Hspro HW1 User manual

HW1
Digital Wireless TV Headphones
User Manual

CONTENTS
1
2
3
3
3
5
7
8
8
8
8
9
In the Box
Product Overview
LED Indicators Guide
How to Turn on/off the Headphones
How to Charge the Headphones
How to Connect the Transmitter to TV
FAQs
Technical Specifications
Warranty
Care and Maintenance
Warranty Disclaimer
Important Safety Instructions

Headphones
Charging Dock
(Also serve as a transmitter)
In the Box
- 1 -
RCA Adapter Cable
User Manual
HW1
Digital Wireless TV Headphones
User Manual
Power Adaptor
3.5mm Audio Cable

Overview of the Charging Dock/Transmitter
Overview of the Headphones
Product Overview
Charging Port
3.5mm Audio Input
Product Overview
Charging Pins
Signal Indicator
Charging Indicator
- 2 -
Charging Contacts
Power Button
Volume + Button
Volume - Button
Signal Indicator
Power Indicator

Power on
Power off
Low Battery
Charging
Fully Charged
Connected
The power indicator on the right ear cup stays red.
The power indicator on the right ear cup goes off.
The signal indicator on the left ear cup flashes green
and you hear a beep every 1 minute until the
headphones turn off automatically.
The charging indicator on the charging dock keeps
flashing green.
The charging indicator on the charging dock stays
green.
The signal indicator on the charging dock turns red,
and the signal indicator at the lower right corner of
the left ear cup turns green.
LED Indicators Guide
How to Turn on/off the Headphones
- 3 -
How to Charge the Headphones
1. Connect the charging
dock to a power source.
Power on/off: Press and hold the power button for 2 seconds.

Notes:
a) Before charging the headphones for the first time, please remove the insulating
sheet from the headphones.
b) Fully charge the headphones before the first-time using.
c) A complete charging cycle takes about 6 hours, and the headphones can play 10
hours on a full charge.
d) If the battery is almost drained, you will hear beeps in the headphones.
- 4 -
2. Place the headphones on the charging dock. Make sure the charging contacts
under the headband match well with the charging pins on the charging dock.
3. The charging indicator on the charging dock keeps flashing green once
charging starts, and it stops flashing and stays green when the headphones are
fully charged.
100%

Connect the Transmitter to a TV with a 3.5mm Audio-out Port
How to Connect the Transmitter to TV
- 5 -
①
Connect the power adapter to the
transmitter and plug the mains charger
into a power source.
②
Connect one end of the 3.5mm
audio cable to the audio input port
of the transmitter and the other end
to your TV's audio output port.
③
The signal indicator on the transmitter
turns red.
④
Turn on the headphones.

Note:
If the headphones don’t receive the signal from the transmitter within 5 minutes, the
headphones will power off automatically.
- 6 -
Connect the Transmitter to a TV with RCA Outputs
①
Connect the power adapter to the
transmitter and plug the mains charger
into a power source.
②
Plug the provided RCA adapter
cable into the RCA outputs on your
TV and the 3.5 audio cable into the
audio jack of the adapter cable.
③
The signal indicator on the transmitter
turns red.
④
Turn on the headphones.

