No. Pos. Description No. Pos. Description
543044586 SCREW 543850257 SEPARATOR
543044681 SCREW 543850258 SEPARATOR SUPPORT BRACKET
543044747 HEX NUT 543850259 DEFLECTOR
543044749 RIVET 543850260 SWITCH BOX
543044802 ELASTIC PIN 3.5 X 10 543850261 CONDENSATOR
543044866 SCREW 543850262 STRAP
543044897 FLAT WASHER 543850263 AUTO THREADING SCREW
502641001 SWITCH-240V(RELAY) 543850264 CONNECTOR BLOCK
543045325 POWER SUPPLY CABLE 543850265 LEAD WIRE
543045710 LEFT RULER SCALE-SHORT 543850266 SCREW
543045727 FRONT RULER SCALE-LONG 543850267 FLAT HEAD SCREW
543046084 BEVEL THUMB SCREW 543850268 GLAND PACKING
543046087 BUTTERFLY BOLT 543850269 FLAT HEAD SCREW
543046161 AXLE SPRING 543850270 NYLOC NUT
543046211 LOCKING AXLE 543850271 SCREW
543046266 TABLE 543850272 SPLASH SHIELD STRIP
543046267 REAR COVER PANEL 543850273 FLAT WASHER
543046268 FRONT COVER PANEL 543850274 MOTOR FAN COVER PLATE
543046273 ANGULAR GUIDE 543850275 FLAT WASHER
543046274 GUIDE&RULER Sub A'ssy 543850276 GLAND PACKING
543048538 BLADE GUARD 543850277 THREE WAY CONNECTOR
543048998 INSTRUCTION MANUAL 543850278 HEX NUT
543067161 Blade GS6C 722781702 CIRCLIP
543850230 CLIPS-RULER A'ssy 725228961 ALLEN HEX BOLT
543850231 FAN 725537001 ALLEN HEX BOLT
543850232 MOTOR TAIL COVER 731431601 NYLOC NUT
543850233 MOTOR FRONT COVER 732211601 SPACER
543850234 MOTOR HOUSING 735273601 STAR WASHER
543850235 ROTOR
543850236 STATOR
543850237 MOTOR REAR BEARING
543850238 MOTOR FRONT BEARING
543850239 STATOR SCREWS
543850240 SEAL
543850241 INNER FLANGE
543850242 OUTER FLANGE
543850243 BLADE FIXING BOLT
543850244 COMPLETE MOTOR UNIT
504129601 BODY FRAME
543850246 LOWER BLADE SHROUD
543850247 WATER TRAY
543850248 MOTOR SWIVEL AXLE-LONG
543850249 MOTOR SWIVEL AXLE-SHORT
543850250 FRONT MOTOR SUPPORT
543850251 TURF MUD GUARD-LARGE
543850252 TURF MUD GUARD-SMALL
543850253 FOOT PAD
543850254 WATER TRAY SUPPORT-LEFT
543850255 WATER TRAY SUPPORT-RIGHT
543850256CONNECTING ROD
502641002 SWITCH 110V RELAY
502651201 MOTOR 115V
502651701 ELECTRIC CABLE 115V UK PLUG
