170
rsync······························································································································· 170
rsync client source············································································································· 172
sha256sum ······················································································································ 173
tar create························································································································· 174
tar extract ························································································································ 175

iv
tar list······························································································································ 176
umount···························································································································· 176
undelete ·························································································································· 177
Configuration file management commands ········································ 179
archive configuration·········································································································· 179
archive configuration interval······························································································· 180
archive configuration location ······························································································ 180
archive configuration max ··································································································· 182
backup startup-configuration ······························································································· 183
configuration encrypt·········································································································· 184
configuration replace file····································································································· 185
display archive configuration ······························································································· 185
display current-configuration································································································ 186
display current-configuration diff··························································································· 188
display default-configuration································································································ 189
display diff························································································································ 189
display saved-configuration································································································· 191
display startup ·················································································································· 192
display this······················································································································· 194
reset saved-configuration···································································································· 195
restore startup-configuration································································································ 197
save ······························································································································· 199
startup saved-configuration ································································································· 203
Software upgrade commands ························································· 205
boot-loader file·················································································································· 205
boot-loader update ············································································································ 208
bootrom update················································································································· 211
display boot-loader ············································································································ 212
firmware update················································································································ 214
version auto-update enable································································································· 216
version check ignore·········································································································· 217
ISSU commands·········································································· 218
display install active··········································································································· 218
display install backup········································································································· 222
display install committed····································································································· 224
display install inactive········································································································· 226
display install ipe-info········································································································· 227
display install job··············································································································· 227
display install log··············································································································· 228
display install package ······································································································· 229
display install rollback ········································································································ 231
display install which··········································································································· 231
display version comp-matrix ································································································ 233
install abort ······················································································································ 238
install activate··················································································································· 239
install add ························································································································ 244
install commit ··················································································································· 245
install deactivate ··············································································································· 246
install remove ··················································································································· 247
install rollback to ··············································································································· 248
install verify······················································································································ 249
reset install log-history oldest······························································································· 252
reset install rollback oldest·································································································· 252
Emergency shell commands··························································· 254
copy ······························································································································· 254
delete······························································································································ 255
dir··································································································································· 255
display copyright ··············································································································· 257

v
display install package ······································································································· 257
display ip routing-table ······································································································· 258
display ipv6 routing-table ···································································································· 259
display version·················································································································· 260
format ····························································································································· 260
ftp··································································································································· 261
mkdir ······························································································································ 261
more······························································································································· 262
move ······························································································································ 262
ping································································································································ 263
ping ipv6·························································································································· 264
pwd ································································································································ 265
quit································································································································· 265
reboot ····························································································································· 265
reset ssh public-key··········································································································· 266
rmdir······························································································································· 267
shutdown························································································································· 267
ssh2 ······························································································································· 268
system-view ····················································································································· 269
telnet ······························································································································ 269
tftp·································································································································· 269
Automatic configuration commands·················································· 271
autodeploy sms enable······································································································· 271
autodeploy udisk enable····································································································· 271
Security zone commands······························································· 272
display security-zone ········································································································· 272
display zone-pair security···································································································· 272
import interface················································································································· 273
security-zone···················································································································· 274
security-zone intra-zone default permit·················································································· 274
zone-pair security·············································································································· 275
Device management commands······················································ 277
card-mode ······················································································································· 277
clock datetime ·················································································································· 279
clock protocol ··················································································································· 280
clock summer-time ············································································································ 281
clock timezone·················································································································· 282
command························································································································· 283
copyright-info enable·········································································································· 284
display alarm···················································································································· 284
display clock····················································································································· 286
display copyright ··············································································································· 287
display cpu-usage ············································································································· 287
display cpu-usage configuration··························································································· 290
display cpu-usage history···································································································· 291
display device··················································································································· 294
display device manuinfo ····································································································· 297
display device manuinfo fan ································································································ 300
display device manuinfo power ···························································································· 302
display diagnostic-information······························································································ 303
display environment··········································································································· 305
display fan ······················································································································· 307
display memory················································································································· 308
display memory-threshold··································································································· 309
display power ··················································································································· 311
display power-supply ········································································································· 311
display scheduler job ········································································································· 312
display scheduler logfile······································································································ 313
display scheduler reboot····································································································· 313

