HPFI Hyperwork User manual

© HPFi 1104 Bedford Street High Point, NC 27263 www.hpfi.com (p) 800.447.3462 (f) 800.231.6784
• Wall Hanger Rail
Hardware Provided
Step 1
Position the cabinet against the wall in the desired location. Place
your level on top of the cabinet. With your pencil, mark the wall
where the top of the cabinet will be located. Two (2) people may be
required for this step to hold the cabinet in place while the second
person levels and draws the first locator line. After taking the cabinet
away from the wall, use the Wall Hanger Rail, tape measure and level
to draw a second line 6” below the first line.
Storage Cabinets
Wall Mount
Hyperwork
Assembly Instructions
• Level
• Tape Measure (at least 10’)
• Phillips screwdriver (manual or power)
• Pencil
• Stud locator (when attaching to drywall surface)
Tools Needed
NOTE: No fasteners are included for attachment to the wall. It is
the responsibility of the installer to provide the correct fasteners for
the applicable (structural) wall type, e.g. block or drywall with studs.
Be certain to use fasteners that will support the total weight of the
cabinet (listed below) and its contents when fully loaded.
6”
Open Storage Cabinet Weight (Empty)
30” Wide Cabinet - 48 lbs.
36” Wide Cabinet - 55 lbs.
42” Wide Cabinet - 63 lbs.
48” Wide Cabinet - 70 lbs.
54” Wide Cabinet - 77 lbs.
60” Wide Cabinet - 96 lbs.
66” Wide Cabinet - 103 lbs.
72” Wide Cabinet - 110 lbs.
Enclosed (doors) Storage Cabinet Weight (Empty)
30” Wide Cabinet - 68 lbs.
36” Wide Cabinet - 76 lbs.
42” Wide Cabinet - 85 lbs.
48” Wide Cabinet - 102 lbs.
54” Wide Cabinet - 110 lbs.
60” Wide Cabinet - 126 lbs.
66” Wide Cabinet - 135 lbs.
72” Wide Cabinet - 150 lbs.

Storage Cabinets
Wall Mount
Hyperwork
Assembly Instructions
Step 3
Place the Storage Cabinet flush against the wall slightly above the
mounted Wall Hanger Rail. Carefully lower the Storage Cabinet onto
the Wall Hanger Rail. The opposing angles of the Wall Hanger Rail
and the Storage Cabinet mounted Rail should snugly engage.
Align the Wall Hanger Rail to the lower locator line on the wall and
attach to the wall using your installer-supplied fastening devices.
Note that the Wall Hanger Rail is shorter than the rail on the back of
the Storage Cabinet so that it may be secured to wall studs (where
applicable) and allow it to adjust side-to-side to the final desired
location.
Step 2
