Standard Operating Procedure
HUSQVARNA TILE SAW 9” TS73R
Version 2 Issue date: 10/06/2016
Page 1 of 3
20 Goodshed Road Upper Hutt
Phone [phone]
Name
Husqvarna Tile Saw 9” TS73R
Recommended Use
When used with a Diamond Disc, for water-lubricated
cutting of marble, stone, granite, brick and facings,
including porcelain, glazed tiles, ceramics etc
Section 1: Equipment Details
Manufacturer
Husqvarna Construction Products
Supplied by Youngman Richardson & Co, NZ
wwwyrco.co.nz
Emergency Contact details
Garry Bull (Upper Hutt Hire) 027 742 6583
IMPORTANT: The information contained in this SOP is intended as a summary only. Users must
read the operating manual and familiarize themselves with the equipment before commencing
use.
Section 2: Hazards Identification
HIGH SPEED BLADE Keep hands and limbs clear of
the blade and mechanism at all times. RISK of limbs
being crushed or severed. If a blockage occurs turn off
power, unplug the electrical cable and allow the
machine to come to a complete stop before clearing
obstructions.
Operate this item only on an electrical supply
equipped with a 30 mA earthed current-limiting circuit
breaker (RCCB).
DO NOT use the equipment for any other purpose
other than that for which it was designed. Use only an
approved blade supplied by Upper Hutt Hire.
Do not allow persons to operate machinery without full
and proper instruction in the use of the machine. Do
not allow person under 16 years age to operate the
machinery.
Always keep safety guards in place.
Avoid loose-fitting clothing. Risk of entrapment in
machinery.
Always ensure water supply is abundant, and dust
minimised.
Operation of the equipment must not be performed by
persons under the influence of alcohol, drugs, medications
or any chemical substances capable of impairing the
abilities of that person.

Standard Operating Procedure
HUSQVARNA TILE SAW 9” TS73R
Version 2 Issue date: 10/06/2016
Page 2 of 3
20 Goodshed Road Upper Hutt
Phone [phone]
Never leave the engine running when unattended. Shut the
machine down even if unattended for a short period.
Parts of machine may be hot. Touching may result in
burns. Wear protective gloves.
Unit weighs 43 kg. Take care when lifting. Requires two
people to lift.
Section 3: Additional Information
Certification: Does this item require special
licensing or certification?
No
Additional links? Worksafe NZ etc
None available at time of issue.
Section 4: Power Source
Electrical
Single Phase 230 volt. Machine is rated at 1000W.
Use RCCB or other suitable electrical protection.
Section 5: Log Book
Does this equipment require a daily check and entry in the log book?
No
Section 6: Personal Protective Equipment (PPE)
Appropriate personal protective equipment (PPE) is required for the operator and
persons assisting with loading and unloading.
Section 7: Emergency precautions for site
Do you have a
FIRST AID KIT?
Do you have a
FIRE EXTINGUISHER?
Can you make an
EMERGENCY CALL?

Standard Operating Procedure
HUSQVARNA TILE SAW 9” TS73R
Version 2 Issue date: 10/06/2016
Page 3 of 3
20 Goodshed Road Upper Hutt
Phone [phone]
Section 8: Operating instructions
1. To start the machine press the green button on the switch.
2. To stop the machine, press the red button.
Section 9: Transport
1. Unplug the machine
2. Lock the head on the rear part of the saw, using clip ‘A”, so that the head is
secured.
3. Loosen the two flywheels (B) of the front legs, and swivel them to a horizontal
position, then retighten the flywheels.
4. Repeat the same procedure for the back legs.
5. To reinstall the machine on its legs, carry out the above procedure in reverse.
Section 10: Additional Information
Always use common sense! It is not possible to cover every conceivable situation you can face when using our equipment.
Always exercise care and use your common sense. Avoid all situations which you consider to be beyond your capability. If
you still feel uncertain about operating procedures after reading these instructions and the owner’s manual, you should
consult an expert before continuing.
The information contained herein is true and accurate to the best of our knowledge. No warranty or guarantee is expressed
or implied regarding the accuracy of information or instructions. Users MUST consult the manufacturer’s manual or
handbook. While every effort has been made to summarise the important Health and Safety information for the safe use of
this equipment, Upper Hutt Hire Ltd shall not be liable in any way for any reliance by any person or entity on the accuracy
of information or data contained in this document or its attachments.
Revision date
June 2021 (SOP based on Husqvarna Manual TS73R 115 03 00-20 2007-03-15)
