Husqvarna 7021 RS User manual

2008-01
O0802022
7021 RS
Operator's
Manual
Operator's Manual
Walk Mower
96143003001

2
WARNING: Battery posts, terminals and
related accessories contain lead and lead
compounds, chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm. Wash
hands after handling.
WARNING: Engine exhaust, some of its
constituents, and certain vehicle compo-
nents contain or emit chemicals known to
the State of California to cause cancer and
birth defects or other reproductive harm.
CAUTION: Always disconnect spark plug
wireandplacewirewhereitcannotcontact
spark plug in order to prevent accidental
starting when setting up, transporting,
adjusting or making repairs.
Look for this symbol to point out im-
portant safety precautions. It means
CAUTION!!! BECOME ALERT!!! YOUR
SAFETY IS INVOLVED.
CAUTION: Muffler and other engine parts
become extremely hot during operation
and remain hot after engine has stopped.
Toavoidsevereburnsoncontact,stayaway
from these areas.
Safe Operation Practices for Walk-Behind Mowers
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE
TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
SAFETY RULES
I. GENERAL OPERATION
• Read, understand, and follow all instructions on the
machine and in the manual(s) before starting. Be thor-
oughly familiar with the controls and the proper use of
the machine before starting.
• Do not put hands or feet near or under rotating parts.
Keep clear of the discharge opening at all times.
• Only allow responsible individuals, who are familiar
with the instructions, to operate the machine.
• Clear the area of objects such as rocks, toys, wire,
bones,sticks,etc., whichcouldbepickedupandthrown
by the blade.
• Be sure the area is clear of other people before mow-
ing. Stop machine if anyone enters the area.
• Do not operate the mower when barefoot or wearing
open sandals. Always wear substantial foot wear.
• Do not pull mower backwards unless absolutely nec-
essary. Alwayslookdownandbehindbeforeandwhile
moving backwards.
• Never direct discharged material toward anyone.
Avoid discharging material against a wall or obstruc-
tion. Materialmayrichochetbacktowardtheoperator.
Stop the blade when crossing gravel surfaces.
• Do not operate the mower without proper guards,
plates,grasscatcherorothersafetyprotectivedevices
in place.
• See manufacturer’s instructions for proper operation
and installation of accessories. Only use accessories
approved by the manufacturer.
• Stop the blade(s) when crossing gravel drives, walks,
or roads.
• Stoptheengine(motor)wheneveryouleavetheequip-
ment, before cleaning the mower or unclogging the
chute.
• Shuttheengine(motor)offandwaituntilthebladecomes
to complete stop before removing grass catcher.
• Mow only in daylight or good artificial light.
• Do not operate the machine while under the influence
of alcohol or drugs.
• Neveroperatemachineinwetgrass. Alwaysbesureof
your footing: keep a firm hold on the handle and walk;
never run.
• Disengagetheself-propelledmechanismordriveclutch
onmowerssoequippedbeforestartingtheengine(motor).
• If the equipment should start to vibrate abnormally,
stop the engine (motor) and check immediately for the
cause. Vibration is generally a warning of trouble.
• Alwayswearsafetygogglesorsafetyglasseswithside
shields when operating mower.
II. SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents
which can result in severe injury. All slopes require extra
caution. If you feel uneasy on a slope, do not mow it.
DO:
• Mowacrossthefaceofslopes:neverupanddown. Exer-
ciseextremecautionwhenchangingdirectiononslopes.
• Remove obstacles such as rocks, tree limbs, etc.
• Watch for holes, ruts, or bumps. Tall grass can hide
obstacles.
DO NOT:
• Do not trim near drop-offs, ditches or embankments.
The operator could lose footing or balance.
• Do not trim excessively steep slopes.
• Donotmowonwetgrass.Reducedfootingcouldcause
slipping.
III. CHILDREN
Tragic accidents can occur if the operator is not alert to
the presence of children. Children are often attracted to
the machine and the mowing activity. Never assume that
children will remain where you last saw them.
• Keep children out of the trimming area and under the
watchful care of another responsible adult.
• Be alert and turn machine off if children enter the
area.
• Before and while walking backwards, look behind and
down for small children.
• Never allow children to operate the machine.
• Useextracarewhenapproachingblindcorners,shrubs,
trees, or other objects that may obscure vision.
IV. SAFE HANDLING OF GASOLINE
Use extreme care in handling gasoline. Gasoline is ex-
tremely flammable and the vapors are explosive.
• Extinguishallcigarettes,cigars,pipesandothersources
of ignition.
• Use only an approved container.
• Neverremove gas cap oradd fuel with theengine run-
ning. Allow engine to cool before refueling.

