HPE LSWM2QP2P Interface Card
(JH155A) User Guide
Part number: 5998-7831s
▌Introduction
Product code HPE description Alias
JH155A HPE 5510 2-port QSFP+
Module LSWM2QP2P
Overview
The LSWM2QP2P interface card provides two QSFP+ ports.
Figure 1 LSWM2QP2P interface card
(1) QSFP+ port LED (2) QSFP+ port
(3) Captive screw (4) Ejector lever
NOTE:
The switch models that the LSWM2QP2P interface card is
applicable to may change over time. For the most recent list of
applicable switch models, contact HPE Support or marketing
staff.
4
1 2 3

2
QSFP+ ports
You can install QSFP+ transceiver modules in Table 1 and Table 2,
QSFP+ DAC cables in Tabl e 3, and QSFP+ to SFP+ DAC cables
in Table 4 in the QSFP+ ports on the LSWM2QP2P interface card.
Table 1 QSFP+ transceiver modules available for the QSFP+
ports (1)
Product
code
HPE
description
Central
wavelength (nm) Connector
JG325B
HP X140 40G
QSFP+ MPO
SR4 Transceiver
850 MPO
JG709A
HP X140 40G
QSFP+ MPO
MM 850nm
CSR4 300m
Transceiver
850 MPO
JG661A
HP X140 40G
QSFP+ LC LR4
SM 10km
1310nm
Transceiver
Four lanes:
•1271
•1291
•1311
•1331
LC
Table 2 QSFP+ transceiver modules available for the QSFP+
ports (2)
Product
code
Cable/fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JG325B Multi-mode,
50/125
2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
JG709A Multi-mode,
50/125
2000 300 m (984.25 ft)
4700 400 m (1312.33 ft)

3
Product
code
Cable/fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
JG661A Single-mode,
9/125 N/A 10 km (6.21 miles)
Table 3 QSFP+ DAC cables available for the QSFP+ ports
Product
code HPE description Cable length Data rate
JG326A
HP X240 40G
QSFP+ QSFP+ 1m
Direct Attach Copper
Cable
1 m (3.28 ft)
40 Gbps
JG327A
HP X240 40G
QSFP+ QSFP+ 3m
Direct Attach Copper
Cable
3 m (9.84 ft)
JG328A
HP X240 40G
QSFP+ QSFP+ 5m
Direct Attach Copper
Cable
5 m (16.40 ft)
Table 4 QSFP+ to SFP+ DAC cables available for the QSFP+
ports
Product
code HPE description Cable length Data rate
JG329A
HP X240 40G
QSFP+ to 4x10G
SFP+ 1m Direct
Attach Copper
Splitter Cable
1 m (3.28 ft) 40 Gbps to
4*10 Gbps

4
Product
code HPE description Cable length Data rate
JG330A
HP X240 40G
QSFP+ to 4x10G
SFP+ 3m Direct
Attach Copper
Splitter Cable
3 m (9.84 ft)
JG331A
HP X240 40G
QSFP+ to 4x10G
SFP+ 5m Direct
Attach Copper
Splitter Cable
5 m (16.40 ft)
NOTE:
HPE recommends that you use HPE QSFP+ transceiver
modules, QSFP+ DAC cables, or QSFP+ to SFP+ DAC cables fo
r
the QSFP+ ports on the LSWM2QP2P interface card. The
QSFP+ transceiver modules, QSFP+ DAC cables, and QSFP+ to
SFP+ DAC cables available for the interface card are subject to
change over time. For the most recent list of QSFP+ transceiver
modules, QSFP+ DAC cables, and QSFP+ to SFP+ DAC cables
available for the interface card, contact HPE Support or marketing
staff.
LEDs
Table 5 describes LEDs for the QSFP+ ports.
Table 5 QSFP+ LED descriptions
LED status Description
Steady green
A transceiver module is installed in the port. The
port is operating at 40 Gbps, and a link is
present on the port.
Flashing green The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module is installed in the port. The
port is operating at 10 Gbps, and a link is
present on the port.

5
LED status Description
Flashing yellow The port is sending or receiving data at 10 Gbps.
Off No transceiver module is installed in the port, or
no link is present on the port.
NOTE:
The QSFP+ port LEDs are not affected by the port mode
switching button on your switch. For more information about the
port mode switching button, see the installation guide of the
switch.
▌Installing and removing an interface card
CAUTION:
•Before you install or remove an interface card, wear an ESD
wrist strap and make sure the wrist strap makes good skin
contact and is reliably grounded.
•To avoid device damage, do not use excessive force when you
install or remove an interface card.
Prepare the following tools before you install or remove an interface
card:
•Phillips screwdriver.
•Flat blade screwdriver.
•ESD wrist strap.
The installation tools are not provided with HPE devices. Prepare
them yourself.
Installing an interface card
This guide uses the HPE 5510 24G 4SFP+ HI 1-slot Switch (JH145A)
as an example.
To install an interface card:
1. Use the Phillips screwdriver to remove the screw on the filler
panel in the target interface card slot, as shown by callout 1
in Figure 2.
Keep the removed screw secure for future use.

6
2. Insert the flat blade screwdriver through the handle on the filler
panel to pull out the filler panel, as shown by callout 2 in Figure 2.
Keep the removed filler panel secure for future use.
3. Unpack the LSWM2QP2P interface card.
4. Insert the interface card slowly into the slot along the guide rails,
as shown by callout 1 in Figure 3.
5. Rotate inward the ejector lever as shown by callout 2 in Figure 3
until the interface card is in close contact with the switch.
6. Use the Phillips screwdriver to tighten the captive screw on the
interface card as shown by callout 3 in Figure 3.
Figure 2 Removing a filler panel
Figure 3 Installing an LSWM2QP2P interface card

7
Removing an interface card
CAUTION:
•Before you remove an interface card, remove the cable from it.
•After removing an interface card, if no new interface card is to
be installed, install the filler panel as soon as possible to
prevent dust and ensure good ventilation in the device.
To remove an interface card:
1. Prepare an anti-static bag.
2. Use the Phillips screwdriver to loosen the captive screw on the
interface card, as shown by callout 1 in Figure 4.
3. Rotate outward the ejector lever as shown by callout 2 in Figure 4.
4. Pull out the interface card slowly out the interface card slot as
shown by callout 3 in Figure 4.
5. Place the removed interface card in the anti-static bag.
Figure 4 Removing an LSWM2QP2P interface card
Installing and removing QSFP+ transceiver modules
or DAC cables
For information about installing or removing QSFP+ transceiver
modules or DAC cables, see QSFP+ Transceiver Modules/Cables
Installation Guide
Verifying the installation
After the installation is complete, identify whether the interface card is
operating correctly according to the status of the QSFP+ port LEDs.

8
If the interface card fails to operate correctly, perform the following
steps:
1. Reinstall it following the installation procedures described in this
document.
2. If the problem persists, contact HPE Support.
▌Documentation
To access documentation and support services, go to the Hewlett
Packard Enterprise Support Center website:
www.hpe.com/support/hpesc
