Hunt HWS-01HD SERIES User manual

1/27
User Manual v.1.6
HWS-01HD series
Content

2/27
I. PREFACE....................................................................................................................................... 3
II. PRODUCT SPECIFICATIONS....................................................................................................... 3
III. PRODUCT INSTALLATION....................................................................................................... 6
A. HARDWARE INSTALLATION ............................................................................................................. 6
B. IPASSIGNMENT............................................................................................................................ 6
C. MONITOR SETTING........................................................................................................................ 8
D. INSTALLACTIVEXCONTROL:.......................................................................................................... 9
IV. LIVE VIDEO ..............................................................................................................................11
V. HWS-01HD CONFIGURATION.................................................................................................... 13
A. SYSTEM ..................................................................................................................................... 13
B. NETWORK .................................................................................................................................. 15
C. MULTIMEDIA ............................................................................................................................... 19
D. EVENT ....................................................................................................................................... 21
VI. NETWORK CONFIGURATION................................................................................................ 25
VII. FACTORY DEFAULT............................................................................................................... 26
VIII. PACKAGE CONTENTS........................................................................................................... 27

3/27
I. Preface
HWS-01HD is a 1 channel video server. It builds in web server. User views
real-time video via IE browser. HWS-01HD supports MPEG-4 and M-JPEG video
compression which provides smooth and high quality video. The video can be
stored in the SD card, and can be playback remotely.
HWS-01HD is an easy-to-use video server which can connect any kind of
analogue camera to fit the customer’s need.
II.Product Specifications
zMPEG4/ M-JPEG compression
zSupports SD card for local recording
zWireless network connection﹝Optional﹞
z2-way audio
zSupport PTZ control
zOnline firmware upgrade
zReal-time video recording
zCompatible with Microsoft Windows Media Player

4/27
Product Specifications
Hardware
CPU ARM 9 ,32 bit RISC
RAM 64MB
ROM 8MB
Video in/ out 1 in/ 1 out, BNC connector
Audio in/ out 1 in/ 1 out
I/O 2 in/ 4 out
RS-485 1, for PTZ control
Power Consumption DC 12V, 1A, 4W
Dimensions 134mm (W) x 42mm (L) x 107mm (D)
Network
Ethernet 10/ 100 Base-T
Wireless (Optional) 802.11b/g
WEP 64/ 128 bit
Network Protocol HTTP, TCP/ IP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP
System
Video Resolution NTSC: 720x480, 352x240, 176x120
PAL: 720x576, 352x288, 176x144
Image snapshot Yes
Full screen monitoring Yes
Compression format MPEG-4/ M-JPEG
Video bitrate adjust CBR, VBR
Motion Detection Yes, 3 different areas
Triggered action Mail, FTP, Save to SD card
Pre/ Post alarm Yes, configurable
Remote PTZ control Yes
Security Password protection
Firmware upgrade HTTP mode, can be upgraded remotely
Simultaneous connection Up to 10
Audio Yes, 2-way
SD card management
Recording trigger Motion Detection, IP check, Network down (Wire
connection only)
Video format AVI, JPEG
Video playback Yes
File Management Yes, can be deleted or overwrite

5/27
Web browsing requirement
OS Windows 2000, XP, 2003, IE 6 or above
Hardware Suggested Intel-C 2.0G, RAM: 512MB, Graphic card: 64MB
Minimum Intel-C 1.6G, RAM: 256MB, Graphic card: 32MB

6/27
III. Product Installation
A. Hardware Installation
i. Connect power adaptor
ii. Connect Ethernet cable
iii. Set up the network configurations according to the network environment.
For further explanation, please refer to chapter VI, “Network
Configuration for HWS-01HD”.
B. IP Assignment
i. Use the software, “IP Installer” to assign the IP address of HWS-01HD.

7/27
The software is in the attached software CD.
ii. There are two languages for the IP installer
a. IPInstallerCht.exe: Chinese version
b. IPInstallerEng.exe: English version
iii. There are 3 kinds of IP configuration.
a. Fixed IP (Public IP or Virtual IP)
b. DHCP (Dynamic IP)
c. Dial-up (PPPoE)
iv. Execute IP Installer
v. For Windows XP SP2 user, it may popup the following message box.
Please click “Unblock”.
vi. The GUI of the IP Installer:

8/27
vii. IP Installer searches all the IP cameras which connect to the intranet
and lists on the left side of the IP Installer. Just click the “Search Device”
to re-search again.
viii. Click one of the IP camera listed on the left side. The network
configuration of this IP camera will show on the right side. Change the
parameter and click “Submit”. The following dialogue box will show. Just
click “OK”. It will the change the IP and reboot the camera.
ix. Click “Search Device” to research the IP camera. Double click the IP
camera listed on the left side. It will open an IE browser and connect to
this IP camera directly.
C. Monitor Setting
i. Right-Click on the desktop. Select “ Properties”
ii. Change color quality to highest (32bit).

9/27
D. Install ActiveX control:
For the first time to view the camera video via IE, it will ask you to install the
ActiveX component.
If the installation failed, please check the security setting for the IE browser.
i. IE ÆTools ÆInternet Options… ÆSecurity Tab ÆCustom Level… Æ
Security Settings ÆDownload unsigned ActiveX controlsÆSelect
“Enable” or Prompt.
ii. IE ÆTools ÆInternet Options… ÆSecurity Tab ÆCustom Level…
ÆInitialize and script ActiveX controls not marked as safe ÆSelect
“Enable” or Prompt.

10/27
1 2
3 4
5
When popup the following dialogue box, click “Yes”.