3
SAFETY RULES.........................................................2-3
PRODUCT SPECIFICATIONS.......................................3
CUSTOMER RESPONSIBILITIES.................................3
ASSEMBLY.................................................................4-5
OPERATION .............................................................6-10
MAINTENANCE SCHEDULE......................................11
MAINTENANCE......................................................11-13
SERVICE AND ADJUSTMENTS............................14-15
STORAGE...............................................................15-16
TROUBLESHOOTING................................................. 17
REPAIR PARTS......................................................18-21
WARRANTY.................................................................22
CONGRATULATIONS on your purchase of a new lawn
mower. Ithasbeendesigned,engineeredandmanufactured
togiveyouthebestpossibledependabilityandperformance.
Should you experience any problem you cannot easily
remedy, please contact your nearest authorized service
center/department. We have competent, well-trained
technicians and the proper tools to service or repair this
lawn mower.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your lawn mower
properly. Always observe the “SAFETY RULES”.
SERIAL
NUMBER: _________________________________
DATE OF PURCHASE: _______________________
THEMODELANDSERIALNUMBERSWILLBEFOUND
ON ADECALATTACHEDTOTHEREAROFTHELAWN
MOWER HOUSING.
YOUSHOULDRECORDBOTHSERIALNUMBERAND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE
FOR FUTURE REFERENCE.
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Follow a regular schedule in maintaining, caring for
and using your lawn mower.
• Followtheinstructionsunder“Maintenance”and“Stor-
age” sections of this owner’s manual.
TABLE OF CONTENTS
• Never refuel the machine indoors.
• Never store the machine or fuel container where there
is an open flame, spark or pilot light such as a water
heater or on other appliances.
• Neverfillcontainersinsideavehicle,onatruckortrailer
bed with a plastic liner. Always place containers on
the ground away from your vehicle before filling.
• Removegas-poweredequipmentfromthetruckortrailer
and refuel it on the ground. If this is not possible, then
refuelsuchequipmentwithaportablecontainer,rather
than from a gasoline dispenser nozzle.
• Keep the nozzle in contact with the rim of the fuel tank
orcontaineropeningatalltimesuntilfuelingiscomplete.
Do not use a nozzle lock-open device.
• If fuel is spilled on clothing, change clothing immedi-
ately.
• Never overfill fuel tank. Replace gas cap and tighten
securely.
V. GENERAL SERVICE
• Never run a machine inside a closed area.
• Never make adjustments or repairs with the engine
(motor)running. Disconnectsparkplugwire, andkeep
wire away from plug to prevent accidental starting.
• Keep nuts and bolts, especially blade attachement
bolts, tight and keep equipment in good condition.
• Never tamper with safety devices. Check their proper
operation regularly.
• Keep machine free of grass, leaves, or other debris
build-up. Clean oil or fuel spillage. Allow machine to
cool before storing.
• Stopand inspect the equipment ifyou strike an object.
Repair, if necessary, before restarting.
• Neverattempttomakewheelheightadjustmentswhile
the engine (motor) is running.
• Grass catcher components are subject to wear, dam-
age, and deterioration, which could expose moving
parts or allow objects to be thrown. Frequently check
components and replace with manufacturer’s recom-
mended parts, when necessary.
• Mower blade is sharp and can cut. Wrap the blade or
wear gloves, and use extra caution when servicing it.
• Donotchangetheenginegovernorsettingoroverspeed
the engine.
• Maintain or replace safety and instruction labels, as
necessary.
WARNING: This lawn mower is equipped with an internal combustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with
a spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in
effective working order by the operator.
A spark arrester for the muffler is available through your nearest authorized service center.
PRODUCT SPECIFICATIONS
Gasoline Capacity 1.6 Quarts
and Type: (Unleaded Regular Only)
Oil Type (API SG–SL): SAE 30 (above 32°F);
SAE 5W-30 (below 32°F)
Oil Capacity: 20 Ounces
Spark Plug (Gap: .030"): Champion RC12YC
Blade Bolt Torque: 35-40 ft. lbs. (47-54 N-m)

4
ASSEMBLY
FIG. 2
HANDLE
BRACKET
HANDLE PIN
SQUEEZE
TO ASSEMBLE GRASS CATCHER
(See Fig. 3)
1. Put grass catcher frame into grass bag with rigid part
of bag on the bottom. Make sure the frame handle is
outside of the bag top.
2. Slip vinyl bindings over frame.
NOTE: If vinyl bindings are too stiff, hold them in warm
water for a few minutes. If bag gets wet, let it dry before
using.
FIG. 1
OPERATOR
PRESENCE
CONTROL
BAR
HANDLE
KNOB
LIFT
UP
LIFT
UP
LOWER
HANDLE
MOWING
POSITION
UPPER
HANDLE
FIG. 3
FRAME
HANDLE
VINYL
BINDINGS FRAME
OPENING
Read these instructions and this manual in its entirety before you attempt to assemble or operate your new lawn mower.
IMPORTANT: THIS LAWN MOWER IS SHIPPED WITHOUT OIL OR GASOLINE IN THE ENGINE.
Your new lawn mower has been assembled at the factory with the exception of those parts left unassembled for shipping
purposes. All parts such as nuts, washers, bolts, etc., necessary to complete the assembly have been placed in the parts
bag. To ensure safe and proper operation of your lawn mower, all parts and hardware you assemble must be tightened
securely. Use the correct tools as necessary to ensure proper tightness.
TO INSTALL ATTACHMENTS
Your lawn mower was shipped ready to be used as a
mulcher. To convert mower to bagging or discharging,
see “TO CONVERT MOWER” in the Operation section of
this manual.
TO REMOVE MOWER FROM CARTON
1. Remove loose parts included with mower.
2. Cutdowntwoendcorners of carton and lay end panel
down flat.
3. Removeallpackingmaterialsexceptpaddingbetween
upper and lower handle and padding holding operator
presence control bar to upper handle.
4. Roll lawn mower out of carton and check carton thor-
ougly for additional loose parts.
HOW TO SET UP YOUR MOWER
TO UNFOLD HANDLE (See Figs. 1 and 2)
IMPORTANT: UNFOLD HANDLE CAREFULLY SO AS
NOT TO PINCH OR DAMAGE CONTROL CABLES.
1. Raise lower handle section to operating position and
squeeze the bottom ends of lower handle towards
each other until the pin in handle can be inserted into
one of the three height adjustment holes.
2. Remove protective padding, raise upper handle sec-
tionintoplaceonlowerhandleandtightenbothhandle
knobs.
3. Removeanypackingmaterialfromaroundcontrolbar.
Your handles may be adjusted for your mowing comfort.
Referto“ADJUSTHANDLE”intheServiceandAdjustments
section of this manual.

