Husqvarna 701 Supermoto 2023 User manual

OWNER'S MANUAL 2023
701 Supermoto
Art. no. 3402674en

DEAR HUSQVARNA MOTORCYCLES CUSTOMER
*3402674en*
3402674en
12.10.2022
DEAR HUSQVARNA MOT ORCYCLES CUSTOMER
Congratulations on your decision to purchase a Husqvarna motorcycle. You are now the owner of a state-of-
the-art sports vehicle which, with appropriate care, will bring you pleasure for a long time to come.
We wish you good and safe riding at all times!
Enter the serial numbers of your vehicle below.
Vehicle identification number ( p. 16) Dealer's stamp
Engine number ( p. 17)
Key number ( p. 16)
The Owner's Manual contained the latest information for this model series at the time of publication. However,
minor differences due to further developments in design cannot be ruled out completely.
All specifications contained herein are non-binding. Husqvarna Motorcycles GmbH specifically reserves the
right to modify or delete technical specifications, prices, colors, forms, materials, services, designs, equipment,
etc., without prior notice and without specifying reasons, to adapt these to local conditions, as well as to stop
production of a particular model without prior notice. Husqvarna Motorcycles accepts no liability for delivery
options, deviations from illustrations and descriptions, as well as misprints and other errors. The models por-
trayed partly contain special equipment that does not belong to the regular scope of supply.
© 2022 Husqvarna Motorcycles GmbH, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission
of the copyright owner.
ISO 9001(12 100 6061)
Husqvarna Motorcycles applies quality assurance processes that lead to the highest possible
product quality as defined in the ISO 9001 international quality management standard.
Issued by: TÜV Management Service
Husqvarna Motorcycles GmbH
Stallhofnerstraße 3
5230 Mattighofen, Austria
This document is valid for the following models:
701 Supermoto US (F2675W3)
