HSS Hire 458 Troubleshooting guide

Wet Vacuum
with
Auto Pump
A powerful industrial vacuum cleaner
for dedicated wet pick-up. Ideal for
liquid spillage’s and lightly flooded
areas.
Operating & Safety Guide 458
Always position yourself so you can control the
vacuums whereabouts while ensuring that neither of
the hose or the power supply cable are under strain.
Move the wand back-wards in straight strips across
the floor, working in a methodical pattern to ensure the
entire area is vacuumed.
Take your time and don’t over do it. You are more
likely to have an accident if you are tired or rushing.
If you do not switch the auto pump ON, once the
waste tank is filled to its maximum capacity, the
sound of the motor will increase and the suction
will stop.
When this happens, turn the vacuum OFF (move
the switch to the ‘0’ position), then making sure that
the discharge hose is routed to a suitable
discharge point, switch the auto pump ON.
Once the waste tank is empty, the pump will
automatically stop. If the discharge hose has to be
removed from the discharge point, make sure that
you switch the pump OFF before proceeding.
When you have finished with the vacuum, empty
the contents via the pump and discharge hose
then switch everything OFF and disconnect the
vacuum from its power supply.
Disconnect the vacuum hose and wand and the
discharge hose. Empty
both of any remaining
water and neatly coil.
Unclip the power unit and
remove the ball filter.
Unclip the top cover and
remove the inlet filter box.
Tip out any remaining
water into a suitable
container or down a
suitable drain if the liquid is
safe to do so.
Empty the filter box of any
debris and rinse with fresh
water before re assembling
the unit. Refit the power
unit securing it in place
with the side clips.
Never push the equipment beyond its design
limits. If it will not do what you want with reasonable
ease and speed, assume you have the wrong tool for the
job. Contact your local HSS Hire Shop for advice.
Keep the equipment clean – you will find this less of a
chore if you clean it regularly, rather than wait until the
end of the hire period.
Remember, it is your responsibility to dispose of the
contents of the waste tank in a responsible manner.
EQUIPMENT CARE
When not in use, store the equipment somewhere
clean, dry and safe from thieves.
Switch OFF and unplug the vacuum. Clean the
inlet filter box and remove any remaining liquid
from the waste tank as described in BASIC
TECHNIQUES.
Collect all the parts together, neatly coil the power
supply cable and give the unit a final clean up
ready for return, to your local HSS Hire Shop.
FINISHING OFF
Code 58231
©HSS Hire Service Group Plc 2001 No. 458/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Web Site: http://www.hss.co.uk
Contact your local
0845 728 2828
…any comments?
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
address below
Fax: [phone]
458/01
Inlet Filter Box

For advice on the safety and suitability of this equipment
contact your local HSS Hire Shop.
There is a serious risk of personal injury if you do
not follow all instructions laid down in this guide.
The hirer has a responsibility to ensure that all
necessary risk assessments have been completed
prior to the use of this equipment.
This equipment should only be used by an operator
who has been deemed competent to do so by
his/her employer.
This equipment should be used by an able bodied,
competent adult who has read and understood these
instructions. Anyone with either a temporary or
permanent disability, should seek expert advice before
using it.
Keep children, animals and bystanders away from
the work area. Cordon off a NO GO area using
cones and either barriers or tape, available for hire
from your local HSS Hire Shop.
Never use this equipment if you are ill,
feeling tired, or under the influence of
alcohol or drugs.
Wear practical, waterproof clothing, gloves
and footwear. Avoid loose garments and
jewellery that could catch in moving parts, tie back long
hair.
Never operate the vacuums ON/OFF switches with
wet hands.
This equipment is heavy (31Kg dry), never attempt
to lift it on your own, always get help.
Take all necessary precautions to protect yourself
and others against the possibility of contracting
infectious diseases in your work environment.
Always switch OFF and unplug the equipment
when not in use.
Ensure the work area is well lit and ventilated, if in
doubt, ask about lighting and ventilation equipment at
your local HSS Hire Shop.
Make sure you know how to switch this machine
OFF before you switch it ON in case you get into
difficulty.
Make sure that anyone in the immediate work area
is warned of what you are doing.
Always disconnect the machine from its power
supply before making adjustments to it.
Always transport, store and operate the machine in
an upright position.
Keep the unit’s air vents clear of all obstructions.
NEVER use this equipment for removing hazardous
or corrosive fluids. Never attempt to pick-up
flammable liquids.
This unit is for WET pickup only, NEVER use this
vacuum for dry pick-up.
GENERAL SAFETY Check the condition of the equipment before use.
If it shows signs of damage or excessive wear, return it to
your local HSS Hire Shop.
The HSS Wet Vacuum with Auto Pump requires a
suitable 110V 16amp generated supply, or may be
powered from the mains via a suitable 110V transformer.
If the equipment fails, or if its power supply cable
or plug becomes damaged, return it. Never try to
repair it yourself.
Keep cables out of harm’s way, and clear of the
work area.
Extension leads should be fully unwound and
loosely coiled, away from the equipment. Never run
them through water, over sharp edges or where they
could trip someone.
Keep the equipment dry, using electrical equipment
in very damp or wet conditions can be dangerous.
HSS Wet Vacuum Cleaners are designed to be used in a
wet environment, and are perfectly safe to do so,
provided that all electrical components, switches and
leads are kept dry.
To reduce the risk of electric shock, always
use a suitable RCD (Residual Current-Operated
Device) available from your local HSS Hire Shop.
Ensure the machine and power socket are switched
OFF before plugging into the power supply.
It is essential to familiarise yourself with all the
controls before starting.
Unclip and remove the motor unit complete with filter.
Connect the hose to the base by screwing on to the
inlet (clockwise), then fit the 3 wand sections
together followed by the vacuum head.
Connect the discharge hose
to the pumps outlet port.
The hose is fitted with a
screw connector, ensure the
‘0’ring is present, as this
provides an air-tight seal.
Run the discharge hose to
a convenient drain or other
suitable discharge point,
making sure it is free from
kinks and sharp turns that
could impede the flow of
water.
Check that the pump
power lead is connected to
the power socket on the
rear of the power head. To
connect the power lead simply push the lead plug
firmly into the power socket.
GETTING STARTED
ELECTRICAL SAFETY
To switch the vacuum ON simply move the VAC
ON/OFF switch to the ‘I’position.
To switch the auto pump ON simply move the
PUMP ON/OFF switch to the ‘I’position.
To switch either OFF move the switch to the ‘0’ position.
Familiarise yourself with the switches and their location
so that you can operate them quickly in an emergency.
All that remains is to plug the vacuum into its power
supply and switch the supply ON.
The advantage of this machine over conventional
wet pick up vacuums is that you do not have to
stop and empty the unit when full.
The auto pump will operate as soon as the water
content reaches a set level, provided you have
switched the unit ON.
Switch the vacuum and the auto pump ON.
BASIC TECHNIQUES
Pump
ON/OFF
Switch Vacuum
ON/OFF
Switch
ON
OFF
ON
OFF
Ball
Filter
Power
Unit
Power
Socket
Pump
Power
Lead Clip Inlet
Outlet
Outlet
Port
Discharge
Hose
Inlet
Hose
Wet Vacuum with Auto Pump