5
KNOW YOUR LAWN MOWER
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR LAWN MOWER.
Comparetheillustrations with your lawn mowerto familiarize yourself with thelocationof various controls andadjustments.
Save this manual for future reference.
MEETS CPSC SAFETY REQUIREMENTS
Our rotary walk-behind power lawn mowers conform to the safety standards of the American National Standards Institute
and the U.S. Consumer Product Safety Commission. The blade turns when the engine is running.
OPERATOR PRESENCE CONTROL BAR – must be
held down to the handle to start the engine. Release to
stop the engine.
DRIVE CONTROL LEVER – used to engage power-pro-
pelled forward motion of lawn mower.
HOUSING
GRASS
CATCHER
STARTER HANDLE – used for starting the engine.
MULCHER DOOR – allows conversion to discharge or
bagging operation.
MULCHERPLUG–locatedatthedischargeopening,must
be removed when converting to bagging operation.
OPERATOR PRESENCE CONTROL BAR
MULCHER
PLUG
STARTER
HANDLE
ENGINE OIL CAP WITH DIPSTICK
HANDLE KNOB
GASOLINE FILLER CAP
These symbols may appear on your lawn mower or in literature supplied with the product. Learn and understand
their meaning.
MULCHER DOOR
OPERATION
IMPORTANT: This lawn mower is shipped
WITHOUT OIL OR GASOLINE in the engine.
DRIVE
CONTROL
LEVER
MUFFLER
SINGLE POINT HEIGHT ADJUSTER HANDLE
AIR FILTER
SPARK PLUG
DRIVE COVER

6
DRIVE CONTROL ADJUSTMENT (See Fig. 5)
Over time, the drive control system may become “loose”,
resultingindecreasedspeed. There is a turnbuckle onthe
underside of the drive control housing to increase tension
on the drive cable. Proceed as follows:
1. Turn unit off and disconnect spark plug wire from plug.
2. Turnnutonundersideofdrivecontroltoincreasedrive
speed.
3. Operate mower to test drive speed. Readjust as re-
quired.
4. If condition fails to improve after the above steps (for-
wardspeed remains the same), your drive beltis worn
and should be replaced.
HOW TO USE YOUR LAWN MOWER
ENGINE SPEED
The engine speed was set at the factory for optimum per-
formance. Speed is not adjustable.
ENGINE ZONE CONTROL
CAUTION: Federal regulations require
anenginecontroltobeinstalledonthis
lawnmowerinordertominimizetherisk
of blade contact injury. Do not under
any circumstances attempt to defeat
the function of the operator control.
The blade turns when the engine is
running.
• Yourlawnmowerisequippedwithanoperatorpresence
controlbarwhichrequirestheoperatortobepositioned
behindthe lawnmowerhandleto startandoperatethe
lawn mower.
DRIVE CONTROL (See Fig. 4)
• Self-propelling is controlled by holding the operator
presence control bar down to the handle and pulling
the drive control lever rearward to the handle. The
farther toward the handle the lever is pulled, the faster
the unit will travel.
• Forwardmotionwillstopwheneithertheoperatorpres-
ence control bar or drive control lever are released. To
stop forward motion without stopping engine, release
the drive control lever only. Hold operator presence
control bar down against handle to continue mowing
without self-propelling.
NOTE: If after releasing the drive control the mower will
not roll backwards, push the mower forward slightly to
disengage drive wheels.
The operation of any lawn mower can result in foreign objects thrown into the eyes, which can result in
severe eye damage. Always wear safety glasses or eye shields while operating your lawn mower or per-
forming any adjustments or repairs. We recommend standard safety glasses or a wide vision safety mask
over spectacles.
OPERATION
WHEEL
ADJUSTER
LEVER
FIG. 6
LEVER BACKWARD
TO LOWER MOWER
LEVER FORWARD
TO RAISE MOWER
TO ADJUST CUTTING HEIGHT (See Fig. 6)
All four wheels are adjusted by a single lever.
• Pulladjusterlevertowardwheel.Toraisemower,move
leverforwardtodesiredposition.Tolowermower,move
the lever toward the rear.
FIG. 5
ADJUSTMENT
TURNBUCKLE
TO ENGAGE
DRIVE CONTROL
DRIVE
CONTROL
LEVER
DRIVE CONTROL
DISENGAGED
OPERATOR PRESENCE CONTROL BAR
FIG. 4

7
SIDE DISCHARGING (See Fig. 10)
• Mulcher plug must be installed into rear discharge
opening of mower.
• Open mulcher door and install discharge deflector
under door as shown.
• Mower is now ready for discharging operation.
• Toconverttomulchingorbaggingoperation,discharge
deflector must be removed and mulcher door closed.
SIMPLE STEPS TO REMEMBER
WHEN CONVERTING YOUR LAWN MOWER
FOR MULCHING -
1. Rear mulcher plug installed.
2. Mulcher door closed.
FOR REAR BAGGING -
1. Rear mulcher plug removed.
2. Grass catcher installed.
3. Mulcher door closed.
FOR SIDE DISCHARGING -
1. Rear mulcher plug installed.
2. Discharge deflector installed.
CAUTION: Donotrunyourlawnmower
withoutmulcherplugorapprovedgrass
catcher in place. Never attempt to op-
eratethelawnmowerwiththereardoor
removed or propped open.
OPERATION
TO EMPTY GRASS CATCHER (See Fig. 8)
1. Lift up on grass catcher using the frame handle.
2. Remove grass catcher with clippings from under lawn
mower handle.
3. Empty clippings from bag.
NOTE: Do not drag the bag when emptying; it will cause
unnecessary wear.
TO CONVERT MOWER
Your lawn mower was shipped ready to be used as a
mulcher. To convert to bagging or discharging:
REAR BAGGING (See Fig. 9)
• Open rear door and remove mulcher plug. Store
mulcher plug in a safe place.
• You can now install the grass catcher.
• Toconverttomulchingordischargingoperation,install
mulcher plug into rear discharge opening of mower.
FIG. 9
MULCHER PLUG
TO ATTACH GRASS CATCHER (See Fig. 7)
1. Liftthereardoorofthelawnmowerandplacethegrass
catcher frame side hooks onto the door pivot pins.
2. Thegrasscatcherissecuredtothelawnmowerhousing
when the rear door is lowered onto the grass catcher
frame.
CAUTION: Donotrunyourlawnmower
withoutmulcherplugorapprovedgrass
catcher in place. Never attempt to op-
eratethelawnmowerwiththereardoor
removed or propped open.
FIG. 7
PIVOT PINS REAR DOOR
GRASS
CATCHER
HANDLE
CATCHER FRAME HOOK
FIG. 8
FRAME
HANDLE

