HPE LSWM2XMGT2PM User manual

1
BOM: 3101A135
Part number: 5200-8510
HPE LSWM2XMGT2PM Interface Card (R9L65A) User
Guide-5PW100
Introduction
Product code HPE description Alias
R9L65A HPE FlexNetwork 5140/5520
10GBASE-T MACsec 2p Mod LSWM2XMGT2PM
•The switch models that the LSWM2XMGT2PM interface card is
applicable to might change over time. For the most up-to-date list of
applicable switch models, contact HPE Support or marketing staff.
•The restrictions for using the LSWM2XMGT2PM vary by device model.
For more information, see the installation guide for the device.
Overview
The LSWM2XMGT2PM interface card provides two 10G/5G/2.5G/1000/100BASE-T
autosensing Ethernet port.
10G/5G/2.5G/1000/100BASE-T antosensing Ethernet port
Autosensing Ethernet
port LED
Ejector lever
Captive screw

2
Specifications
Item Specification
Ports 2 × 10G/5G/2.5G/1000/100BASE-T autosensing Ethernet ports
Dimensions (H × W × D) 40.1 × 95.0 × 147.5 mm (1.58 × 3.74 × 5.81 in)
Weight 0.3 kg (0.66 lb)
Min power consumption 2.0 W
Max power consumption 4.0 W
Operation temperature –5°C to +45°C (23°F to 113°F)
Operating humidity 5% RH to 95% RH, noncondensing
Ports
Item Specification
10G/5G/2.5G/1000/100BASE-T autosensing Ethernet ports
Connector RJ-45
Port mode
10 Gbps, full duplex.
5 Gbps, full duplex.
2.5 Gbps, full duplex.
1 Gbps, full duplex.
100 Mbps, half/full duplex.
MDI/MDI-X autosensing.
Maximum
transmission distance
10G mode: 100 m (328.08 ft) over Category-6 shielded foil twisted
pair (S/FTP) or above twisted pair
10G mode: 55 m (180.45 ft) over Category-6 unshielded twisted
pair (UTP) or Category-5e twisted pair
5G mode: 100 m (328.08ft) over Category-5e or above twisted pair
2.5G mode: 200 m (656.17 ft) over Category-5e or above twisted
pair
1G mode: 140 m (459.32ft) over Category-5e or above twisted pair
100M mode: 140 m (459.32 ft) over Category-5e or above twisted
pair
NOTE:
The data is for reference only. The actual maximum transmission
distance varies by the capabilities of the peer device and the twisted
pair quality.
Cable 10G mode: Category-6 or above twisted pair cable
5G/2.5G/1G/100M mode: Category-5e or above twisted pair cable
Standard IEEE 802.3an
IEEE 802.3ab

3
LEDs
The 1/10GBase-T autosensingEthernet port LEDs are not affected by the port LED
mode switching button on your switch. For more information about the port LED
mode switching button, see the installation guide for the switch.
LED Status Description
10G/5G/2.5G/1000/100BASE-T autosensing Ethernet port LED
Steady green A link is present on the port and the port is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow A link is present on the port and the port is operating at 100 Mbps, 1 Gbps, 2.5
Gbps, or 5 Gbps.
Flashing yellow The port is sending or receiving data at 100 Mbps, 1 Gbps, 2.5 Gbps, or 5
Gbps.
Off No link is present on the port.
Installing and removing the card
•
Prepare the following tools before you install or remove the card: Phillips
screwdriver, flat-blade screwdriver, and ESD wrist strap.
•No installation tools are provided with the device. Prepare these tools
yourself.
•Remove the filler panel (if any) from the target slot before installing the
card. Keep the removed screw and filler panel secure for future use.
Safety precautions
•
Before you install or remove the card, wear an ESD wrist strap and make
sure the strap makes good skin contact and is reliably grounded.
•
To avoid device damage, do not use excessive force when you install or
remove the card.
•To avoid cable damage, remove the cables from the card before
removing the card.
•
If you are not to install a newcard afterremoving the original one, install a
filler panel in the slot to prevent dust and ensure good ventilation in the
device.
•Place the removed card on an anti-static mat or in an anti-static bag.

4
Installing the interface module
To Install the interface module:
(1) Unpack the card. Insert the card slowly into the slot along the guide rails.
(2) Rotate inward the ejector lever until the card is in close contact with the switch.
(3) Use the Phillips screwdriver to tighten the captive screw on the card.
Removing the interface module
To remove the interface module:
(1) Use a Phillips screwdriver to loosen the captive screw on the card.
(2) Hold the ejector lever to pull the card outward until the card is disconnected
from the connectors.
(3) Hold the card with both hands and take it out slowly.
1
3
2
1
32

5
Verifying the installation
After the installation is complete, determine whether the card is operating correctly.
If the card fails to operate correctly, perform the following steps:
(1) Reinstall the card following the installation procedures described in this
document.
(2) If the problem persists, contact Hewlett Packard Enterprise Support.
Documentation
To access documentation and support services, go to the Hewlett Packard
Enterprise Support Center website:
www.hpe.com/support/hpesc
The information contained herein is subject to change without notice.
©Copyright 2022 Hewlett Packard Enterprise Development LP
5200-8510