FAQs
Q: No sound comes from headphones, what should I do?
A:
Check whether the signal light on the transmitter stays red, if not, please try the
following:
• Make sure the charging dock is connected to a power source.
• Make sure the headphones have been turned on.
• Do not plug into any ports labeled as “AV IN”.
• If your TV has a 3.5mm audio output, please make sure the 3.5mm audio cable is
plugged into the audio-out port behind the TV. Do not plug it into any audio-in
port behind the TV.
• If your TV has RCA outputs, please make sure the RCA adapter cable is plugged
into RCA output ports behind the TV. Do not plug it into any RCA input ports
behind the TV.
• Please make sure that your audio device is turned on and in play mode.
• If connecting the transmitter to a TV with a 3.5mm audio-out port, please do not
mute your TV.
• Instead of TV, connect to your phone to test.
• If the steps above did not resolve your issue, contact us for help.
Q: The volume is not loud enough, what should I do?
A:
Turn up your TV’s volume to the maximum level.
Q: Headphones HW1 cannot get charged, what should I do?
A:
Check whether the charging light on the charging dock keeps flashing green, if
not, please try the following:
• Make sure the charging dock is connected to a power source.
• Make sure the charging contacts under the headband match well with the
charging pins on the charging dock. The charging indicator keeps flashing
green once charging starts and it stops flashing and stays green when the
headphones are fully charged.
Q: How to pair two or more headphones HW1 with one transmitter?
A:
• When a pair of Hspro TV headphones HW1 has successfully paired with the
transmitter, press and hold the power button of a second pair of headphones
HW1 until the power indicator on the right ear cup stays red, and the signal
indicator on the left ear cup keeps flashing green.
• Unplug the power adaptor from the yellow charging port on the transmitter, and
plug the power adaptor back into the yellow charging port, then you can hear a
beep from the second pair of headphones, and the green signal indicator on the
left ear cup stops flashing and stays green. Then the two headphones are paired
with the transmitter.
- 7 -

All Hspro TV headphones are backed by a one-year warranty. If you have any
questions or suggestions about the product or packaging, please contact us via email:
[email protected].
Warranty
Only clean this product with a slightly damp, lint-free cloth and do not use aggressive
cleaning agents.
Care and Maintenance
Number One Commerce Company Limited assumes no liability and provides no
warranty for damage resulting from improper installation, improper use of the product
or from failure to observe the operating instructions or safety notes.
Warranty Disclaimer
- 8 -
Technical Specifications
Frequency Response
Operating Voltage
Transmission Range
Charging Time
Operating Time
20Hz-20KHz
transmitter (5V) receiver (2.4V)
Up to 100 feet/30 meters (open area)
6 hours
10 hours (at medium volume)
Q: Sound only comes from headphones. What should I do if I need sound
coming from headphones and TV simultaneously?
A:
Please refer to the steps for connecting the transmitter to a TV with RCA outputs.

- 9 -
● Use of headphones will impair your ability to hear other sounds. Use caution while using
your headphones when you are engaging in any activity that requires your full attention.
● If you have a pacemaker or other electrical medical devices, you should consult your
physician before using this product.
● This package contains small parts that may be hazardous to children and should be
kept out of reach from children. This product is not a toy – never allow children to play
with this product. Always store the product out of reach from children. The bags
themselves or the many small parts they contain may cause choking if ingested.
● Never try to dismantle the product yourself, or push objects of any kind into the
products, as this may cause short circuits which could result in a fire or electric shock.
● None of the components can be replaced or repaired by users. Only authorized dealers
or service centers may open the product. If any parts of your product require
replacement for any reason, including normal wear and tear or breakage, please
contact us.
● Avoid exposing your product to heat and humidity to protect against damage to the
product or injury to you.
● Keep all products, cords, and cables away from operating machinery.
● If the product overheats, if the product has been dropped or damaged, if the product
has a damaged cord or plug, or if the product has been dropped in a liquid, discontinue
use and contact us.
● Do NOT use in areas where there are explosive hazards.
● Do NOT submerge the headphones in water. Do NOT expose the headphones to
moving water (e.g., from a faucet, etc.).
● Do NOT wear the headphones while showering or bathing, or when participating in
water sports, e.g., swimming, water skiing, surfing, etc.
● This product contains magnetic material. Consult your physician on whether this might
affect your implantable medical device.
● Leaving the product in hot or cold places, such as in a closed car in the summer and
winter conditions, will reduce the capacity and lifetime of the headphones.
● Dispose of the product according to local standards and regulations.
● Remember: Always drive safely, avoid distractions and follow local laws!
Using the headphones while operating a motor vehicle, motorcycle, watercraft or
bicycle may be dangerous, and is illegal in some jurisdictions, just as use of the
headphones with both ears covered while driving is not permitted in certain
jurisdictions. Check your local laws. Use with caution while using your
headphoneswhen you are engaging in any activity that requires your full attention.
While engaging in any such activity, removing the headphones from your ear or turning
off your headphones will keep you from being distracted, so as to avoid accident or
injury. Do not take notes or read documents while driving.
Important Safety Instructions