8
OPERATION
BEFORE STARTING ENGINE
ADD OIL (See Fig. 11)
Your lawnmower is shipped without oil in the engine. For
type and grade of oil to use, see “ENGINE” in the Mainte-
nance section of this manual.
CAUTION: DO NOT overfill engine with
oil, or it will smoke on startup.
1. Be sure lawnmower is level.
2. Remove oil dipstick from oil fill spout.
3. Engine holds 20 ounces of oil. For type and grade of
oil to use, see “ENGINE” in the Maintenance section
of this manual.
4. Pouroilslowly. Donotoverfill. Waitoneminutetoallow
oil to settle. Insert and tighten dipstick, then remove it
to check oil level.
IMPORTANT:
• Checkoillevel before each use. Add oilifneeded. Fill
to full line on dipstick.
• Changetheoilafterevery25hoursofoperationoreach
season. Youmayneedtochangetheoilmoreoftenun-
derdusty,dirtyconditions. See“TOCHANGEENGINE
OIL” in the Maintenance section of this manual.
FIG. 10
OPEN
MULCHER
DOOR
DISCHARGE
DEFLECTOR
ENGINE
OIL CAP
GASOLINE
FILLER
CAP
FIG. 11

9
ADD GASOLINE (See Fig. 11)
• Fill fuel tank to bottom of tank filler neck. Do not over-
fill. Use fresh, clean, regular unleaded gasoline with
a minimum of 87 octane. Do not mix oil with gasoline.
Purchase fuel in quantities that can be used within 30
days to assure fuel freshness.
CAUTION: Wipe off any spilled oil or
fuel. Donotstore, spill or use gasoline
near an open flame.
Alcoholblended fuels(called gasoholor using
ethanolormethanol)canattractmoisturewhich
leadstoseparationand formationofacidsdur-
ing storage. Acidic gas can damage the fuel
system of an engine while in storage. To avoid
engine problems, the fuel system should be
emptied before storage of 30 days or longer.
Empty the gas tank, start the engine and let
it run until the fuel lines and carburetor are
empty. Usefreshfuelnextseason. SeeStorage
Instructions for additional information. Never
use engine or carburetor cleaner products in
the fuel tank or permanent damage may occur.
TO STOP ENGINE
• To stop engine, release operator presence control
bar.
TO START ENGINE
NOTE: Due to protective coatings on the engine, a small
amount of smoke may be present during the initial use of
the product and should be considered normal.
NOTE: Your engine is equipped with an automatic choke
system. No priming or choking is required before start-
ing.
• To start engine, hold operator presence control bar
down to the handle and pull starter handle quickly. Do
not allow starter rope to snap back.
MOWING TIPS
CAUTION:Donotusede-thatcherblade
attachments on your mower. Such at-
tachments are hazardous, will damage
yourmowerandcouldvoidyourwarranty.
• Under certain conditions, such as very tall grass, it
may be necessary to raise the height of cut to reduce
pushingeffortandtokeepfromoverloadingtheengine
and leaving clumps of grass clippings. It may also be
necessarytoreducegroundspeed and/orrunthelawn
mower over the area a second time.
• For extremely heavy cutting, reduce the width of cut
by overlapping previously cut path and mow slowly.
• For better grass bagging and most cutting conditions,
the engine speed should be set in the fast position.
• Pores in cloth grass catchers can become filled with
dirt and dust with use and catchers will collect less
grass. To prevent this, regularly hose catcher off with
water and let dry before using.
• Keep top of engine around starter clear and clean of
grassclippings andchaff. Thiswillhelpengineairflow
and extend engine life.
MULCHING MOWING TIPS
IMPORTANT: FOR BEST PERFORMANCE, KEEP MOWER
HOUSING FREE OF BUILT-UP GRASS AND TRASH. SEE
“CLEANING”INTHEMAINTENANCESECTIONOFTHISMANUAL.
• The special mulching blade will recut the grass clip-
pings many times and reduce them in size so that as
they fall onto the lawn they will disperse into the grass
andnotbenoticed. Also,themulchedgrasswillbiode-
gradequicklytoprovidenutrientsfor the lawn. Always
mulch with your highest engine (blade) speed as this
will provide the best recutting action of the blades.
• Avoidcuttingyourlawnwhenitiswet. Wetgrasstends
toformclumpsandinterfereswiththemulchingaction.
The best time to mow your lawn is the early afternoon.
At this time the grass has dried, yet the newly cut area
will not be exposed to direct sunlight.
• For best results, adjust the lawn mower cutting height
so that the lawn mower cuts off only the top one-third
of the grass blades (See Fig. 12). If the lawn is over-
grown it will be necessary to raise the height of cut to
reduce pushing effort and to keep from overloading
the engine and leaving clumps of mulched grass. For
extremelyheavymulching, reduce yourwidthofcutby
overlapping previously cut path and mow slowly.
OPERATION
• Certaintypesofgrassandgrassconditionsmayrequire
that an area be mulched a second time to completely
hide the clippings. When doing a second cut, mow
across (perpendicular) to the first cut path.
• Change your cutting pattern from week to week. Mow
northtosouthoneweektheneasttowestthenextweek.
Thiswillhelp prevent matting and grainingofthe lawn.
FIG. 12
MAX 1/3

