Husqvarna Automover 536576003 User manual

Fence Door Installation Kit
536576003
415X
2022-05 536638301 Rev. 0
EN-ES (MX)-FR (CA)

415X
INTRODUCTION
Introduction
Serial number:
Use the serial number on the transmitter circuit board to register your product on www.husqvarna.
com.
Support
For support about the product, speak to your Husqvarna servicing dealer.
Product description and intended use
This kit includes a transmitter to be installed on certain robotic lawn mowers. It is required for use
with the Husqvarna Automower® Fence Door.
The transmitter sends a signal to unlock the door as the mower approaches.
Note: National regulations can set limit to the operation of the product.
Only use the product with parts and accessories that are approved by the manufacturer.
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
Product liability
As referred to in the product liability laws, we are not liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the manufacturer or not approved by the
manufacturer.
• the product is not repaired at an approved service center or by an approved authority.
If the installation is performed by an end customer, the customer assumes all responsibility.
Safety denitions
Warnings, cautions and notes are used to point out specially important parts of the manual.
aWARNING: Used if there is a risk of injury or death for the operator or bystanders if the
instructions in the manual are not obeyed.
aCAUTION: Used if there is a risk of damage to the product, other materials or the adjacent
area if the instructions in the manual are not obeyed.
Note: Used to give more information that is necessary in a given situation.
General safety instructions
Under no circumstances may the design of the product be modied without the permission of the
manufacturer. Never use a product that has been modied in any way from its original specication
and always use original accessories. Non-authorized modications and/or accessories can result in
serious personal injury or the death of the operator or others.
2

415X
Safety instructions for operation
aWARNING: Read the warning instructions that follow before you use the product. If you
encounter a situation where you are uncertain how to proceed you should ask a Husqvarna
Service Agent. Contact your dealer or your service workshop. Avoid all usage which you
consider to be beyond your capability.
• Never use a product that is faulty. Carry out the safety checks, maintenance and service
instructions described in this manual.
• Never allow children or pets to be in the vicinity of the product.
• Use approved eye protection.
• The life span of the product can be reduced and the risk of accidents can increase if product
maintenance is not carried out correctly and if service and/or repairs are not carried out
professionally. If you need further information please contact your nearest servicing dealer.
aWARNING: Never use a product with defective safety components. The product’s safety
equipment must be inspected and maintained as described in this manual. If your product
fails any of these checks, contact your service agent to get it repaired.
aCAUTION: All servicing and repair work on the machine requires special training. This is
especially true of the product’s safety equipment. If your machine fails any of the checks
described below you must contact your service agent. When you buy any of our products
we guarantee the availability of professional repairs and service. If the retailer who sells
your machine is not a servicing dealer, ask for the address of your nearest service agent.
Accessories and changes to the product that are not approved by the manufacturer, can
cause serious injury or death. Do not change the product. Always use original accessories.
• If the maintenance is not done correctly and regularly, there is an increased risk of injury and
damage to the product.
• Only do the maintenance as this operator’s manual recommends. Let an approved Husqvarna
service agent do all other servicing.
• Let an approved Husqvarna service agent do servicing on the product regularly.
• Replace damaged, worn or broken parts.
SAVE THESE INSTRUCTIONS
3

415X
PRODUCT OVERVIEW
A
B
C
E
F
G
D
H
J
K
L
A. Center roof bumper (1)
B. Center roof bumper adhesive strip, small (2)
C. Center roof bumper adhesive strip, large (1)
D. Outside roof bumper (2)
E. Outside roof bumper adhesive strip, small (2)
F. Outside roof bumper adhesive strip, large (2)
G. Transmitter mounting bracket adhesive strip (1)
H. Transmitter mounting bracket (1)
J. Transmitter circuit board (1)
K. Wiring assembly (1)
L. Sealing strip (1)
4

415X
INSTALLATION
Note: All pictures shown are for illustration purposes only. Actual product appearance may dier
due to variations among models.
Preparing the door
A separate kit is needed to install the Husqvarna Automower® Fence Door. Refer to the installation
instructions provided with the door kit.
Removing the body
aCAUTION: Pull the connectors. Do not pull the cables.
1. Clean dirt and grass from the product before you remove the parts.
2. Push the ON/OFF button for 3 seconds and make sure the product is switched o󰀨.
3. Gently pull the top cover at the rear, the middle and the front to remove it.
4. Clean the area around the grommets.
5. Pull out the rubber grommet and remove the charge cable and the headlight cable.
6. Find the 4 positions where the body is attached.
5

