Husqvarna P 520D With cabin User manual

EE
EEnn nngg ggll llii iiss sshh hh
P 520D W ith cabin
P 525D With cabin
Oper ator ′ s manual
Please r ead the operator’s manual carefully and make sure you understand the
instructions before using the machine.

2 – English
KEY T O SYMBOLS
Symbols
These symbols are on the machine and in the instr uctions.
WARNING! Careless or incorrect use can
result in serious or fatal injury to the
operator or others.
Please read the operator’s manual
carefully and make sure you understand
the instructions before using the machine.
Always wear:
• Approved hearing protection
This product is in accordance with applicable
EC directives.
Fast
Slow
Stop the engine.
Fuel
Oil pressure
Backwards
Forwards
Starting instructions
Ignition
Parking brake
Noise emission to the environment
according to the European Community’s
Directive. The machine’s emission is
specified in the Technical data chapter and
on the label.
Connecting the power take-off (PTO).
Disengaging the power take-off (PTO)
Warning: rotating parts. Keep hands and feet
clear.
Watch your hands and other body parts
so they do not get caught and crushed
between the belt and belt pulley.
Rotary blades Keep hands and feet
away from under the hood when the
engine is running
Never drive across a slope
Never use the machine if persons,
especially children, or animals, are in the
vicinity
Never carry passengers on the machine or
equipment
>10

English – 3
KEY T O SYMBOLS
Drive very slowly if no cutting unit is
fitted
Risk of crush injuries!
Danger of crushing between the lift arms
and base plate.
If the frame is folded up, the safety belt must
be used.
If the frame is folded down the safety
belt should NOT be used.
Explanation of warning le vels
The w arnings are graded in three levels.
W ARNING!
IMPORTANT!
CAUTION!
!
W ARNING! Used if there is a risk of serious
injury or death for the operator or damage to
the surroundings if the instructions in the
manual are not followed.
IMPOR TANT! Used if there is a risk of injury to the operator
or damage to the surroundings if the instructions in the
manual are not followed.
CAUTION! Used if there is a risk of damage to materials or
the machine if the instructions in the manual are not
followed.

4 – English
CONTENTS
Contents
KEY TO SYMBOLS
Symbols ....................................................................... 2
Explanation of warning levels ...................................... 3
CONTENTS
Contents ...................................................................... 4
Ser vice journal
Pre-deliv ery service ..................................................... 6
After the first 25 hours ................................................. 6
PRESENT ATION
Dear Customer , ............................................................ 7
Driving and transport on public roads .......................... 7
Towing .......................................................................... 7
Use .............................................................................. 7
Insure your Rider ......................................................... 7
Good service ................................................................ 8
WHA T IS WHAT?
What is what on the machine? ..................................... 9
MA CHINE´S SAFETY EQUIPMENT
Gener al ........................................................................ 10
Ignition key ................................................................... 10
Safety circuit ................................................................ 10
Warning lamp ............................................................... 10
Speed limiter ................................................................ 10
Parking brake ............................................................... 11
ROPS (Roll Over Protective Structure) ........................ 11
Safety belt ................................................................... 11
Counter weight ............................................................. 12
Muffler .......................................................................... 12
Protective covers .......................................................... 12
ASSEMBLING AND ADJUSTMENTS
Saf ety when assembling and settings .......................... 13
Cutting unit ................................................................... 13
Fitting the cutting head ................................................ 14
Removing the cutting unit ............................................ 15
Seat adjustment ........................................................... 16
Auxiliary lift system settings ......................................... 16
Dismantling the doors .................................................. 16
Dismantling the cab ..................................................... 17
Assembling the ROPS (Roll Over Protective Structure) 18
Lowering the ROPS (Roll Over Protective Structure) .. 18
FUEL HANDLING
Gener al ........................................................................ 19
Fuel .............................................................................. 19
Winter fuel .................................................................... 19
Fueling ......................................................................... 19
Transport and storage .................................................. 19
OPERA TING
Gener al safety precautions .......................................... 20
Personal protective equipment ..................................... 20
Other protective equipment .......................................... 20
Work safety .................................................................. 21
Instrument panel .......................................................... 21
Driving the Rider .......................................................... 21
Lights and power outlet ................................................ 23
Controls - Cabin ........................................................... 23
Controls - Control panel ............................................... 24
Heating and fan system ................................................ 24
Transport and storage .................................................. 24
Transportation and storage of the cabin ....................... 25
Transport with engine off .............................................. 25
Bypass valves .............................................................. 25
ST ARTING AND STOPPING
Bef ore starting .............................................................. 26
Start the engine ............................................................ 26
Starting the engine with a weak battery ....................... 27
Braking ......................................................................... 28
Stop the engine ............................................................ 28
MAINTENANCE AND SER VICE
Maintenance schedule ................................................. 29
General ........................................................................ 30
Cleaning ....................................................................... 30
Checking the engine’s cooling air intake ...................... 30
Cleaning the radiator cell package ............................... 30
Cleaning the air filter .................................................... 30
Cleaning the engine and muffler .................................. 31
Removing of the machine hoods .................................. 31
Adjustment of pump and alternator belt ....................... 31
Change pump and alternator belt ................................. 31
Adjusting the parking brake .......................................... 32
Replacing the light bulbs .............................................. 32
Main fuse ...................................................................... 33
Service position for the cutting unit .............................. 34