10
➁ENGINE OIL
➀HANDLE BRACKET MOUNTING PINS
➀REAR DOOR HINGE
➀MULCHER
DOOR
HINGE PIN
LUBRICATION CHARTGENERAL RECOMMENDATIONS
Thewarrantyonthislawnmowerdoesnotcoveritemsthat
have been subjected to operator abuse or negligence. To
receivefullvaluefromthewarranty,operatormustmaintain
mower as instructed in this manual. Some adjustments
will need to be made periodically to properly maintain your
unit. At least once a season, check to see if you should
make any of the adjustments described in the Service and
Adjustments section of this manual.
• At least once a year, replace the spark plug, clean or
replace air filter element and check blade for wear. A
newsparkplugandclean/newairfilterelementassure
proper air-fuel mixture and help your engine run better
and last longer.
• Follow the maintenance schedule in this manual.
BEFORE EACH USE
1. Check engine oil level.
2. Check for loose fasteners.
LUBRICATION
Keep unit well lubricated (See “LUBRICATION CHART”).
IMPORTANT: DO NOT OIL OR GREASE PLASTIC WHEEL
BEARINGS. VISCOUS LUBRICANTS WILL ATTRACT DUST
AND DIRT THAT WILL SHORTEN THE LIFE OF THE SELF-
LUBRICATING BEARINGS. IF YOU FEEL THEY MUST BE
LUBRICATED, USE ONLY A DRY, POWDERED GRAPHITE
TYPE LUBRICANT SPARINGLY. ➀SPRAY LUBRICANT
➁SEE “ENGINE” IN MAINTENANCE SECTION
Check for Loose Fasteners
Clean / Inspect Grass Catcher *
Check Tires
Check Drive Wheels ***
Clean Lawn Mower ****
Clean under Drive Cover ***
Check Drive Belt / Pulleys ***
Check / Sharpen / Replace Blade
Lubrication
Clean and Recharge Battery **
Check Engine Oil level
Change Engine Oil
Clean Air Filter
Inspect Muffler
Replace Spark Plug
Replace Air Filter Paper Cartridge
Empty fuel system or add Stabilizer
BEFORE
EACH
USE
AFTER
EACH
USE
EVERY
10
HOURS
EVERY
25 HOURS
OR SEASON
EVERY
100
HOURS
BEFORE
STORAGE
1- Change more often if operating under a heavy load or in high outdoor temperatures.
2- Service more often if operating in dirty or dusty conditions.
3- Replace blades more often when mowing in sandy soil.
4- Charge 48 hours at end of season.
5- And after each 5 hours of use.
(if so equipped)
Electric-Start mowers
Power-Propelled mowers
Use a scraper
to clean under deck
*
**
***
****
MAINTENANCE

11
LAWN MOWER
Always observe safety rules when performing any main-
tenance.
TIRES
• Keep tires free of gasoline, oil, or insect control chem-
icals which can harm rubber.
• Avoid stumps, stones, deep ruts, sharp objects and
other hazards that may cause tire damage.
DRIVE WHEELS
Checkreardrivewheelseachtimeyoumowtobesurethey
move freely. The wheels not turning freely means trash,
grasscuttings,etc.,maybeinsidethedrivewheelanddust
cover area and must be cleaned out to free drive wheels.
Ifnecessarytocleandrivewheels,checkbothrearwheels.
BLADE CARE
Forbestresults,mowerblademustbekeptsharp. Replace
bent or damaged blades.
CAUTION: Useonlyareplacementblade
approved by the manufacturer of your
mower. Using a blade not approved
by the manufacturer of your mower is
hazardous, could damage your mower
and void your warranty.
TO REMOVE BLADE (See Fig. 13)
1. Disconnect spark plug wire from spark plug and place
wire where it cannot come in contact with plug.
2. Turn lawn mower on its side. Make sure air filter and
carburetor are up.
3. Use a wood block between blade and mower housing
topreventbladefromturningwhenremovingbladebolt.
NOTE: Protect your hands with gloves and/or wrap blade
with heavy cloth.
4. Remove blade bolt by turning counter-clockwise.
5. Removebladeandattachinghardware(bolt,lockwasher
and hardened washer).
NOTE: Removethebladeadapterandcheckthekeyinside
hubof blade adapter.The key must bein good conditionto
work properly. Replace adapter if damaged.
TO REPLACE BLADE (See Fig. 13)
1. Positionthebladeadapterontheenginecrankshaft.Be
surekeyinadapterandcrankshaftkeywayarealigned.
2. Position blade on the blade adapter aligning the two
(2) holes in the blade with the raised lugs on the
adapter.
3. Besurethetrailingedgeofblade(oppositesharpedge)
is up toward the engine.
4. Installthebladeboltwiththelockwasherandhardened
washer into blade adapter and crankshaft.
5. Use block of wood between blade and lawn mower
housing and tighten the blade bolt, turning clockwise.
• The recommended tightening torque is 35-40 ft. lbs.
IMPORTANT: BLADEBOLTISHEATTREATED. IFBOLTNEEDS
REPLACING,REPLACEONLYWITHAPPROVEDBOLTSHOWN
IN THE REPAIR PARTS SECTION OF THIS MANUAL.
MAINTENANCE
FIG. 13
BLADE
BOLT HARDENED
WASHER
LOCK
WASHER
BLADE ADAPTER KEY
BLADE
TRAILING EDGE
CRANKSHAFT
KEYWAY
CRANKSHAFT
TO SHARPEN BLADE
NOTE: We do not recommend sharpening blade - but if
you do, be sure the blade is balanced.
Care should be taken to keep the blade balanced. An
unbalanced blade will cause eventual damage to lawn
mower or engine.
• Thebladecanbesharpenedwithafileoronagrinding
wheel. Do not attempt to sharpen while on the mower.
• To check blade balance, drive a nail into a beam or
wall.Leaveaboutoneinchofthestraightnailexposed.
Place center hole of blade over the head of the nail.
If blade is balanced, it should remain in a horizontal
position. If either end of the blade moves downward,
sharpen the heavy end until the blade is balanced.
GRASS CATCHER
• The grass catcher may be hosed with water, but must
be dry when used.
• Check your grass catcher often for damage or dete-
rioration. Through normal use it will wear. If catcher
needs replacing, replace only with approved replace-
ment catcher shown in the Repair Parts section of this
manual. Give the lawn mower model number when
ordering.
GEAR CASE
• To keep your drive system working properly, the gear
case and area around the drive should be kept clean
andfreeof trash build-up. Cleanunderthedrivecover
twice a season.
• The gear case is filled with lubricant to the proper
level at the factory. The only time the lubricant needs
attention is if service has been performed on the gear
case.
• If lubricant is required, use only Texaco Starplex Pre-
mium 1 Grease, Part No. 750369. Do not substitute.

