NX MEDIA CONVERTER
INSTALLATION AND OPERATION INSTRUCTIONS
™
2.1 PACKAGE
Check that the following components have been included:
• 10/100 Media Converter
• 120V/60 Hz AC Adapter
• Wall mount kit
• Installation guide
If an item is missing or damaged, please contact Hubbell Control Solutions Tech Services.
2.2 SAFETY PRECAUTIONS
PRECAUTIONS
Read and understand all instructions before beginning installation.
NOTICE: For installation by a licensed electrician in accordance with National and/or local Electrical Codes and the following instructions.
Conrm device ratings are suitable for application prior to installation. Use of device in applications beyond its specied ratings or in applications other
than its intended use may cause an unsafe condition and will void manufacturer’s warranty.
Operate the product only from the type of external power source indicated on the electrical ratings label. If you are not sure of the type of power source
or adapter required, consult your local agent or manufacturer directly.
Not rated for outdoor use.
NOTICE: Do not install if product appears to be damaged.
2.3 MOUNTING THE DEVICE
DESKTOP MOUNTING
The media converter can be mounted on a desktop or shelf. Make sure that there is proper heat dissipation and adequate ventilation around the device.
Do not place heavy objects on the device.
WALL MOUNTING
The media converter can be mounted using the wall mounting bracket (included). There are two holes on each side of the media converter that allow
the wall mounting brackets to be attached.
Wall Mount Bracket
DIMENSIONAL DRAWING SHOWING MEDIA CONVERTER ATTACHED WITH 2 WALL MOUNT BRACKETS
.55
.33
2.71
.30
1.71
.50
1.00
4.14
1.00
.50
ø.156
2.31
ø.156
2.02
1.24
.37
3.25
1.41
.41
.21 .28
.41
.41
1.29
1.35
.50
.28
.39
.32
.85

3481B 063020
701 Millennium Blvd. | Greenville, SC 29607 | [phone] | www.hubbellcontrolsolutions.com
Copyright © 2020 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
REV A 72-00664
NX MEDIA CONVERTER
INSTALLATION AND OPERATION INSTRUCTIONS
™
2.4 INSTALLATION STEPS
1. Attach the RJ45 Port of the NX Media Converter to the NX Bridge (NXHNB2) or NX PoE Switch via Cat5 or Copper Ethernet Cable.
2. Attach the ber port of the NX Media Converter to a 100Base-X Fast Ethernet Device (in this case, it would be a NX Media Converter) via an
appropriate ber cable.
3. Use dual-ber multimode cable with ST connectors (OM1 62.5/125, OM2/OM3/OM4 50/125) . See picture below for reference.
4. The NX Media Converter transmitter (Tx) must attach to the receiver side of its link partner; the receiver (Rx) must attach to the transmitter.
Note: In this application, you would need to connect two ber cables, so that the data can ow in both directions. See Figure 2 for reference.
5. Connect the provided AC Adapter to the Media Converter, shown below.
a. Connect power adapter DC plug to the DC input jack located on the back of the converter before connecting to the AC outlet.
b. To ensure against accidental disconnection, tie the DC cable with the cable tie if needed.
c. Connect the power adapter to the AC outlet.
d. Check Power LED indication. Green indicates DC power is applied and the converter is “ON”.
6. The NX Media Converter has 4 DIP switches on the side of the module. The DIP switches allow the RJ45 port to be congured for auto-negotiation or
manual operation.
Note: The factory default should have ALL DIP switches in the down position. Leave DIP switch settings to factory default. Do not change.
*If switches are not in default position upon unpacking, set them back to default.
FIGURE 2: TYPICAL APPLICATION FOR NX MEDIA CONVERTER
Connection for the
ber cable (Tx or Rx)
RJ45 Connection for the
copper ethernet cable
FIGURE 1: KEY CONNECTION POINTS
Direction of the
data ow (Tx or Rx)
DUAL-FIBER MULTIMODE CABLE

3481B 063020
701 Millennium Blvd. | Greenville, SC 29607 | [phone] | www.hubbellcontrolsolutions.com
Copyright © 2020 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.
REV A 72-00664
NX MEDIA CONVERTER
INSTALLATION AND OPERATION INSTRUCTIONS
™
POWERED BY EXTERNAL POWER ADAPTER
The NX media converter should only be used with the supplied AC power supply included in the package. Using any power supply other than what is
provided will void the Limited 5-Year Warranty for the product. Before inserting the Power Adapter, verify that the outlet being used is rated for 120V only.
EXTERNAL POWER ADAPTER SPECIFICATIONS
• Rated Input: 120VAC/ 60Hz @ 0.03A
• Rated Output: 9VDC @ 0.28A
1 4
UP
DOWN
Link Mode 2
Link Mode 1
RJ45 Mode 2
RJ45 Mode 1
FIGURE 3: DEFAULT CONFIGURATION MODE FOR DIP-SWITHCES
FIGURE 4: AC POWER ADAPTER