English – 5
CONTENTS
Cutting height and tilt angle adjustment. ...................... 36
Replacing the cutting unit belts .................................... 37
Checking the blades .................................................... 38
Replacing the blades ................................................... 38
Removing the BioClip plug ........................................... 38
Adjustment of PTO belts .............................................. 38
Change PTO belts ....................................................... 39
Change coolant ............................................................ 40
Inspecting the muffler ................................................... 40
Checking the tyre pressure .......................................... 40
Check the battery ......................................................... 41
Replacement of fuel filter ............................................. 41
Replacing the air filter .................................................. 41
Changing the fan system inlet filter .............................. 42
The cutting unit bevel gear ........................................... 42
Checking the engine’s oil level. .................................... 42
Replacing the engine oil .............................................. 43
Changing the oil filter ................................................... 43
Check the hydraulic system oil level ............................ 43
Check the oil level in the transmission gearboxes ....... 43
Lubrication
Lubr ication schedule .................................................... 44
General ........................................................................ 44
Accessories ................................................................. 45
Pivot wheel bearings ................................................... 45
Universal drive shaft joints ........................................... 45
Cutting unit bracket ...................................................... 45
Lift arm rear bearings ................................................... 45
Lift cylinder ................................................................... 45
The drive shaft front support bearing ........................... 45
The drive shaft rear support bearing ............................ 45
Steering cylinder .......................................................... 45
Joint bearing ................................................................ 46
Link brace .................................................................... 46
Knobs for setting the cutting height .............................. 46
Driver seat .................................................................... 46
Lubricating the cables .................................................. 46
Throttle and choke cables, lever bearings ................... 46
Lubricate the parking brake wire .................................. 46
T roubleshooting schedule
TECHNICAL DATA
Ride-on mo wer dimensions ......................................... 51
Cabin dimensions ........................................................ 52
Cabin support dimensions ........................................... 52
EC Declaration of Conformity ...................................... 53