12
MAINTENANCE
TO CLEAN AIR FILTER
1. Loosen screws and remove cover.
2. Carefully remove cartridge.
3. Clean by gently tapping on a flat surface. If very dirty,
replace cartridge.
CAUTION: Petroleumsolvents,suchas
kerosene, are not to be used to clean
cartridge.Theymaycausedeterioration
of the cartridge. Do not oil cartridge.
Do not use pressurized air to clean or
dry cartridge.
4. Install cartridge, then replace cover.
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
SAE VISCOSITY GRADES
-20 0 30 40 80 100
-30 -20 0 20 30 40
F
C
32
-10 10
60
5W-30
SAE 30
FIG. 14
CONTAINER
ENGINE
LUBRICATION
Use only high quality detergent oil rated with API service
classification SG–SL. Select the oil's SAE viscosity grade
according to your expected operating temperature.
NOTE: Multi-viscosity oils (5W30, 10W30 etc.) improve
startingincoldweather,andyoushouldcheckyourengine
oil level frequently to avoid possible engine damage from
running low on oil.
Change the oil after every 25 hours of operation or at least
onceayearifthelawnmowerisnotusedfor25hoursinone
year. Checkthecrankcaseoillevelbeforestartingtheengine
and after each five (5) hours of continuous use. Tighten oil
plug securely each time you check the oil level.
TO CHANGE ENGINE OIL (See Fig. 14)
NOTE: Before tipping lawn mower to drain oil, empty fuel
tank by running engine until fuel tank is empty.
1. Disconnect spark plug wire from spark plug and place
wire where it cannot come in contact with plug.
2. Remove engine oil cap; lay aside on a clean surface.
3. Tip lawn mower on its side as shown and drain oil into
a suitable container. Rock lawn mower back and forth
to remove any oil trapped inside of engine.
4. Wipe off any spilled oil from mower or side of engine.
5. Slowly pour oil down the oil fill spout, stopping every
few ounces to check the oil level with the dipstick.
6. Stop adding oil when you reach the FULL mark on the
dipstick. Wait a minute to allow oil to settle.
7. Continue adding small amounts of oil, rechecking the
dipstickuntiloil level settlesatFULL. DONOToverfill,
orenginewillsmokeheavilyfromthemuffleronstartup.
8. Alwaysbesuretoretightendipstickbeforestartingengine.
9. Reconnect spark plug wire to spark plug.
AIR FILTER (See Fig. 15)
Your engine will not run properly and may be damaged by
using a dirty air filter. Replace the air filter cartridge every
100 hours of operation or every season, whichever occurs
first. Serviceaircleanermoreoftenunderdustyconditions.
MUFFLER
Inspect and replace corroded muffler as it could create a
fire hazard and/or damage.
SPARK PLUG
Replacesparkplugatthebeginningofeachmowingseason
or after every 100 hours of operation, whichever occurs
first. Spark plug type and gap setting are shown in the
“PRODUCT SPECIFICATIONS” section of this manual.
CLEANING
IMPORTANT: FOR BEST PERFORMANCE, KEEP MOWER
HOUSING FREE OF BUILT-UP GRASS AND TRASH. CLEAN
THE UNDERSIDE OF YOUR MOWER AFTER EACH USE.
CAUTION: Disconnectspark plugwire
fromsparkplugandplacewirewhereit
cannot come in contact with plug.
• Clean the underside of your lawn mower by scraping
to remove build-up of grass and trash.
• Cleanengineoftentokeeptrashfromaccumulating. A
clogged engine runs hotter and shortens engine life.
• Keepfinishedsurfaces/wheelsfreeofgasoline,oil,etc.
• We do not recommend using a garden hose to clean
lawn mower unless the electrical system, muffler, air
filter and carburetor are covered to keep water out.
Water in engine can result in shortened engine life.
CLEAN UNDER DRIVE COVER
Cleanunderdrivecoveratleasttwiceaseason.Scrapeun-
dersideofcoverwithputtyknifeorsimilartooltoremoveany
build-up of trash or grass on underside of drive cover.
FIG. 15
SCREWS
BASE
CARTRIDGE
COVER

13
LAWN MOWER
TO ADJUST CUTTING HEIGHT
See “TO ADJUST CUTTING HEIGHT” in the Operation
section of this manual.
REAR DEFLECTOR
The rear deflector, attached between the rear wheels of
your mower, is provided to minimize the possibility that
objects will be thrown out of the rear of the mower into
the operator's mowing position. If the deflector becomes
damaged, it should be replaced.
TO REMOVE DRIVE BELT (See Fig. 16)
1. Remove drive cover.
2. Remove spring and belt keeper.
3. Remove belt from gearcase pulley.
4. Turn lawn mower on its side with air filter and carbu-
retor up.
5. Remove blade, engine pulley and debris shield.
6. Remove engine pulley and belt from debris shield.
CAUTION: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS:
1. Release control bar and stop engine.
2. Make sure the blade and all moving parts have completely stopped.
3. Disconnect spark plug wire from spark plug and place where it cannot come in contact with plug.
SERVICE AND ADJUSTMENTS
TO REPLACE DRIVE BELT (See Fig. 17)
1. Place new drive belt in engine pulley and belt retainer
of debris shield.
2. Route the other end of the new drive belt through hole
in housing.
3. Reinstall debris shield.
4. Return mower to upright position.
5. Install new belt on gearcase pulley.
6. Reinstall belt keeper and spring.
7. Reinstall drive cover.
NOTE: Always use factory approved belt to assure proper
fit and long life.
8. Turn lawn mower on its side with air filter and carbu-
retor down.
9. Reinstall blade.
DEBRIS SHIELD
BELT
BELT RETAINER
FIG. 17
ENGINE PULLEY
FIG. 16
BELT
BELT
KEEPER
SPRING
DRIVE
COVER
GEAR-
CASE
PULEY
TO ADJUST HANDLE (See Fig. 18)
The handle on your lawn mower has three (3) height posi-
tions - adjust to height that suits you.
• Squeezethebottomendsoflowerhandletowardseach
other until the pin in handle can be inserted into one
of the three height adjustment holes.