415X
5. Push the maintenance tool down in 1 of the 4 positions, and pull the body up.
6. Continue with the remaining positions while holding the body up.
7. Lift up and remove the body.
Removing the upper chassis
1. Remove the 12 screws.
2. Remove the warranty seal at the point of separation between the chassis halves on the right
side.
3. Lift the front end of the upper chassis.
6

415X
4. Disconnect the power cable (A) from the motor control circuit board.
aCAUTION: Always disconnect the power cable rst to prevent current spikes that may harm
the circuit boards or the battery.
A
B
5. Disconnect the application circuit board cable (B) from the motor control circuit board.
6. Remove the upper chassis.
7

415X
Installing the transmitter
1. Clean any dirt and debris from the chassis interior.
2. Peel the paper from the transmitter mounting bracket adhesive strip (G) and apply it to the
planned transmitter mounting location (X).
3. Apply the transmitter mounting bracket (H) onto the adhesive strip. Press rmly into place.
4. Install the transmitter circuit board (J) onto the transmitter mounting bracket. The side of the
transmitter circuit board into which the wiring assembly connects must face forward relative to
the normal motion of the mower.
5. Connect one end of the wiring assembly into an available “AUX” port on the motor control circuit
board (Z).
Note: Some models have multiple options for connecting the wiring assembly. All are acceptable,
but the wiring assembly MUST be connected to the motor control circuit board or application circuit
board. Do not connect the wiring assembly to the COM board.
6. Pass the wiring assembly through the cable holders (Y).
aCAUTION: Make sure the wiring assembly is not pinched.
7. Connect the other end of the wiring assembly to the transmitter circuit board.
TRANSMITTER CONNECTION DIAGRAM
G
H
J
8

415X
Reassembling the mower
1. Discard the existing sealing strip and replace it with the included sealing strip (H).
2. Reassemble the mower in the opposite sequence.
aCAUTION: Always connect the HMI cable before the power cable to avoid current spikes
that may harm the circuit boards or the battery.
Note: Attach a new warranty seal. The warranty seal must be included and unbroken for the
warranty to be valid.
Note: Make sure the that the grommets are correctly installed to seal against moisture.
Installing the roof bumpers
Install the roof bumpers around the STOP button on the mower. The roof bumpers prevent the
door from accidentally striking and engaging the STOP button as the mower passes through the
opening.
Refer to the following diagram for suggested roof bumper locations.
ROOF BUMPER LOCATIONS
1. Clean any dirt and debris from the application
surface.
2. Peel the paper from the roof bumper adhesive strips
(B, C, E, F) and apply the strips at the planned
roof bumper locations. Use 1 large strip and 2
small strips for the center roof bumper (A). Use 1
large strip and 1 small strip for each of the outside
bumpers (D).
»Position the center bumper rst.
»The center bumper is centered on the lid, as close
to the STOP button as possible.
»When positioned, the center bumper should
remain fully on the lid and not overhang the edges
of the lid.
»The outside bumpers should be positioned close
to the STOP button, and fully outside the lid. The
lid should open without contacting the outside
bumpers.
»The front section of the outside bumpers should
extend slightly beyond the center bumper, as
indicated by the dashed line. The rear section of
the outside bumpers should bend to follow the
contour of the mower body.
3. Apply the roof bumpers onto the roof bumper
adhesive strips. Press rmly into place.
9

415X
Installing guide & boundary wires
• Install the wires as shown in the diagram.
• The arrangement of your boundary and guide wires relative to the Husqvarna Automower®
Fence Door is important to the general operation of the mower in coordination with the door. If the
mower has trouble accessing the area on the opposite side of the door from the charging station,
or has trouble returning to the charging station after mowing, ensure that the wires are installed
according to these instructions.
• While the mower may operate without a guide connected, a guide wire is absolutely necessary
for operation with the Husqvarna Automower® Fence Door. It is not possible for the mower
to reliably pass through the fence door without installing the guide wire according to these
instructions.
• The mower does not run the cutting disk while following the guide. It is important to keep the
grass around the door and fence opening trimmed to ensure that the door can swing freely and
the mower can navigate through easily.
GUIDE & BOUNDARY WIRE DIAGRAM
2
1
AB
3
4
C
#
DE
F
5
2
1
AB
3
4
C
#
DE
F
5
1 Fence
2Door
3Boundary wire
4 Guide wire
5 Charging station
A = 45°
B = 24 in (61 cm)
C = 36 in (91 cm)
D = 5 in (12.7 cm)
E = 12 in (30.5 cm)
F = 7 in (17.8 cm)
# = Pin side of door