6 – English
Ser vice journal
Pre-deliver y service
1 Charge the battery for at least 4 hours at max. 5
amp.
2 Check coolant level and antifreeze.
3 Check and adjust tyre pressure (150 kPa, 1,5 bar,
21,8 PSI).
4 Make sure the correct amount of oil is in the
cutting unit's bevel gear.
5 Check that the right amount of oil is in the engine.
6 Check that there is oil in the transmission’s oil
tank.
7 Fit cutting unit.
8 Adjust cutting unit:
Adjust cutting unit so that rear edge is about 6-9
mm higher than front edge.
Conduct a function test of the cutting deck height
adjustment. - Combi 132 X, Combi 155 X
9 Lubricate the universal drive shaft with grease.
10 Connect battery.
11 Fill with fuel and start engine.
12 Check that machine does not move in neutral.
13 Check:
Forward drive.
Reverse drive.
Operation of blades.
Seat safety switch.
Safety switch for parking brake.
14 Tell customer about:
The requirement and advantages of servicing the
machine according to the service plan
Servicing and the influence of this journal on the
second-hand value of the machine.
The transmission warranty is only valid if front
and rear wheel rotation speed has be checked in
accordance with the service schedule. Adjust if
necessary according to the table values specified in the
workshop manual. Performed by authorized servicing
dealer. The system will be damaged if this adjustment is
not carried out.
At temperatures below 0 ° C, the machine must
be warmed up for at least 10 minutes for the
hydraulic oil and transmission to get hot.
Otherwise there is a risk of the transmission breaking
down thereby reducing the service life of the transmission.
Range of applications for BioClip function.
Complete proof of sale etc.
Pre-delivery service carried out. No outstanding
problems. Certified:
After the fi rst 25 hours
1 Change the engine oil and oil filter
2 Changing oil in transmission gearboxes (front and
rear).
3 Replace the engine’s hydraulic oil filter
4 Check front and rear wheel rotation speed
according to the service schedule.
Date:
Mileage:
Signature:
Label:

English – 7
PRESENT A TION
Dear Customer ,
Thank y ou for choosing a Husqvarna Rider. Husqvarna Riders are built to a unique design with a front-mounted cutting unit and a
patented articulated steering. Riders are designed for maximum efficiency even in small or confined areas. The closely grouped
controls and pedal-operated hydrostatic transmission also contribute to the performance of this machine.
This operator’s manual is a valuable document. By following its instructions (on operation, service, maintenance, etc.) you will
significantly extend the life of the machine and even its second-hand value.
When you sell your Rider, make sure you pass on the operator’s manual to the new owner.
A service journal accompanies the operator’s manual. Ensure that service and repair work is documented. A well-documented
service history reduces the costs of seasonal maintenance and influences the second-hand value of the machine. Bring the service
journal when bringing the machine to a workshop for a service.
Driving and transpor t on public roads
Chec k the relevant road traffic regulations before driving the machine on a public road. If transporting the machine on another
vehicle always use approved securing devices and make sure that the machine is securely held.
T owing
When y our machine is equipped with a hydrostatic transmission you should only tow the machine over short distances and at a
low speed, otherwise there is a risk of damaging the transmission.
The transmission must be disengaged when towing, see instructions under the heading Bypass valves.
Use
This r ide-on mower is designed to mow grass on open and level ground surfaces. In addition, there is a number of accessories
recommended by the manufacturer that broadens the application area. Please contact your dealer for more information about
which accessories are available. The machine may only be used with the equipment recommended by the manufacturer. All other
types of use are incorrect. Compliance with and strict adherence to the conditions of operation, service and repair as specified by
the manufacturer also constitute essential elements of the intended use.
This machine should be operated, serviced and repaired only by persons who are familiar with its particular characteristics and
who are acquainted with the relevant safety procedures.
Accident prevention regulations, all other generally recognised regulations on safety and occupational medicine, and all road traffic
regulations must be observed at all times.
Any arbitrary modifications carried out to this machine may relieve the manufacturer of liability for any resulting damage or injury.
Insure y our Rider
Chec k the insurance coverage for your new Rider.
• Contact your insurance company.
• You should have fully comprehensive insurance including: third party, fire, damage, theft and liability
IMPORTANT! The transmission warranty is only valid if front and rear wheel rotation speed has be checked in accordance with
the service schedule. Adjust if necessary according to the table values specified in the workshop manual. Performed by
authorized servicing dealer. The system will be damaged if this adjustment is not carried out.