14
FIG. 18
HIGH
MED.
LOW
HANDLE
BRACKET
HANDLE PIN
SQUEEZE
SERVICE AND ADJUSTMENTS
ENGINE
ENGINE SPEED
Yourenginespeedhasbeenfactoryset. Donot attempt to
increaseenginespeedoritmay resultinpersonalinjury. If
you believe that the engine is running too fast or too slow,
take your lawn mower to a Husqvarna service center for
repair and adjustment.
CARBURETOR
Your carburetor is not adjustable. If your engine does not
operate properly due to suspected carburetor problems,
take your lawn mower to a Husqvarna service center for
repair and/or adjustment.
IMPORTANT: NEVER TAMPER WITH THE ENGINE
GOVERNOR,WHICHISFACTORYSETFORPROPERENGINE
SPEED. OVERSPEEDINGTHEENGINEABOVETHEFACTORY
HIGHSPEEDSETTINGCANBEDANGEROUS. IFYOUTHINK
THEENGINE-GOVERNEDHIGHSPEEDNEEDSADJUSTING,
CONTACTYOURNEARESTHUSQVARNASERVICECENTER,
WHICH HAS PROPER EQUIPMENT AND EXPERIENCE TO
MAKE ANY NECESSARY ADJUSTMENTS.
STORAGE
Immediately prepare your mower for storage at the end of the season or if the unit will not be used for 30 days or more.
HANDLE (See Figs. 19 and 20)
You can fold your lawn mower handle for storage.
1. Loosenthetwo (2) handle knobson sides of theupper
handle and allow handle to fold down to the rear.
2. Squeezethebottomendsoflowerhandletowardeach
other until pins in handle clear the brackets and pivot
entire handle assembly forward and allow it to rest on
mower.
• Whensettingupyourhandlefromthestorageposition,
the lower handle will require manually locking into the
mowing position.
IMPORTANT: WHENFOLDINGTHEHANDLEFORSTORAGE
ORTRANSPORTATION, BESURE TOFOLD THEHANDLE AS
SHOWN OR YOU MAY DAMAGE THE CONTROL CABLES.
LAWN MOWER
Whenlawnmoweristobestoredforaperiodoftime,clean
it thoroughly, remove all dirt, grease, leaves, etc. Store in
a clean, dry area.
1. Clean entire lawn mower (See “CLEANING” in the
Maintenance section of this manual).
2. Lubricate as shown in the Maintenance section of this
manual.
3. Besurethatallnuts,bolts,screws,andpinsaresecurely
fastened. Inspect movingpartsfordamage,breakage
and wear. Replace if necessary.
4. Touch up all rusted or chipped paint surfaces; sand
lightly before painting.

15
STORAGE
HANDLE PIN
SQUEEZE
HANDLE
BRACKET
FIG. 20
ENGINE
FUEL SYSTEM
IMPORTANT: IT IS IMPORTANT TO PREVENT GUM
DEPOSITS FROM FORMING IN ESSENTIAL FUEL SYSTEM
PARTSSUCH ASCARBURETOR, FUELFILTER, FUELHOSE,
OR TANK DURING STORAGE. ALCOHOL BLENDED FUELS
(CALLED GASOHOL OR USING ETHANOL OR METHANOL)
CAN ATTRACT MOISTURE WHICH LEADS TO SEPARATION
ANDFORMATIONOFACIDSDURINGSTORAGE. ACIDICGAS
CAN DAMAGE THE FUEL SYSTEM OF AN ENGINE WHILE IN
STORAGE.
• Empty the fuel tank by starting the engine and letting
it run until the fuel lines and carburetor are empty.
• Neveruseengineorcarburetorcleanerproductsinthe
fuel tank or permanent damage may occur.
• Use fresh fuel next season.
NOTE: Fuel stabilizer is an acceptable alternative in mini-
mizing the formation of fuel gum deposits during storage.
Add stabilizer to gasoline in fuel tank or storage container.
Always follow the mix ratio found on stabilizer container.
Run engine at least 10 minutes after adding stabilizer to
allow the stabilizer to reach the carburetor. Do not empty
the gas tank and carburetor if using fuel stabilizer.
ENGINE OIL
Drainoil(withenginewarm)andreplacewithcleanengine
oil. (See “ENGINE” in the Maintenance section of this
manual).
CYLINDER
1. Remove spark plug.
2. Pour one ounce (29 ml) of oil through spark plug hole
into cylinder.
3. Pull starter handle slowly a few times to distribute oil.
4. Replace with new spark plug.
OTHER
• Do not store gasoline from one season to another.
• Replace your gasoline can if your can starts to rust.
Rust and/or dirt in your gasoline will cause problems.
• If possible, store your unit indoors and cover it to give
protection from dust and dirt.
• Cover your unit with a suitable protective cover that
does not retain moisture. Do not use plastic. Plastic
cannot breathe, which allows condensation to form
and will cause your unit to rust.
IMPORTANT: NEVER COVER MOWER WHILE ENGINE AND
EXHAUST AREAS ARE STILL WARM.
CAUTION: Neverstorethelawnmower
withgasoline in thetankinside a build-
ing where fumes may reach an open
flameorspark. Allowtheenginetocool
before storing in any enclosure.
FIG. 19
MOWING
POSITION
OPERATOR
PRESENCE
CONTROL
BAR FOLD
FORWARD
FOR
STORAGE
LOWER
HANDLE
HANDLE
KNOB
UPPER
HANDLE