vi
display scheduler schedule ································································································· 314
display system stable state·································································································· 315
display transceiver alarm ···································································································· 317
display transceiver diagnosis······························································································· 318
display transceiver interface································································································ 319
display transceiver manuinfo ······························································································· 320
display version·················································································································· 321
display version-update-record······························································································ 321
header ···························································································································· 322
job·································································································································· 324
memory-threshold ············································································································· 324
memory-threshold usage ···································································································· 327
monitor cpu-usage enable··································································································· 328
monitor cpu-usage interval·································································································· 329
monitor cpu-usage threshold ······························································································· 330
password-recovery enable ·································································································· 331
power-supply off················································································································ 332
power-supply on················································································································ 333
power-supply policy enable ································································································· 334
power-supply policy redundant····························································································· 335
reboot ····························································································································· 336
remove···························································································································· 339
reset scheduler logfile ········································································································ 340
restore factory-default ········································································································ 341
scheduler job···················································································································· 341
scheduler logfile size·········································································································· 342
scheduler reboot at············································································································ 342
scheduler reboot delay······································································································· 343
scheduler schedule············································································································ 344
shutdown-interval·············································································································· 345
sysname·························································································································· 346
time at····························································································································· 346
time once························································································································· 347
time repeating··················································································································· 348
usb disable ······················································································································ 350
user-role·························································································································· 350
Tcl commands············································································· 352
cli··································································································································· 352
tclquit······························································································································ 352
tclsh································································································································ 353
Python commands········································································ 354
python····························································································································· 354
python filename ················································································································ 354
Document conventions and icons ···················································· 356
Conventions···························································································································· 356
Network topology icons ············································································································· 357
Support and other resources··························································· 358
Accessing Hewlett Packard Enterprise Support·············································································· 358
Accessing updates··················································································································· 358
Websites ························································································································· 359
Customer self repair ·········································································································· 359
Remote support ················································································································ 359
Documentation feedback ···································································································· 359
Index························································································· 361

1
Basic CLI commands
alias
Use alias to configure a command alias.
Use undo alias to delete a command alias.
Syntax
alias alias command
undo alias alias
Default
The device has a set of system-defined command aliases, as listed in Table 1.
Table 1 System-defined command aliases
Command alias
Command or command keyword
access-list acl
end return
erase delete
exit quit
hostname sysname
logging info-center
no undo
show display
write save
Views
System view
Predefined user roles
network-admin
Parameters
alias: Specifies an alias, a case-sensitive string of 1 to 20 characters. An alias cannot be alias or
contain spaces.
command: Specifies a command string. Make sure the command string meets the syntax
requirements.
Usage guidelines
System-defined command aliases cannot be deleted.
You can configure one or more aliases for a command or the starting keywords of commands. Then,
you can use the aliases to execute the command or commands. If the command or commands have
undo forms, you can also use the aliases to execute the undo command or commands.
For example, if you configure the alias shiprt for display ip routing-table, you can enter shiprt to
execute the display ip routing-table command. If you configure the alias ship for display ip, you
can use ship to execute all commands that start with display ip:

2
•
Enter ship routing-table to execute the display ip routing-table command.
•
Enter ship interface to execute the display ip interface command.
The command string can include up to nine parameters. Each parameter starts with the dollar sign
($) and a sequence number in the range of 1 to 9. For example, you can configure the alias shinc for
the display ip $1 | include $2 command. Then, to execute the display ip routing-table | include
Static command, you only need to enter shinc routing-table Static. To execute the display ip
interface | include GigabitEthernet0/0/1 command, you only need to enter shinc interface
GigabitEthernet0/0/1.
Examples
# Configure the alias shiprt for the display ip routing-table command and verify the configuration.
<Sysname> system-view
[Sysname] alias shiprt display ip routing-table
[Sysname] shiprt
Destinations : 14Routes : 14
Destination/Mask Proto Pre Cost NextHop Interface
0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
3.3.3.3/32 Static 60 0 192.168.1.62 GE0/0
127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0
127.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0
127.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0
169.254.0.0/24 Direct 0 0 169.254.0.188 GE0/0
169.254.0.0/32 Direct 0 0 169.254.0.188 GE0/0
169.254.0.188/32 Direct 0 0 127.0.0.1 InLoop0
169.254.0.255/32 Direct 0 0 169.254.0.188 GE0/0
192.168.57.0/24 RIP 100 1 192.168.1.62 GE0/0
224.0.0.0/4 Direct 0 0 0.0.0.0 NULL0
224.0.0.0/24 Direct 0 0 0.0.0.0 NULL0
255.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0
# Configure the alias shinc for display ip $1 | include $2.
[Sysname] alias shinc display ip $1 | include $2
# Use the alias shinc to display all static routes.
[Sysname] shinc routing-table Static
3.3.3.3/32 Static 60 0 192.168.1.62 GE0/0
# Use the alias shinc to display all RIP routes.
[Sysname] shinc routing-table RIP
192.168.57.0/24 RIP 100 1 192.168.1.62 GE0/0
Related commands
display alias
display | { begin | exclude | include }
Use display |{ begin | exclude | include } to filter the output from a display command with a regular
expression.
Syntax
display command |{ begin | exclude | include } regular-expression