8 – English
PRESENT A TION
Good ser vice
Husqv arna products are sold all over the world and ensures that you, the customer, get the best support and service. For example,
before this machine was delivered it was inspected and adjusted by your dealer. See the certificate in the Service Journal in this
manual.
When you need spare parts or advice on service issues, warranty terms, etc., contact:
On the machine's rating plate you will find the following information:
• The machines type designation.
• The manufacturer’s type number.
• The machine’s serial number.
State the type designation and serial number when ordering spare parts.
IMPORTANT! All service intervals are described in the service journal. Ensure service is carried out at the right time.
Name: Dealer:
This operator’s manual belongs to the machine with the
manufacturing number (serial number):
Transmission
PNC: Engine

English – 9
WHA T IS WHA T?
What is what on the mac hine?
22
2
1
3
21
23
6
7
8
9
10
12
11
16
17
18
20 19
13
15
5
4
14
14
1 High and low speed catches
2 Speed limiter for driving forward
3 Speed limiter for reversing
4 Heating controls
5 Window washer fluid container
6 Parking brake
7 Lever for hydraulic lift of attachments
8 Function button for accessories with extra hydraulics
9 Cutting height control
10 Control for cutting unit drive
11 Emergency exit
12 Throttle trigger
13 Product and serial number plate
14 Cover lock
15 Bypass valve rear axle
16 Fuel cap
17 Fuel gauge
18 Driver’s door
19 Controls - Control panel
20 Venting stay
21 Instrument panel
22 Air distributor
23 Ignition lock

10 – English
MA CHINE´S SAFETY EQ UIPMENT
General
Ignition ke y
The ignition k ey is used to turn the engine on and off together
with all electrical functions except the power outlet.
1 OFF - the machine is powered down
2 ON - Glow plug heating and drive position
3 START - spring-back ignition position
The ignition key is on the right side of the dash.
Ignition ke y check
• Check the ignition key by starting and stopping the
engine. See instructions under the heading Starting and
stopping.
• The engine should start when the ignition key is turned to
START (3).
• The engine should stop immediately when the ignition key
is turned to OFF (1).
Saf ety circuit
The machine has a saf ety circuit that triggers whenever the
driver gets off the seat while the blades are engaged. The
safety circuit is also tripped when the parking brake has not
been applied and the driver rises from the seat.
Drive to the blades is stopped when the safety circuit is
tripped. There is a short delay to prevent stopping if the driver
bounces on the seat.
• When the safety circuit has stopped the drive to the
cutting unit, the control must be pushed and pulled out
again to start the blades. Drive to the blades can be
started only when the driver is sitting on the seat.
• Push in the lever to disengage the blades.
• Pull out the lever to engage the drive of the blades.
Saf ety circuit check
• Check daily to ensure that the safety system works by
attempting to start the engine when one of the conditions
above is not met. Change the conditions and try again.
Warning lamp
The cab has two types of warning lamps.
Hazard flashers, all the direction indicator on the machine
flash at once. Hazard flashers are used to warn other vehicles
on public roads that the machine is stationary or moving
slower than other traffic.
Rotating warning light, warning lamp with flashing orange
light located on the roof of the cab. The rotating warning light
is used to warn of work in progress.
Warning lamp check
Regularly check that the lamps are in working order and are
free from dirt and cracks.
Operating the machine without cab
National and local rules and regulations must be observed
also when the machine is used without cab. This may
concern, for example, protective equipment, traffic kit and
traffic regulations.
Speed limiter
The speed of the machine is steplessly regulated with two
pedals. Pedal (1) is used to drive forwards, and pedal (2) to
drive backwards.
The machine is braked when the forward pedal is released.
The reverse pedal can also be used if additional braking
power is required.
!
WARNING! Never use a machine that has
faulty safety equipment!
If your machine fails any checks contact
your service agent to get it repaired.
23
1
2
1