16
TROUBLESHOOTING POINTS
Does not start 1. Dirty air filter. 1. Clean/replace air filter.
2. Out of fuel. 2. Fill fuel tank.
3. Stale fuel. 3. Empty fuel tank and refill tank with fresh,
clean gasoline.
4. Water in fuel. 4. Empty fuel tank and refill tank with fresh,
clean gasoline.
5. Spark plug wire is disconnected. 5. Connect wire to plug.
6. Bad spark plug. 6. Replace spark plug.
7. Loose blade or broken blade adapter. 7. Tighten blade bolt or replace blade adapter.
8. Control bar in released position. 8. Depress control bar to handle.
9. Control bar defective. 9. Replace control bar.
10. Fuel valve lever (if equipped) in OFF position. 10. Turn fuel valve lever to the ON position.
11. Weak battery (if equipped). 11. Charge battery.
12. Disconnected battery connector (if equipped). 12. Connect battery to engine.
Loss of power 1. Rear of lawn mower housing or cutting 1. Raise cutting height.
blade dragging in heavy grass.
2. Cutting too much grass. 2. Raise cutting height.
3. Dirty air filter. 3. Clean/replace air filter.
4. Buildup of grass, leaves and trash under 4. Clean underside of mower housing.
mower.
5. Too much oil in engine. 5. Check oil level.
6. Walking speed too fast. 6. Cut at slower walking speed.
Poor cut – 1. Worn, bent or loose blade. 1. Replace blade. Tighten blade bolt.
uneven 2. Wheel heights uneven. 2. Set all wheels at same height.
3. Buildup of grass, leaves and trash under 3. Clean underside of mower housing.
mower.
Excessive 1. Worn, bent or loose blade. 1. Replace blade. Tighten blade bolt.
vibration 2. Bent engine crankshaft. 2. Contact a Husqvarna service center.
Starter rope 1. Engine flywheel brake is on when control 1. Depress control bar to upper handle before
hard to pull bar is released. pulling starter rope.
2. Bent engine crankshaft. 2. Contact a Husqvarna service center.
3. Blade adapter broken. 3. Replace blade adapter.
4. Blade dragging in grass. 4. Move lawn mower to cut grass or other
hard surface before starting.
Grass catcher 1. Cutting height too low. 1. Raise cutting height.
not filling 2. Lift on blade worn off. 2. Replace blade.
(if so equipped) 3. Catcher not venting air. 3. Clean grass catcher.
Hard to push 1. Grass is too high or wheel height is too low. 1. Raise cutting height.
2. Rear of lawn mower housing or cutting 2. Raise rear of lawn mower housing one (1)
blade dragging in heavy grass. setting higher.
3. Grass catcher too full. 3. Empty grass catcher.
4. Handle height position not right for you. 4. Adjust handle height to suit.
Loss of drive 1. Belt wear. 1. Check/replace drive belt.
(or slowing of 2. Belt off of pulley. 2. Check/reinstall drive belt.
drive speed) 3. Drive cable worn or broken. 3. Put belt on pulleys / replace belts if broken.
4. “Loose” drive control system. 4. Adjust drive control.
PROBLEM CAUSE CORRECTION

17
SERVICE NOTES

18
ROTARY LAWN MOWER - - MODEL NUMBER 7021RS (96143003001) - PRODUCT NUMBER 961 43 00-30

19
ROTARY LAWN MOWER - - MODEL NUMBER 7021RS (96143003001) - PRODUCT NUMBER 961 43 00-30
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.
1 532 19 99-82 Handle, Upper (Includes Foam Grip)
2 532 19 72-02 Handle, Lower
3 532 40 54-16 Spring, Rear Door, RH
4 532 19 47-88 Guide, Rope, Side
5 532 13 20-04 Nut, Hex Lockwasher Insert 1/4-20
6 532 06 64-26 Wire, Tie
7 532 19 15-74 Bolt, Handle 5/16-18 x 1.75
8 532 18 55-88 Knob, Handle
9 532 19 70-19 Bail, Flat, Auto-Walk, Orange
10 532 18 88-21 Bolt, Carriage
11 532 75 11-53 Nut, Hex, Centerlock 5/16-18 UNC
12 532 05 17-93 Cotter, Hairpin
13 532 40 54-15 Spring, Rear Door, LH
14 532 75 06-34 Screw
15 532 12 51-62 Bracket, Upstop
16 532 40 88-88 Rear Door Assembly
17 532 18 41-93 Bolt, Rear Door
18 532 19 81-70 Plug, Mulcher
19 532 41 04-53 Kit, Lawn Mower Housing
20 532 41 82-39 Handle Bracket Assembly, LH
21 532 41 82-51 Handle Bracket Assembly, RH
22 532 15 00-78 Screw, Hex Washer Head
23 532 16 31-83 Bolt, Hex Head 5/16-18 x 5/8
24 873 80 05-00 Nut, Hex, with Lock Washer Insert 5/16-18
25 532 16 13-33 Baffle, Side
26 532 16 34-09 Screw, Hi-Lo Thread #12 x 5/8
27 532 40 84-42 Skirt, Rear
28 532 08 86-52 Screw, Hinge 1/4-20 x 1.25
29 532 16 15-86 Cable, Operator Presence
30 532 18 91-79 Blade Adapter / Pulley
31 532 18 90-28 Blade, 21"
32 532 85 10-74 Washer, Hardened
33 532 85 02-63 Lockwasher, Helical Spring 3/8
34 532 85 10-84 Screw, Hex Head 3/8-24 x 1.38
35 532 40 58-43 Debris Shield
36 532 19 23-25 Screw
37 532 15 04-06 Bolt, Engine
38 - - - Engine, Briggs & Stratton, Model Number 100602
(For engine service and replacement parts,
call Briggs & Stratton at 1-800-233-3723)
39 532 40 97-26 Grassbag
40 532 41 19-51 Frame, Grassbag
41 532 40 47-63 Danger Decal
42 532 05 45-83 Screw
45 532 19 05-10 Mulcher Door Assembly
46 532 19 05-76 Deflector, Discharge
47 532 08 83-49 Nut, Hex
48 532 19 09-39 Mounting Bracket, Debris Shield
58 532 18 20-03 Clip
59 532 18 27-48 Grip, Handle, Foam, Smooth
96 532 19 79-91 Clip, Cable
- - 532 40 47-64 Warning Decal (not shown)
- - 532 41 86-31 Owner’s Manual, English / French
KEY PART
NO. NO. DESCRIPTION KEY PART
NO. NO. DESCRIPTION

20
ROTARY LAWN MOWER - - MODEL NUMBER 7021RS (96143003001) - PRODUCT NUMBER 961 43 00-30
